Relion
670 series
Transformer protection RET670
Customized
Product Guide

Advertisement

Table of Contents
loading

Related Manuals for ABB RET670

Summary of Contents for ABB RET670

  • Page 1 ® Relion 670 series Transformer protection RET670 Customized Product Guide...

  • Page 2: Table Of Contents

    22. Ordering..............93 Disclaimer The information in this document is subject to change without notice and should not be construed as a commitment by ABB. ABB assumes no responsibility for any errors that may appear in this document. © Copyright 2012 ABB.

  • Page 3: Application

    Since optionally be made directional and/or voltage RET670 has very low requirements on the main controlled, provide further alternative backup CTs, no interposing CTs are required.It is suitable protection. Thermal overload with two time-...

  • Page 4: Available Functions

    Transformer protection RET670 1MRK 504 117-BEN D Customized Product version: 1.2 2. Available functions Main protection functions = number of basic instances = option quantities IEC 61850 ANSI Function description Transformer RET670 Differential protection T2WPDIF Transformer differential protection, two winding...

  • Page 5: Current Protection

    Transformer protection RET670 1MRK 504 117-BEN D Customized Product version: 1.2 Back-up protection functions IEC 61850 ANSI Function description Transformer RET670 Current protection PHPIOC Instantaneous phase overcurrent protection OC4PTOC 51_67 Four step phase overcurrent protection EFPIOC Instantaneous residual overcurrent protection...

  • Page 6: Secondary System Supervision

    Transformer protection RET670 1MRK 504 117-BEN D Customized Product version: 1.2 Control and monitoring functions IEC 61850 ANSI Function description Transformer RET670 Control SESRSYN Synchrocheck, energizing check and synchronizing 0-6, 0-5 APC30 Apparatus control for up to 6 bays, max 30 apparatuses (6CBs) incl.

  • Page 7: Monitoring

    Transformer protection RET670 1MRK 504 117-BEN D Customized Product version: 1.2 IEC 61850 ANSI Function description Transformer RET670 IB16FVCB Integer to Boolean 16 conversion with Logic Node representation Monitoring CVMMXN Measurements CNTGGIO Event counter Event Event function DRPRDRE Disturbance report...
  • Page 8 Transformer protection RET670 1MRK 504 117-BEN D Customized Product version: 1.2 Designed to communicate IEC 61850 ANSI Function description Transformer RET670 Station communication SPA communication protocol LON communication protocol IEC60870-5-103 communication protocol 20/1 Operation selection between SPA and IEC60870-5-103 for SLM DNP3.0 for TCP/IP and EIA-485 communication protocol...

