- Page 2 This manual is the copyright property of VTRON Corporation. Without the prior written approval from VTRON, no part of this manual shall be copied or distributed to any third party in any manner. This manual is used for user operation instruction only and shall not be used for maintenance services.
- Page 3 CAUTION: In order to avoid electric shock, do not open the cover, nor place any useless part in the cabinet. Please contact qualified service staff. User Manual for Digicom HC Series Multi-Screen Processor...
-
Page 4: Important Instructions
◆ All installations and wirings must be firm and reliable as poor contact may lead to malfunction; ◆ In case of applications with serious interferences, shielded cables should be used for input or output of high-frequency signals, so as to enhance the anti-interference performance of the system. User Manual for Digicom HC Series Multi-Screen Processor... - Page 5 ◆ Do not disassemble the equipment lest the internal electric components may be damaged; ◆ Please read this manual carefully and fully confirm the safety before performing any program variation, commissioning, starting or stopping operation. User Manual for Digicom HC Series Multi-Screen Processor...
- Page 6 ◆ Explosion of electrolytic capacitor: during combustion, the electrolytic capacitor on PCB may explode; ◆ Please collect and dispose separately and do not mix with domestic garbage; ◆ Please dispose as industrial waste or according to local provisions on environmental protection. User Manual for Digicom HC Series Multi-Screen Processor...
-
Page 7: Table Of Contents
Chapter 5 Display Wall Application Administration Software: VWAS (Optional) ..5-1 Chapter 6 Daily Maintenance ....................6-1 Daily Inspection and Maintenance ..................6-2 Routine Inspection ........................6-2 Chapter 7 Common Faults and Troubleshooting ..............7-1 Chapter 8 Contact Us ........................8-1 User Manual for Digicom HC Series Multi-Screen Processor... -
Page 8: Chapter 1 Overview
Chapter 1 Overview The Digicom HC Series Multi-Screen Processor is a high-quality, professional multi-screen processor with a purely hardware architecture developed by VTRON. It features an advanced modular design, VTRON’s proprietary ultra-wideband digital signal stream transmission technology, and real-time intelligent exchange transmission (RIET) technology, which allows it to realize true, real-time signal display. -
Page 9: Main Features
Ultra high speed bus, true real-time display Thanks to VTRON’s proprietary ultra-bandwidth digital signal stream transmission technology, the Digicom HC Series Multi-Screen Processor system is equipped with ultra high speed bandwidth and is thus able to realize unparalleled display speed. -
Page 10: Topological Diagram Of The Processor System
Chapter I Overview 1.2 Topological Diagram of the Processor System Topological diagram of the system Command stream HC s eri es processor VWAS console Data stream Video signal source Video signal: RGB, Video User Manual for Digicom HC Series Multi-Screen Processor... -
Page 11: Chapter 2 Description Of Matrix Panel
The following front and rear panels are for reference only. Actual customer orders may have a different number of interfaces on the rear panel. Please refer to your actual order for your configuration. 2.1 Front Panel Description User Manual for Digicom HC Series Multi-Screen Processor... -
Page 12: Led Indicators
To display the IP address of the main control board (if the system adopts a dual-control configuration, two IPs will be displayed) TIME To display the system time ALARM CLEAR To clear the system alarm User Manual for Digicom HC Series Multi-Screen Processor... -
Page 13: Rear Panel Description
② Slot 2 – HDMI signal input board(UH21) Interface type: 2 HDMI inputs/board. The board has operating status indicator and alarm indicator functions. ③ Slot 3 – IP signal input board Interface type: 2 RJ45/board. User Manual for Digicom HC Series Multi-Screen Processor... - Page 14 Interface type: 4 DVI-D outputs/board, Supports multiple resolution output display. With D40 board, a HC processor can support “one video wall + multiple display units” combination display and support ground image loading and User Manual for Digicom HC Series Multi-Screen Processor...
- Page 15 ⑫ Slot 20 – Blend stop ⑬ Slots 21 – System control board Interfaces contained in the system control board: dial switch, RS232 debug interface, RS232 control interface, network interface, syn. in/out, BNC interface, etc. User Manual for Digicom HC Series Multi-Screen Processor...
-
Page 16: Chapter 3Technical Specifications
DP input Input resolution: 800×600@60Hz~3840×2400@30Hz (expandable) Input interface: DP interface Number of outputs: up to 2 Mutil-view output Output resolution: board DVI interface: 1920×1080@60Hz; Network interface: 1920×1080@30Hz （expandable） Output interface: DVI-D and RJ45 User Manual for Digicom HC Series Multi-Screen Processor... - Page 17 Supports the configuration of network applications, such as IP address, gateway, time server, etc. Supports alarm monitoring for temperature, fan, voltage, etc. Intelligent management Supports version checking and online software upgrades VTRON VWAS Standard software for large-screen control (must be purchased Processor software separately) Product certification CCC, CE, CB, RoHS Note: ...
