EC9100i and EC9600i Series Scanner User Guide
Signals in a typical document processing cycle
1. The LED is Green (Solid): The unit is idle.
2. The LED is Green (Flashing): The scanner is waiting for a document to be inserted for scanning.
3. The LED is Green/Red (Flashing): The scanning operation is in progress.
4. The LED is Green (Solid): The scanning operation is complete. The scanner has returned to its
idle state.

EC9600i series signals

Signals
Immediately after starting the
scanner:
Solid red
Long-red and two short-green
flashing cycle
Long-green and short-red
flashing cycle
Long-green and short-green
flashing cycle
Solid green
When scanning:
Green flashing
When scanning:
Solid green
When scanning:
Green and red flashing cycle
When scanning:
Red flashing
©2016 RDM Corporation
Meaning
The scanner is starting.
The scanner does not detect an Ethernet or USB connection.
The scanner is ready and idle.
Note: The idle signal depends on your scanning application.
The scanner is waiting for the user to insert a document into the
feeder.
The scanner is waiting for the user to take action on the PC
application.
The scanner is processing the documents. Wait for the scanner to
finish.
An error occurred while the scanner was processing the document.
Check your PC application for instructions or refer to your local
procedures. If you need more help, contact your distributor (reseller).
Operating the scanner
Page 25
