Installation Guide
Installation Guide
Transport DR Series Installation Guide
D isclaimer
Digi International makes no representations or warranties with respect to the contents or
use of this manual, any software drivers or associated application software provided with
this product and specifically disclaims any expressed or implied warranties of
merchantability or fitness for any particular purpose.
Digi International reserves the right to modify or revise all or part of this document, its
contents, and any products described herein at any time without prior notification and
shall not be responsible for any loss, cost, or damage, including consequential damage,
caused by reliance on these materials.
Product disposal instructions
The WEEE (Waste Electrical and Electronic Equipment: 2002/96/EC) directive has been
introduced to ensure that electrical/electronic products are recycled using the best
available recovery techniques to minimise the impact on the environment.
This product contains high quality materials and components which can be recycled. At
the end of it's life this product MUST NOT be mixed with other commercial waste for
disposal. Check with the terms and conditions of your supplier for disposal information.
Copyright
© 2009 Digi International. All rights reserved. No part of this document covered by
copyright may be reproduced or copied in any form or by any means graphic, electronic,
or mechanical, including photocopying, recording, taping, or information and retrieval
systems without written permission of Digi International.
1
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Digi DR64-H
Summary of Contents for Digi DR64-H
- Page 1 Digi International reserves the right to modify or revise all or part of this document, its contents, and any products described herein at any time without prior notification and shall not be responsible for any loss, cost, or damage, including consequential damage, caused by reliance on these materials.
- Page 2 PDF format that can adapter shows signs of damage or malfunction, you should stop using it immediately be downloaded from the Digi International website (www.digi.com). – turn off the power at the mains and disconnect it from the mains supply before contacting your supplier for a repair or replacement.
- Page 3 However, GSM based products contain radio devices which require specific consideration. Please take the time to read and understand the following guidance. Digi International assumes no liability for an end user’s failure to comply with these precautions.
-
Page 4: Front Panel Features
Transport DR Series Installation Guide Transport DR Series Installation Guide 1 Introduction The Transport DR series IP routers fa cilitate the transmission of data over DSL, ISDN, PSTN or wireless WAN networks. The Transport DR provides an ADSL/2/2+ interface along with a 4-port 10/100 Ethernet switch. - Page 5 Transport DR Series Installation Guide Transport DR Series Installation Guide SIGNAL The three indicators labelled SIGNAL illuminate to indicate the Rear Panel Features GSM signal strength as follows: None illuminated < -113 dBm (effectively no signal) 1 LED illuminated >= -112 dBm and <= -87 dBm (weak) 2 LED’s illuminated >= -86 dBm and <= -71 dBm (medium) 3 LED’s illuminated...
-
Page 6: Installation
Reset Switch reception. Digi International can supply a range of suitable antennas. This is located on the underside of the unit near the front. Pressing the switch gently with Safety notice the tip of a pen or other suitable implement will generate a hardware reset. - Page 7 DB25 sockets. Asuitable cable will be required to connect your terminal device(s) to these ports. The 6 serial ports ar e presented as RJ45 connectors. A range of suitable cables and adapters are available from Digi International for connecting terminal devices to these ports.
- Page 8 Default Password: password remote host or bbrowse the Internet,. By default the Digi Transport should have issued your This setting can be changed by going to: worstation an IP address of 192.168.1.100 via DHCP. DHCP will pass the proper default Configuration ->...
-
Page 9: General Specifications
Reverse link 153,6 Kbps support, coding schemes CS 1-4 1 x Rtt (IS-2000) Forward and reverse link speeds up to 153,6 Kbps HSDPA 1.8: Categories 1-4, 11 and 12 DR64-H HSDPA 3.6: Categories 5 and 6 fax modem . V.92 compliant,...
