Vtron Digicom AP Series User Manual page 12

SDI input (expandable)
IP video input (standard
configuration)
IP encoder
(expandable)
Network computer
signal access
(expandable)
Signal window
superimposition
Intelligent surveillance
System power supply
Rated power
Chassis dimension
Chassis fan
Noise
Weight
Operating environment
Storage environment (in
packed manner)
OS
Application software of
the processor
Product certification
User manual for Digicom AP series multi-screen processor
Number of inputs: 20 at most
Signal standard supported: SD-SDI, HD-SDI or 3G-SDI
Input resolution: 1080P@60, 1080P@30, 1080i@60, 1080i@50, 720P@60,
The display wall can display a
maximum of 8-channel 1080P
video, 32-channel D1 video, or 32-
channel CIF video.
Support standard H264, MPEG4, MPEG2, and MJPEG encoding formats.
Note: Devices that are not contained in the standard signal source list support
Users should offer secondary development protocols (SDK) of IP videos that are
used on WINDOW-based brand platforms.
While working with various types of VTRON IP encoder devices, it can collect
distributed signals from long distances and display quality images.
Up to 8-channel VLink signals can be displayed simultaneously.
Support free combination, zooming in/out, superimposition, and roaming display
Real-time monitor system running states, including chassis temperature, CPU
temperature, GPU temperature, fan speed, CPU usage, and memory usage.
1+1 redundant power（optional ）
100-240V AC 50/60 Hz 2.0A
≤ 300W
Black, 19" standard rack-mount
method; height: 4U
W × H × D = 482 mm × 177 mm ×
480 mm
Fan standby, replaceable by means of hot swap
< 45 dB
≤ 20 Kg
Relative humidity: 20%~80% (non-condensing)
Relative humidity: 0%~95% (non-condensing)
Windows 7/Windows 8
professional; 64-bit
Large-screen control software: VTRON VWAS Standard (additional payment)
remote access control software: VLinkExpress (optional)
CCC, CE, CB, RoHS
- - 7
Number of inputs: 32 at most
720P@50, 576i@50, 480i@60
The display wall can display a maximum of
8-channel 1080P video, 32-channel D1
video, or 32-channel CIF video.
secondary development;
of signal windows.
1+1 redundant power, hot-swappable
100V-240VAC 50/60 Hz 8-6A
Black, 19" standard rack-mount method;
single-chassis height: 8U
W × H × D = 431 × 354.3 × 501.7
(excluding the front-panel handle)
Operating temperature: 0° C~40° C
Storage temperature: –40° C-70° C
Standard configuration: Windows 8
≤ 600W
< 45 dB
≤ 40 Kg
professional; 64-bit
CCC, CE, CB, RoHS
