MiCOM P341
Interconnection Protection Relay
Software Version 0050B
Technical Guide

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MiCOM P341 and is the answer not in the manual?

Questions and answers

Related Manuals for Areva MiCOM P341

Summary of Contents for Areva MiCOM P341

  • Page 1 MiCOM P341 Interconnection Protection Relay Software Version 0050B Technical Guide...
  • Page 3 Technical Guide MiCOM P341 Interconnection Protection Relay Volume 1...
  • Page 5 Issue Control P341/EN T/C22 MiCOM P341 Manual Issue D Amendments completed 09.12.2004 Description Section Page Ref. Front Cover Software version details removed from back of front cover Contents Reference to P14x brochure, removed from Application Notes heading Handling of electronic equipment...
  • Page 6 P341/EN T/C22 Issue Control MiCOM P341 Manual Issue D Amendments completed 09.12.2004 Description Section Page Ref. CT and VT ratios Data in table amended Rate of change of frequency protection DDB information in sentences 1 and 2 : amended Voltage vector shift protection...
  • Page 7 Issue Control P341/EN T/C22 MiCOM P341 Manual Issue D Amendments completed 09.12.2004 Description Section Page Ref. Calculation of required relay settings Paragraph 3 : last sentence amended 2.13.1 Restricted earth fault protection Paragraph 5 : DDB information in 1 sentence amended 2.14...
  • Page 8 P341/EN T/C22 Issue Control MiCOM P341 Manual Issue D Amendments completed 09.12.2004 Description Section Page Ref. Loss of all three phase voltages under load conditions Minor amendments in paragraph 2 4.1.1 Absence of three phase voltages upon line energisation Sentence and bullet points added after figure 19 4.1.2...
  • Page 9 Issue Control P341/EN T/C22 MiCOM P341 Manual Issue D Amendments completed 09.12.2004 Description Section Page Ref. Control inputs New section added 4.13 CT connections New section added 4.14 Auto reset of trip LED indication New section added 4.15 107 - 108...
  • Page 10 P341/EN T/C22 Issue Control MiCOM P341 Manual Issue D Amendments completed 09.12.2004 Description Section Page Ref. All references to chapters replaced with new subdocument Throughout references ‘Universal’ logic inputs (P340 range) Section re-written Output relay contacts Section re-written 8 - 9...
  • Page 11 Technical Guide P341/EN T/D22 MiCOM P341 INTERCONNECTION PROTECTION RELAY MiCOM P341 CONTENT Issue Control Handling of Electronic Equipment Safety Instructions Introduction P341/EN IT/D22 Application Notes P341/EN AP/D22 Relay Description P341/EN HW/D22 Technical Data P341/EN TD/D22 SCADA Communications P341/EN CT/D22 Relay Menu Database...
  • Page 12 P341/EN T/D22 Technical Guide MiCOM P341...
  • Page 13 The electronic circuits of AREVA T&D products are immune to the relevant levels of electrostatic discharge when housed in their cases. Do not expose them to the risk of damage by withdrawing modules unnecessarily.

  • Page 15: Table Of Contents

    CONTENT SAFETY SECTION Health and Safety Explanation of symbols and labels INSTALLING, COMMISSIONING AND SERVICING EQUIPMENT OPERATING CONDITIONS Current transformer circuits External resistors Battery Replacement Insulation and dielectric strength testing Insertion of modules and pcb cards Fibre optic communication OLDER PRODUCTS DECOMMISSIONING AND DISPOSAL TECHNICAL SPECIFICATIONS...

  • Page 17: Safety Section

    SAFETY SECTION This Safety Section should be read before commencing any work on the equipment. Health and Safety The information in the Safety Section of the product documentation is intended to ensure that products are properly installed and handled in order to maintain them in a safe condition.

  • Page 18: Equipment Operating Conditions

    Voltage and current connections should be made using insulated crimp terminations to ensure that terminal block insulation requirements are maintained for safety. To ensure that wires are correctly terminated, the correct crimp terminal and tool for the wire size should be used. Before energising the equipment it must be earthed using the protective earth terminal, or the appropriate termination of the supply plug in the case of plug connected equipment.

  • Page 19: Older Products

    OLDER PRODUCTS Electrical adjustments Equipments which require direct physical adjustments to their operating mechanism to change current or voltage settings, should have the electrical power removed before making the change, to avoid any risk of electrical shock. Mechanical adjustments The electrical power to the relay contacts should be removed before checking any mechanical settings, to avoid any risk of electric shock.

  • Page 20: Technical Specifications

    TECHNICAL SPECIFICATIONS Protective fuse rating The recommended maximum rating of the external protective fuse for this equipment is 16A, Red Spot type of equipment, unless otherwise stated in the technical data section of the product documentation. Insulation class: IEC 601010-1 : 1990/A2 : 1995 This equipment requires a Class I protective (safety) earth...
  • Page 21 Introduction P341/EN IT/D22 MiCOM P341 INTRODUCTION...
  • Page 22 P341/EN IT/D22 Introduction MiCOM P341...
  • Page 23 Introduction P341/EN IT/D22 MiCOM P341 Page 1/24 CONTENT INTRODUCTION TO MiCOM INTRODUCTION TO MiCOM GUIDES USER INTERFACES AND MENU STRUCTURE Introduction to the relay 3.1.1 Front panel 3.1.2 Relay rear panel Introduction to the user interfaces and settings options Menu structure 3.3.1...
  • Page 24 P341/EN IT/D22 Introduction Page 2/24 MiCOM P341 Figure 1: Relay front view Figure 2: Relay rear view Figure 4: Front panel user interface Figure 5: Front port connection Figure 6: PC – relay signal connection Figure 7: Remote communication connection arrangements...

  • Page 25: Introduction To Micom

    Page 3/24 INTRODUCTION TO MICOM MiCOM is a comprehensive solution capable of meeting all electricity supply requirements. It comprises a range of components, systems and services from AREVA T&D. Central to the MiCOM concept is flexibility. MiCOM provides the ability to define an application solution and, through extensive communication capabilities, to integrate it with your power supply control system.

  • Page 26: Introduction To Micom Guides

    P341/EN IT/D22 Introduction Page 4/24 MiCOM P341 INTRODUCTION TO MiCOM GUIDES The guides provide a functional and technical description of the MiCOM protection relay and a comprehensive set of instructions for the relay’s use and application. Divided into two volumes, as follows: Volume 1 –...
  • Page 27 Introduction P341/EN IT/D22 MiCOM P341 Page 5/24 P341/EN GC Relay Menu Database: User interface/Courier/Modbus/IEC 60870-5- 103/DNP 3.0 Listing of all of the settings contained within the relay together with a brief description of each. P341/EN CO External Connection Diagrams All external wiring connections to the relay.

  • Page 28: User Interfaces And Menu Structure

    P341/EN IT/D22 Introduction Page 6/24 MiCOM P341 USER INTERFACES AND MENU STRUCTURE The settings and functions of the MiCOM protection relay can be accessed both from the front panel keypad and LCD, and via the front and rear communication ports.

  • Page 29: Relay Rear Panel

    Introduction P341/EN IT/D22 MiCOM P341 Page 7/24 The front panel of the relay includes the following, as indicated in Figure 1: a 16-character by 2-line alphanumeric liquid crystal display (LCD). (/, 6, 8 and 2), a 7-key keypad comprising 4 arrow keys...

  • Page 30: Introduction To The User Interfaces And Settings Options

    P341/EN IT/D22 Introduction Page 8/24 MiCOM P341 Optional IRIG-B board Digital input connections Power supply connection IRIG B Rear comms port (RS485) Current * and voltage Digital output input terminals (relays) connections P0104ena Figure 2: Relay rear view Refer to the wiring diagram in Appendix B for complete connection details.

  • Page 31: Menu Structure

    Introduction P341/EN IT/D22 MiCOM P341 Page 9/24 IEC870-5- Keypad/ Courier Modbus DNP3.0 Display & modification of all • • • settings • • • • • Digital I/O signal status Display/extraction of • • • • • measurements Display/extraction of fault •...

  • Page 32: Protection Settings

    P341/EN IT/D22 Introduction Page 10/24 MiCOM P341 Column header Up to 4 protection setting groups System data Overcurrent Overcurrent View records Ground fault Ground fault Column data settings Control & support Group 1 Group 2 Repeated for groups 2, 3 and 4...

  • Page 33: Control And Support Settings

    Introduction P341/EN IT/D22 MiCOM P341 Page 11/24 3.3.3 Control and support settings The control and support settings include: relay configuration settings open/close circuit breaker* CT & VT ratio settings* reset LEDs active protection setting group password & language settings circuit breaker control & monitoring settings*...

  • Page 34: Relay Configuration

    Page 12/24 MiCOM P341 passwords are lost an emergency password can be supplied – contact AREVA T&D with the relay’s serial number. The current level of access enabled for an interface can be determined by examining the 'Access level' cell in the 'System data' column, the access level for the front panel User Interface (UI), can also be found as one of the default display options.

  • Page 35: Default Display And Menu Time-Out

    Introduction P341/EN IT/D22 MiCOM P341 Page 13/24 System Other default displays 3-phase voltage frequency Alarm messages Date and time Column n Column 1 Column 2 Group 4 Sytem data View records Other column headings Overcurrent Data 1.1 Data 2.1 Data n.1...

  • Page 36: Menu Navigation And Setting Browsing

    P341/EN IT/D22 Introduction Page 14/24 MiCOM P341 Entry to the menu structure of the relay is made from the default display and is not affected if the display is showing the ‘Alarms/Faults present’ message. 3.6.2 Menu navigation and setting browsing The menu can be browsed using the four arrow keys, following the structure shown in Figure 4.

  • Page 37: Setting Changes

    Introduction P341/EN IT/D22 MiCOM P341 Page 15/24 cleared, the alarm LED will change from flashing to constant illumination and the latest fault record will be displayed (if there is one). To scroll through the pages of this use the key. When all pages of the fault record have been viewed, the...

  • Page 38: Front Communication Port User Interface

    PC locally to the relay (up to 15m distance) as shown in Figure 5. This port supports the Courier communication protocol only. Courier is the communication language developed by AREVA T&D to allow communication with its range of protection relays. The front port is particularly designed for use with the relay settings program MiCOM S1 which is a Windows 98/NT based software package.

  • Page 39: Rear Communication Port User Interface

    Introduction P341/EN IT/D22 MiCOM P341 Page 17/24 This could happen if a ‘cross-over’ serial connector is used, i.e. one that connects pin 2 to pin 3, and pin 3 to pin 2, or if the PC has the same pin configuration as the relay.

  • Page 40: Courier Communication

    To use the rear port to communicate with a PC-based master station using Courier, a KITZ K-Bus to EIA(RS)232 protocol converter is required. This unit is available from AREVA T&D. A typical connection arrangement is shown in Figure 7. For more detailed information on other possible connection arrangements refer to the manual for the Courier master station software and the manual for the KITZ protocol converter.
  • Page 41 Introduction P341/EN IT/D22 MiCOM P341 Page 19/24 Twisted pair ‘K-Bus’ RS485 communications link MiCOM relay MiCOM relay MiCOM relay RS232 K-Bus KITZ protocol converter PC serial port Modem Courier master station Public switched eg. substation control room telephone network Modem...

  • Page 42: Modbus Communication

    P341/EN IT/D22 Introduction Page 20/24 MiCOM P341 Protocol Courier The next cell down the column controls the address of the relay: Remote address Since up to 32 relays can be connected to one K-bus spur, as indicated in Figure 7, it is necessary for each relay to have a unique address so that messages from the master control station are accepted by one relay only.
  • Page 43 Introduction P341/EN IT/D22 MiCOM P341 Page 21/24 To use the rear port with Modbus communication, the relay’s communication settings must be configured. To do this use the keypad and LCD user interface. In the relay menu firstly check that the ‘Comms settings’ cell in the ‘Configuration’ column is set to ‘Visible’, then move to the ‘Communications’...

  • Page 44: Iec 60870-5 Cs 103 Communication

    P341/EN IT/D22 Introduction Page 22/24 MiCOM P341 The parity can be set to be one of ‘None’, ‘Odd’ or ‘Even’. It is important that whatever parity format is selected on the relay is the same as that set on the Modbus master station.

  • Page 45: Dnp 3.0 Communication

    Introduction P341/EN IT/D22 MiCOM P341 Page 23/24 The next cell down controls the period between IEC 60870-5-103 measurements: Measure’t period 30.00 s The IEC 60870-5-103 protocol allows the relay to supply measurements at regular intervals. The interval between measurements is controlled by this cell, and can be set between 1 and 60 seconds.
  • Page 46 P341/EN IT/D22 Introduction Page 24/24 MiCOM P341 The next cell controls the DNP 3.0 address of the relay: DNP 3.0 address Upto 32 relays can be connected to one DNP 3.0 spur, and therefore it is necessary for each relay to have a unique address so that messages from the master control station are accepted by only one relay.
  • Page 47 Application Notes P341/EN AP/D22 MiCOM P341 APPLICATION NOTES...
  • Page 48 P341/EN AP/D22 Application Notes MiCOM P341...
  • Page 49 Application Notes P341/EN AP/D22 MiCOM P341 Page 1/116 CONTENT INTRODUCTION Interconnection protection MiCOM interconnection protection relay 1.2.1 Protection features 1.2.2 Non-protection features APPLICATION OF INDIVIDUAL PROTECTION FUNCTIONS Configuration column CT and VT ratios Loss of mains protection Rate of change of frequency protection 2.4.1...
  • Page 50 P341/EN AP/D22 Application Notes Page 2/116 MiCOM P341 2.10.2 Sensitive earth fault protection element (SEF) 2.11 Directional earth fault protection (DEF) 2.11.1 Residual voltage polarisation 2.11.2 Negative sequence polarisation 2.11.3 General setting guidelines for DEF 2.11.4 Application to insulated systems 2.11.5...
  • Page 51 Application Notes P341/EN AP/D22 MiCOM P341 Page 3/116 2.22.2 Breaker fail undercurrent settings OTHER PROTECTION CONSIDERATIONS Blocked overcurrent protection APPLICATION OF NON-PROTECTION FUNCTIONS Voltage transformer supervision (VTS) 4.1.1 Loss of all three phase voltages under load conditions 4.1.2 Absence of three phase voltages upon line energisation 4.1.2.1...
  • Page 52 P341/EN AP/D22 Application Notes Page 4/116 MiCOM P341 Event & fault records 4.8.1 Types of event 4.8.1.1 Change of state of opto-isolated inputs 4.8.1.2 Change of state of one or more output relay contacts 4.8.1.3 Relay alarm conditions 4.8.1.4 Protection element starts and trips 4.8.1.5...
  • Page 53 Application Notes P341/EN AP/D22 MiCOM P341 Page 5/116 4.13.2 VT single point earthing 4.14 Auto reset of trip LED indication CT/VT REQUIREMENTS Non-directional definite time/IDMT overcurrent & earth fault protection 109 5.1.1 Time-delayed phase overcurrent elements 5.1.2 Time-delayed earth fault overcurrent elements Non-directional instantaneous overcurrent &...
  • Page 54 P341/EN AP/D22 Application Notes Page 6/116 MiCOM P341 Test mode Test pattern Contact test Test LEDs 6.10 Using a monitor/download port test box Figure 1: Typical system with embedded generation Figure 2a: Vector diagram representing steady state condition Figure 2b:...
  • Page 55 Application Notes P341/EN AP/D22 MiCOM P341 Page 7/116 Figure 22: Pole dead logic Figure 23: Remote control of circuit breaker Figure 24: TCS scheme 1 Figure 25: PSL for TCS schemes 1 and 3 Figure 26: TCS scheme 2 Figure 27:...
  • Page 56 P341/EN AP/D22 Application Notes Page 8/116 MiCOM P341...
  • Page 57 MiCOM interconnection protection relay MiCOM relays are a new range of products from AREVA T&D. Using the latest numerical technology the platform includes devices designed for the application to a wide range of power system plant such as motors, generators, feeders, overhead lines and cables.
  • Page 58 P341/EN AP/D22 Application Notes Page 10/116 MiCOM P341 power supply networks when the main connection with the Electricity Supply system is lost. The relays also include a comprehensive range of non-protection features to aid with power system diagnosis and fault analysis.
  • Page 59 Application Notes P341/EN AP/D22 MiCOM P341 Page 11/116 Continuous Self Monitoring – power-on diagnostics and self checking routines to · provide maximum relay reliability and availability. · Commissioning test facilities. APPLICATION OF INDIVIDUAL PROTECTION FUNCTIONS The following sections detail the individual protection functions in addition to where and how they may be applied.
  • Page 60 P341/EN AP/D22 Application Notes Page 12/116 MiCOM P341 Menu Text Default Setting Available Settings Function Selects if Group 2 Setting Group 2 Disabled Enabled or Disabled settings are available on the relay Selects if Group 3 Setting Group 3 Disabled...
  • Page 61 Application Notes P341/EN AP/D22 MiCOM P341 Page 13/116 Menu Text Default Setting Available Settings Function Makes settings visible Comms Settings Visible Invisible or Visible in the relay menu Makes settings visible Commission Tests Visible Invisible or Visible in the relay menu...
  • Page 62 P341/EN AP/D22 Application Notes Page 14/116 MiCOM P341 generator rating, in this case the generator can continue to operate normally supplying the external loads. The local system will now be operating unearthed and overcurrent protection may be inoperative at S1 and S2 due to the low fault supplying capacity of generator EG1.
  • Page 63 Application Notes P341/EN AP/D22 MiCOM P341 Page 15/116 Rate of change of frequency protection When a machine is running in parallel with the main power supply the frequency and hence speed of the machine will be governed by the grid supply.
  • Page 64 P341/EN AP/D22 Application Notes Page 16/116 MiCOM P341 A DDB (Digital Data Bus) signal is available to indicate that the element has operated (DDB 440 df/dt Trip). A second DDB signal is available to indicate that the element has started (DDB 630 df/dt Start). These signals are used to operate the output relays (as programmed into the Programmable Scheme Logic (PSL)) and trigger the disturbance recorder.
  • Page 65 Application Notes P341/EN AP/D22 MiCOM P341 Page 17/116 operation of circuit breakers must be prevented by disconnection of the embedded machine when the system becomes separated. Voltage vector shift protection An expression for a sinusoidal mains voltage waveform is generally given by the...
  • Page 66 P341/EN AP/D22 Application Notes Page 18/116 MiCOM P341 P2031ENa Figure 2b: Single phase line diagram showing generator parameters X” P2032ENa Figure 2c: Transient voltage vector change q due to change in load current D The voltage vector shift function is designed to respond within one to two full mains cycles when its threshold is exceeded.
  • Page 67 Application Notes P341/EN AP/D22 MiCOM P341 Page 19/116 The following table shows the relay menu for the Voltage Vector Shift protection element, including the available setting ranges and factory defaults: Setting Range Menu Text Default Setting Step Size Min. Max.
  • Page 68 P341/EN AP/D22 Application Notes Page 20/116 MiCOM P341 the element will provide a pulsed output signal. This signal can be used to initiate external synchronising equipment that can re-synchronise the machine with the system and reclose the CB. A DDB (Digital Data Bus) signal is available to indicate that the element has operated (DDB 742 Reconnection).
  • Page 69 Application Notes P341/EN AP/D22 MiCOM P341 Page 21/116 Setting ranges for the Power elements are shown in the following table: Setting Range Menu Text Default Setting Step Size Min. Max. GROUP 1 POWER Power1 Function Reverse Disabled, Reverse, Low Forward, Over...
  • Page 70 P341/EN AP/D22 Application Notes Page 22/116 MiCOM P341 The sensitive power protection measures only A-phase active power, as the abnormal power condition is a 3-phase phenomenon. Having a separate CT input also means that a correctly loaded metering class CT can be used which can provide the required angular accuracy for the sensitive power protection function.
  • Page 71 Application Notes P341/EN AP/D22 MiCOM P341 Page 23/116 Setting Range Menu Text Default Setting Step Size Group 1: Sensitive Power Sen Power2 Func Low Forward Disabled, Reverse, Low Forward, Over 0.5 x In W 0.3 x In W 15 x In W 0.1 x In W...
  • Page 72 P341/EN AP/D22 Application Notes Page 24/116 MiCOM P341 2.7.3 Low forward power protection function Low forward power may be used where the P341 relay is being used to protect a small generator. When the CB connecting the generator to the system is tripped, the electrical load on the machine is cut.
  • Page 73 Application Notes P341/EN AP/D22 MiCOM P341 Page 25/116 motoring power and possible motoring damage that could occur for various types of generating plant are given in Table 1. Motoring Power Prime Mover Possible Damage (Percentage Rating) Risk of fire or explosion from unburned Diesel Engine 5% –...
  • Page 74 P341/EN AP/D22 Application Notes Page 26/116 MiCOM P341 The reverse power protection function should be time-delayed to prevent false trips or alarms being given during power system disturbances or following synchronisation. A time delay setting, “Power1 Time Delay/Sen Power1 Delay” or “Power2 Time Delay/Sen Power2 Delay”...
  • Page 75 Application Notes P341/EN AP/D22 MiCOM P341 Page 27/116 Setting Range Menu Text Default Setting Step Size Min. Max. GROUP 1 OVERCURRENT Disabled, DT, IEC S Inverse, IEC V Inverse, IEC E Inverse, UK LT Inverse, IEEE M IEC S Inverse >1 Function...
  • Page 76 P341/EN AP/D22 Application Notes Page 28/116 MiCOM P341 The IEEE/US IDMT curves conform to the following formula: æ ö æ ö ç ÷ ç ÷ (I/I s ) a - 1 ç ÷ è ø è ø where t = operation time...
  • Page 77 Application Notes P341/EN AP/D22 MiCOM P341 Page 29/116 2.8.1 Transformer magnetising inrush When applying overcurrent protection to the HV side of a power transformer, it is usual to apply a high set instantaneous overcurrent element, in addition to the time delayed low-set, to reduce fault clearance times for HV fault conditions.
  • Page 78 P341/EN AP/D22 Application Notes Page 30/116 MiCOM P341 The timer hold facility can be found for the first and second overcurrent stages as settings ‘ >1 tRESET’ and ‘ >2 tRESET’, respectively. Note that this cell is not visible if an inverse time reset characteristic has been selected, as the reset time is then determined by the programmed time dial setting.
  • Page 79 Application Notes P341/EN AP/D22 MiCOM P341 Page 31/116 In order to give directionality to an overcurrent relay, it is necessary to provide it with a suitable reference, or polarising, signal. The reference generally used is the system voltage, as it’s angle remains relatively constant under fault conditions. The phase...
  • Page 80 P341/EN AP/D22 Application Notes Page 32/116 MiCOM P341 33kV OC/EF OC/EF SBEF DOC/DEF DOC/DEF OC/EF OC/EF 11kV OC/EF Loads P0110ENa Figure 3: Typical distribution system using parallel transformers Note that the principles previously outlined for the parallel transformer application are equally applicable for plain feeders which are operating in parallel.
  • Page 81 Application Notes P341/EN AP/D22 MiCOM P341 Page 33/116 2.9.2 Setting guidelines The applied current settings for directional overcurrent relays are dependent upon the application in question. In a parallel feeder arrangement, load current is always flowing in the non-operate direction. Hence, the relay current setting may be less than the full load rating of the circuit;...
  • Page 82 P341/EN AP/D22 Application Notes Page 34/116 MiCOM P341 2.10 Earth fault protection The P341 relay has a total of four input current transformers; one for each of the phase current inputs and one for supplying the sensitive earth fault protection element.
  • Page 83 Application Notes P341/EN AP/D22 MiCOM P341 Page 35/116 Setting Range Menu Text Default Setting Step Size Min. Max. GROUP 1 EARTH FAULT 1 IN>3 Status Disabled Disabled, Enabled Non- IN>3 Direction Non-Directional, Directional Fwd, Directional Rev Directional IN>3 Current set 20 x In A 0.08 x In A...
  • Page 84 P341/EN AP/D22 Application Notes Page 36/116 MiCOM P341 2.10.2 Sensitive earth fault protection element (SEF) If a system is earthed through high impedance, or is subject to high ground fault resistance, the earth fault level will be severely limited. Consequently, the applied earth fault protection requires both an appropriate characteristic and a sensitive setting range in order to be effective.
  • Page 85 Application Notes P341/EN AP/D22 MiCOM P341 Page 37/116 Setting Range Menu Text Default Setting Step Size Min. Max. GROUP 1 SEF/REF PROT’N ISEF DIRECTIONAL Sub Heading ISEF> Char Angle 90º –95° +95° 1° ISEF> VNpol Input Measured Measured, Derived 0.5V 0.5V...
  • Page 86 P341/EN AP/D22 Application Notes Page 38/116 MiCOM P341 Cable gland Cable box Cable gland/sheath earth connection “Incorrect” No operation “Correct” Operation P0112ENa Figure 4: Positioning of core balance current transformers As can be seen from the diagram, if the cable sheath is terminated at the cable gland and earthed directly at that point, a cable fault (from phase to sheath) will not result in any unbalance current in the core balance CT.
  • Page 87 Application Notes P341/EN AP/D22 MiCOM P341 Page 39/116 measuring the polarising signal is set in the “ N> Vnpol Input” cell. Where the residual voltage is derived from the 3 phase voltages a 5-limb or three single phase VT’s must be used. These types of VT design allow the passage of residual flux and consequently permit the relay to derive the required residual voltage.
  • Page 88 P341/EN AP/D22 Application Notes Page 40/116 MiCOM P341 For negative sequence polarisation, the RCA settings must be based on the angle of the nps source impedance, much the same as for residual polarising. Typical settings would be: Distribution systems Þ –45º...
  • Page 89 Application Notes P341/EN AP/D22 MiCOM P341 Page 41/116 - jXc1 - jXc2 IH1 + IH2 + IH3 - jXc3 IR3 = IH1 + IH2 + IH3 - IH3 IH1 + IH2 IR3 = IH1 + IH2 P2035ENa Figure 5: Current distribution in an insulated system with C phase fault...
  • Page 90 P341/EN AP/D22 Application Notes Page 42/116 MiCOM P341 From Figure 5, it can be seen that the relays on the healthy feeders see the unbalance in the charging currents for their own feeder. The relay on the faulted feeder, however, sees the charging current from the rest of the system ( H1 and in this case), with it’s own feeders charging current (...
  • Page 91 Application Notes P341/EN AP/D22 MiCOM P341 Page 43/116 correct relay connections to give a defined direction for operation are shown on the relay connection diagram. Note that discrimination can be provided without the need for directional control. This can only be achieved if it is possible to set the relay in excess of the charging current of the protected feeder and below the charging current for the rest of the system.
  • Page 92 P341/EN AP/D22 Application Notes Page 44/116 MiCOM P341 calculations show that if the reactance of the earthing coil is set correctly, the resulting steady state earth fault current will be zero. f = - c + Van = 0 if Van = Ib + Ic...
  • Page 93 Application Notes P341/EN AP/D22 MiCOM P341 Page 45/116 H1 + H2 - P2038ENa Figure 8: Distribution of currents during a C phase to earth fault Figures 9 (a, b and c) show vector diagrams for the previous system, assuming that it is fully compensated (i.e.
  • Page 94 P341/EN AP/D22 Application Notes Page 46/116 MiCOM P341 a) Capacitive & inductive currents – R1 = R3 = b) Unfaulted line c) Faulted line – I L – Vres = -3Vo Vres=-3Vo P2039ENa Figure 9: Theoretical case – no resistance present in XL or Xc...
  • Page 95 Application Notes P341/EN AP/D22 MiCOM P341 Page 47/116 Faulted feeder Healthy feeders –Vo Key: R0F = Residual current on faulted feeder R0H = Residual current on healthy feeder It can therefore be seen that:- L – H1 – H2 –...
  • Page 96 P341/EN AP/D22 Application Notes Page 48/116 MiCOM P341 Resistive component Resistive component in feeder in grounding coil H1 + H2 + H3)’ L’ a) Capacitive & inductive currents with resistive components Restrain Operate Zero torque line R1 = for 0° RCA...
  • Page 97 Application Notes P341/EN AP/D22 MiCOM P341 Page 49/116 A suitably sensitive directional earth fault relay having a relay characteristic angle setting (RCA) of zero degrees, with the possibility of fine adjustment about this threshold. A sensitive directional zero sequence wattmetric relay having similar requirements to 1.
  • Page 98 P341/EN AP/D22 Application Notes Page 50/116 MiCOM P341 As can be seen from the following formula, the power setting within the relay menu is called PN> and is therefore calculated using residual rather than zero sequence quantities. Residual quantities are three times their respective zero sequence values...
  • Page 99 Application Notes P341/EN AP/D22 MiCOM P341 Page 51/116 state per phase value. Therefore, for a fully compensated system, the total unbalance current detected by the relay is equal to three times the per phase charging current of the faulted circuit. A typical relay setting may therefore be in the order of 30% of this value, i.e.
  • Page 100 P341/EN AP/D22 Application Notes Page 52/116 MiCOM P341 external fault conditions is less than that required to drive setting current through the relay. The REF protection in the P341 should be applied as a high impedance differential element. Note that the high impedance REF element of the relay shares the same CT input as the SEF protection.
  • Page 101 Application Notes P341/EN AP/D22 MiCOM P341 Page 53/116 Saturated CT Healthy CT Protected circuit A – G Voltage across relay circuit ) where K = 1 Stabilising resistor R limits spill current to (relay setting) – R = Maximum secondary through fault current...
  • Page 102 P341/EN AP/D22 Application Notes Page 54/116 MiCOM P341 STAB SEF Input P2044ENa Figure 14: High impedance REF relay/CT connections 2.14.2 Setting guidelines for high impedance REF From the ‘Sens E/F Options’ cell, ‘Hi Z REF’ must be selected to enable this protection.
  • Page 103 Application Notes P341/EN AP/D22 MiCOM P341 Page 55/116 In order to achieve the required primary operating current with the current transformers that are used, a current setting ( REF> s) must be selected for the high impedance element, as detailed in expression (2.) above.
  • Page 104 P341/EN AP/D22 Application Notes Page 56/116 MiCOM P341 0.25 where V = Instantaneous voltage applied to the non-linear resistor (“metrosil”) = constant of the non-linear resistor (“metrosil” ) = instantaneous current through the non-linear resistor (“metrosil”) . With a sinusoidal voltage applied across the metrosil, the RMS current would be approximately 0.52x the peak current.
  • Page 105 AREVA T&D for detailed applications. Note: The Metrosil units recommended for use with 5 Amp CTs can also be applied for use with triple pole relays and consist of three single pole units mounted on the same central stud but electrically insulated for each other. To order these units please specify "Triple Pole Metrosil Type", followed by the single pole type...
  • Page 106 P341/EN AP/D22 Application Notes Page 58/116 MiCOM P341 distribution transformer earthed, the neutral displacement voltage can be measured directly in the earth path via a single phase VT. This type of protection can be used to provide earth fault protection irrespective of whether the system is connected to earth or not, and irrespective of the form of earth connection and earth fault current level.
  • Page 107 Application Notes P341/EN AP/D22 MiCOM P341 Page 59/116 alarm is generated soon after the condition is detected, which serves to indicate the presence of an earth fault on the system. This gives time for system operators to locate and isolate the fault. The second stage of the protection can issue a trip signal if the fault condition persists.