  • Page 9: Basic Ied Functions

    Transformer protection RET670 1MRK 504 117-BEN D Customized Product version: 1.2 Basic IED functions IEC 61850 Function description Basic functions included in all products IntErrorSig Self supervision with internal event list TIME Time and synchronization error TimeSynch Time synchronization ActiveGroup...
  • Page 10 Transformer protection RET670 1MRK 504 117-BEN D Customized Product version: 1.2 Two-winding applications three-winding power transformer with two two-winding power circuit breakers and transformer two CT-sets on one xx05000048.vsd side IEC05000048 V1 EN xx05000053.vsd two-winding power IEC05000053 V1 EN transformer with...
  • Page 11 Transformer protection RET670 1MRK 504 117-BEN D Customized Product version: 1.2 and a voltage dependent resistor which are mounted externally connected to the IED. HZPDIF can be used to protect tee-feeders or busbars. Six single phase function blocks are available to allow application for two three-phase zones busbar protection.
  • Page 12 Transformer protection RET670 1MRK 504 117-BEN D Customized Product version: 1.2 encroachment, which gives the possibility to enlarge the resistive setting of both the phase selection and the measuring zones without interfering with the load. Forward operation The extensive output signals from the phase...
  • Page 13 Transformer protection RET670 1MRK 504 117-BEN D Customized Product version: 1.2 The distance protection zones can operate, enlarge the resistive setting of the measuring independent of each other, in directional (forward zones without interfering with the load. or reverse) or non-directional mode. This makes...
  • Page 14 Transformer protection RET670 1MRK 504 117-BEN D Customized Product version: 1.2 encroachment, which gives the possibility to 5. Current protection enlarge the resistive setting of both the phase Instantaneous phase overcurrent protection selection and the measuring zones without PHPIOC interfering with the load.
  • Page 15 Transformer protection RET670 1MRK 504 117-BEN D Customized Product version: 1.2 IDir, UPol and IPol can be independently selected protected circuit to operate closer to the thermal to be either zero sequence or negative sequence. limits. Second harmonic blocking can be set individually The three-phase current measuring protection for each step.
  • Page 16 Transformer protection RET670 1MRK 504 117-BEN D Customized Product version: 1.2 one phase plus the residual current start. This Capacitor bank protection (CBPGAPC) gives a higher security to the back-up trip Shunt Capacitor Banks (SCB) are used in a power command.
  • Page 17 Transformer protection RET670 1MRK 504 117-BEN D Customized Product version: 1.2 for negative sequence currents down to the Reset delay ensures operation for intermittent continuous capability of a generator. earth faults. A separate output is available as an alarm feature...
  • Page 18 Transformer protection RET670 1MRK 504 117-BEN D Customized Product version: 1.2 detection of high fundamental power system voltage and/or current controlled/restrained. 2nd frequency is needed. harmonic restraining facility is available as well. At too low polarizing voltage the overcurrent feature...
  • Page 19 Transformer protection RET670 1MRK 504 117-BEN D Customized Product version: 1.2 The fuse failure supervision function basically has SESRSYN function includes a built-in voltage three different algorithms, negative sequence and selection scheme for double bus and 1½ breaker zero sequence based algorithms and an or ring busbar arrangements.
  • Page 20 Transformer protection RET670 1MRK 504 117-BEN D Customized Product version: 1.2 supervised. Enhanced security means that the switches are used extensively by utilities, in order command is evaluated with an additional to have different functions operating on pre-set supervision of the status value of the control values.
  • Page 21 Transformer protection RET670 1MRK 504 117-BEN D Customized Product version: 1.2 voltage apparatuses or for other user defined a fault current reversal logic (transient blocking functionality. logic) can be used. Permissive communication schemes for residual 11. Scheme communication overcurrent protection can basically operate only...
  • Page 22 Transformer protection RET670 1MRK 504 117-BEN D Customized Product version: 1.2 • measured voltages, currents, frequency, conditions, recording times, and large storage active, reactive and apparent power and capacity. power factor A disturbance is defined as an activation of an •...
  • Page 23 Transformer protection RET670 1MRK 504 117-BEN D Customized Product version: 1.2 short term (for example corrective actions) and in seconds of data before the trigger instant can be the long term (for example functional analysis). saved in the disturbance file.

  • Page 24: Human Machine Interface

    Transformer protection RET670 1MRK 504 117-BEN D Customized Product version: 1.2 14. Metering label. All LEDs are configurable from PCM600. Pulse counter logic PCGGIO • Liquid crystal display (LCD). Pulse counter (PCGGIO) function counts • Keypad with push buttons for control and...

  • Page 25: Station Communication

    LON interface. This allows full SA functionality including peer-to-peer messaging and cooperation between existing ABB IED's and the new IED 670. SPA communication protocol A single glass or plastic port is provided for the ABB SPA protocol.

  • Page 26: Remote Communication

    Transformer protection RET670 1MRK 504 117-BEN D Customized Product version: 1.2 19. Hardware description Select IEC 62439-3 Edition 1 protocol at the time of ordering Hardware modules when an existing redundant Power supply module PSM station bus DuoDriver The power supply module is used to provide the installation is extended.
  • Page 27 Transformer protection RET670 1MRK 504 117-BEN D Customized Product version: 1.2 protocol (port A, B). The module has one or two GPS time synchronization module GTM optical ports with ST connectors. This module includes a GPS receiver used for time synchronization. The GPS has one SMA Serial and LON communication module SLM, contact for connection to an antenna.
  • Page 28 Transformer protection RET670 1MRK 504 117-BEN D Customized Product version: 1.2 xx05000003.vsd IEC05000003 V1 EN Figure 7. 1/2 x 19” case with rear cover xx05000004.vsd IEC05000004 V1 EN Figure 8. Side-by-side mounting Case size 6U, 1/2 x 19” 265.9 223.7 201.1...
  • Page 29 Transformer protection RET670 1MRK 504 117-BEN D Customized Product version: 1.2 – 1/2 case size (h) 254.3 mm (w) 210.1 mm – 3/4 case size (h) 254.3 mm (w) 322.4 mm – 1/1 case size (h) 254.3 mm (w) 434.7 mm •...

