Active Speakers
PM0.4c
Thank you very much for purchasing a Fostex product.
This manual provides instructions for basic use of the unit.
Read this before using the unit for the first time.
Owner's Manual
© FOSTEX COMPANY All Rights Reserved.
8588154001
(610872)

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PM0.4c and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Fostex PM0.4c

Summary of Contents for Fostex PM0.4c

  • Page 1 Owner’s Manual Active Speakers PM0.4c Thank you very much for purchasing a Fostex product. This manual provides instructions for basic use of the unit. Read this before using the unit for the first time. © FOSTEX COMPANY All Rights Reserved.

  • Page 2: Important Notice

    FCC and ICES-003 requirements. Changes or modifications not • Increase the separation between the equipment and receiver. expressly approved by Fostex Company for compliance could void the user’ s • Connect the equipment into an outlet on a circuit different from that to authority to operate the equipment.
  • Page 3 Introductions PM0.4c are active speakers with high efficiency, high-quality sound. You can enjoy music with PM0.4c in various situations such as DTM, DJ, listening to PC audio, watching TV and listening to portable audio players. „ Features of the PM0.4c „...

  • Page 4: Parts Names And Functions

    Parts names and functions Active speaker (R channel) Equipped with stereo power amplifier, plays back right channel of input signal. Front Back ④ ② ① ⑤ ③ ⑥ ⑦ ① Power indicator ⑤ [AUTO STANDBY MODE] switch Indicates power state. Switches the auto standby function ON/OFF.
  • Page 5 Passive speaker (L channel) As the unit is not equipped with an amplifier, play back the left channel of the input signal by connecting to the active speaker using the supplied speaker cable. Back ⑧ ⑧ [LEFT] terminal Connects to the [OUTPUT TO LEFT] terminal of the active speaker using the supplied speaker cable.
  • Page 6 Black Power cord (2.0 m) Speaker cable (red/black, 1.5 m) Caution ✐  Do not connect a product other than the passive speaker of PM0.4c to the [OUTPUT TO LEFT] terminal of the active speaker. Doing so may cause a malfunction.

  • Page 7: Specifications

    Specifications Speakers Enclosure 2way bass reflex Low range driver 100 mm (4 inch) cone speaker High range driver 19 mm (3/4 inch) soft dome tweeter Frequency characteristic 60 Hz to 20 kHz Crossover frequency 1.6 kHz Amplifier (active speaker only) Input terminal RCA pin jack, 320 mV (input sensitivity) Input impedance...

  • Page 8: Declaration Of Ec Directive

    FOSTEX DISTRIBUTORS LIST IN EUROPE * Including non-EU countries (as of Jan. 2016) Albania, Bosnia and Hezegovina, Croatia,...
