  • Page 1 ECZ 330/230 ” ” Installation and Operation...
  • Page 2 Table of Content Table of content Safety Warning ...............................- 3 - Introduction ..............................- 4 - Features................................- 4 - Delivery scope..............................- 4 - Technical specification ..........................- 5 - Installation................................- 6 - - 2 -...

  • Page 3: Safety Warning

    This is a Class B product which can be used in commercial and limited industrial areas. Your EverFocus product is designed and manufactured with high quality materials and components which can be recycled and reused. This symbol means that electrical and electronic equipment should be disposed of separately from your household waste at their end-of-life.
  • Page 4 INTRODUCTION Introduction The ECZ 330 / 230 camera series contain a CCD camera in a stylish and attractive weatherproof housing. ECZ 330 / 230 series use a SONY high sensitive 1/3” colour interline transfer CCD sensor with low lux performance.
  • Page 5 TECHNICAL SPECIFICATION Technical specification ECZ 330 ECZ 230 Sensor 1/3” SONY CCD Picture element 752 x 582 (PAL) 500 x 582 (PAL) Horizontal resolution 480 TV lines 380 TV lines Sensitivity 0,5 lux / F = 1.2 (IR-LED off) 0,3 lux / F = 1.2 (IR-LED off)
  • Page 6 INSTALLATION Installation 1. Connect the camera with the included mounting bracket. 2. Assemble the sunshield. 3. Connect the BNC connector of the camera to a monitor or other video device through a 75 Ohm type coaxial cable with BNC female connector at cable extension.
  • Page 7 INSTALLATION 5. Adjust the pan/tilt manually to reach the best viewing angle. Neigen Schwenken - 7 -...
  • Page 8 EverFocus Electronics Corp. Headoffice: European office: 12F, No. 79 Sec. 1 Shin-Tai Wu Road, Albert-Einstein-Straße 1 Hsi-Chih, Taipei, Taiwan 46446 Emmerich, Germany Fon: +886-2-2698-2334 Fon: +49-2822-9394-0 Fax: +886-2-2698-2380 Fax: +49-2822-9394-95 www.everfocus.com.tw www.everfocus.de US office L.A.: China office: 1801 Highland Ave. Unit A...

This manual is also suitable for:
