SenTech STC-GE33OX User Manual

Power plus vga color/monochrome ccd gige vision cameras
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Sentech Power Plus
VGA Color / Monochrome CCD
GigE Vision Camera
STC-GE33OX
STC-GEC33OX
Users guide
Sentech Co., Ltd
STC-GE33OX/GEC33OX
Users guide Rev. 1.03
No.11S098-03
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the STC-GE33OX and is the answer not in the manual?

Questions and answers

Related Manuals for SenTech STC-GE33OX

Summary of Contents for SenTech STC-GE33OX

  • Page 1 No.11S098-03 Sentech Power Plus VGA Color / Monochrome CCD GigE Vision Camera STC-GE33OX STC-GEC33OX Users guide Sentech Co., Ltd STC-GE33OX/GEC33OX Users guide Rev. 1.03...
  • Page 2 Add the strobeSignal for the output signal Change the GenICam command / Camera command reference table 1.02 2012/04/12 Update Update the GenICam command / Camera command reference table 1.03 2017/04/17 Update Address, TEL, FAX number for relocation STC-GE33OX/GEC33OX Users guide Rev. 1.03...

  • Page 3: Table Of Contents

    Important design cautions ..........................29 3.4.3 Notice for use DDR2 memory ........................... 30 3.4.4 Recommend the image data handle between the Sentech FPGA and the user configurable FPGA ....31 3.4.5 Copy guard function ............................31 3.4.6 Schematics of the user configurable FPGA (XILINX) ..................31 The camera output timing charts ..........................
  • Page 4 Description of the camera control commands (Device code: 000000) ............. 50 6.4.3 Description of the camera control commands (Device code: 100000) ............. 59 6.4.4 Sequence for the command saves to the EEPROM ..................70 GenICam command / Camera command reference table ..................71 STC-GE33OX/GEC33OX Users guide Rev. 1.03...
  • Page 5 No.11S098-03 This document is the connectivity and operation users guide for STC-GE33OX/GEC33OX. STC-GE33OX/GEC33OX Users guide Rev. 1.03...

  • Page 6: The Connector Specifications

    Please check the NIC and HUB setting is “1Gb transferring” when use with 1Gb supported NIC and HUB. When snapping of the CAT5e cable, possibility to change the transferring speed from 1Gb to 100Mb. Please change the CAT5e cable. STC-GE33OX/GEC33OX Users guide Rev. 1.03...

  • Page 7: Power/Io Connector

    12pin connector IO GND IO GND Refer Fig. 3 Note.1: All I/Os (Pin number 3 through 10) are user assignable. Note.2: DO NOT connect or disconnect the power/IO connector while the power input though PoE. STC-GE33OX/GEC33OX Users guide Rev. 1.03...

  • Page 8: Input Signal

    This TrigerInternal signal is the input trigger signal with the trigger delay time. F) SensorReadOut This SensorReadOut signal is the FVAL signal, which is the image output period of the time. G) StrobeSignal The StrobeSignal signal is the strobe control signal. STC-GE33OX/GEC33OX Users guide Rev. 1.03...

  • Page 9: Dc Iris Lens Connector

    No.11S098-03 1.3. DC IRIS lens connector Connector: M1951 (EMUDEN) or equivalent. Pin assignment Pin No. Signal name DAMP- DAMP+ DRIVE+ DRIVE- STC-GE33OX/GEC33OX Users guide Rev. 1.03...

  • Page 10: O Circuits

    OPTO ISOLATOR SHARP：PC400J00000F Input circuits Response timing USER INPUT INPUT Response time IO_VCC 3.3[V] 5.0[V] 12[V] 24[V] 2.5[us] 2.8 [us] 3.0[us] 3.0[us] 100[ns] 100[ns] 100 [ns] 100[ns] 689[ns] 584[ns] 545[ns] 520[ns] 11[ns] 11[ns] 11[ns] 11[ns] STC-GE33OX/GEC33OX Users guide Rev. 1.03...
  • Page 11 No.11S098-03 Example circuit for the input signal CAMERA CAM_VCC IO_VCC INPUT USER_INPUT OPTO ISOLATOR SHARP：PC400J00000F IO_GND CAMERA CAM_VCC IO_VCC INPUT IO_VCC USER_INPUT OPTO ISOLATOR SHARP：PC400J00000F IO_GND STC-GE33OX/GEC33OX Users guide Rev. 1.03...

  • Page 12: Output Circuit

    OPTO ISOLATOR SHARP PC354NJ0000F IO_GND Output circuits Response timing OUTPUT USER_OUTPUT Response time IO_VCC 3.3[V] 5.0[V] 12[V] 24[V] 29.6[us] 30.4 [us] 35.2[us] 28.4[us] 67.5[us] 60.2[us] 42.3[us] 31.0[us] 2.2[us] 2.2[us] 2.8[us] 2.8[us] 3.1[us] 3.8[us] 6.9[us] 10.9[us] STC-GE33OX/GEC33OX Users guide Rev. 1.03...

  • Page 13: User Configurable Fpga (Xilinx)

    The customer would program the provided FPGA (XILINX) with its own proprietary code and the customer would also have complete control over the “Memory” utilization. Sentech checks the camera for proper operation by “Disabling” around the customer’s code and memory control. 3.1 User configurable FPGA (XILINX) information 3.1.1...

  • Page 14: Block Diagram And Explanation

    Configuration ROM (8Mbit) DDR2 Memory (32MB) User configuration FPGA (XILINX) JTAG JTAG (TCK, TMS, TDI, TDO) connector Image data Configuration 25MHz JTAG SPI BUS User configuration EEPROM UART FPGA (XILINX) area (512Kbit) Fig.1 Block diagram STC-GE33OX/GEC33OX Users guide Rev. 1.03...

  • Page 15: Explanations Of Data Flows

    A/D converter. 2) This data is sent to "Sentech FPGA" for further processing. 3) Once the data is sent into "Sentech FPGA", the image data can be routed to "User Configurable FPGA". Three different extraction points are provided in "Sentech FPGA"...
  • Page 16 3.2.2.1.2 The image data generated by the CCD is converted into 12-bit digital data as the section 3.2.2.1.1 explained. Then this data is extracted into the user FPGA, processed and inserted back to Sentech FPGA. Image data flow block diagram...
  • Page 17 Data after the gamma processing 3) Data extraction from user configurable FGPA After processing the 12-bit image data in the user FPGA, the data is inserted back to the Sentech FPGA Image as DOUT11-0 at any points listed below. These points A, B and C are, again, indicated in fig.2 ( data flow block diagram).
  • Page 18 As explained in the section 3.2.2.1.2, there are three points to extract out the image data from the Sentech FPGA and the image process at Sentech FPGA after the image data send back from the user configurable FPGA. There are two different methods to achieve this switching.
  • Page 19 No.11S098-03 B) By changing the register value through the UART Also please see section “6 The communication protocol specifications”. a) Set the image data between FPGAs (Device code: 20H, command: C0H). STC-GE33OX/GEC33OX Users guide Rev. 1.03...
  • Page 20 1) The FPGA program created by users is sent to "Configuration ROM" through the Ethernet connector as "Configuration data". 2) The data is sent through "GigE I/F" and "Sentech FPGA" to "Configuration ROM" and stored. (Note) Please see “ ” for more detailed User configurable FPGA (XILINX) uploading instructions information.
  • Page 21 1) This JTAG connection is provided for the debugging procedures of the "User Configurable FPGA" program. JTAG connector is connected to "User Configurable FPGA". (Note) The rear panel of the camera masks JTAG connector. Rear panel kit is available from Sentech for JTAG accessibility.
  • Page 22 User configurable FPGA (XILINX) Sample Codes. a) Select “OP Setting” under “Option” in the menu. b) Select which FPGA (Sentech FPGA or user configurable FPGA) send the output signal to 12pin power/IO connector at I/O Out0 to I/O Out4. In case of above window: Sentech FPGA send output signals to Output 1 and 2 of 12pin power/IO connector.
  • Page 23 1) Please setup UART port as following Baud rate: 115,200bps Data bit: 8bit Parity: None Stop bit: 1bit Flow control: None Sentech FPGA Ethernet connector USER_ USER_ TXD_PC RXD_PC User configurable FPGA (XILINX) Fig. 4 UART diagram STC-GE33OX/GEC33OX Users guide Rev. 1.03...

  • Page 24: Important Design Consideration Of Data Timing And Handling

    1) DIN (image data), LVALIN and FVALIN are activated at the rising edges of CLKIN as the data comes into the user FPGA. 2) As the data sent back to the Sentech FPGA, add the delay equivalent to the process time in the user FPGA on LVALIN and FVALIN.

  • Page 25: Connection Information Between The Devices

    39 USER_IN_AUX0 input USER_I/O 40 USER_IN_AUX1 input USER_I/O 41 USER_IN_AUX2 input USER_I/O 42 ExposureActive input EXP_OUT 43 FrameTriggerWait input TRG_RDY 44 USER_TRG output TRG_OUT (Table-4) Connection between the user configurable FPGA (XILINX) and the Sentech FPGA STC-GE33OX/GEC33OX Users guide Rev. 1.03...
  • Page 26 No.11S098-03 (Note) Signal directions indicated as inputs and outputs are referencing to the user FPGA. “Input” means a signal from the Sentech FPGA to the user FPGA and “output” means from the user FPGA to Sentech FPGA. Image data transferred between the Sentech FPGA and the user FPGA is 12-bit data. The MSB (Most Significant Bit) is bit-11 and the LSB (Least Significant Bit) is bit-0.

  • Page 27: Connection Between User Configurable Fpga (Xilinx) And Ddr2

    Please sets Float, Pull-up or Pull-down for unused input and I/O signal of the user configurable FPGA. Please sets Pull-up or Pull-down, or sets [H] or [L] with RTL code, for unused output signal of the user configurable FPGA. STC-GE33OX/GEC33OX Users guide Rev. 1.03...

  • Page 28: Connection Between The User Configurable Fpga (Xilinx) And The Eeprom

    Please sets Float, Pull-up or Pull-down for unused input signal of the user configurable FPGA. Please sets Pull-up or Pull-down, or sets [H] or [L] with RTL code, for unused output signal of the user configurable FPGA. STC-GE33OX/GEC33OX Users guide Rev. 1.03...

  • Page 29: Development Guideline

    (Fig-8) Conceptual drawing of the FPGA programming. Caution 1) Latch all signal timings of the image data, LVAL and FVAL coming from Sentech FPGA at the rising edges of the clock pulse (symbol CLKIN). 2) In the same manner, the signal timings of the image data, LVAL and FVAL after image processing must be latched at the rising edges of the clock pulse (symbol CLKIN).

  • Page 30: Notice For Use Ddr2 Memory

    (¥ipcore_dir¥mig_dcm_ddr2¥mig_dcm_ddr2¥user_design¥par¥mig_dcm_ddr2.ucf) is reflect to the power_plus_000.ucf file. The optional setting of the ISE was changed as below from the default setting, to use DDR2 memory. Category Property name Value Synthesis OptionsKeep Hierarchy Soft (Table-8) Optional setting of ISE STC-GE33OX/GEC33OX Users guide Rev. 1.03...

  • Page 31: Recommend The Image Data Handle Between The Sentech Fpga And The User Configurable Fpga

    No.11S098-03 3.4.4 Recommend the image data handle between the Sentech FPGA and the user configurable FPGA Recommend to make the image processing with synchronize CLKIN when make the image processing in the user configurable FPGA. Recommend to set timing restriction for secure the timing margin of CLKIN and the image data (DIN, DOUT, LVALIN, LVALOUT, FVALIN, FVALOUT) between the Sentech FPGA and the user configurable FPGA.

