1MRK504114-UEN E
11.6.5.3
11.6.5.4
11.6.5.5
11.6.5.6
11.6.6
11.6.6.1
Operator's manual
Displays available instances of OEXPVPH with a number of measurements per
instance. These measurements indicate whether values are out of the measuring
range (ERROR) and if the overexcitation function has caused a trip (TRIP). The
thermal status as a percentage of the trip level and the calculated time to trip are
among the other outputs available here.

Two step overvoltage protection OV2PTOV

Main menu/Test/Function status/Voltage protection/OverVoltage2Step(PTOV,
59)/OV2PTOV:x
Displays available instances of OV2PTOV with several measurements per
instance. The measurements include operate and start signal data.

Two step residual overvoltage protection ROV2PTOV

Main menu/Test/Function status/Voltage protection/
ResidualOverVoltage2Step(PTOV,59N)/ROV2PTOV:x
Displays available instances of ROV2PTOV with some measurements per instance.
The measurements include operate/trip and signal data.

Two step undervoltage protection UV2PTUV

Main menu/Test/Function status/Voltage protection/
UnderVoltage2Step(PTUV, 27)/UV2PTUV:x
Displays available instances of UV2PTUV with several measurements per
instance. The measurement data includes operate signals and start signals.

Voltage differential protection VDCPTOV

Main menu/Test/Function status/Voltage protection/VoltageDiff(PTOV,60)/
VDCPTOV:x
Displays the output data of VDCPTOV.

Frequency protection

The measurements generated by the Underfrequency, Overfrequency and Rate-of-
change of frequency functions are available under the paths outlined below.

Overfrequency protection SAPTOF

Main menu/Test/Function status/Frequency protection/
OverFrequency(PTOF)/SAPTOF:x
Section 11
Test the IED
85