  • Page 30: Connection Diagrams

    Transformer protection RET670 1MRK 504 117-BEN D Customized Product version: 1.2 20. Connection diagrams Table 1. Designations for 1/2 x 19” casing with 1 TRM slot Module Rear Positions BIM, BOM, SOM, IOM or X31 and X32 etc. to X51...
  • Page 31 Transformer protection RET670 1MRK 504 117-BEN D Customized Product version: 1.2 Table 2. Designations for 3/4 x 19” casing with 1 TRM slot Module Rear Positions BIM, BOM, SOM, IOM or X31 and X32 etc. to X101 and X102 X301:A, B, C, D...
  • Page 32 Transformer protection RET670 1MRK 504 117-BEN D Customized Product version: 1.2 Table 3. Designations for 3/4 x 19” casing with 2 TRM slot Module Rear Positions BIM, BOM, SOM, IOM or X31 and X32 etc. to X71 and X301:A, B, C, D...
  • Page 33 Transformer protection RET670 1MRK 504 117-BEN D Customized Product version: 1.2 Table 5. Designations for 1/1 x 19” casing with 2 TRM slots Module Rear Positions BIM, BOM, SOM, X31 and X32 etc. to X131 IOM or MIM and X132...
  • Page 34 Transformer protection RET670 1MRK 504 117-BEN D Customized Product version: 1.2 1MRK002801-AC-10-670-1.2-PG V1 EN Figure 9. Transformer input module (TRM) ￭ Indicates high polarity CT/VT-input designation according to figure AI01 AI02 AI03 AI04 AI05 AI06 AI07 AI08 AI09 AI10 AI11...
  • Page 35 Transformer protection RET670 1MRK 504 117-BEN D Customized Product version: 1.2 3I, 5A 110-220V 110-220V 110-220V 110-220V 110-220V 110-220V +3I, 1A 6I, 1A 6I, 5A *) Metering Note that internal polarity can be adjusted by setting of analog input CT neutral direction and/or on SMAI pre- processing function blocks.
  • Page 36 Transformer protection RET670 1MRK 504 117-BEN D Customized Product version: 1.2 1MRK002801-AC-8-670-1.2-PG V1 EN Figure 12. IED with basic functionality and communication interfaces 1MRK002801-AC-7-670-1.2-PG V1 EN Figure 13. Power supply module (PSM)
  • Page 37 Transformer protection RET670 1MRK 504 117-BEN D Customized Product version: 1.2 1MRK002801-AC-12-670-1.2-PG V1 EN Figure 14. Binary output module (BOM). Output contacts named XA corresponds to rear position X31, X41, and so on, and output contacts named XB to rear position X32, X42, and so on.
  • Page 38 Transformer protection RET670 1MRK 504 117-BEN D Customized Product version: 1.2 1MRK002801-AC-14-670-1.2-PG V1 EN Figure 16. Binary in/out module (IOM). Input contacts named XA corresponds to rear position X31, X41, and so on, and output contacts named XB to rear position X32, X42, and so on.