  • Page 32: The Camera Output Timing Charts

    132 CLK 648 CLK 132 CLK Horizontal blanking Video output 4.1.1 Color Bayer order (This information is only for STC-GEC33OX) LVAL Video out ・・・ ・・・ ・・・ Line 1 Video out ・・・ ・・・ ・・・ Line 2 STC-GE33OX/GEC33OX Users guide Rev. 1.03...

  • Page 33: The Vertical Timing

    No.11S098-03 4.2 The vertical timing 4.2.1 Full scanning 1 H = 21.1852 µseconds, 89.910172 Hz 525H One vertical (1V) FVAL 494H Video out 494H Vertical blanking Video output LVAL STC-GE33OX/GEC33OX Users guide Rev. 1.03...

  • Page 34: Aoi

    Blanking (Front) Blanking (Back) Number of the effective lines [Y] [BLK_F] [BLK_B) Total number of the line at 1 frame [TOTAL_LINE] Optical black Dummy bit Blanking (Front) Effective CCD effective lines lines Blanking (Back) Optical black STC-GE33OX/GEC33OX Users guide Rev. 1.03...

  • Page 35: The Transferring Image

    No.11S098-03 The transferring image STC-GE33OX (Monochrome) Pixel1 of Pixel2 of Data Data Pixeln of Data: The transferring pixel n: The order number STC-GEC33OX (Color) Pixel11 of Pixe12 of Data Data Pixel21 of Pixel22 of Data Data Pixelmn of Data: The transferring pixel...

  • Page 36: Camera Function Modes

    I n t e r n a l V D E x p o s u r e t i m e C C D e x p o s u r e V i d e o o u t STC-GE33OX/GEC33OX Users guide Rev. 1.03...

  • Page 37: Pulse Width Trigger Mode

    Note.1: The video output is going to be V reset by the next internal HD signal immediate after the exposure is finished. Note.2: The exposure time sets by the pulse width of the trigger signal. STC-GE33OX/GEC33OX Users guide Rev. 1.03...

  • Page 38: Exposure Timing With The Positive Polarity Trigger Signal

    Note.1: The trigger signal is removed by the filtering if the pulse width of the input trigger signal is less than 30 CLK. Please input the trigger signal has more then 31 CLK pulse width. Note.2: The exposure is going to start 75 CLK after the rising edge of the trigger signal. STC-GE33OX/GEC33OX Users guide Rev. 1.03...

  • Page 39: Edge Preset Trigger Mode

    Video out FVAL Note.1: The video output is going to be V reset by the next internal HD signal immediate after the exposure is finished. Note.2: The exposure time sets by the preset electronic shutter speed. STC-GE33OX/GEC33OX Users guide Rev. 1.03...

  • Page 40: Exposure Timing With The Positive Polarity Trigger Signal

    Note.1: The trigger signal is removed by the filtering if the pulse width of the input trigger signal is less than 30 Please input the trigger signal has more then 31 CLK pulse width. Note.2: The exposure is going to start 75 CLK after the rising edge of the trigger signal. STC-GE33OX/GEC33OX Users guide Rev. 1.03...

  • Page 41: Edge Preset Trigger Mode (The Trigger Input While The Image Is Out)

    Video out FVAL Note.1: The video output is going to be V reset by the next internal HD signal immediate after the exposure is finished. Note.2: The exposure time sets by the preset electronic shutter speed. STC-GE33OX/GEC33OX Users guide Rev. 1.03...

  • Page 42: Exposure Timing With The Positive Polarity Trigger Signal

    Note.1: The trigger signal is removed by the filtering if the pulse width of the input trigger signal is less than 30 Please input the trigger signal has more then 31 CLK pulse width. Note.2: The exposure is going to start 75 CLK after the rising edge of the trigger signal. STC-GE33OX/GEC33OX Users guide Rev. 1.03...

