Quick Start Guide
ConnectPort WAN
ConnectPort WAN VPN
without integrated cellular module

Connect Hardware

CONNECT
1
Unscrew cover
and slide off. Unscrew
access door and remove.

Install Wizard and Configure Device

Install
Software &
Documentation
1
Insert CD
4
Follow the wizard
to discover your device,
set an IP address, and configure
mobile settings.
The ConnectPort WAN has DHCP server enabled by default.
!
In order to discover your Digi device, make sure your host
computer is setup to obtain IP addresses automatically.
Also ensure all firewall software is temporarily disabled.

Configure Your Cellular Settings

CELLULAR
1
From the web interface, go to the
Configure Mobile settings and set the
proper mobile settings supported by
your SIM card. Click Apply
© Digi International Inc., 2005.
Digi, Digi International, the Digi logo, the Making Device Networking Easy logo, and Digi ConnectPort
are trademarks or registered trademarks of Digi International, Inc. in the United States and other countries worldwide.
All other trademarks are the property of their respective owners.
Verify SIM card is properly installed
2
in PC card slot and slide PC Card
Modem through access opening
and seat on board.
Silde antenna barrel end into
4
PC Card Modem after it is seated
on the board.
2
Under Hardware,
click Install
3
Click
Launch
Launch Wizard
Wizard
ConnectPort WAN
SIGNAL STRENGTH
PRIMARY
ANTENNA
LINK
ACT
Digi ConnectPort WAN
Software &
Documentation
Digi Connectware
Manager CD
Straight-through
cable
Antenna
sold separately
5
Connect antenna
to connector.
3
Attach antenna
to P23 connector next
to the Primary antenna
connector.
ConnectPort WAN
Under Management click Connections to verify your
2
configuration has found an access point. To test your
configuration and verify proper Ethernet to cellular
routing, see the back of this guide.
PRIMARY
ANTENNA
The LINK and ACT lights
will blink when the connection
is active.
If you have any difficulties, use the test scenario on the back
of this guide to verify or troubleshoot your configuration.

What you will need

SECONDARY
9-30VDC
ANTENNA
1A MAX
RESET
POWER
STATUS
Loopback plug
Power supply
PN:(1P)
90000766_
ConnectPort WAN
SIGNAL STRENGTH
PRIMARY
ANTENNA
LINK
ACT
!
Warning: Do not over-tighten the
antenna. Over-tightening may
damage internal connections.
Loosen antenna before adjusting
antenna angles.
Connect Ethernet cable
6
from any one of the
Ethernet ports directly to
laptop computer.
Connect
7
power supply
4
Select a scenario that best
describes your environment.
5
Enter your Connectware server
settings.
You may skip this page if you are not
using Connectware Manager.
For more information on Connectware
Manager, refer to the Connectware
Manager Getting Started Guide.
After saving your
6
configuration check
"Log on to unit..." This will
open the web interface
where you must configure
your mobile settings.
SECONDARY
9-30VDC
ConnectPort WAN
ANTENNA
1A MAX
SIGNAL STRENGTH
RESET
POWER
LINK
ACT
STATUS
C
SECONDARY
9-30VDC
ANTENNA
1A MAX
RESET
POWER
STATUS