  • Page 39: Technical Data

    Transformer protection RET670 1MRK 504 117-BEN D Customized Product version: 1.2 21. Technical data General Definitions Reference value The specified value of an influencing factor to which are referred the characteristics of the equipment Nominal range The range of values of an influencing quantity (factor) within which, under specified conditions,...
  • Page 40 Transformer protection RET670 1MRK 504 117-BEN D Customized Product version: 1.2 Table 7. TRM - Energizing quantities, rated values and limits for measuring transformer modules Quantity Rated value Nominal range Current = 1 or 5 A (0-1.8) × I at I = 1 A (0-1.6) ×...
  • Page 41 Transformer protection RET670 1MRK 504 117-BEN D Customized Product version: 1.2 Auxiliary DC voltage Table 10. PSM - Power supply module Quantity Rated value Nominal range Auxiliary dc voltage, EL (input) EL = (24 - 60) V EL ± 20% EL = (90 - 250) V EL ±...
  • Page 42 Transformer protection RET670 1MRK 504 117-BEN D Customized Product version: 1.2 Table 13. IOM - Binary input/output module Quantity Rated value Nominal range Binary inputs DC voltage, RL 24/30 V RL ± 20% 48/60 V RL ± 20% 110/125 V RL ±...
  • Page 43 Transformer protection RET670 1MRK 504 117-BEN D Customized Product version: 1.2 Table 15. IOM with MOV - contact data (reference standard: IEC 60255-23) Function or quantity Trip and Signal relays Fast signal relays (parallel reed relay) Binary outputs IOM: 10...
  • Page 44 Transformer protection RET670 1MRK 504 117-BEN D Customized Product version: 1.2 Table 16. SOM - Static Output Module (reference standard: IEC 61810-2): Static binary outputs Function of quantity Static binary output trip Rated voltage 48 - 60 VDC 110 - 250 VDC...
  • Page 45 Transformer protection RET670 1MRK 504 117-BEN D Customized Product version: 1.2 Table 18. BOM - Binary output module contact data (reference standard: IEC 61810-2) Function or quantity Trip and Signal relays Binary outputs Max system voltage 250 V AC, DC...
  • Page 46 Transformer protection RET670 1MRK 504 117-BEN D Customized Product version: 1.2 Table 21. Frequency influence (reference standard: IEC 60255–1) Dependence on Within nominal range Influence Frequency dependence, operate value ± 2.5 Hz for 50 Hz ± 1.0% / Hz ± 3.0 Hz for 60 Hz Frequency dependence for distance ±...
  • Page 47 Transformer protection RET670 1MRK 504 117-BEN D Customized Product version: 1.2 Type tests according to standards Table 22. Electromagnetic compatibility Test Type test values Reference standards 1 MHz burst disturbance 2.5 kV IEC 60255-22-1 100 kHz slow damped oscillatory wave 2.5 kV...
  • Page 48 Transformer protection RET670 1MRK 504 117-BEN D Customized Product version: 1.2 Table 24. Environmental tests Test Type test value Reference standard Cold test Test Ad for 16 h at -25°C IEC 60068-2-1 Storage test Test Ad for 16 h at -40°C...
  • Page 49 Transformer protection RET670 1MRK 504 117-BEN D Customized Product version: 1.2 Differential protection Table 27. Transformer differential protection T2WPDIF, T3WPDIF Function Range or value Accuracy Operating characteristic Adaptable ± 1.0% of Ir for I < Ir ± 1.0% of I for I > Ir Reset ratio >95%...
  • Page 50 Transformer protection RET670 1MRK 504 117-BEN D Customized Product version: 1.2 Table 28. Restricted earth fault protection, low impedance REFPDIF Function Range or value Accuracy Operate characteristic Adaptable ± 1% of IBase 2% of theoretical operate value (Idiff) if Ibias >= 1.25 IBase (i.e.
  • Page 51 Transformer protection RET670 1MRK 504 117-BEN D Customized Product version: 1.2 Impedance protection Table 30. Distance measuring zone, Quad ZMQPDIS Function Range or value Accuracy Number of zones 5 with selectable direction Minimum operate residual (5-1000)% of IBase current, zone 1...
  • Page 52 Transformer protection RET670 1MRK 504 117-BEN D Customized Product version: 1.2 Table 31. Distance measuring zone, quadrilateral characteristic for series compensated lines ZMCPDIS, ZMCAPDIS Function Range or value Accuracy Number of zones 5 with selectable direction IBase Minimum operate residual...