  • Page 108 P341/EN AP/D22 Application Notes Page 60/116 MiCOM P341 Each stage of protection can be blocked by energising the relevant DDB signal, via the PSL (DDB 368, DDB 369), this can be used to improve grading with downstream devices. DDB signals are also available to indicate the start and trip of each stage of protection, (Starts: DDB 577, DDB 578, Trips: DDB 451, DDB 452).
  • Page 109 Application Notes P341/EN AP/D22 MiCOM P341 Page 61/116 The voltage setting applied to the elements is dependent upon the magnitude of residual voltage that is expected to occur during the earth fault condition. This in turn is dependent upon the method of system earthing employed and may be calculated by using the formulae previously given in Figs.
  • Page 110 P341/EN AP/D22 Application Notes Page 62/116 MiCOM P341 Setting ranges for this element are shown in the following table: Setting Range Menu Text Default Setting Step Size Min. Max. GROUP 1 VOLT PROTECTION UNDERVOLTAGE Sub Heading V< Measur’t Mode Phase-Neutral Phase-Phase, Phase-Neutral V<...
  • Page 111 Application Notes P341/EN AP/D22 MiCOM P341 Page 63/116 Where the relay is used to provide the protection required for connecting the generator in parallel with the local electricity supply system (e.g. requirements of G59 in the UK), the local electricity supply authority will advise settings for the element.
  • Page 112 P341/EN AP/D22 Application Notes Page 64/116 MiCOM P341 Note: If the overvoltage protection is set for phase-phase operation then the DDB signals V>1/2 Start/Trip A/AB, V>1/2 Start/Trip B/BC, V>1/2 Start/Trip C/CA refer to V>1/2 Start/Trip AB and V>1/2 Start/Trip BC and V>1/2 Start/Trip CA. If set for phase- neutral then the DDB signals V>1/2 Start/Trip A/AB, V>1/2...
  • Page 113 Application Notes P341/EN AP/D22 MiCOM P341 Page 65/116 The over voltage protection can be set to operate from Phase-Phase or Phase-Neutral voltage as selected by “V> Measur’t Mode” cell. Single or three phase operation can be selected in “V> Operate Mode” cell. When ‘Any Phase’ is selected the element will operate if any phase voltage falls below setting, when ‘Three Phase’...
  • Page 114 P341/EN AP/D22 Application Notes Page 66/116 MiCOM P341 Energising the relevant DDB signal, via the PSL (DDB 374-377), can block each stage of underfrequency protection. DDB signals are also available to indicate start and trip of each stage, (Starts: DDB 622-625, Trips: DDB 469-472). The state of the DDB signals can be programmed to be viewed in the “Monitor Bit x”...
  • Page 115 Application Notes P341/EN AP/D22 MiCOM P341 Page 67/116 Frequency F1< F2< Turbine prohibited area Time System frequency response with minimum load shed for recovery System frequency response with under shedding of load Optimum underfrequency protection characteristic P2047ENa Figure 16: Co-ordination of underfrequency protection function with...
  • Page 116 P341/EN AP/D22 Application Notes Page 68/116 MiCOM P341 2.19 Over frequency protection function Over frequency running of a generator arises when the mechanical power input to the alternator is in excess of the electrical load and mechanical losses. The most common occurrence of over frequency is after substantial loss of load.
  • Page 117 Application Notes P341/EN AP/D22 MiCOM P341 Page 69/116 example in the UK over frequency protection should be set to 50.5Hz with a trip time of less than 0.5s. 2.20 Thermal overload protection 2.20.1 Introduction Thermal overload protection can be used to prevent electrical plant from operating at temperatures in excess of the designed maximum withstand.
  • Page 118 P341/EN AP/D22 Application Notes Page 70/116 MiCOM P341 For a machine not to exceed T , the rated temperature, then the time ‘t’ for which the machine can withstand the current ‘I’ can be shown to be given by: = KI (1-e t.
  • Page 119 Application Notes P341/EN AP/D22 MiCOM P341 Page 71/116 The equivalent current for operation of the overload protection is in accordance with the following expression: Ö(I + MI Where positive sequence current negative sequence current a user settable constant proportional to the thermal capacity of the machine As previously described, the temperature of a generator will rise exponentially with increasing current.
  • Page 120 P341/EN AP/D22 Application Notes Page 72/116 MiCOM P341 t. Log -1)) Where /Thermal I> /Thermal I> The Thermal state of the machine can be viewed in the “Thermal Overload” cell in the “MEASUREMENTS 3” column. The thermal state can be reset by selecting ‘Yes’ in the “Reset ThermalO/L”...
  • Page 121 Application Notes P341/EN AP/D22 MiCOM P341 Page 73/116 The “M Factor” is used to increase the influence of negative sequence current on the thermal replica protection due to unbalanced currents. If it is required to account for the heating effect of unbalanced currents then this factor should be set equal to the ratio of negative phase sequence rotor resistance to positive sequence rotor resistance at rated speed.
  • Page 122 P341/EN AP/D22 Application Notes Page 74/116 MiCOM P341 2.21.2 Reset mechanisms for breaker fail timers It is common practice to use low set undercurrent elements in protection relays to indicate that circuit breaker poles have interrupted the fault or load current, as required.
  • Page 123 Application Notes P341/EN AP/D22 MiCOM P341 Page 75/116 Three options are available. The user can select any or all of the options. [All < and N< elements operate] External protection [External trip reset] AND [All < and N< elements operate] CB open (all 3 poles) AND [All <...
  • Page 124 P341/EN AP/D22 Application Notes Page 76/116 MiCOM P341 Typical Delay for CB Fail Reset Mechanism tBF Time Delay 2º Cycle Circuit Breaker CB interrupting time + 50 + 12 + 50 = 112 ms Undercurrent elements undercurrent element (max.) + operating time Note that all CB Fail resetting involves the operation of the undercurrent elements.
  • Page 125 Application Notes P341/EN AP/D22 MiCOM P341 Page 77/116 SETTING [4503] : DDB #162 : Any Trip (RL3) CB Fail 1 Timer SETTING [4502] : tbf1 DDB #380 : Ext. Trip 3ph CB Fail 1 Status DDB #493 : Bfail1 Trip 3ph DDB #631 : IA<...
  • Page 126 P341/EN AP/D22 Application Notes Page 78/116 MiCOM P341 Generator Block highset element CB fail backtrip from fail start backtrip contact Feeder 1 Feeder 2 Feeder 3 Feeder 4 P2184enb Figure 18a: Simple busbar blocking scheme (single incomer) 10.0 Time P3xx IDMT element...
  • Page 127 Alternatively, the relays scheme logic could be arranged to block any of the overcurrent/earth fault stages that would operate non-discriminatively due to the blocking signal failure. For further guidance on the use of blocked overcurrent schemes refer to AREVA T&D. APPLICATION OF NON-PROTECTION FUNCTIONS Voltage transformer supervision (VTS) The voltage transformer supervision (VTS) feature is used to detect failure of the ac voltage inputs to the relay.
  • Page 128 P341/EN AP/D22 Application Notes Page 80/116 MiCOM P341 4.1.2 Absence of three phase voltages upon line energisation If a VT were inadvertently left isolated prior to line energisation, incorrect operation of voltage dependent elements could result. The previous VTS element detected three phase VT failure by absence of all 3 phase voltages with no corresponding change in current.
  • Page 129 Application Notes P341/EN AP/D22 MiCOM P341 Page 81/116 I2>, this level detector operates on negative sequence current and has a user · setting. This level detector picks-up at 100% of setting and drops-off at 95% of setting. · DIIA>, DIB>, DIC>, these level detectors operate on superimposed phase currents and have a fixed setting of 10% of nominal.
  • Page 130 P341/EN AP/D22 Application Notes Page 82/116 MiCOM P341 4.1.2.2 Outputs Signal Name Description VTS Fast Block Used to block voltage dependent functions VTS Slow block Used to block the Any Pole dead signal VTS Indication Signal used to indicate a VTS operation 4.1.3...
  • Page 131 Application Notes P341/EN AP/D22 MiCOM P341 Page 83/116 Where a miniature circuit breaker (MCB) is used to protect the voltage transformer ac output circuits, it is common to use MCB auxiliary contacts to indicate a three phase output disconnection. As previously described, it is possible for the VTS logic to operate correctly without this input.
  • Page 132 P341/EN AP/D22 Application Notes Page 84/116 MiCOM P341 Setting Range Menu Text Default Setting Step Size Min. Max. GROUP 1 SUPERVISION CT Supervision Sub Heading CTS Status Disabled Enabled, Disabled 0.5/2V 22/88V 0.5/2V CTS VN< Inhibit 110/440V 110/440V 110/440V respectively...
  • Page 133 Application Notes P341/EN AP/D22 MiCOM P341 Page 85/116 In the CB CONTROL column of the relay menu there is a setting called ‘CB Status Input’. This cell can be set at one of the following four options: None Both 52A and 52B Where ‘None’...
  • Page 134 P341/EN AP/D22 Application Notes Page 86/116 MiCOM P341 SETTING [0711] : CB Status Input G118-0 : None G118-1 : 52A G118-2 : 52B G118-3 : Both 52A & 52B DDB #381 : CB Aux 3ph(52-A) DDB #755 : CB Closed 3ph...
  • Page 135 Application Notes P341/EN AP/D22 MiCOM P341 Page 87/116 If one or more poles are dead the relay will indicate which phase is dead and will also assert the ANY POLE DEAD DDB signal (DDB 758). If all phases were dead the ANY POLE DEAD signal would be accompanied by the ALL POLE DEAD DDB signal (DDB 757).
  • Page 136 P341/EN AP/D22 Application Notes Page 88/116 MiCOM P341 4.5.1 Circuit breaker condition monitoring features For each circuit breaker trip operation the relay records statistics as shown in the following table taken from the relay menu. The menu cells shown are counter values only.
  • Page 137 Application Notes P341/EN AP/D22 MiCOM P341 Page 89/116 Setting Range Menu Text Default Setting Step Size Min. Max. CB MONITOR SETUP Fault Freq Time 3600s 9999s The circuit breaker condition monitoring counters will be updated every time the relay issues a trip command.
  • Page 138 P341/EN AP/D22 Application Notes Page 90/116 MiCOM P341 Certain circuit breakers, such as oil circuit breakers (OCB’s) can only perform a certain number of fault interruptions before requiring maintenance attention. This is because each fault interruption causes carbonising of the oil, degrading its dielectric properties.
  • Page 139 Application Notes P341/EN AP/D22 MiCOM P341 Page 91/116 + ve Protection trip Trip Remote control trip Close Remote control close Local Remote Trip Close – ve P0123ENa Figure 23: Remote control of circuit breaker The following table is taken from the relay menu and shows the available settings and commands associated with circuit breaker control.
  • Page 140 P341/EN AP/D22 Application Notes Page 92/116 MiCOM P341 Once a CB Close command is initiated the output contact can be set to operate following a user defined time delay (‘Man Close Delay’). This would give personnel time to move away from the circuit breaker following the close command. This time delay will apply to all manual CB Close commands.
  • Page 141 Application Notes P341/EN AP/D22 MiCOM P341 Page 93/116 4.7.1 TCS scheme 1 4.7.1.1 Scheme description Optional P2228ENa Figure 24: TCS scheme 1 This scheme provides supervision of the trip coil with the breaker open or closed, however, pre-closing supervision is not provided. This scheme is also incompatible with latched trip contacts, as a latched contact will short out the opto for greater than the recommended DDO timer setting of 400ms.
  • Page 142 P341/EN AP/D22 Application Notes Page 94/116 MiCOM P341 110/250 2.5k 48/54 220/250 5.0k 110/125 Note: When R1 is not fitted the opto voltage setting must be set equal to supply voltage of the supervision circuit.
  • Page 143 Application Notes P341/EN AP/D22 MiCOM P341 Page 95/116 4.7.2 Scheme 1 PSL Figure 25 shows the scheme logic diagram for the TCS scheme 1. Any of the available opto inputs can be used to indicate whether or not the trip circuit is healthy.
  • Page 144 P341/EN AP/D22 Application Notes Page 96/116 MiCOM P341 When the breaker is closed, supervision current passes through opto input A and the trip coil. When the breaker is open current flows through opto input B and the trip coil. As with scheme 1, no supervision of the trip path is provided whilst the breaker is open.
  • Page 145 Application Notes P341/EN AP/D22 MiCOM P341 Page 97/116 Scheme 3 is designed to provide supervision of the trip coil with the breaker open or closed, but unlike schemes 1 and 2, it also provides pre-closing supervision. Since only one opto input is used, this scheme is not compatible with latched trip contacts.
  • Page 146 These cells are numbers representative of the occurrence. Report Type They form a specific error code which should be quoted in any related correspondence to AREVA T&D. Either Yes or No. This serves to reset the trip LED indications Reset Indication provided that the relevant protection element has reset.
  • Page 147 Application Notes P341/EN AP/D22 MiCOM P341 Page 99/116 Time & date of event “LOGIC INPUTS” “Event Value 0101010101010101” The Event Value is an 8 or 16 bit word showing the status of the opto inputs, where the least significant bit (extreme right) corresponds to opto input 1 etc. The same information is present if the event is extracted and viewed via PC.
  • Page 148 P341/EN AP/D22 Application Notes Page 100/116 MiCOM P341 The previous table shows the abbreviated description that is given to the various alarm conditions and also a corresponding value which displays alarms as bit positions in a 32 bit field. The bit will be set to 1 if the alarm is ON and 0 if it is OFF.
  • Page 149 Application Notes P341/EN AP/D22 MiCOM P341 Page 101/116 Each time a Maintenance Report is generated, an event is also created. The event simply states that a report was generated, with a corresponding time stamp. 4.8.1.8 Setting changes Changes to any setting within the relay are logged as an event. Two examples are...
  • Page 150 P341/EN AP/D22 Application Notes Page 102/116 MiCOM P341 - Monday 03 November 1998 15:34:54 GMT Output Contacts 0010000 ALSTOM : MiCOM Model Number: P141 Address: 001 Column: 00 Row: 21 Event Type: Relay output changed state As can be seen, the first line gives the description and time stamp for the event, whilst the additional information that is displayed below may be collapsed via the +/–...
  • Page 151 Application Notes P341/EN AP/D22 MiCOM P341 Page 103/116 For further information regarding events and their specific meaning, refer to Appendix A. Disturbance recorder The integral disturbance recorder has an area of memory specifically set aside for record storage. The number of records that may be stored by COURIER MODBUS and DNP3.0 relays is dependent upon the selected recording duration but the relays...
  • Page 152 P341/EN AP/D22 Application Notes Page 104/116 MiCOM P341 The pre and post fault recording times are set by a combination of the "Duration" and "Trigger Position" cells. "Duration" sets the overall recording time and the "Trigger Position" sets the trigger point as a percentage of the duration. For example, the default settings show that the overall recording time is set to 1.5s with the trigger...
  • Page 153 Application Notes P341/EN AP/D22 MiCOM P341 Page 105/116 Measurement Mode Parameter Signing Export Power Import Power – 0 (Default) Lagging Vars Leading VArs – – Export Power Import Power Lagging Vars – Leading VArs Export Power Import Power – Lagging Vars –...
  • Page 154 P341/EN AP/D22 Application Notes Page 106/116 MiCOM P341 4.10.5.3 Peak demand values Peak demand values are produced for each phase current and the real and reactive power quantities. These display the maximum value of the measured quantity since the last reset of the demand values.
  • Page 155 Application Notes P341/EN AP/D22 MiCOM P341 Page 107/116 4.10.6.7 Rolling sub-period and number of sub-periods These two settings are used to set the length of the window used for the calculation of rolling demand quantities and the resolution of the slide for this window.
  • Page 156 P341/EN AP/D22 Application Notes Page 108/116 MiCOM P341 4.13 VT connections 4.13.1 Open delta (vee connected) VT's The P341 relay can be used with vee connected VTs by connecting the VT secondaries to C19, C20 and C21 input terminals, with the C22 input left unconnected (see Figures 2 and 17 in Appendix B).
  • Page 157 Application Notes P341/EN AP/D22 MiCOM P341 Page 109/116 Tr3Ph (Any Trip) Trip LED Reset (Command) Reset (Logic Input) ENABLE SETTING: & SELF RESET DISABLE Any Pole Dead P2129ENa Any Start Figure 29: Trip LED logic diagram CT/VT REQUIREMENTS The CT requirements for P341 are as shown below.
  • Page 158 P341/EN AP/D22 Application Notes Page 110/116 MiCOM P341 5.3.2 Time-delayed earth fault overcurrent elements ³ /2 * (R + 2R Directional instantaneous overcurrent & earth fault protection 5.4.1 CT requirements for instantaneous phase overcurrent elements /2 * (R ³ 5.4.2 CT requirements for instantaneous earth fault overcurrent elements ³...
  • Page 159 Application Notes P341/EN AP/D22 MiCOM P341 Page 111/116 Maximum prospective secondary phase fault current or 31 times > setting (whichever is lower) (amps) Stage 2 & 3 Earth Fault setting (amps) Stage 2 and 3 setting (amps) Resistance of current transformer secondary winding (ohms)
  • Page 160 P341/EN AP/D22 Application Notes Page 112/116 MiCOM P341 5.7.2 Metering class current transformers For low Power settings (<3%Pn), the I Sensitive current input of the P340 should be driven by a correctly loaded metering class current transformer. The current transformer accuracy class will be dependent on the reverse power and low forward power sensitivity required.
  • Page 161 Application Notes P341/EN AP/D22 MiCOM P341 Page 113/116 Resistance of current transformer secondary winding (W) If R is not available, then the second term in the above equation can be ignored. Example: 400/5A, 15VA 5P 10, R = 0.2W 15 x 10 + 10 x 5 x 0.2...
  • Page 162 P341/EN AP/D22 Application Notes Page 114/116 MiCOM P341 The following table shows the relay menu of commissioning tests, including the available setting ranges and factory defaults: Menu Text Default Setting Settings COMMISSION TESTS Opto I/P Status Relay O/P Status Test Port Status...
  • Page 163 Application Notes P341/EN AP/D22 MiCOM P341 Page 115/116 Note: When the ‘Test Mode’ cell is set to ‘Enabled’ this cell will continue to indicate which contacts would operate if the relay was in-service, it does not show the actual status of the output relays.
  • Page 164 A monitor/download port test box containing 8 LED’s and a switchable audible indicator is available from AREVA T&D, or one of their regional sales offices. It is housed in a small plastic box with a 25-pin male D-connector that plugs directly into the relay’s monitor/download port.
  • Page 165 Relay Description P341/EN HW/D22 MiCOM P341 RELAY DESCRIPTION...
  • Page 166 P341/EN HW/D22 Relay Description MiCOM P341...
  • Page 167 Relay Description P341/EN HW/D22 MiCOM P341 Page 1/16 CONTENT RELAY SYSTEM OVERVIEW Hardware overview 1.1.1 Processor board 1.1.2 Input module 1.1.3 Power supply module 1.1.4 IRIG-B board Software overview 1.2.1 Real-time operating system 1.2.2 System services software 1.2.3 Platform software 1.2.4...
  • Page 168 P341/EN HW/D22 Relay Description Page 2/16 MiCOM P341 3.4.1 Overview - protection & control scheduling 3.4.2 Signal processing 3.4.3 Programmable scheme logic 3.4.3.1 PSL data 3.4.4 Event, fault & maintenance recording 3.4.5 Disturbance recorder SELF TESTING & DIAGNOSTICS Start-up self-testing 4.1.1...

