STC – TC83USB-ASH STC – TB83USB-ASH Safety Precautions For U.S.A. For U.S.A. CAUTION CAUTION Warning: Warning: For U.S.A. CAUTION RISK OF ELECTRIC SHOCK Warning: This equipment generates and uses radio frequency energy and if RISK OF ELECTRIC SHOCK This equipment generates and uses radio frequency energy and if DO NOT OPEN DO NOT OPEN not installed and used properly, I.e., in strict accordance with the...
Page 3
While every effort has been made to ensure that the details contained in Sentech America’s website and all documentation are correct and up-to-date, Sentech America assumes no liability, legal or otherwise for any errors in listings, specifications, part numbers, process, software or model applications.
STC – TC83USB-ASH STC – TB83USB-ASH I. Specifications A. Electronic Specifications / Mechanical Specifications / Environmental Conditions Product STC-TC83USB-ASH STC-TB83USB-ASH 1/3” Interline XGA Color 1/3” Interline XGA Monochrome Electronic Imager Specifications Progressive CCD: ICX204AK Progressive CCD: ICX204AL Total Picture Elements...
Page 5
STC – TC83USB-ASH STC – TB83USB-ASH B. Connector Specifications 1. USB Connector (Mini B USB Connector) Please connect the USB cable to this connector only while using the software trigger function or while using this camera without the trigger function. If the hardware trigger function is used with the camera including any signal output, please connect the cable to the 12 pin connector.
STC – TC83USB-ASH STC – TB83USB-ASH 2. 12 Pin Connector CAUTIONARY NOTE: a. When the USB signals in the 12 pin connector are in use 1) Please make sure that the cable which connects to the 12 pin connector is an authorized USB2.0 cable.
Page 7
STC – TC83USB-ASH STC – TB83USB-ASH C. Input / Output Signals Specifications. 1. Input Signals Specifications Input signal pins (IO 0 and IO 1) can be configured with “Trigger Input” or “Readout Request” through the software. a. Trigger Input Signal Requirements 1) Input Signal Level: High: 2.5 to 5V Low: 0 to 0.3 V...
STC – TC83USB-ASH STC – TB83USB-ASH 2. Output Signals Specifications Output signal pins (IO2 and IO3) can be configured with “Strobe Signal Output”, “Trigger Output”, “End of Exposure” or “End of Transfer” through the software. a. Strobe (Exposure Time) Output Signal Specifications 1) Output Signal Level: 3.3 Vp-p 2) Output Impedance:...
Page 9
STC – TC83USB-ASH STC – TB83USB-ASH d. Trigger Output Signal Specifications 1) Output signal level: 3.3 Vp-p 2) Output impedance: High-impedance 3) Pulse polarity: Positive or Negative (selectable by the software) 4) Pulse width: 1 clock to 4094 clocks (selectable by the software) 3.3 V 1 clock to 4094 clock e.
Page 10
STC – TC83USB-ASH STC – TB83USB-ASH II. Cautions A. Trigger Input Signal Cycle Time Set the trigger signal input cycle time to be more than the sum of the exposure time and the video output, otherwise the following phenomenon may occur: Double images Excess or abnormal noise No video image.
Page 11
STC – TC83USB-ASH STC – TB83USB-ASH III. Dimensions Unit: mm Product Specifications 11 of 11 Rev 1.1...
Page 12
STC – TC83USB-ASH STC – TB83USB-ASH Revisions Date Changes Note 2008/11/28 New document 2009/03/13 Update Add the caution of the 12pin connector Add the S/N ratio (Standard deviation) Change the right 2009/04/01 Edited English 2009/06/15 Inserted new dimension drawing...
Page 13
7F, Harada Center Building 9-17, Naka cho 4chrome Atsugi-city, Kanagawa 243-0018 Japan TEL +81-46-295-7061 FAX +81-46-295-7066 http://www.sentech.co.jp/ Taiwan Sensor Technology, Inc. 3F-6, No. 9, Aiguo W, Rd,. Jhong Jheng District Taipei City 100, Taiwan, R.O.C. TEL 886-2-2383-2331 FAX 886-2-2370-8775 EMAIL: sentech0501@yahoo.com.tw...