  • Page 43: H Reset Mode

    OFF. The maximum delay to start exposure from the trigger input is 1H. Trigger signal (Rising edge） Next HD Internal HD Normal SUB pulse timing SUB pulse Noise CCD exposure Video out STC-GE33OX/GEC33OX Users guide Rev. 1.03...

  • Page 44: The Communication Protocol Specifications

    Please use “StCamGigEWare” or “StGigECtrl” communication software or use following the communication protocol to communicate to the camera. The communication method UART (RS232C), Binary communication The communication settings Settings Baud rate 115,200bps Data bit 8bit Parity None Stop bit 1bit Flow control None STC-GE33OX/GEC33OX Users guide Rev. 1.03...

  • Page 45: The Communication Format

    Sets (or gets) the value is as “03H” always Receiving code Result of the sending command 01H: OK (ACK), 14H: Time out error (Two seconds), 16H: Data length error (Not mach), 17H: EPPROM write error STC-GE33OX/GEC33OX Users guide Rev. 1.03...
  • Page 46 Send the read command to read the 00H address data of the register 02, 00, 00, 01, 00, 03 SOF, (Device code/Read/Register), Command code, Data length, Data, EOF The return command 02, 01, 00, 03 STC-GE33OX/GEC33OX Users guide Rev. 1.03...

  • Page 47: The Camera Control Commands

    UserOutput signal for the power/IO connector (8bit: D[7..0]) F2 to F7H Reserved Read / Write The signals of the power/IO connector (8bit: D[7..0]) Read / Write The signals of the power/IO connector (8bit: D[7..0]) FA to FFH Reserved STC-GE33OX/GEC33OX Users guide Rev. 1.03...
  • Page 48 Read / Write Preset_3 white balance (Gb gain) (8bit: D[7..0]) Reserved Read / Write Threshold for auto white balance (16bit: D[7..0]) 3,072 0 to 4,095 Read / Write Threshold for auto white balance (16bit: D[16..8]) STC-GE33OX/GEC33OX Users guide Rev. 1.03...
  • Page 49 84 to 91H Reserved Read / Write Iris lens manual adjustment (8bit: D[7..0]) 93 to BFH Reserved Read / Write Image data between FPGAs (8bit: D[7..0]) Read / Write Output signal selection (8bit: D[7..0]) C2 toFFH Reserved STC-GE33OX/GEC33OX Users guide Rev. 1.03...

  • Page 50: Description Of The Camera Control Commands (Device Code: 000000)