  • Page 53 Transformer protection RET670 1MRK 504 117-BEN D Customized Product version: 1.2 Table 33. Full-scheme distance protection, Mho characteristic ZMHPDIS Function Range or value Accuracy Number of zones with selectable 5 with selectable direction directions Minimum operate current (10–30)% of I...
  • Page 54 Transformer protection RET670 1MRK 504 117-BEN D Customized Product version: 1.2 Table 35. Faulty phase identification with load encroachment FMPSPDIS Function Range or value Accuracy Minimum operate current (5-30)% of IBase ± 1.0% of I Load encroachment criteria: (0.5–3000) W/phase ±...
  • Page 55 Transformer protection RET670 1MRK 504 117-BEN D Customized Product version: 1.2 Table 37. Phase selection with load encroachment, quadrilateral characteristic FRPSPDIS Function Range or value Accuracy Minimum operate current (5-500)% of IBase Reactive reach, positive (0.50–3000.00) Ω/phase ± 2.0% static accuracy sequence ±...
  • Page 56 Transformer protection RET670 1MRK 504 117-BEN D Customized Product version: 1.2 Table 40. Phase preference logic PPLPHIZ Function Range or value Accuracy Operate value, phase-to-phase (10.0 - 100.0)% of UBase ± 0,5% of U and phase-to-neutral undervoltage Reset ratio, undervoltage <...
  • Page 57 Transformer protection RET670 1MRK 504 117-BEN D Customized Product version: 1.2 Current protection Table 41. Instantaneous phase overcurrent protection PHPIOC Function Range or value Accuracy Operate current (1-2500)% of lBase ± 1.0% of I at I £ I ± 1.0% of I at I > I Reset ratio >...
  • Page 58 Transformer protection RET670 1MRK 504 117-BEN D Customized Product version: 1.2 Table 43. Instantaneous residual overcurrent protection EFPIOC Function Range or value Accuracy Operate current (1-2500)% of lBase ± 1.0% of I at I £ I ± 1.0% of I at I > I Reset ratio >...
  • Page 59 Transformer protection RET670 1MRK 504 117-BEN D Customized Product version: 1.2 Table 45. Four step negative sequence overcurrent protection NS4PTOC Function Range or value Accuracy Operate value, negative (1-2500)% of lBase ± 1.0% of I at I £ I sequence current, step 1-4 ±...
  • Page 60 Transformer protection RET670 1MRK 504 117-BEN D Customized Product version: 1.2 Table 46. Sensitive directional residual overcurrent and power protection SDEPSDE Function Range or value Accuracy Operate level for 3I ·cosj (0.25-200.00)% of lBase ± 1.0% of I at I £ I directional residual ±...
  • Page 61 Transformer protection RET670 1MRK 504 117-BEN D Customized Product version: 1.2 Table 46. Sensitive directional residual overcurrent and power protection SDEPSDE, continued Function Range or value Accuracy Operate time, non-directional 60 ms typically at 0 to 2 x I residual over current...
  • Page 62 Transformer protection RET670 1MRK 504 117-BEN D Customized Product version: 1.2 Table 49. Breaker failure protection CCRBRF Function Range or value Accuracy Operate phase current (5-200)% of lBase ± 1.0% of I at I £ I ± 1.0% of I at I > I Reset ratio, phase current >...
  • Page 63 Transformer protection RET670 1MRK 504 117-BEN D Customized Product version: 1.2 Table 53. Broken conductor check BRCPTOC Function Range or value Accuracy Minimum phase current for operation (5–100)% of IBase ± 0.1% of I Unbalance current operation (0–100)% of maximum current ±...
  • Page 64 Transformer protection RET670 1MRK 504 117-BEN D Customized Product version: 1.2 Table 55. Negative sequence time overcurrent protection for machines NS2PTOC Function Range or value Accuracy Operate value, step 1 and 2, negative (3-500)% of IBase ± 1.0% of I at I <...
  • Page 65 Transformer protection RET670 1MRK 504 117-BEN D Customized Product version: 1.2 Voltage protection Table 56. Two step undervoltage protection UV2PTUV Function Range or value Accuracy UBase Operate voltage, low and high step (1–100)% of ± 0.5% of U UBase Absolute hysteresis (0–100)% of...