-
Page 18: Chapter 4 Installation
When shipped from the factory, the Digicom HC Series Multi-Screen Processor is provided to the user as a whole unit. All hardware board modules and software program modules of the... -
Page 19: Installation Environment
Please make sure that such power supply can be provided in the installation environment. In addition, to ensure the stability of the power supply to the Digicom HC Series Multi-Screen Processor, the power socket of the Digicom HC Series Multi-Screen Processor must be connected to independent power plugboard (220V 10A standard plugboard recommended). - Page 20 Chapter 4 Installation Besides, when installing the Digicom HC Series Multi-Screen Processor in the high-rise building, the equipment shall be connected to the true earth through the dedicated safe grounding system and kept away from the SPD grounding system of the building. Improper system grounding will have large negative effect on the signal transmission, which will result in the imaging interferences that cannot be removed through debugging.
-
Page 21: System Installation
1. Install or adjust the plate to a suitable position according to the layout of the processor in the cabinet. 2. Install the chassis and attach it with screws (special screws for the cabinet must be used). User Manual for Digicom HC Series Multi-Screen Processor... - Page 22 Chapter 4 Installation 3. Fix the outgoing cables to the back of the cabinet. User Manual for Digicom HC Series Multi-Screen Processor...
-
Page 23: Connection To Peripherals
Connection to a signal source Connect the CVBS input channels on the Digicom HC Series Multi-Screen Processor to the output channels on your CVBS signal sources, with the CVBS video signal cables delivered with the User Manual for Digicom HC Series Multi-Screen Processor... - Page 24 VGA signal sources, with the delivered VGA signal conversion cables; connect the DVI signal input channels on the Digicom HC Series Multi-Screen Processor to the output channels on your DVI signal sources, with the delivered DVI signal conversion cables delivered with the product.
- Page 25 Connection with network cable The Digicom HC Series Multi-Screen Processor can be physically located in the network and can also be controlled through the network. Therefore, in actual application, the user needs to connect the Digicom HC Series Multi-Screen Processor with the network through switching equipment, that is, to use network cables to connect the switching equipment with the network interface.
- Page 26 Chapter 4 Installation Connection with power cord The power socket of the Digicom HC Series Multi-Screen Processor is located at the bottom left corner of the rear panel of the equipment, as shown in the following figure. Power supply input When connecting the equipment power socket and the plugboard, please use the cable delivered together with the equipment.
- Page 27 Besides, the grounding bolt at the right lower corner of the chassis rear panel must be connected to the dedicated grounding system with dedicated grounding conductor through proper method. System grounding stud User Manual for Digicom HC Series Multi-Screen Processor 4-10...
- Page 28 (e.g., adopting the certified three-core power cable and power socket). Besides, when installing the Digicom HC Series Multi-Screen Processor in the high-rise building, the equipment shall be connected to the true earth through the dedicated safe grounding system and kept away from the SPD grounding system of the building.
-
Page 29: Chapter 5 Display Wall Application Administration Software: Vwas (Optional)
The VWAS (VTRON Display Wall Administration System) is the application administration system developed by VTRON for the development, design, and production of the display wall system and its multi-screen processing system. It is mainly used to control and manage the hardware in the display wall system (e.g., the display unit, the multi-screen processor, and other peripherals), so as to realize the... -
Page 30: Chapter 6 Daily Maintenance
Keep the equipment away from any corrosive chemical gases, agents, or inflammable, explosive materials. Do not add or change any of the equipment’s mechanical parts or electrical circuits; if you do, VTRON will assume no liability for the results thusly caused. -
Page 31: Daily Inspection And Maintenance
If the system is not frequently used, turn it on and run it for 1 to 2 hours every week. In damp seasons, the frequency of such operations should be more than once a day. User Manual for Digicom HC Series Multi-Screen Processor... -
Page 32: Chapter 7 Common Faults And Troubleshooting
Check to see if the signal output equipment has a Abnormal image color signal output problem. Make sure the signal source parameters are properly set; User Manual for Digicom HC Series Multi-Screen Processor... - Page 33 Make sure the power supply ground wire is in good condition; Obvious static electricity can be felt when Make sure the grounding stud on the host machine is touching the metal parts of the host properly grounded. machine. User Manual for Digicom HC Series Multi-Screen Processor...
-
Page 34: Chapter 8 Contact Us
Chapter 8 Contact US Chapter 8 Contact Us About after sales service matters please contact after sales department of VTRON GROUP CO.,LTD. VTRON GROUP CO.,LTD. No. 233 Kezhu Road, Guangzhou Hi-Tech Industrial Development Zone (Guangzhou Science City), Guangzhou 510670, China...