  • Page 169: Relay System Overview

    Relay Description P341/EN HW/D22 MiCOM P341 Page 3/16 RELAY SYSTEM OVERVIEW Hardware overview The relay hardware is based on a modular design whereby the relay is made up of an assemblage of several modules which are drawn from a standard range. Some modules are essential while others are optional depending on the user’s...

  • Page 170: Software Overview

    P341/EN HW/D22 Relay Description Page 4/16 MiCOM P341 Executable software Present Alarm, event, fault, values Default settings & code & data, setting disturbance & of all parameters, language text, database data maintenance settings software code records Battery Flash backed-up E PROM...

  • Page 171: Real-Time Operating System

    Relay Description P341/EN HW/D22 MiCOM P341 Page 5/16 1.2.1 Real-time operating system The real time operating system is used to provide a framework for the different parts of the relay’s software to operate within. To this end the software is split into tasks.

  • Page 172: Internal Communication Buses

    P341/EN HW/D22 Relay Description Page 6/16 MiCOM P341 The processor board is located directly behind the relay’s front panel which allows the LCD and LEDs to be mounted on the processor board along with the front panel communication ports. These comprise the 9-pin D-connector for EIA(RS)232 serial communications (e.g.
  • Page 173 Relay Description P341/EN HW/D22 MiCOM P341 Page 7/16 The signal multiplexing arrangement provides for 16 analogue channels to be sampled. The P341 provides 4 current inputs and 4 voltage inputs. 3 spare channels are used to sample 3 different reference voltages for the purpose of continually checking the operation of the multiplexer and the accuracy of the A-D converter.
  • Page 174 P341/EN HW/D22 Relay Description Page 8/16 MiCOM P341 a battery earth fault, when stray capacitance may present up to 50% of battery voltage across an input. Each input also has a pre-set filter of ½ cycle which renders the input immune to induced noise on the wiring: although this method is secure it can be slow, particularly for intertripping.
  • Page 175 Relay Description P341/EN HW/D22 MiCOM P341 Page 9/16 The two other functions provided by the power supply board are the EIA(RS)485 communications interface and the watchdog contacts for the relay. The EIA(RS)485 interface is used with the relay’s rear communication port to provide communication using one of either Courier, Modbus, DNP 3.0 or IEC 60870-5-103 protocols.
  • Page 176 P341/EN HW/D22 Relay Description Page 10/16 MiCOM P341 and 25-pin female D-connectors are used at the front of the relay for data communication. Inside the relay the PCBs plug into the connector blocks at the rear, and can be removed from the front of the relay only. The connector blocks to the relay’s CT...
  • Page 177 Relay Description P341/EN HW/D22 MiCOM P341 Page 11/16 System services software As shown in Figure 3, the system services software provides the interface between the relay’s hardware and the higher-level functionality of the platform software and the protection & control software. For example, the system services software provides...

  • Page 178: Overview - Protection & Control Scheduling

    P341/EN HW/D22 Relay Description Page 12/16 MiCOM P341 Protection & control software The protection and control software task is responsible for processing all of the protection elements and measurement functions of the relay. To achieve this it has to communicate with both the system services software and the platform software as well as organise its own operations.

  • Page 179: Programmable Scheme Logic

    Relay Description P341/EN HW/D22 MiCOM P341 Page 13/16 3.4.3 Programmable scheme logic The purpose of the programmable scheme logic (PSL) is to allow the relay user to configure an individual protection scheme to suit their own particular application. This is achieved through the use of programmable logic gates and delay timers.

  • Page 180: Disturbance Recorder

    P341/EN HW/D22 Relay Description Page 14/16 MiCOM P341 message, it instructs the platform software to create the appropriate log in battery backed-up SRAM. The operation of the record logging to battery backed-up SRAM is slower than the supervisor’s buffer. This means that the protection software is not delayed waiting for the records to be logged by the platform software.

  • Page 181: System Boot

    Relay Description P341/EN HW/D22 MiCOM P341 Page 15/16 The operations that are performed at start-up are as follows: 4.1.1 System boot The integrity of the flash EPROM memory is verified using a checksum before the program code and data stored in it is copied into SRAM to be used for execution by the processor.
  • Page 182 P341/EN HW/D22 Relay Description Page 16/16 MiCOM P341 the battery status. · · the level of the field voltage. · the integrity of the digital signal I/O data from the opto-isolated inputs and the relay contacts, is checked by the data acquisition function every time it is executed.
  • Page 183 Technical Data P341/EN TD/D22 MiCOM P341 TECHNICAL DATA...
  • Page 184 P341/EN TD/D22 Technical Data MiCOM P341...
  • Page 185 Technical Data P341/EN TD/D22 MiCOM P341 Page 1/42 CONTENT RATINGS Currents Voltages Auxiliary voltage Frequency ‘Universal’ logic inputs (P340 range) Output relay contacts Field voltage Loop through connections Wiring requirements BURDENS Current circuit Voltage circuit Auxiliary supply Optically-isolated inputs ACCURACY...
  • Page 186 P341/EN TD/D22 Technical Data Page 2/42 MiCOM P341 AC voltage dips and short interruptions 5.3.1 AC voltage short interruptions 5.3.2 AC voltage dips High frequency disturbance Fast transients Conducted/radiated emissions 5.6.1 Conducted emissions 5.6.2 Radiated emissions Conducted/radiated immunity 5.7.1 Conducted immunity 5.7.2...
  • Page 187 Technical Data P341/EN TD/D22 MiCOM P341 Page 3/42 10.1.1 Setting ranges 10.1.2 Time delay settings 10.1.3 Transient overreach and overshoot 10.1.3.1 Accuracy 10.2 Inverse time (IDMT) characteristic 10.2.1 Time multiplier settings for IEC/UK curves 10.2.1.1 Time dial settings for IEEE/US curves 10.2.1.2 Definite time characteristic...
  • Page 188 P341/EN TD/D22 Technical Data Page 4/42 MiCOM P341 10.6.2 Over voltage protection time delay characteristics 10.6.3 Accuracy 10.7 Under frequency (81U) 10.7.1 Accuracy 10.8 Over frequency (81O) 10.8.1 Accuracy 10.9 Reverse power/low forward power/over power (32R /32L /32O) 10.9.1 Accuracy 10.10...
  • Page 189 Technical Data P341/EN TD/D22 MiCOM P341 Page 5/42 DISTURBANCE RECORDS 14.1 Level settings 14.2 Accuracy PLANT SUPERVISION 15.1 CB state monitoring control and condition monitoring 15.1.1 CB monitor settings 15.1.2 CB control settings 15.1.3 Accuracy 15.2 CB fail and backtrip breaker fail 15.2.1...
  • Page 190 P341/EN TD/D22 Technical Data Page 6/42 MiCOM P341...

  • Page 191: Ratings

    Technical Data P341/EN TD/D22 MiCOM P341 Page 7/42 RATINGS Currents = 1A or 5A ac rms. Separate terminals are provided for the 1A and 5A windings, with the neutral input of each winding sharing one terminal. CT Type Operating Range Standard 0 to 64 Ιn...

  • Page 192: Frequency

    P341/EN TD/D22 Technical Data Page 8/42 MiCOM P341 Frequency The nominal frequency (Fn) is dual rated at 50 – 60Hz, the operate range is 40Hz – 70Hz. ‘Universal’ logic inputs (P340 range) The P340 series relays are fitted with universal opto isolated logic inputs that can be programmed for the nominal battery voltage of the circuit of which they are a part.

  • Page 193: Field Voltage

    Technical Data P341/EN TD/D22 MiCOM P341 Page 9/42 existing models for suffix issue B or greater hardware. Note, the model number suffix letter refers to the hardware version. The P341 has a base number of relay contacts of 7 in the 40TE case. One optional board can be added to the P341 to increase it’s number of output contacts, the...

  • Page 194: Voltage Circuit

    P341/EN TD/D22 Technical Data Page 10/42 MiCOM P341 Voltage circuit Reference Voltage (Vn) Vn = 100 – 120V <0.06VA rms at 110V Vn = 380 – 480V <0.06VA rms at 440V Auxiliary supply Case Size Minimum* Size 8 /40TE 11W or 24 VA...

  • Page 195: Influencing Quantities

    Technical Data P341/EN TD/D22 MiCOM P341 Page 11/42 Quantity Reference Conditions Test Tolerance General Phase angle 0° Influencing quantities No additional errors will be incurred for any of the following influencing quantities: Quantity Operative Range (Typical Only) Environmental Temperature –25°C to +55°C...

  • Page 196: Impulse

    P341/EN TD/D22 Technical Data Page 12/42 MiCOM P341 Impulse IEC60255-5:1997 The product will withstand without damage impulses of 5kV peak, 1.2/50µs, 0.5J across: Each independent circuit and the case with the terminals of each independent circuit connected together. Independent circuits with the terminals of each independent circuit connected together.

  • Page 197: Class C

    Technical Data P341/EN TD/D22 MiCOM P341 Page 13/42 The relay communications and IRIG-B signal must continue uncorrupted via the communications ports and IRIG-B port respectively during the test, however relay communications and the IRIG-B signal may be momentarily interrupted during the tests, provided that they recover with no external intervention.

  • Page 198: High Frequency Disturbance

    P341/EN TD/D22 Technical Data Page 14/42 MiCOM P341 AC Auxiliary Supply 60% Voltage Dips 50, 100, 200ms, 1s, 40s. Performance criteria - Class C. AC Auxiliary Supply 30% Voltage Dips 2, 5, 10, 20ms. Performance criteria - Class A. AC Auxiliary Supply 30% Voltage Dips 50, 100, 200ms, 1s, 40s.