  • Page 66 Transformer protection RET670 1MRK 504 117-BEN D Customized Product version: 1.2 Table 58. Two step residual overvoltage protection ROV2PTOV Function Range or value Accuracy Operate voltage, step 1 and step 2 (1-200)% of UBase ± 0.5% of U at U < U ±...
  • Page 67 Transformer protection RET670 1MRK 504 117-BEN D Customized Product version: 1.2 Table 61. Loss of voltage check LOVPTUV Function Range or value Accuracy Operate voltage (0–100)% of UBase ± 0.5% of U Pulse timer (0.050–60.000) s ± 0.5% ± 10 ms Timers (0.000–60.000) s...
  • Page 68 Transformer protection RET670 1MRK 504 117-BEN D Customized Product version: 1.2 Frequency protection Table 62. Underfrequency protection SAPTUF Function Range or value Accuracy Operate value, start function (35.00-75.00) Hz ± 2.0 mHz Operate time, start function 100 ms typically Reset time, start function...
  • Page 69 Transformer protection RET670 1MRK 504 117-BEN D Customized Product version: 1.2 Multipurpose protection Table 65. General current and voltage protection CVGAPC Function Range or value Accuracy Measuring current input phase1, phase2, phase3, PosSeq, NegSeq, 3*ZeroSeq, MaxPh, MinPh, UnbalancePh, phase1-phase2, phase2-...
  • Page 70 Transformer protection RET670 1MRK 504 117-BEN D Customized Product version: 1.2 Table 65. General current and voltage protection CVGAPC , continued Function Range or value Accuracy Reset time start undervoltage 25 ms typically at 0 to 2 x U High and low voltage limit, voltage (1.0 - 200.0)% of UBase...
  • Page 71 Transformer protection RET670 1MRK 504 117-BEN D Customized Product version: 1.2 Secondary system supervision Table 66. Current circuit supervision CCSRDIF Function Range or value Accuracy Operate current (5-200)% of I ± 10.0% of I at I £ I ± 10.0% of I at I > I...
  • Page 72 Transformer protection RET670 1MRK 504 117-BEN D Customized Product version: 1.2 Control Table 68. Synchronizing, synchrocheck and energizing check SESRSYN Function Range or value Accuracy Phase shift, j (-180 to 180) degrees line Voltage ratio, U 0.500 - 2.000 line...
  • Page 73 Transformer protection RET670 1MRK 504 117-BEN D Customized Product version: 1.2 Table 69. Voltage control TR1ATCC, TR8ATCC, TCMYLTC and TLCYLTC Function Range or value Accuracy Transformer reactance (0.1–200.0)Ω, primary Time delay for lower command when fast (1.0–100.0) s step down mode is activated Voltage control set voltage (85.0–120.0)% of UB...
  • Page 74 Transformer protection RET670 1MRK 504 117-BEN D Customized Product version: 1.2 Table 69. Voltage control TR1ATCC, TR8ATCC, TCMYLTC and TLCYLTC, continued Function Range or value Accuracy Type of code conversion BIN, BCD, GRAY, SINGLE, mA Time after position change before the value (1–60) s...
  • Page 75 Transformer protection RET670 1MRK 504 117-BEN D Customized Product version: 1.2 Scheme communication Table 70. Scheme communication logic for residual overcurrent protection ECPSCH Function Range or value Accuracy Scheme type Permissive Underreaching Permissive Overreaching Blocking Communication scheme (0.000-60.000) s ± 0.5% ± 10 ms coordination time Table 71.
  • Page 76 Transformer protection RET670 1MRK 504 117-BEN D Customized Product version: 1.2 Logic Table 72. Tripping logic SMPPTRC Function Range or value Accuracy Trip action 3-ph, 1/3-ph, 1/2/3-ph Minimum trip pulse length (0.000-60.000) s ± 0.5% ± 10 ms Timers (0.000-60.000) s ±...
  • Page 77 Transformer protection RET670 1MRK 504 117-BEN D Customized Product version: 1.2 Monitoring Table 74. Measurements CVMMXN Function Range or value Accuracy Frequency (0.95-1.05) × f ± 2.0 mHz Voltage (0.1-1.5) ×U ± 0.5% of U at U£U ± 0.5% of U at U > U Connected current (0.2-4.0) ×...
  • Page 78 Transformer protection RET670 1MRK 504 117-BEN D Customized Product version: 1.2 Table 78. Current sequence component measurement CMSQI Function Range or value Accuracy Current positive sequence, I1 (0.1–4.0) × I ± 0.2% of I at I ≤ 0.5 × I Three phase settings ±...