    (Trigger signal input from 5pin of Power/IO connector) D4 to D3: Exposure start mode 00: Normal, 10 to 11: H reset, 01: No function (Prohibited setting. Do not set this value) D2 to D0: No function Sets always as "000" STC-GE33OX/GEC33OX Users guide Rev. 1.03...
  • Page 51 Please generate the trigger signal has more than 200 useconds pulse duration in the user configurable FPGA. Note.4: When select "Command software trigger", it's necessary to generate software trigger signal with "Generate command software trigger(SOFTRIG-D0)". STC-GE33OX/GEC33OX Users guide Rev. 1.03...
  • Page 52 CDS gain = 6.16 + 0.04 x (PGA[7..0] X 2 + GOFS[7..0]) dB * CDS_BASEGAIN[15..0]: The gain base offset (The value of the address 5EH and 5FH) * GOFS[7..0]: The gain offset (The value of the address 32H) STC-GE33OX/GEC33OX Users guide Rev. 1.03...
  • Page 53 Initial data: DELAY_F[23..0] ＝ 0, data range: 0 to 99 [7..0] Sets the delay time that is from the trigger signal input to start exposure as usecond. Delay time for the trigger signal = (DELAY_I[23..0]). (DELAY_F[7..0]) useconds STC-GE33OX/GEC33OX Users guide Rev. 1.03...
  • Page 54 1: Reverse The polarity of the output signal for 4 pin of the power/IO connector 0: Normal, 1: Reverse The polarity of the output signal for 3 pin of the power/IO connector 0: Normal, 1: Reverse STC-GE33OX/GEC33OX Users guide Rev. 1.03...
  • Page 55 D7 to D1: No function Sets always as "0000000" Write control to the EEPROM 0: Prohibited, 1: Accept Note. This bit is cleared to "0" automatically by the internal process after the execution of the command. STC-GE33OX/GEC33OX Users guide Rev. 1.03...
  • Page 56 5: SensorReadOut signal, 6: StrobeSignal signal, 7 to F: No function (Prohibited setting. Do not set this value) Note: When select "UserOutput signal", sets the status of the signal with "UserOutput signal for the power/IO connector(TEST2-D3,4)". STC-GE33OX/GEC33OX Users guide Rev. 1.03...
  • Page 57 4: TriggerInternal signal (after mask and delay process), 5: SensorReadOut signal, 6 to F: No function (Prohibited setting. Do not set this value) Note: When select "UserOutput signal", sets the status of the signal with "UserOutput signal for the power/IO connector(TEST2-D3,4)". STC-GE33OX/GEC33OX Users guide Rev. 1.03...
  • Page 58 4: TriggerInternal signal (after mask and delay process), 5: SensorReadOut signal, 6 to F: No function (Prohibited setting. Do not set this value) Note: When select "UserOutput signal", sets the status of the signal with "UserOutput signal for the power/IO connector(TEST2-D3,4)". STC-GE33OX/GEC33OX Users guide Rev. 1.03...

  • Page 59: Description Of The Camera Control Commands (Device Code: 100000)

    25H:[20..16] [The lower limit of the electronic shutter for auto shutter] 26H:[7..0] Initial data: 0, data range: 0 to 1,048,575 27H:[15..8] Sets the lower limit of the electronic shutter for auto shutte as usecond. 28H:[20..16] STC-GE33OX/GEC33OX Users guide Rev. 1.03...
  • Page 60 D7 to D4: Weight for ALC weight area 8 Range: 0 to 15 D3 to D0: Weight for ALC weight area 7 Range: 0 to 15 * Please set the ALC weight area with "30H to 3FH". STC-GE33OX/GEC33OX Users guide Rev. 1.03...
  • Page 61 Sets the vertical 3 position for ALC weight area. [Vertical_4 position for the ALC weight area] 36H:[7..0] 37H:[15..8] Initial data: 462, data range: 0 to 493 Sets the vertical 4 position for ALC weight area. STC-GE33OX/GEC33OX Users guide Rev. 1.03...
  • Page 62 Sets the horizontal 3 position for ALC weight area. [Horizontal_4 position for the ALC weight area] 3EH:[7..0] Initial data: 612, data range: 0 to 647 3FH:[15..8] Sets the horizontal 4 position for ALC weight area. STC-GE33OX/GEC33OX Users guide Rev. 1.03...
  • Page 63 Blue of the camera output image data = (CCD_B - CLAMP Level) x (1 + GainB1[7..0] / 64) + CLAMP Level * CCD_B: Blue of the CCD output image data * CLAMP Level: Clamp level (The calculated value of 38H) STC-GE33OX/GEC33OX Users guide Rev. 1.03...
  • Page 64 Gb of the camera output image data = (CCD_Gb - CLAMP Level) x (1 + GainGb1[7..0] / 64) + CLAMP Level * CCD_Gb: Gb of the CCD output image data * CLAMP Level: Clamp level (The calculated value of 38H) STC-GE33OX/GEC33OX Users guide Rev. 1.03...
  • Page 65 4EH:[7..0] Sets the bright level threshold for auto white balance process. 4FH:[15..8] Auto white balance process use the color information of the pixel, which is the brightness of the pixel is greater than this value. STC-GE33OX/GEC33OX Users guide Rev. 1.03...
  • Page 66 Initial data: 647, data range: 0 to 647 5FH:[15..8] Sets the horizontal 2 position, which is the horizontal end position for white balance area. This aread use for the gain calcuration for auto white balance and push to set white balance. STC-GE33OX/GEC33OX Users guide Rev. 1.03...
  • Page 67 Gb of the camera output image data = (CCD_Gb - CLAMP Level) x (1 + GainGbP[7..0] / 64) + CLAMP Level * CCD_Gb: Gb of the CCD output image data * CLAMP Level: Clamp level (The calculated value of 38H) STC-GE33OX/GEC33OX Users guide Rev. 1.03...
  • Page 68 10: Gamma and color interpolation, 11: Color interpolation D3 to D2: No function Sets alwayas as "00" Image data from Sentech FPGA to the user configurable FPGA D1 to D0: 00: CCD out image data, 01: White balance processed image data,...
  • Page 69 0: Output signal from Sentech FPGA, 1: Output signal from the user configurable FPGA Note: When select "Output signal from Sentech FPGA", select output signal from Sentech FPGA for the power/IO connector with "Output signal selection (F0H, F8H and F9H)". STC-GE33OX/GEC33OX...