  • Page 199: Conducted Immunity

    Technical Data P341/EN TD/D22 MiCOM P341 Page 15/42 Conducted/radiated immunity 5.7.1 Conducted immunity EN 61000-4-6:1996 Level 3. 10V emf @ 1kHz 80% am, 150kHz to 80MHz. Spot tests at 27MHz, 68MHz. Performance criteria Class A. 5.7.2 Radiated immunity IEC 60255-22-3:1989 Class III (EN 61000-4-3: 1997 Level 3).

  • Page 200: Power Frequency Magnetic Field

    P341/EN TD/D22 Technical Data Page 16/42 MiCOM P341 5.10 Power frequency magnetic field IEC 61000-4-8:1994 Level 5. 100A/m field applied continuously in all planes for the EUT in a quiescent state and tripping state 1000A/m field applied for 3s in all planes for the EUT in a quiescent state and tripping state Performance criteria Class A.

  • Page 201: Atmospheric Environment

    Technical Data P341/EN TD/D22 MiCOM P341 Page 17/42 ATMOSPHERIC ENVIRONMENT Temperature IEC 60068-2-1:1990/A2:1994 - Cold IEC 60068-2-2:1974/A2:1994 - Dry heat IEC 60255-6:1988. Operating Temperature Range °C Storage Temperature Range °C (Time Period in Hours) (Time Period in Hours) Cold Dry Heat...

  • Page 202: Severity Classes

    P341/EN TD/D22 Technical Data Page 18/42 MiCOM P341 7.1.1 Severity classes The following table details the Class and Typical Applications of the vibration, shock bump and seismic tests detailed previously: Class Typical Application Measuring relays and protection equipment for normal use in...

