Upgrade Manual for KX-HGT100 from Ver1.XX to Ver2.04
The necessary one
1.
HGT100 that does upgrade
2.
PC
3.
firmware(IPPAPL_02_04_20090515.img)
Connection
1.
LAN port of HGT100 and PC is connected with the same hub.
HGT100
HGT100 and PC's connected charts
Setting
1.
IPaddress of PC is set to 192.168.0.100.
2.
HGT100 turns on the power supply while pushing MUTE and OK at the same time.
figure of HGT100
HUB
LAN port
PC
OK button
MUTE button

Advertisement

Table of Contents

   Related Manuals for Panasonic KX-HGT100

   Summary of Contents for Panasonic KX-HGT100

  • Page 1 Upgrade Manual for KX-HGT100 from Ver1.XX to Ver2.04 The necessary one HGT100 that does upgrade firmware(IPPAPL_02_04_20090515.img) Connection LAN port of HGT100 and PC is connected with the same hub. LAN port HGT100 HGT100 and PC's connected charts Setting IPaddress of PC is set to 192.168.0.100.
  • Page 2 2. Connection PC and HGT100 Internet Explorer is started up with PC, and IPaddress of HGT100 is input to the address. If the screen of Authorization is displayed, the following values are input. User name:KX-HGT100 Password:kx-hgt100 KX-HGT100 kx-hgt100 login display of HGT100...
  • Page 3 3. Saving of configuration "Configuration File" is selected from a left menu. And, "Save Configuration File" is clicked. Cfg.txt is saved to an arbitrary directory. 1. click 2. click Configuration File display of HGT100...
  • Page 4 4. Firmware upgrade "Upgrade Firmware" is selected from a left menu. File (IPPAPL_02_04_20090515.img) for the update is selected clicking "Browse...". "Upgrade Firmware" is clicked. If "Successfully completed" is displayed, the power supply of HGT100 is turned off. 2. select firmware file 1.
  • Page 5 5. HGT100 is made a factory default setting. The power supply is turned on while pushing [PROGRAM], [OK], and [MUTE] at the same time. It is confirmed to become "Not configured Web setting" screen. PROGRAM button OK button MUTE button figure of HGT100...
  • Page 6 6. Connection PC and HGT100 Internet Explorer is started up with PC, and IPaddress of HGT100 is input to the address(192.168.0.241). If the screen of Authorization is displayed, the following values are input. User name:KX-HGT100 Password:kx-hgt100 KX-HGT100 kx-hgt100 login display of HGT100...
  • Page 7 7. The Network setting of HGT100 is returned to the value before. "LAN Connection" is selected from a left menu. It makes it to the value in which the network setting is confirmed by step 1. 1. click 2. setting the value LAN Connection display of HGT100...
  • Page 8 If "Successfully completed" is displayed, "Restart" is clicked. "Restart now" is clicked when becoming "Restart" screen. NOTE: Caller ID list, Redial list and Speed dial are erased. If you have not set “Basic setting” of KX-HGT100, execute steps 2, 4, and 5.