  • Page 70: Sequence For The Command Saves To The Eeprom

    Note.3) When save the multiple command data, which is not sequence command, to the EEPROM, it is necessary to operate the number of times from 1) to 4). Example of the multiple command: “10H, 13H, 19H and 1BH” or “20H, 23H and 25H”. STC-GE33OX/GEC33OX Users guide Rev. 1.03...

  • Page 71: Genicam Command / Camera Command Reference Table

    000000 F1H.5 UserOutput signal for 5 pin of the power/IO connector UserOutputValue3 000000 F1H.6 UserOutput signal for 6 pin of the power/IO connector UserOutputValue4 000000 F1H.7 UserOutput signal for 7 pin of the power/IO connector STC-GE33OX/GEC33OX Users guide Rev. 1.03...
  • Page 72 Output signal’s polarity for 6 pin of the power/IO LineInverter3 000000 5DH.3 connector Output signal’s polarity for 7 pin of the power/IO LineInverter4 000000 5DH.4 connector StrobeSignalOnTime 000000 90-93H Strobe signal active time StrobeSignalDelay 000000 54-57H The delay time for the strobe signal STC-GE33OX/GEC33OX Users guide Rev. 1.03...
  • Page 73 The lower limit of the electronic shutter for auto shutter Max_ShutterTime 100000 23-25H The upper limit of the electronic shutter for auto shutter AGCRange 100000 AGC maximum limit TargetBrightness 100000 Target brightness for ALC ALC_Peak_Average 100000 ALC peak-average DigitalGain 000000 The digital gain STC-GE33OX/GEC33OX Users guide Rev. 1.03...
  • Page 74 Horizontal2 position for the white balance area WB_WindowMode 100000 60H.4 White balance area ON/OFF YThreshold 100000 4E-4FH Bright level threshold for auto white balance ALCWeight4 100000 2AH.4-7 Weight4 for ALC ALCWeight5 100000 2BH.0-3 Weight5 for ALC STC-GE33OX/GEC33OX Users guide Rev. 1.03...
  • Page 75 Please use GenICam command name command when change these values like below sample code. In the case to change the Width BOOL SetWidth( PvDevice *pDevice, PvInt64 lValue ) PvGenInteger* lGenInteger = dynamic_cast<PvGenInteger*>( pDevice->GetGenParameters()->Get( "Width" ) ); PvResult lResult = lGenInteger->SetValue(lValue); return lResult.IsOK(); STC-GE33OX/GEC33OX Users guide Rev. 1.03...
  • Page 76 No.11S098-03 9F Ebina Prime Tower. 9-50 Chuo 2 Chome Ebina-city, Kanagawa 243-0432, JAPAN Sentech Co., Ltd TEL +81-46-236-6660 FAX +81-46-236-6661 URL http://www.sentech.co.jp/ STC-GE33OX/GEC33OX Users guide Rev. 1.03...