  • Page 203: Ec Emc Compliance

    Technical Data P341/EN TD/D22 MiCOM P341 Page 19/42 Peak Displacement Peak Acceleration Below Cross Over Above Cross Number of Frequency Severity Frequency (mm) Over Frequency Sweep Cycles Range Class in Each Axis (Hz) 1- 35 EC EMC COMPLIANCE Compliance to the European Community Directive 89/336/EEC amended by 93/68/EEC is claimed via the Technical Construction File route.
  • Page 204 P341/EN TD/D22 Technical Data Page 20/42 MiCOM P341 10.1.2 Time delay settings Each overcurrent element has an independent time setting and each time delay is capable of being blocked by an optically isolated input: Element Time Delay Type 1st Stage...
  • Page 205 Technical Data P341/EN TD/D22 MiCOM P341 Page 21/42 IDMT characteristics α IDMT Curve Description Standard Constant Constant Constant Standard inverse 0.14 0.02 Very inverse 13.5 Extremely inverse Long time inverse Moderately inverse IEEE 0.0515 0.02 0.114 Very inverse IEEE 19.61 0.491...
  • Page 206 P341/EN TD/D22 Technical Data Page 22/42 MiCOM P341 Where reset time Reset constant Ι measured current Ι current threshold setting α constant TD = time dial Setting (same setting as that employed by IDMT curve) IEEE/US IDMT Curve Description Standard tr Constant α...
  • Page 207 Technical Data P341/EN TD/D22 MiCOM P341 Page 23/42 IEC Curves 1000 Curve 4 Curve 1 Curve 2 Curve 3 10.0 100.0 Current (Multiples of Is) Curve 1 Standard inverse Curve 2 Very inverse Curve 3 Extremely inverse Curve 4 UK long time inverse...
  • Page 208 P341/EN TD/D22 Technical Data Page 24/42 MiCOM P341 Amercian Curves Curve 5 Curve 6 Curve 9 Curve 7 Curve 8 10.0 100.0 Current (Multiples of Is) Curve 5 IEEE moderately inverse Curve 6 IEEE very inverse Curve 7 IEEE extremely inverse...
  • Page 209 Technical Data P341/EN TD/D22 MiCOM P341 Page 25/42 10.3 Earth fault & sensitive earth fault protection (50N/51N) (67N) (64) There are two standard earth fault elements, Earth Fault 1 uses measured quantities, Earth Fault 2 uses derived quantities. 10.3.1 Setting ranges 10.3.1.1 Earth fault, sensitive earth fault...
  • Page 210 P341/EN TD/D22 Technical Data Page 26/42 MiCOM P341 10.3.1.3 Restricted earth fault (low impedance) Setting Range Step Size 0% to 20% 1% (minimum) ΙREF> K1 0% to 150% 1% (minimum) ΙREF> K2 ΙREF> Ιs1 8% to 100% Ιn 1% Ιn ΙREF>...
  • Page 211 Technical Data P341/EN TD/D22 MiCOM P341 Page 27/42 10.3.4 Accuracy 10.3.4.1 Earth fault 1 Pick-up Setting ±5% Drop-off 0.95 x Setting ±5% Minimum trip level of IDMT elements 1.05 x Setting ±5% ±5% or 40ms whichever is greater IDMT characteristic shape...
  • Page 212 P341/EN TD/D22 Technical Data Page 28/42 MiCOM P341 10.3.4.4 REF Pick-up Setting formula ±5% Drop-off 0.80 x Setting formula ±5% Low impedance operating time <60ms High impedance pick-up Setting ±5% High impedance operating time <30ms Repeatability <15% 10.3.4.5 Wattmetric SEF For P=0W ΙSEF>...
  • Page 213 Technical Data P341/EN TD/D22 MiCOM P341 Page 29/42 10.4.2 Time delay settings The inverse characteristic for VN>1 shall be given by the following formula : (M - 1) where Time multiplier setting operating time in seconds Applied input voltage/relay setting voltage (Vs)
  • Page 214 P341/EN TD/D22 Technical Data Page 30/42 MiCOM P341 The inverse characteristic shall be given by the following formula : (1 - M) where Time multiplier setting operating time in seconds Applied input voltage/relay setting voltage (Vs) Range Step Size DT setting 0 –...
  • Page 215 Technical Data P341/EN TD/D22 MiCOM P341 Page 31/42 where Time multiplier setting Operating time in seconds Applied input voltage/relay setting voltage (Vs) Range Step Size DT setting 0 – 100s 0.01s TMS Setting (K) 0.5 – 100s Definite time and TMS setting ranges 10.6.3 Accuracy...
  • Page 216 P341/EN TD/D22 Technical Data Page 32/42 MiCOM P341 10.9 Reverse power/low forward power/over power (32R /32L /32O) Settings Range Step Size Stage 1 Enable/disable Mode Reverse/low forward/over 14W – 40W (Ιn=1A, Vn=100/120V) 56W – 160W (Ιn=1A, Vn=380/480V) 70W – 200W (Ιn=5A, Vn=100/120V) –P>...
  • Page 217 Technical Data P341/EN TD/D22 MiCOM P341 Page 33/42 10.10 Sensitive reverse power/low forward power/over power (32R /32L /32O) Settings Range Step Size Stage 1 Enable/disable Mode Reverse/low forward/over 0.3W – 15W (Ιn=1A, Vn=100/120V) 0.1W 1.2W – 60W (Ιn=1A, Vn=380/480V) 0.4W –P>...
  • Page 218 P341/EN TD/D22 Technical Data Page 34/42 MiCOM P341 10.11 Rate of change of frequency 10.11.1 Setting range Settings Range Step Size df/dt Status Enable/Disable df/dt Setting 0.1 – 10Hz/s 0.01Hz df/dt Time Delay 0 – 100s 0.01s df/dt f Low 45 –...
  • Page 219 Technical Data P341/EN TD/D22 MiCOM P341 Page 35/42 10.14 Thermal overload (49) Settings Range Step Size Thermal I> 0.5 - 1.5 Ιn 0.01Ιn Thermal Alarm 20 -100% T-heating 1 - 200 minutes 1 minute T-cooling 1 - 200 minutes 1 minute...
  • Page 220 P341/EN TD/D22 Technical Data Page 36/42 MiCOM P341 11.2 Current transformer supervision The Ι and V thresholds take the same values as set for the directional earth fault element. Settings Range Step Size 0.5 - 22V (Vn = 100/120V) 0.5V VN <...
  • Page 221 Technical Data P341/EN TD/D22 MiCOM P341 Page 37/42 MEASUREMENTS AND RECORDING FACILITIES 13.1 Measurements Accuracy under reference conditions. Measurand Range Accuracy Current 0.05 to 3 Ιn ±1.0% of reading Voltage 0.05 to 2 Vn ±1.0% of reading 0.2 to 2 Vn ±5% of reading at unity...
  • Page 222 P341/EN TD/D22 Technical Data Page 38/42 MiCOM P341 DISTURBANCE RECORDS 14.1 Level settings Settings Range Step Size Duration 0.1 – 10.5s 10ms Trigger position 0 – 100% 0.1% 8 analogue channels, 32 digital channels, single or extended trigger modes 14.2...
  • Page 223 Technical Data P341/EN TD/D22 MiCOM P341 Page 39/42 15.2 CB fail and backtrip breaker fail 15.2.1 Timer settings Setting Range Step CB fail 1 timer 0 – 10s 0.01s CB fail 2 timer 0 – 10s 0.01s The timers are reset by: •...
  • Page 224 P341/EN TD/D22 Technical Data Page 40/42 MiCOM P341 BATTERY LIFE Battery life (assuming relay energised for 90% of time) > 10 years 1/2 AA size 3.6 V lithium thionyl chloride battery (SAFT advanced battery reference LS14250) FREQUENCY RESPONSE With the exception of the RMS measurements all other measurements and protection functions are based on the Fourier derived fundamental component.
  • Page 225 Technical Data P341/EN TD/D22 MiCOM P341 Page 41/42 LOCAL AND REMOTE COMMUNICATIONS The following claims for Local & Remote Communications are applicable to the P34x range of generator relays. 19.1 Front port Setting Protocol Courier Message format IEC 60870-5 FT1.2...
  • Page 226 P341/EN TD/D22 Technical Data Page 42/42 MiCOM P341...
  • Page 227 SCADA Communications P341/EN CT/D22 MiCOM P341 SCADA COMMUNICATIONS...
  • Page 228 P341/EN CT/D22 SCADA Communications MiCOM P341...
  • Page 229 SCADA Communications P341/EN CT/D22 MiCOM P341 Page 1/20 CONTENT INTRODUCTION COURIER INTERFACE Courier protocol Front courier port Supported command set Relay courier database Setting changes 2.5.1 Method 1 2.5.2 Method 2 2.5.3 Relay settings 2.5.4 Setting transfer mode Event extraction 2.6.1...
  • Page 230 P341/EN CT/D22 SCADA Communications Page 2/20 MiCOM P341 Setting changes 3.7.1 Password protection 3.7.2 Control and support settings 3.7.3 Protection and disturbance recorder settings IEC60870-5-103 INTERFACE Physical connection and link layer Initialisation Time synchronisation Spontaneous events General interrogation Cyclic measurements...
  • Page 231 COURIER INTERFACE Courier protocol Courier is an AREVA T&D communication protocol. The concept of the protocol is that a standard set of commands are used to access a database of settings/data within the relay.
  • Page 232 P341/EN CT/D22 SCADA Communications Page 4/20 MiCOM P341 Front courier port The front EIA(RS)232 port supports the Courier protocol for one to one communication. designed during installation commissioning/maintenance and is not suitable for permanent connection. Since this interface will not be used to link the relay to a substation communication system some of the features of Courier are not implemented.
  • Page 233 SCADA Communications P341/EN CT/D22 MiCOM P341 Page 5/20 Get Value Get Column Setting Limits Setting Changes Enter Setting Mode Preload Setting Abort Setting Execute Setting Reset Menu Cell Set Value Control Commands Select Setting Group Change Device Address* Set Real Time...
  • Page 234 P341/EN CT/D22 SCADA Communications Page 6/20 MiCOM P341 Setting changes (See Courier User Guide Chapter 9) Courier provides two mechanisms for making setting changes, both of these are supported by the relay. Either method can be used for editing any of the settings within the relay database.
  • Page 235 SCADA Communications P341/EN CT/D22 MiCOM P341 Page 7/20 2.5.4 Setting transfer mode If it is necessary to transfer all of the relay settings to or from the relay a cell within the Communication System Data column can be used. This cell (location BF03) when set to 1 makes all of the relay settings visible.
  • Page 236 P341/EN CT/D22 SCADA Communications Page 8/20 MiCOM P341 2.6.3 Event format The Send Event command results in the following fields being returned by the relay: Cell Reference Timestamp Cell Text Cell Value Appendix B contains a table of the events created by the relay and indicates how the contents of the above fields are interpreted.
  • Page 237 SCADA Communications P341/EN CT/D22 MiCOM P341 Page 9/20 Select Record Number (Row 01) - This cell can be used to select the record to be extracted. Record 0 will be the oldest unextracted record, older records will be assigned positive values, and negative values will be used for more recent records.
  • Page 238 P341/EN CT/D22 SCADA Communications Page 10/20 MiCOM P341 MODBUS INTERFACE The Modbus interface is a master/slave protocol, it is defined by MODICON Inc by the following document: Modicon Modbus Protocol Reference Guide PI-MBUS-300 Rev. E Communication link This interface also uses the rear EIA(RS)485 port for communication using RTU mode communication rather than ASCII mode as this provides more efficient use of the communication bandwidth.
  • Page 239 SCADA Communications P341/EN CT/D22 MiCOM P341 Page 11/20 Response codes Code Modbus description MiCOM interpretation Illegal Function Code The function code transmitted is not supported by the slave Illegal Data Address The start data address in the request is not an allowable value.
  • Page 240 P341/EN CT/D22 SCADA Communications Page 12/20 MiCOM P341 There are three registers available to manually select stored records. 40100 - Select Event, 0 to 249 40101 - Select Fault, 0 to 4 40102 - Select Maintenance Record, 0 to 4 For each of the above registers a value of 0 represents the most recent stored record.
  • Page 241 SCADA Communications P341/EN CT/D22 MiCOM P341 Page 13/20 Event Modbus Length Comments Description Address Event Index 30111 This register will contain the DDB No for protection events or the bit No for alarm events. The direction of the change will be...
  • Page 242 P341/EN CT/D22 SCADA Communications Page 14/20 MiCOM P341 3.6.3 Record data The timestamp for a record selected using either of the above means can be read from registers 30930 to 30933. The disturbance record data itself is stored in a compressed format, due to the size of the disturbance record it must be read using a paging system.
  • Page 243 SCADA Communications P341/EN CT/D22 MiCOM P341 Page 15/20 The following registers are available to control Password protection: 40001&40002 Password Entry 40022 Default Password Level 40023&40024 Setting to Change password level 1 40025&40026 Setting to Change password level 2 30010 Can be read to indicate current access level 3.7.2...
  • Page 244 P341/EN CT/D22 SCADA Communications Page 16/20 MiCOM P341 IEC60870-5-103 INTERFACE The IEC60870-5-103 interface is a master/slave interface with the relay as the slave device. This protocol is based on the VDEW communication protocol. The relay conforms to compatibility level 2, compatibility level 3 is not supported.
  • Page 245 SCADA Communications P341/EN CT/D22 MiCOM P341 Page 17/20 Time synchronisation The relay time and date can be set using the time synchronisation feature of the IEC60870-5-103 protocol. The relay will correct for the transmission delay as specified in IEC60870-5-103. If the time synchronisation message is sent as a send/confirm message then the relay will respond with a confirm.
  • Page 246 P341/EN CT/D22 SCADA Communications Page 18/20 MiCOM P341 Disturbance records The disturbance records stored in uncompressed format and can be extracted using the standard mechanisms described in IEC60870-5-103. 4.10 Blocking of monitor/command direction The relay does support a facility to block messages in the Monitor direction and also in the Command direction.
  • Page 247 SCADA Communications P341/EN CT/D22 MiCOM P341 Page 19/20 Object 10 binary outputs Object 10, binary outputs, contains commands which can be operated via DNP3. As such all points accept commands of type pulse on and latch on and execute the command once for either command.
  • Page 248 P341/EN CT/D22 SCADA Communications Page 20/20 MiCOM P341 5.7.1 Object 1 For every point included in the device profile document there is a check box for membership of class 0 and radio buttons for class 1, 2 or 3 membership. Any point which is in class 0 must be a member of one of the change event classes, 1, 2 or 3.
  • Page 249 Relay Menu Database P341/EN GC/D22 MiCOM P341 RELAY MENU DATABASE...
  • Page 250 Model Number Software Number P341------0050B P341------0050-A/B/C For other models / software versions, please contact AREVA T&D for the relevant information. (Software versions P341------0010*, P341------0020*, P341------0030*, P341------0040* are not supported by this menu database, see P341/EN T/B11 (0020 – 0040) and TG8617A (0010) for information...
  • Page 251 Relay Menu Database P341/EN GC/D22 MiCOM P341 Page 1/158 RELAY MENU DATABASE This database is split into several sections, these are as follows: • Menu Database for Courier, User Interface and Modbus • Menu Datatype Definition • Event Data for Courier, User Interface and Modbus •...
  • Page 252 P341/EN GC/D22 Relay Menu Database Page 2/158 MiCOM P341 Internal digital signals This table defines all of the relay internal digital signals (opto inputs, output contacts and protection inputs and outputs). A relay may have up to 512 internal signals each referenced by a numeric index as shown in this table.
  • Page 253 Relay Menu Database P341/EN GC/D22 MiCOM P341 Page 3/158 Courier Model Modbus Address Modbus Password Courier Text Data Type Default Setting Step Comment Strings Cell Type Database Level Start P341 P342 P343 SYSTEM DATA Language Indexed String English Setting Password...
  • Page 254 Relay Menu Database P341/EN GC/D22 MiCOM P341 Page 4/158 Courier Model Modbus Address Modbus Password Courier Text Data Type Default Setting Step Comment Strings Cell Type Database Level Start P341 P342 P343 Note DTL depends on event type binary flag for o/p, opto, alarm &...
  • Page 255 Relay Menu Database P341/EN GC/D22 MiCOM P341 Page 5/158 Courier Model Modbus Address Modbus Password Courier Text Data Type Default Setting Step Comment Strings Cell Type Database Level Start P341 P342 P343 1/2/3/4 visible if Trip Trip IN> 1234 IN>1/2/3/4...
  • Page 256 Relay Menu Database P341/EN GC/D22 MiCOM P341 Page 6/158 Courier Model Modbus Address Modbus Password Courier Text Data Type Default Setting Step Comment Strings Cell Type Database Level Start P341 P342 P343 RTD Alarm Data RTD 1 label RTD Alarm...
