- Page 1 ACTIVE UTP RECEIVER WITH AUTO VIDEO LEVEL CONTROL SC-UT0124H/H6 SC-UR0124H SC-UR1618H User's Manual SC-UT0124H/H6 SC-UR0124H SC-UR1618H...
- Page 2 Precaution and Safety Guidelines Please read this user’s manual thoroughly prior to use the unit for its easy and convenient use. Do not install the product in the following places: extremely low or high temperature conditions; places exposed to rain, snow, or high humidity;...
- Page 3 Brown Brown White & Brown Brown Please note that the SeeEyes UTP cable wiring method is different from TIA/EIA 568B method. RJ-45 JACK Wiring SeeEyes TIA / EIA 568B Please note that SeeEyes RJ-45 Wiring method is different from TIA/EIA 568B.
- Page 4 1. Introduction 1.1. Overview The SC-UT0124H (Tx.) & SC-UT0124H6 (Tx.) together with SC-UR0124H or SC- UR1618H are able to perform the long distance video transmission with excellent immunity interference. Using these solutions, you can transmit video signals from 1.8km away in color and 2.4 km away in B/W via Twisted Pair Cable (UTP, FTP, STP).
-
Page 5: Product Parts And Peripheral Device Connection
3. Product Parts and Peripheral Device Connection 3.3. Part Names and Functions 3.1.1. SC-UT0124H, SC-UT0124H6 ① VIDEO IN: Connect with the video output terminal of Camera. ② CAM POWER: Driving power output terminal of Camera. For cameras using separate power, it should not be connected. ③... - Page 6 • Notes: - When using separate power supply unit (power adapter) to feed the camera and the transmitter and connecting the SC-UT0124H/H6 to the receiver or the junction box one to one (1:1), please cut the power lines # 5,6,7,8 of the UTP cable as below.
- Page 7 3.1.2. SC-UR0124H ④ A.Level ⑤ F. Level ⑥ Cable Length ⑦ Video Out ① POWER IN: Adaptor connection terminal. ② RS-485: RS-485 DATA connection terminal. Be careful with polarity. ③ UTP CABLE: Connect the UTP Cable attached with a RJ-45 Plug. Yellow LED: Video, Green LED: Power ④...
-
Page 8: Rear Side
3.1.3.2. Rear side ①② ③ ④ ①, ② VIDEO OUTPUT (BNC-F): Put out sixteen (16) videos received from the UTP cable. Connect to the DVR or Monitor. ③ UTP INPUT: Receive sixteen (16) video signals Each RJ-45 Jack port receives 4 videos. Please refer to the UTP cabling method. - Page 9 4.2. SC-UR1618H...
-
Page 10: Specification
5. Specification MODEL SC-UT0124H(1ch Transmitter) Video Input CVBS 1.0Vp-p, 75Ω Video Output 51Ω 1Vp-p ~ 8Vp-p Camera adapter Input (24VAC / 12VDC~48VDC) Power Output Bypass Bandwidth 1.8 Km:6MHz Maximum Transmission Low: under 900m, High: 900m~2.4Km Distance (CAT 5) Video Input DC-M &... - Page 11 MODEL SC-UR0124H (1Ch Receiver) Video Input 51Ω 1Vp-p ~ 8Vp-p Video Output CVBS 1.0Vp-p, 75Ω Power consumption 30mA INPUT Adapter: 24VAC, 12~48VDC POWER OUTPUT Bypass Bandwidth 1.8Km : 6MHz Maximum Transmission Low: under 900m, High: 900m~2.4Km Distance (CAT 5) Video Level Control VR (A.
-
Page 12: Warranty Certificate
6. Warranty Certificate This product has passed thorough quality control and test, and if this gets broken during normal use, we provide 12 months warranty service. Model No. Serial No. Distributor Date you purchased Place you purchased Warranty Period One (1) year from the date of purchase Name Purchaser Address...
