1 Introduction

1.1 Scope

1.1 1.1 1.1 Scope Scope Scope
This document describes the interfaces, the technical specifications, the main
electrical parameters and functional descriptions for the integrated modem
called WMOi3. This product includes a WM2C-G900-G1900 EGSM/PCS dual
band module (pls refer to the WM2C-G900/G1900 specifications).

2 Generality

2.1 Overview

2.1 2.1 2.1 Overview Overview Overview
The integrated modem is a product with a sole connector which puts together
all the interface signals in order to facilitate its integration.
It has an integrated SIM connector as well as a standard RF connector type
MMCX (Miniature Micro Connector).
2.2

2.2 Physical characteristics

Physical characteristics
2.2 2.2 Physical characteristics Physical characteristics
The WMOI3 integrated modem has a complete self-contained shield.
The physical characteristics are the following ones:
confidential
©
This document is the sole and exclusive property of WAVECOM. Not to be distributed or divulged
without prior written agreement. Ce document est la propriété exlcusive de WAVECOM. Il ne peut
être communiqué ou divulgué à des tiers sans son autorisation préalable.
Physical characteristic
Dimension
Absolute maximum
dimension
Weight
Volume
Case
WMOi3 integrated Modem
Qualification
46 x64 x 12.4
mm
About 80 g
3
36.21 cm
Zamack +
stainless steel
3