  • Page 257 Relay Menu Database P341/EN GC/D22 MiCOM P341 Page 7/158 Courier Model Modbus Address Modbus Password Courier Text Data Type Default Setting Step Comment Strings Cell Type Database Level Start P341 P342 P343 PoleSlip z based Data Start Z1 Z2 PoleSlip z based...
  • Page 258 Relay Menu Database P341/EN GC/D22 MiCOM P341 Page 8/158 Courier Model Modbus Address Modbus Password Courier Text Data Type Default Setting Step Comment Strings Cell Type Database Level Start P341 P342 P343 I Sensitive Courier Number (current) 30171 30172 Data...
  • Page 259 Relay Menu Database P341/EN GC/D22 MiCOM P341 Page 9/158 Courier Model Modbus Address Modbus Password Courier Text Data Type Default Setting Step Comment Strings Cell Type Database Level Start P341 P342 P343 I2 Magnitude Courier Number (current) 30220 30221 Data...
  • Page 260 Relay Menu Database P341/EN GC/D22 MiCOM P341 Page 10/158 Courier Model Modbus Address Modbus Password Courier Text Data Type Default Setting Step Comment Strings Cell Type Database Level Start P341 P342 P343 3Ph WHours Fwd Courier Number (Wh) 30343 30345...
  • Page 261 Relay Menu Database P341/EN GC/D22 MiCOM P341 Page 11/158 Courier Model Modbus Address Modbus Password Courier Text Data Type Default Setting Step Comment Strings Cell Type Database Level Start P341 P342 P343 3 Phase W Peak Demand 30431 30432 G125...
  • Page 262 Relay Menu Database P341/EN GC/D22 MiCOM P341 Page 12/158 Courier Model Modbus Address Modbus Password Courier Text Data Type Default Setting Step Comment Strings Cell Type Database Level Start P341 P342 P343 Visible only when Spower is APh Sen Watts...
  • Page 263 Relay Menu Database P341/EN GC/D22 MiCOM P341 Page 13/158 Courier Model Modbus Address Modbus Password Courier Text Data Type Default Setting Step Comment Strings Cell Type Database Level Start P341 P342 P343 Copy To Indexed String 40407 No Operation Command...
  • Page 264 Relay Menu Database P341/EN GC/D22 MiCOM P341 Page 14/158 Courier Model Modbus Address Modbus Password Courier Text Data Type Default Setting Step Comment Strings Cell Type Database Level Start P341 P342 P343 40401 Record control command register values for multiplier see mult...
  • Page 265 Relay Menu Database P341/EN GC/D22 MiCOM P341 Page 15/158 Courier Model Modbus Address Modbus Password Courier Text Data Type Default Setting Step Comment Strings Cell Type Database Level Start P341 P342 P343 DDB 415 - 384 Binary Flag (32 bits)
  • Page 266 Relay Menu Database P341/EN GC/D22 MiCOM P341 Page 16/158 Courier Model Modbus Address Modbus Password Courier Text Data Type Default Setting Step Comment Strings Cell Type Database Level Start P341 P342 P343 Digital Input 5 Indexed String 40619 Relay 5...
  • Page 267 Relay Menu Database P341/EN GC/D22 MiCOM P341 Page 17/158 Courier Model Modbus Address Modbus Password Courier Text Data Type Default Setting Step Comment Strings Cell Type Database Level Start P341 P342 P343 Digital Input 21 Indexed String 40651 Not Used...
  • Page 268 Relay Menu Database P341/EN GC/D22 MiCOM P341 Page 18/158 Courier Model Modbus Address Modbus Password Courier Text Data Type Default Setting Step Comment Strings Cell Type Database Level Start P341 P342 P343 Remote Address Unsigned integer (16 bits) Setting Build = Courier...
  • Page 269 Relay Menu Database P341/EN GC/D22 MiCOM P341 Page 19/158 Courier Model Modbus Address Modbus Password Courier Text Data Type Default Setting Step Comment Strings Cell Type Database Level Start P341 P342 P343 DDB 127 - 96 Binary Flag(32) 30729 30730...
  • Page 270 Relay Menu Database P341/EN GC/D22 MiCOM P341 Page 20/158 Courier Model Modbus Address Modbus Password Courier Text Data Type Default Setting Step Comment Strings Cell Type Database Level Start P341 P342 P343 Broken Current to cause maint. I^ Maintenance Indexed String...
  • Page 271 Relay Menu Database P341/EN GC/D22 MiCOM P341 Page 21/158 Courier Model Modbus Address Modbus Password Courier Text Data Type Default Setting Step Comment Strings Cell Type Database Level Start P341 P342 P343 Opto Input 22 Indexed String G201 40922 G201...
  • Page 272 Relay Menu Database P341/EN GC/D22 MiCOM P341 Page 22/158 Courier Model Modbus Address Modbus Password Courier Text Data Type Default Setting Step Comment Strings Cell Type Database Level Start P341 P342 P343 Control Input 32 Indexed String G203 40983 G203...
  • Page 273 Relay Menu Database P341/EN GC/D22 MiCOM P341 Page 23/158 Courier Model Modbus Address Modbus Password Courier Text Data Type Default Setting Step Comment Strings Cell Type Database Level Start P341 P342 P343 FFail2 TimeDelay Courier Number (Time) 41111 Setting 0.01...
  • Page 274 Relay Menu Database P341/EN GC/D22 MiCOM P341 Page 24/158 Courier Model Modbus Address Modbus Password Courier Text Data Type Default Setting Step Comment Strings Cell Type Database Level Start P341 P342 P343 I>1 Time Dial Courier Number (Decimal) 41255 Setting I>1 Reset Char...
  • Page 275 Relay Menu Database P341/EN GC/D22 MiCOM P341 Page 25/158 Courier Model Modbus Address Modbus Password Courier Text Data Type Default Setting Step Comment Strings Cell Type Database Level Start P341 P342 P343 IN>1 Time Dial Courier Number (Decimal) 41405 Setting IN>1 Reset Char...
  • Page 276 Relay Menu Database P341/EN GC/D22 MiCOM P341 Page 26/158 Courier Model Modbus Address Modbus Password Courier Text Data Type Default Setting Step Comment Strings Cell Type Database Level Start P341 P342 P343 ISEF>1 Reset Chr Indexed String 41507 Setting (5>=3A02>=1 OR ISEF>1 tRESET...
  • Page 277 Relay Menu Database P341/EN GC/D22 MiCOM P341 Page 27/158 Courier Model Modbus Address Modbus Password Courier Text Data Type Default Setting Step Comment Strings Cell Type Database Level Start P341 P342 P343 VN>2 Status Indexed String 41556 Disabled Setting VN>2 Voltage Set...
  • Page 278 Relay Menu Database P341/EN GC/D22 MiCOM P341 Page 28/158 Courier Model Modbus Address Modbus Password Courier Text Data Type Default Setting Step Comment Strings Cell Type Database Level Start P341 P342 P343 Dead Mach tDO Courier Number (Time) 41804 Setting...
  • Page 279 Relay Menu Database P341/EN GC/D22 MiCOM P341 Page 29/158 Courier Model Modbus Address Modbus Password Courier Text Data Type Default Setting Step Comment Strings Cell Type Database Level Start P341 P342 P343 F< Function Link Binary Flag (4 bits) 42012...
  • Page 280 Relay Menu Database P341/EN GC/D22 MiCOM P341 Page 30/158 Courier Model Modbus Address Modbus Password Courier Text Data Type Default Setting Step Comment Strings Cell Type Database Level Start P341 P342 P343 RTD 9 Trip Set Courier Number (Temperature) 42088...
  • Page 281 Relay Menu Database P341/EN GC/D22 MiCOM P341 Page 31/158 Courier Model Modbus Address Modbus Password Courier Text Data Type Default Setting Step Comment Strings Cell Type Database Level Start P341 P342 P343 Power1 DO Timer Courier Number (Time) 42181 Setting 0.01...
  • Page 282 Relay Menu Database P341/EN GC/D22 MiCOM P341 Page 32/158 Courier Model Modbus Address Modbus Password Courier Text Data Type Default Setting Step Comment Strings Cell Type Database Level Start P341 P342 P343 Opto Input 18 ASCII Text (16 chars) 42436...
  • Page 283 Relay Menu Database P341/EN GC/D22 MiCOM P341 Page 33/158 Courier Model Modbus Address Modbus Password Courier Text Data Type Default Setting Step Comment Strings Cell Type Database Level Start P341 P342 P343 Relay 29 ASCII Text (16 chars) 42780 42787...
  • Page 284 Relay Menu Database P341/EN GC/D22 MiCOM P341 Page 34/158 Courier Model Modbus Address Modbus Password Courier Text Data Type Default Setting Step Comment Strings Cell Type Database Level Start P341 P342 P343 Courier Number (current) Data IC-1 Courier Number (current)
  • Page 285 Relay Menu Database P341/EN GC/D22 MiCOM P341 Page 35/158 Courier Model Modbus Address Modbus Password Courier Text Data Type Default Setting Step Comment Strings Cell Type Database Level Start P341 P342 P343 Sub-Domain Indexed String Group 1 Setting Version Unsigned Integer (2 Bytes)
  • Page 286 Relay Menu Database P341/EN GC/D22 MiCOM P341 Page 36/158 Courier Model Modbus Address Modbus Password Courier Text Data Type Default Setting Step Comment Strings Cell Type Database Level Start P341 P342 P343 UNUSED 2D-3D Dist. Channel 31 Binary Flag Data Build=IEC60870-5-103 Dist.
  • Page 287 Relay Menu Database P341/EN GC/D22 MiCOM P341 Page 37/158 Courier Model Modbus Address Modbus Password Courier Text Data Type Default Setting Step Comment Strings Cell Type Database Level Start P341 P342 P343 Reset Demand None (Reset Menu Cell) Data(but supports Reset Menu cell)
  • Page 288 Relay Menu Database P341/EN GC/D22 MiCOM P341 Page 38/158 Data Types TYPE VALUE/BIT MASK DESCRIPTION UNSIGNED INTEGER eg. 5678 stored as 5678 NUMERIC SETTING Modbus value = (relay setting - minimum setting)/step size ASCII TEXT CHARACTERS 0x00FF Second character 0xFF00...
  • Page 289 Relay Menu Database P341/EN GC/D22 MiCOM P341 Page 39/158 TYPE VALUE/BIT MASK DESCRIPTION (Second reg, First Reg) 0x0000,0x0001 Not Used (0 = Off, 1 = On) 0x0000,0x0002 Not Used (0 = Off, 1 = On) 0x0000,0x0004 Not Used (0 = Off, 1 = On)
  • Page 290 Relay Menu Database P341/EN GC/D22 MiCOM P341 Page 40/158 TYPE VALUE/BIT MASK DESCRIPTION 0x0000,0x0004 Opto 3 Input State (0=Off, 1=On) Opto 3 Input State (0=Off, 1=On) Opto 3 Input State (0=Off, 1=On) 0x0000,0x0008 Opto 4 Input State (0=Off, 1=On) Opto 4 Input State (0=Off, 1=On)
  • Page 291 Relay Menu Database P341/EN GC/D22 MiCOM P341 Page 41/158 TYPE VALUE/BIT MASK DESCRIPTION 0x8000,0x0000 Not Used Not Used Opto 32 Input State (0=Off, 1=On) RELAY OUTPUT STATUS P341 P342 P343 0x0000,0x0001 Relay 1 (0=Off, 1=On) Relay 1 (0=Off, 1=On) Relay 1 (0=Off, 1=On)
  • Page 292 Relay Menu Database P341/EN GC/D22 MiCOM P341 Page 42/158 TYPE VALUE/BIT MASK DESCRIPTION 0x0800,0x0000 Relay 28 (0=Off, 1=On) 0x1000,0x0000 Relay 29 (0=Off, 1=On) 0x2000,0x0000 Relay 30 (0=Off, 1=On) 0x4000,0x0000 Relay 31 (0=Off, 1=On) 0x8000,0x0000 Relay 32 (0=Off, 1=On) SIGNED FIXED POINT NUMBER - 1 DECIMAL PLACE -3276.8 to 3276.7 e.g.
  • Page 293 Relay Menu Database P341/EN GC/D22 MiCOM P341 Page 43/158 TYPE VALUE/BIT MASK DESCRIPTION Maintenance record logged event I> FUNCTION LINK P341 P342 P343 Bit 0 I>1 VTS Block (0=Non-dir, I=VTS Blk) Not Used Not Used Bit 1 I>2 VTS Block (0=Non-dir, I=VTS Blk)
  • Page 294 Relay Menu Database P341/EN GC/D22 MiCOM P341 Page 44/158 TYPE VALUE/BIT MASK DESCRIPTION 0x0000 No Operation 0x0001 Select next event 0x0002 Accept Event 0x0004 Select next Disurbance Record 0x0008 Accept disturbance record 0x0010 Select Next Disturbance record page LANGUAGE English...
  • Page 295 Relay Menu Database P341/EN GC/D22 MiCOM P341 Page 45/158 TYPE VALUE/BIT MASK DESCRIPTION IDMT 2 REGISTERS UNSIGNED LONG VALUE, 3 DECIMAL PLACES High order word of long stored in 1st register Low order word of long stored in 2nd register Example 123456.789 stored as 123456789...
  • Page 296 Relay Menu Database P341/EN GC/D22 MiCOM P341 Page 46/158 TYPE VALUE/BIT MASK DESCRIPTION Power = (Secondary power/CT secondary) * (100/VT secondary) 3 REGISTER POWER MULTIPLER All power measurments use a signed value of type G28 and a 2 register unsigned long multiplier of type G27...
  • Page 297 Relay Menu Database P341/EN GC/D22 MiCOM P341 Page 47/158 TYPE VALUE/BIT MASK DESCRIPTION R6 Control Close R6 E/F trip R6 E/F Trip R7 Control Trip R7 V or F Trip R7 Volt Trip R8 Not Used R8 Not Used R8 Freq Trip...
  • Page 298 Relay Menu Database P341/EN GC/D22 MiCOM P341 Page 48/158 TYPE VALUE/BIT MASK DESCRIPTION L12 Not Used L12 Not Used L4 Block I>2 L13 Not Used L13 Not Used L5 Reset L14 Not Used L14 Not Used L6 Ext Prot Trip...
  • Page 299 Relay Menu Database P341/EN GC/D22 MiCOM P341 Page 49/158 TYPE VALUE/BIT MASK DESCRIPTION CB Op Time Maint CB Op Time Maint LED 2 CB Op Time Lock CB Op Time Lock LED 3 Fault Freq Lock Fault Freq Lock LED 4...
  • Page 300 Relay Menu Database P341/EN GC/D22 MiCOM P341 Page 50/158 TYPE VALUE/BIT MASK DESCRIPTION V<1 Trip C/CA RTD 2 Trip RTD Data Error V<2 Trip RTD 3 Trip RTD Board Fail V<2 Trip A/AB RTD 4 Trip Freq Prot Alm V<2 Trip B/BC...
  • Page 301 Relay Menu Database P341/EN GC/D22 MiCOM P341 Page 51/158 TYPE VALUE/BIT MASK DESCRIPTION I>3 Trip A V>2 Trip B/BC RTD 10 Trip I>3 Trip B V>2 Trip C/CA Any RTD Trip I>3 Trip C F<1 Trip IN>1 Trip I>4 Trip F<2 Trip...
  • Page 302 Relay Menu Database P341/EN GC/D22 MiCOM P341 Page 52/158 TYPE VALUE/BIT MASK DESCRIPTION V>2 Start C/CA Z<2 Trip C Power1 Trip Power1 Start Any Start Power2 Trip Power2 Start VN>1 Start I>1 Trip I>1 Start VN>2 Start I>1 Trip A I>1 Start A...
  • Page 303 Relay Menu Database P341/EN GC/D22 MiCOM P341 Page 53/158 TYPE VALUE/BIT MASK DESCRIPTION F<4 Start IN>1 Start V<1 Start B/BC F>1 Start IN>2 Start V<1 Start C/CA F>2 Start ISEF>1 Start V<2 Start I> BlockStart F<1 Start V<2 Start A/AB IN/SEF>Blk Start...
  • Page 304 Relay Menu Database P341/EN GC/D22 MiCOM P341 Page 54/158 TYPE VALUE/BIT MASK DESCRIPTION Z<2 Start C F<3 Start VTS Fast Block F<4 Start VTS Slow Block F>1 Start CTS Block F>2 Start RTD 1 Alarm IA< Start RTD 2 Alarm IB<...
  • Page 305 Relay Menu Database P341/EN GC/D22 MiCOM P341 Page 55/158 TYPE VALUE/BIT MASK DESCRIPTION Z<2 Start C VTS Fast Block VTS Slow Block CTS Block RTD 1 Alarm RTD 2 Alarm RTD 3 Alarm RTD 4 Alarm RTD 5 Alarm RTD 6 Alarm...
  • Page 306 Relay Menu Database P341/EN GC/D22 MiCOM P341 Page 56/158 TYPE VALUE/BIT MASK DESCRIPTION expressed as 2 register 32 bit unsigned int REAL NUMBERS Polar Rectangular ENABLED / DISABLED Disabled Enabled G38m COMMUNICATION BAUD RATE (MODBUS) 9600 bits/s 19200 bits/s 38400 bits/s...
  • Page 307 Relay Menu Database P341/EN GC/D22 MiCOM P341 Page 57/158 TYPE VALUE/BIT MASK DESCRIPTION CHECK SYNC VOLTAGE BLOCKING None Undervoltage Differential Both CHECK SYNC SLIP CONTROL None Timer Frequency Both IDMT CURVE TYPE Disabled IEC S Inverse IEC V Inverse IEC E Inverse...
  • Page 308 Relay Menu Database P341/EN GC/D22 MiCOM P341 Page 58/158 TYPE VALUE/BIT MASK DESCRIPTION Non-Directional POLARISATION Zero Sequence Neg Sequence MEASURING MODE Phase-Phase Phase-Neutral OPERATION MODE Any Phase Three Phase VN OR IN INPUT Measured Derived RTD SELECT 0x0001 RTD Input #1...
  • Page 309 Relay Menu Database P341/EN GC/D22 MiCOM P341 Page 59/158 TYPE VALUE/BIT MASK DESCRIPTION 3 Ph-neutral Voltage Power Date and Time Description Plant Reference Frequency Access Level SELECT FACTORY DEFAULTS No Operation All Settings Setting Group 1 Setting Group 2 Setting Group 3...
  • Page 310 Relay Menu Database P341/EN GC/D22 MiCOM P341 Page 60/158 TYPE VALUE/BIT MASK DESCRIPTION PSL Configuration SEF/REF SELECTION P341 P342 P343 SEF cos(PHI) SEF cos(PHI) SEF cos(PHI) SEF sin (PHI) SEF sin (PHI) SEF sin (PHI) Wattmetric Wattmetric Wattmetric Hi Z REF...
  • Page 311 Relay Menu Database P341/EN GC/D22 MiCOM P341 Page 61/158 TYPE VALUE/BIT MASK DESCRIPTION Bit 4 Not Used Not Used Not Used Bit 5 Not Used Not Used Not Used Bit 6 Not Used Not Used Not Used Bit 7 Not Used...
  • Page 312 Relay Menu Database P341/EN GC/D22 MiCOM P341 Page 62/158 TYPE VALUE/BIT MASK DESCRIPTION Dual CB Fail Reset Options I< Only CB Open & I< Prot Reset & I< VTS RESET MODE Manual Auto AUTORECLOSE MODE Opto set Auto User Set...
  • Page 313 Relay Menu Database P341/EN GC/D22 MiCOM P341 Page 63/158 TYPE VALUE/BIT MASK DESCRIPTION Inhibited TRANSFER MODE Prepare Rx Complete Rx Prepare Tx Complete Tx Rx Prepared Tx Prepared Error Auto-Reclose Out of Service In Service Autoreclose Telecontrol commands No Operation...
  • Page 314 Relay Menu Database P341/EN GC/D22 MiCOM P341 Page 64/158 TYPE VALUE/BIT MASK DESCRIPTION Block Inst Prot Autoreclose Status Auto Mode Non-auto Mode Live Line Modbus value+bit pos Started Elements (1) (Second reg, First Reg) P341 P342 P343 0x0000,0x0001 General Start...