  • Page 79 Transformer protection RET670 1MRK 504 117-BEN D Customized Product version: 1.2 Table 82. Disturbance report DRPRDRE Function Range or value Accuracy Pre-fault time (0.05–9.90) s Post-fault time (0.1–10.0) s Limit time (0.5–10.0) s Maximum number of recordings 100, first in - first out...
  • Page 80 Transformer protection RET670 1MRK 504 117-BEN D Customized Product version: 1.2 Table 85. Event recorder Function Value Buffer capacity Maximum number of events in disturbance report Maximum number of disturbance reports Resolution 1 ms Accuracy Depending on time synchronizing Table 86. Trip value recorder...
  • Page 81 Transformer protection RET670 1MRK 504 117-BEN D Customized Product version: 1.2 Metering Table 88. Pulse counter PCGGIO Function Setting range Accuracy Input frequency See Binary Input Module (BIM) Cycle time for report of counter (1–3600) s value Table 89. Energy metering ETPMMTR...
  • Page 82 Transformer protection RET670 1MRK 504 117-BEN D Customized Product version: 1.2 Station communication Table 90. IEC 61850-8-1 communication protocol Function Value Protocol IEC 61850-8-1 Communication speed for the IEDs 100BASE-FX Protocol IEC 608–5–103 Communication speed for the IEDs 9600 or 19200 Bd Protocol DNP3.0...
  • Page 83 Transformer protection RET670 1MRK 504 117-BEN D Customized Product version: 1.2 Table 95. SLM – SPA/IEC 60870-5-103/DNP3 port Quantity Range or value Optical connector Glass fibre: type ST Plastic fibre: type HFBR snap-in Fibre, optical budget Glass fibre: 11 dB (3000ft/1000 m typically *)
  • Page 84 Transformer protection RET670 1MRK 504 117-BEN D Customized Product version: 1.2 Remote communication Table 98. Line data communication module Characteristic Range or value Type of LDCM Short range (SR) Medium range (MR) Long range (LR) Type of fibre Graded-index Singlemode 9/125 µm Singlemode 9/125 µm...
  • Page 85 Transformer protection RET670 1MRK 504 117-BEN D Customized Product version: 1.2 Hardware Table 99. Case Material Steel sheet Front plate Steel sheet profile with cut-out for HMI Surface treatment Aluzink preplated steel Finish Light grey (RAL 7035) Table 100. Water and dust protection level according to IEC 60529...
  • Page 86 Transformer protection RET670 1MRK 504 117-BEN D Customized Product version: 1.2 Basic IED functions Table 104. Self supervision with internal event list Data Value Recording manner Continuous, event controlled List size 1000 events, first in-first out Table 105. Time synchronization, time tagging...
  • Page 87 Transformer protection RET670 1MRK 504 117-BEN D Customized Product version: 1.2 Table 108. IRIG-B Quantity Rated value Number of channels IRIG-B Number of channels PPS Electrical connector: Electrical connector IRIG-B Pulse-width modulated 5 Vpp Amplitude modulated – low level 1-3 Vpp –...
  • Page 88 Transformer protection RET670 1MRK 504 117-BEN D Customized Product version: 1.2 Inverse characteristic Table 109. ANSI Inverse time characteristics Function Range or value Accuracy Operating characteristic: k = (0.05-999) in steps of 0.01 æ ö ç ÷ × ç ÷...
  • Page 89 Transformer protection RET670 1MRK 504 117-BEN D Customized Product version: 1.2 Table 110. IEC Inverse time characteristics Function Range or value Accuracy Operating characteristic: k = (0.05-999) in steps of 0.01 æ ö ç ÷ × ç ÷ è ø...
  • Page 90 Transformer protection RET670 1MRK 504 117-BEN D Customized Product version: 1.2 Table 111. RI and RD type inverse time characteristics Function Range or value Accuracy RI type inverse characteristic k = (0.05-999) in steps of 0.01 IEC 60255-151, 5% + 40 ×...
  • Page 91 Transformer protection RET670 1MRK 504 117-BEN D Customized Product version: 1.2 Table 113. Inverse time characteristics for undervoltage protection Function Range or value Accuracy Type A curve: k = (0.05-1.10) in steps of 0.01 5% +40 ms æ ö < - ç...
  • Page 92 Transformer protection RET670 1MRK 504 117-BEN D Customized Product version: 1.2 Table 114. Inverse time characteristics for residual overvoltage protection Function Range or value Accuracy Type A curve: k = (0.05-1.10) in steps of 5% +40 ms 0.01 æ ö...

