i3 International i3B265i Instruction Manual

Lpr camera
Hide thumbs

Advertisement

Quick Links

Download this manual
CONTENTS
PRECAUTION ..................................................................
IMPORTANT SAFTY INSTRUCTIONS....................................
NOTES OF USE.................................................................
MENU SETTING ................................................................
SPECIFICATIONS..............................................................
Before attempting to connect or operate this product, please read these instructions
carefully and save this manual for future use.
i3B265i LPR Camera
2
3
4
6
12

Advertisement

loading
Need help?

Need help?

Do you have a question about the i3B265i and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for i3 International i3B265i

Summary of Contents for i3 International i3B265i

  • Page 1: Table Of Contents

    LPR Camera Instruction Manual CONTENTS PRECAUTION ..............IMPORTANT SAFTY INSTRUCTIONS........NOTES OF USE..............MENU SETTING ..............SPECIFICATIONS.............. Before attempting to connect or operate this product, please read these instructions carefully and save this manual for future use.

  • Page 2: Instruction Manual

    PRECAUTIONS CAUTION CAUTION R I S K E L E C T R I C S H O C K N O T O P E N NOTE: This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to Part The lightening flash with an 15 of the FCC Rules.

  • Page 3: Important Safty Instructions

    IMPORTANT SAFETY INSTRUCTIONS Powersupply cords should be routed 1) Do not touch the imaging surface of the so that they are not likely to be walk- sensor. ed on or pinched by items placed Use a soft cloth moistened with alcohol to upon or against them.

  • Page 4: Notes Of Use

    NOTES OF USE •PART NAMES AND LOCATIONS (1) Lens mount (4) Up button Use this button to move the cursor upward For the installation of CS Mount lenses only. or to select different settings in the OSD menu. (2) Back Focus adjustment : (5) Left button A.Back Focus Screw : Loosen this screw before you use the Focus...
  • Page 5 NOTES OF USE (9) Tripod Stand RJ-45 connector Application for mounting the camera onto the camera holder. Effective for general camera tripods. (10) RJ-45 Terminal Remote control for the OSD menu and B.C.G function (11) Video Output Terminal BNC :Used to give out the video signal. BCG Control •...

  • Page 6: Menu Setting

    MENU SETTING •OSD SETUP MENU...
  • Page 7 MENU SETTING move the cursor to the 'EXIT" Press the ENTER button to execute item and press the enter button to exit the the main menu. The shaded setting area OSD setup menu. represents a item and keeps blinking. You can also restore the settings to factory default by moving the cursor to •...
  • Page 8 MENU SETTING • Day Night LEVEL • EXPOSURE Set the ALC for the Auto IRIS Select D/N LEVEL to set up the lens control and the AES for the auto switchover point of brightness from electronic shutter . Move the cursor to COLOUR mode to B/W mode under the EXPOSURE set up item.
  • Page 9 MENU SETTING • BLC Move the cursor to the BLC set up item. TRAFFIC 3: It’s applied to the speed from 20 km/hr to 110 km/hr. Please set Use the LEFT/ RIGHT button to choose the camera obliquely in front of the cars. OFF, BLC1, BLC2, BLC3, BLC4, BLC5 or * The DAY/NIGHT mode may be hard BLC6.

  • Page 10: White Balance

    MENU SETTING • WHITE BALANCE • PRIVACY ZONE Max 8 blocks can be set on the Select and set the white balance screen. Move the cursor to the PRIVACY system (ATW2, ATW1 and manual ZONE set up item. Press ENTER to get mode).
  • Page 11 MENU SETTING CAMERA TEXT: Use ENTER to get into WITH IR LAMP:Use enter to get into the the submenu. When exiting the OSD submenu. Use the LEFT/RIGHT button, to menu, the text will be shown on the choose YES or NO. display.

  • Page 12: Specifications

    SPECIFICATION NTSC Signal system Image system Imaging area 4.9mm x 3.7mm Image pickup device 1/3”-type Exview CCD Effective pixels(HxV) 768 x 494 752 x 582 Electric 2:1 Interlace V: 59.94Hz, 2:1 Interlace V: 50Hz, Scanning system H: 15.734KHz H: 15.625KHz Sync system Internal / Linelock Horizontal resolution...
