The tab pane of the user interface contains the following four tabs that are arranged horizontally.
1.
Clicking any of these tabs displays a page that enables you to access associated information.
−
Home: The Home tab provides the most relevant information about your broadband service at a
glance. It also provides links to access more detailed information
−
Services: The Services tab provides links to view your voice line status.
−
Settings: The Settings tab provides the most comprehensive system information. Clicking this tab
opens a page that provides sub-tabs to access other pages to configure your i38HG and view
system status.
−
Site Map: The Site Map tab provides a textual view of the user interface. Clicking any links on this
page takes you directly to the page of interest.
The Summary pane displays the status of each service. Except the fourth icon, i3802V, you can click
2.
other icons to directly access more information.
This pane displays the backup battery status. You can click
3.
Notes:
The backup battery status is displayed only if your iPSU is equipped
with one.
It is recommended to have a backup battery if you subscribe to voice-over-IP
services and is required to maintain voice-over-IP service during a power
outage.
The Home Network Devices pane displays all devices that are connected to the i38HG. You can click the
4.
links to view the detailed information of the connected devices.
The Top Networking Features pane provides shortcuts to directly access the most commonly used
5.
pages.
Setting up System Information
(Figure 8).
Battery Info to directly access the page.