  • Page 93: Ordering

    Transformer protection RET670 1MRK 504 117-BEN D Customized Product version: 1.2 22. Ordering Guidelines Carefully read and follow the set of rules to ensure problem-free order management. Be aware that certain functions can only be ordered in combination with other functions and that some functions require specific hardware selections.
  • Page 94 Transformer protection RET670 1MRK 504 117-BEN D Customized Product version: 1.2 Logic Rule: One Tripping logic must be ordered Tripping logic (SMPPTRC) Qty: 1MRK 002 917-AC Optional functions Differential protection 1Ph High impedance differential protection (HZPDIF) Qty: 1MRK 002 901-HB...
  • Page 95 Transformer protection RET670 1MRK 504 117-BEN D Customized Product version: 1.2 Impedance protection Rule: One and only one of the alternatives (Alt. 1-4) can be ordered Alternative 1: Rule: Distance protection and Directional impedance must be ordered together Note: Phase selection FDPSPDIS always included in this...
  • Page 96 Transformer protection RET670 1MRK 504 117-BEN D Customized Product version: 1.2 Phase selection, quadrilateral characteristic with settable Qty: 1MRK 002 925-XA angle (FRPSPDIS) Directional impedance quadrilateral (ZDRDIR) Qty: 1MRK 002 904-YB Note: Optional with alternative 1 Directional impedance element for mho characteristic...
  • Page 97 Transformer protection RET670 1MRK 504 117-BEN D Customized Product version: 1.2 Current protection Instantaneous phase overcurrent protection (PHPIOC) Qty: 1MRK 002 906-AC Four step phase overcurrent protection (OC4PTOC) Qty: 1MRK 002 906-BD Qty: Instantaneous residual overcurrent protection (EFPIOC) 1MRK 002 906-CC...
  • Page 98 Transformer protection RET670 1MRK 504 117-BEN D Customized Product version: 1.2 Voltage protection Two step undervoltage protection (UV2PTUV) Qty: 1MRK 002 908-AC Two step overvoltage protection (OV2PTOV) Qty: 1MRK 002 908-DC Two step residual overvoltage protection (ROV2PTOV) Qty: 1MRK 002 908-GC...
  • Page 99 Transformer protection RET670 1MRK 504 117-BEN D Customized Product version: 1.2 Control Synchrocheck, energizing check and synchronizing Qty: 1MRK 002 916-SD (SESRSYN) Apparatus control for up to 6 bays, max 30 apparatuses 1MRK 002 916-RD (6CBs) incl. interlocking Rule: Only one of (TR1ATCC, TR8ATCC) can be ordered.
  • Page 100 Transformer protection RET670 1MRK 504 117-BEN D Customized Product version: 1.2 Additional local HMI user dialogue language Rule: Maximum one alternative HMI language, German 1MRK 002 920-AB HMI language, Russian 1MRK 002 920-BB HMI language, French 1MRK 002 920-DB HMI language, Spanish...
  • Page 101 Transformer protection RET670 1MRK 504 117-BEN D Customized Product version: 1.2 Analog system Rule: One Transformer input module must be ordered Note: The same type of connection terminals has to be ordered for both TRMs Transformer input module, compression terminals...
  • Page 102 Transformer protection RET670 1MRK 504 117-BEN D Customized Product version: 1.2 Transformer input module, compression terminals 6I, 5A, 50/60 Hz Qty: 1MRK 002 247-DH Transformer input module, ring lug terminals 12I, 1A, 50/60 Hz Qty: 1MRK 002 247-CC Transformer input module, ring lug terminals...
  • Page 103 Transformer protection RET670 1MRK 504 117-BEN D Customized Product version: 1.2 Transformer input module, ring lug terminals 6I, 1A, 50/60 Hz Qty: 1MRK 002 247-DC Transformer input module, ring lug terminals 6I, 5A, 50/60 Hz Qty: 1MRK 002 247-DD Note: One Analog digital conversion module, with time synchronization is always delivered with each Transformer input module.
  • Page 104 Transformer protection RET670 1MRK 504 117-BEN D Customized Product version: 1.2 Binary input/output modules Make BIM with 50 mA inrush current the primary choice. BIM with 50 mA inrush current fulfill additional standards. As a consequence the EMC withstand capability is further increased.
  • Page 105 Transformer protection RET670 1MRK 504 117-BEN D Customized Product version: 1.2 Binary input module (BIM) with enhanced pulse counting capabilities, 16 inputs RL 24-30 VDC Qty: 1MRK 000 508-HA 10 11 12 13 RL 48-60 VDC Qty: 1MRK 000 508-EA...
  • Page 106 Transformer protection RET670 1MRK 504 117-BEN D Customized Product version: 1.2 Make IOM with 50 mA inrush current the primary choice. IOM with 50 mA inrush current fulfill additional standards. As a consequence the EMC withstand capability is further increased.
  • Page 107 Transformer protection RET670 1MRK 504 117-BEN D Customized Product version: 1.2 Station communication ports Note: Optical ethernet module, 2 glass interfaces is not allowed together with SLM. Optical ethernet module, 1 channel glass 1MRK 002 266-AA Optical ethernet module, 2 channel glass...
  • Page 108 Transformer protection RET670 1MRK 504 117-BEN D Customized Product version: 1.2 Accessories GPS antenna and mounting details GPS antenna, including mounting kits Quantity: 1MRK 001 640-AA Cable for antenna, 20 m Quantity: 1MRK 001 665-AA Cable for antenna, 40 m...
  • Page 109 Transformer protection RET670 1MRK 504 117-BEN D Customized Product version: 1.2 Protection cover Protective cover for rear side of RHGS6, 6U, 1/4 x 19” Quantity: 1MRK 002 420-AE Protective cover for rear side of terminal, 6U, 1/2 x 19” Quantity: 1MRK 002 420-AC Protective cover for rear side of terminal, 6U, 3/4 x 19”...
  • Page 110 Transformer protection RET670 1MRK 504 117-BEN D Customized Product version: 1.2 Rule: Specify additional quantity of IED Connect CD requested . Quantity: 1MRK 002 290-AB User documentation Rule: Specify the number of printed manuals requested Operator’s manual Quantity: 1MRK 504 114-UEN...
  • Page 111 670 series SPA and signal list 1MRK 500 092-WEN IEC 61850 Data objects list for 670 series 1MRK 500 091-WEN Engineering manual 670 series 1MRK 511 240-UEN Communication set-up for Relion 670 series 1MRK 505 260-UEN More information can be found on www.abb.com/substationautomation.
  • Page 113 Contact us ABB AB Substation Automation Products SE-721 59 Västerås, Sweden Phone +46 (0) 21 32 50 00 +46 (0) 21 14 69 18 www.abb.com/substationautomation...
