5.3 LOCAL IP SETTINGS – ENCODER
1. In the Local IP Settings Section type in your desired Local IP settings
2. Hit "Save User" to save your desired settings
3. Power cycle the Z3-MVE-100
4.
The new IP settings will now take effect
5.4

ENCODER CONFIGURATION OPTIONS

Video Source
Audio Source
Audio Codec
Video Resolution
Rate Control
Video Bit Rate
Video Profile
Gop Size
Video Burst Size
Output Interface
Output Format
Dest IP Address
Dest Port
Video Passthru
Local IP Address
Local Netmask
Default Gateway
___________________________________________________________________________________________
Z3 Technology, LLC ♦ 100 N 8
Encoder Setup
SDI, HDMI, Component
Automatic, Analog Jacks
AAC-LC ADTS, None
Follow Input, De-interlace
CBR, VBR
Custom
Baseline, Main, High
10 Frames, 12 Frames, 15 Frames, 25 Frames, 30
Frames, 50 Frames, 60 Frames, 100 Frames, 120
Frames, 200 Frames, 240 Frames
150ms, 200ms, 300ms, 400ms, 500ms, 1000ms,
1200ms, 1400ms, 1600ms, 1800ms, 2000ms
Output Setup
Ethernet, ASI
RTP, MPEG-2 TS
192.168.X.XX (Use IP address of your PC)
8888
HDMI, SDI
Local IP Setup
192.168.X.XX
255.255.0.0
192.168.0.1
11