  • Page 315 Relay Menu Database P341/EN GC/D22 MiCOM P341 Page 65/158 TYPE VALUE/BIT MASK DESCRIPTION 0x0080,0x0000 Start z PSlip Z1 0x0100,0x0000 Start z PSlip Z2 0x0200,0x0000 Start Z<1 Start Z<1 Start Z<1 0x0400,0x0000 Start Z<1 Start Z<1 Start Z<1 0x0800,0x0000 0x1000,0x0000 0x2000,0x0000...
  • Page 316 Relay Menu Database P341/EN GC/D22 MiCOM P341 Page 66/158 TYPE VALUE/BIT MASK DESCRIPTION 0x0008,0x0000 Trip ISEF>4 0x0010,0x0000 Trip IREF> Trip IREF> Trip IREF> 0x0020,0x0000 Trip NVD VN>1 Trip NVD VN>1 Trip NVD VN>1 0x0040,0x0000 Trip NVD VN>2 Trip NVD VN>2 Trip NVD VN>2...
  • Page 317 Relay Menu Database P341/EN GC/D22 MiCOM P341 Page 67/158 TYPE VALUE/BIT MASK DESCRIPTION 0x0000,0x8000 Trip F>2 Trip F>2 Trip F>2 0x0001,0x0000 Trip V/Hz Trip V/Hz 0x0002,0x0000 Trip df/dt 0x0004,0x0000 Trip V Shift 0x0008,0x0000 Trip RTD 1 Trip RTD 1 0x0010,0x0000...
  • Page 318 Relay Menu Database P341/EN GC/D22 MiCOM P341 Page 68/158 TYPE VALUE/BIT MASK DESCRIPTION 0x0000,0x0800 Alarm RTD 5 Alarm RTD 5 0x0000,0x1000 Alarm RTD 6 Alarm RTD 6 0x0000,0x2000 Alarm RTD 7 Alarm RTD 7 0x0000,0x4000 Alarm RTD 8 Alarm RTD 8...
  • Page 319 Relay Menu Database P341/EN GC/D22 MiCOM P341 Page 69/158 TYPE VALUE/BIT MASK DESCRIPTION Group 3 Group 4 A/R Protection Blocking Allow Tripping Block Tripping Lockout No Lockout Lockout Commission Test No Operation Apply Test Remove Test Commission Test No Operation...
  • Page 320 Relay Menu Database P341/EN GC/D22 MiCOM P341 Page 70/158 TYPE VALUE/BIT MASK DESCRIPTION VT Fail Alarm VT Fail Alarm VT Fail Alarm CTS Fail Alarm CTS Fail Alarm CTS Fail Alarm CB Fail CB Fail CB Fail I^ Maint Alarm...
  • Page 321 Relay Menu Database P341/EN GC/D22 MiCOM P341 Page 71/158 TYPE VALUE/BIT MASK DESCRIPTION Miles Copy to No Operation Group 1 Group 2 Group 3 Group 4 CB Control Disabled Local Remote Local+Remote Opto Opto+local Opto+Remote Opto+Rem+local G101 Gen Diff Function Select...
  • Page 322 Relay Menu Database P341/EN GC/D22 MiCOM P341 Page 72/158 TYPE VALUE/BIT MASK DESCRIPTION Volt restrained G104 System Backup Vector Rotation None Delta-Star G105 DEFINITE TIME OVERCURRENT SELECTION Disabled G107 Modbus value+bit pos Started Elements (2) (Second reg, First Reg) P341...
  • Page 323 Relay Menu Database P341/EN GC/D22 MiCOM P341 Page 73/158 TYPE VALUE/BIT MASK DESCRIPTION 0x0020,0x0000 0x0040,0x0000 0x0080,0x0000 0x0100,0x0000 0x0200,0x0000 0x0400,0x0000 0x0800,0x0000 0x1000,0x0000 0x2000,0x0000 0x4000,0x0000 0x8000,0x0000 G108 Bit position RTD Open Circuit Flags RTD 1 label RTD 2 label RTD 3 label...
  • Page 324 Relay Menu Database P341/EN GC/D22 MiCOM P341 Page 74/158 TYPE VALUE/BIT MASK DESCRIPTION RTD 8 label RTD 9 label RTD 10 label G110 Bit position RTD Data Error RTD 1 label RTD 2 label RTD 3 label RTD 4 label...
  • Page 325 Relay Menu Database P341/EN GC/D22 MiCOM P341 Page 75/158 TYPE VALUE/BIT MASK DESCRIPTION Generating Motoring Both G114 SEF/REF/Spower Selection Disabled SEF/REF Sensitive Power G118 CB Control Logic Input Assignments None Both 52A and 52B G119 TEST MODE Disabled Test Mode...
  • Page 326 Relay Menu Database P341/EN GC/D22 MiCOM P341 Page 76/158 TYPE VALUE/BIT MASK DESCRIPTION 30-34V 48-54V 110-125V 220-250V G202 Control Input Status (2 REGISTERS) (2nd Reg, 1st Reg) 0x0000,0x0001 Control Input 1 (0 = Reset, 1 = Set) 0x0000,0x0002 Control Input 2 (0 = Reset, 1 = Set)
  • Page 327 Relay Menu Database P341/EN GC/D22 MiCOM P341 Page 77/158 TYPE VALUE/BIT MASK DESCRIPTION 0x0100,0x0000 Control Input 25 (0 = Reset, 1 = Set) 0x0200,0x0000 Control Input 26 (0 = Reset, 1 = Set) 0x0400,0x0000 Control Input 27 (0 = Reset, 1 = Set)
  • Page 328 Relay Menu Database P341/EN GC/D22 MiCOM P341 Page 78/158 IEC60870-5-103: Device Profile Vendor Name: Alstom T&D Ltd., Protection & Control P340 Generator Protection Device Name: Models Covered: P341****3**05** P342****3**05** P343****3**05** Compatibility Level: Physical Layer Electrical Interface: EIA RS-485 Number of Loads:...
  • Page 329 Relay Menu Database P341/EN GC/D22 MiCOM P341 Page 79/158 Model Number ASDU TYPE Description Interpretation DDB Ordinal 1,7,9 Earth Fault Fwd 1,7,9 Earth Fault Rev Fault Indications 1,7,9 Start /pickup L1 1st Stage O/C Start A 1,7,9 Start /pickup L2...
  • Page 330 Relay Menu Database P341/EN GC/D22 MiCOM P341 Page 80/158 Model Number ASDU TYPE Description Interpretation DDB Ordinal Compatible Range Information Numbers in Control Direction Model Number ASDU TYPE Description Interpretation DDB Ordinal System Functions Init General Interrogation Time Synchronisation General Commands...
  • Page 331 Relay Menu Database P341/EN GC/D22 MiCOM P341 Page 81/158 Model Number ASDU TYPE Description Interpretation DDB Ordinal 1,7,9 Contact 9 Output Relay 9 1,7,9 Contact 10 Output Relay 10 1,7,9 Contact 11 Output Relay 11 1,7,9 Contact 12 Output Relay 12...
  • Page 332 Relay Menu Database P341/EN GC/D22 MiCOM P341 Page 82/158 Model Number ASDU TYPE Description Interpretation DDB Ordinal LED 2 Programmable LED 2 LED 3 Programmable LED 3 LED 4 Programmable LED 4 LED 5 Programmable LED 5 LED 6 Programmable LED 6...
  • Page 333 Relay Menu Database P341/EN GC/D22 MiCOM P341 Page 83/158 Model Number ASDU TYPE Description Interpretation DDB Ordinal Input to Relay Output 160 Relay Cond 1 Condition Input to Relay Output 161 Relay Cond 2 Condition Input to Relay Output Any Trip...
  • Page 334 Relay Menu Database P341/EN GC/D22 MiCOM P341 Page 84/158 Model Number ASDU TYPE Description Interpretation DDB Ordinal Input to Relay Output 168 Relay Cond 9 Condition Input to Relay Output 169 Relay Cond 10 Condition Input to Relay Output 170 Relay Cond 11...
  • Page 335 Relay Menu Database P341/EN GC/D22 MiCOM P341 Page 85/158 Model Number ASDU TYPE Description Interpretation DDB Ordinal 224 Timer in 1 Input to Auxiliary Timer 1 225 Timer in 2 Input to Auxiliary Timer 2 226 Timer in 3 Input to Auxiliary Timer 3...
  • Page 336 Relay Menu Database P341/EN GC/D22 MiCOM P341 Page 86/158 Model Number ASDU TYPE Description Interpretation DDB Ordinal Fault REC TRIG Trigger for Fault Recorder Setting Group via opto invalid 1,7,9 SG-opto Invalid Alarm 9,11 Prot'n Disabled Test Mode Enabled Alarm...
  • Page 337 Relay Menu Database P341/EN GC/D22 MiCOM P341 Page 87/158 Model Number ASDU TYPE Description Interpretation DDB Ordinal 1,7,9 Voltage Prot Alm Voltage protection alarm 1,7,9 User Alarm 1 User settable alarm 1 1,7,9 User Alarm 2 User settable alarm 2...
  • Page 338 Relay Menu Database P341/EN GC/D22 MiCOM P341 Page 88/158 Model Number ASDU TYPE Description Interpretation DDB Ordinal 111 Init Close CB Logic Input Close CB Block Residual Overvoltage 112 VN>1 Timer Blk Stage 1 time delay Block Residual Overvoltage 113 VN>2 Timer Blk...
  • Page 339 Relay Menu Database P341/EN GC/D22 MiCOM P341 Page 89/158 Model Number ASDU TYPE Description Interpretation DDB Ordinal 159 Test Mode Input To Initiate Test Mode 160 100% ST EF Trip 100% Stator Earth Fault Trip 161 DeadMachine Trip Dead machine protection Trip...
  • Page 340 Relay Menu Database P341/EN GC/D22 MiCOM P341 Page 90/158 Model Number ASDU TYPE Description Interpretation DDB Ordinal 2nd Stage Phase U/V Trip 202 V<2 Trip A/AB A/AB 2nd Stage Phase U/V Trip 203 V<2 Trip B/BC B/BC 2nd Stage Phase U/V Trip 204 V<2 Trip C/CA...
  • Page 341 Relay Menu Database P341/EN GC/D22 MiCOM P341 Page 91/158 Model Number ASDU TYPE Description Interpretation DDB Ordinal Under Impedance Stage 1 247 Z<1 Trip C Trip C Under Impedance Stage 2 248 Z<2 Trip Trip 3 Ph Under Impedance Stage 2 249 Z<2 Trip A...
  • Page 342 Relay Menu Database P341/EN GC/D22 MiCOM P341 Page 92/158 Model Number ASDU TYPE Description Interpretation DDB Ordinal 1,7,9 Any Start Any Start 1,7,9 VN>1 Start 1st Stage Residual O/V Start 1,7,9 VN>2 Start 2nd Stage Residual O/V Start 1,7,9 V<1 Start...
  • Page 343 Relay Menu Database P341/EN GC/D22 MiCOM P341 Page 93/158 Model Number ASDU TYPE Description Interpretation DDB Ordinal 1,7,9 I>2 Start C 2nd Stage O/C Start C 1,7,9 I>3 Start 3rd Stage O/C Start 3ph 1,7,9 I>3 Start A 3rd Stage O/C Start A 1,7,9 I>3 Start B...
  • Page 344 Relay Menu Database P341/EN GC/D22 MiCOM P341 Page 94/158 Model Number ASDU TYPE Description Interpretation DDB Ordinal Pole Slip (impedance) Blinder 1,7,9 136 PSlipz BlindStrt Start Pole Slip (impedance) 1,7,9 137 PSlipz ReactStrt Reactance Line Start Under Impedance Stage 1 1,7,9 138 Z<1 Start...
  • Page 345 Relay Menu Database P341/EN GC/D22 MiCOM P341 Page 95/158 Model Number ASDU TYPE Description Interpretation DDB Ordinal 224 VTS Fast Block VTS Fast Block 225 VTS Slow Block VTS Slow Block 226 CTS Block CTS Block 227 Control Trip Control Trip...
  • Page 346 Relay Menu Database P341/EN GC/D22 MiCOM P341 Page 96/158 Model Number ASDU TYPE Description Interpretation DDB Ordinal 1,7,9 244 Field volts fail Field Voltage Failure 245 All Poles Dead All Poles Dead 246 Any Pole Dead Any Pole Dead 247 Pole Dead A...
  • Page 347 Relay Menu Database P341/EN GC/D22 MiCOM P341 Page 97/158 Model Number ASDU TYPE Description Interpretation DDB Ordinal 9,11,12,20,21 Control Input 1 Control Input 9,11,12,20,21 Control Input 2 Control Input 9,11,12,20,21 Control Input 3 Control Input 9,11,12,20,21 Control Input 4 Control Input...
  • Page 348 Relay Menu Database P341/EN GC/D22 MiCOM P341 Page 98/158 Model Number ASDU TYPE Description Interpretation DDB Ordinal GOOSE VIP 3 GOOSE VIP 4 100 GOOSE VIP 5 101 GOOSE VIP 6 102 GOOSE VIP 7 103 GOOSE VIP 8 104 GOOSE VIP 9...
  • Page 349 Relay Menu Database P341/EN GC/D22 MiCOM P341 Page 99/158 Model Number ASDU TYPE Description Interpretation DDB Ordinal 155 Direct Ctrl 4 156 Direct Ctrl 5 157 Direct Ctrl 6 158 Direct Ctrl 7 159 Direct Ctrl 8 160 PSL Int. 1 PSL Internal Node 1 161 PSL Int.
  • Page 350 Relay Menu Database P341/EN GC/D22 MiCOM P341 Page 100/158 Model Number ASDU TYPE Description Interpretation DDB Ordinal 212 PSL Int. 53 PSL Internal Node 53 213 PSL Int. 54 PSL Internal Node 54 214 PSL Int. 55 PSL Internal Node 55 215 PSL Int.
  • Page 351 Relay Menu Database P341/EN GC/D22 MiCOM P341 Page 101/158 Model Number ASDU TYPE Description Interpretation DDB Ordinal Control Input 12 Control Input Control Input 13 Control Input Control Input 14 Control Input Control Input 15 Control Input Control Input 16...
  • Page 352 Relay Menu Database P341/EN GC/D22 MiCOM P341 Page 102/158 Digital Data Bus English Text DDB No. Source Description P341 P342 P343 0123456789ABCDEF Output Condition Output Relay 1 see 4B01 Output Condition Output Relay 2 see 4B02 Output Condition Output Relay 3...
  • Page 353 Relay Menu Database P341/EN GC/D22 MiCOM P341 Page 103/158 English Text DDB No. Source Description P341 P342 P343 0123456789ABCDEF OPTO Opto Input 17 see 4A11 OPTO Opto Input 18 see 4A12 OPTO Opto Input 19 see 4A13 OPTO Opto Input 20...
  • Page 354 Relay Menu Database P341/EN GC/D22 MiCOM P341 Page 104/158 English Text DDB No. Source Description P341 P342 P343 0123456789ABCDEF UNUSED UNUSED UNUSED UNUSED UNUSED UNUSED UNUSED UNUSED UNUSED UNUSED UNUSED UNUSED UNUSED UNUSED UNUSED UNUSED UNUSED UNUSED UNUSED UNUSED UNUSED...
  • Page 355 Relay Menu Database P341/EN GC/D22 MiCOM P341 Page 105/158 English Text DDB No. Source Description P341 P342 P343 0123456789ABCDEF UNUSED UNUSED UNUSED UNUSED UNUSED UNUSED UNUSED UNUSED UNUSED UNUSED UNUSED UNUSED Input to Relay Output Condition Relay Cond 1 Input to Relay Output Condition...
  • Page 356 Relay Menu Database P341/EN GC/D22 MiCOM P341 Page 106/158 English Text DDB No. Source Description P341 P342 P343 0123456789ABCDEF UNUSED UNUSED UNUSED UNUSED UNUSED UNUSED UNUSED UNUSED UNUSED UNUSED UNUSED UNUSED UNUSED UNUSED UNUSED UNUSED UNUSED UNUSED UNUSED UNUSED UNUSED...
  • Page 357 Relay Menu Database P341/EN GC/D22 MiCOM P341 Page 107/158 English Text DDB No. Source Description P341 P342 P343 0123456789ABCDEF UNUSED UNUSED UNUSED UNUSED UNUSED UNUSED UNUSED UNUSED Auxiliary Timer Output from Auxiliary Timer 1 Timer out 1 Auxiliary Timer Output from Auxiliary Timer 2...
  • Page 358 Relay Menu Database P341/EN GC/D22 MiCOM P341 Page 108/158 English Text DDB No. Source Description P341 P342 P343 0123456789ABCDEF CB Monitoring No of CB Ops Maintenance Lockout CB Ops Lockout CB Monitoring Excessive CB Op Time Maintenance Alarm CB Op Time Maint...
  • Page 359 Relay Menu Database P341/EN GC/D22 MiCOM P341 Page 109/158 English Text DDB No. Source Description P341 P342 P343 0123456789ABCDEF UNUSED UNUSED UNUSED UNUSED UNUSED Block Voltage Dependent time delay VDepOC Timer Blk Block Under Impedance time delay UnderZ Timer Blk Block Phase O/C Stage 1 time delay I>1 Timer Block...
  • Page 360 Relay Menu Database P341/EN GC/D22 MiCOM P341 Page 110/158 English Text DDB No. Source Description P341 P342 P343 0123456789ABCDEF UNUSED UNUSED UNUSED UNUSED UNUSED UNUSED UNUSED UNUSED UNUSED UNUSED UNUSED UNUSED UNUSED UNUSED UNUSED UNUSED UNUSED UNUSED Input To Initiate Test Mode...
  • Page 361 Relay Menu Database P341/EN GC/D22 MiCOM P341 Page 111/158 English Text DDB No. Source Description P341 P342 P343 0123456789ABCDEF Restricted Earth Fault REF Trip IREF> Trip Sensitive Earth Fault 1st Stage SEF Trip ISEF>1 Trip Sensitive Earth Fault 2nd Stage SEF Trip ISEF>2 Trip...
  • Page 362 Relay Menu Database P341/EN GC/D22 MiCOM P341 Page 112/158 English Text DDB No. Source Description P341 P342 P343 0123456789ABCDEF Sensitive Power Sensitive A Phase Power Stage 2 Trip SPower2 Trip Z based Pole Slipping Pole Slip (Impedance) Zone1 Trip PSlipz Z1 Trip...
  • Page 363 Relay Menu Database P341/EN GC/D22 MiCOM P341 Page 113/158 English Text DDB No. Source Description P341 P342 P343 0123456789ABCDEF UNUSED UNUSED UNUSED UNUSED UNUSED UNUSED UNUSED UNUSED UNUSED UNUSED UNUSED UNUSED UNUSED UNUSED UNUSED UNUSED UNUSED UNUSED UNUSED UNUSED UNUSED...
  • Page 364 Relay Menu Database P341/EN GC/D22 MiCOM P341 Page 114/158 English Text DDB No. Source Description P341 P342 P343 0123456789ABCDEF Power Power stage 1 start Power2 Start Over Current 1st Stage O/C Start 3ph I>1 Start Over Current 1st Stage O/C Start A I>1 Start A...
  • Page 365 Relay Menu Database P341/EN GC/D22 MiCOM P341 Page 115/158 English Text DDB No. Source Description P341 P342 P343 0123456789ABCDEF Z based Pole Slipping Pole Slip (Impedance) Zone2 Start PSlipz Z2 Start Z based Pole Slipping Pole Slip (impedance) Lens Start...
  • Page 366 Relay Menu Database P341/EN GC/D22 MiCOM P341 Page 116/158 English Text DDB No. Source Description P341 P342 P343 0123456789ABCDEF UNUSED UNUSED UNUSED UNUSED UNUSED UNUSED UNUSED UNUSED UNUSED UNUSED UNUSED UNUSED UNUSED UNUSED UNUSED UNUSED UNUSED UNUSED UNUSED UNUSED UNUSED...
  • Page 367 Relay Menu Database P341/EN GC/D22 MiCOM P341 Page 117/158 English Text DDB No. Source Description P341 P342 P343 0123456789ABCDEF RTD Thermal RTD 4 Alarm RTD 4 Alarm RTD Thermal RTD 5 Alarm RTD 5 Alarm RTD Thermal RTD 6 Alarm...
  • Page 368 Relay Menu Database P341/EN GC/D22 MiCOM P341 Page 118/158 English Text DDB No. Source Description P341 P342 P343 0123456789ABCDEF UNUSED UNUSED UNUSED UNUSED UNUSED UNUSED UNUSED UNUSED UNUSED UNUSED UNUSED UNUSED UNUSED UNUSED UNUSED UNUSED UNUSED UNUSED UNUSED UNUSED UNUSED...
  • Page 369 Relay Menu Database P341/EN GC/D22 MiCOM P341 Page 119/158 English Text DDB No. Source Description P341 P342 P343 0123456789ABCDEF CONTROL Control Input Control Input 15 CONTROL Control Input Control Input 16 CONTROL Control Input Control Input 17 CONTROL Control Input...
  • Page 370 Relay Menu Database P341/EN GC/D22 MiCOM P341 Page 120/158 English Text DDB No. Source Description P341 P342 P343 0123456789ABCDEF UNUSED GOOSE VOP 1 UNUSED GOOSE VOP 2 UNUSED GOOSE VOP 3 UNUSED GOOSE VOP 4 UNUSED GOOSE VOP 5 UNUSED...
  • Page 371 Relay Menu Database P341/EN GC/D22 MiCOM P341 Page 121/158 English Text DDB No. Source Description P341 P342 P343 0123456789ABCDEF PSLINT PSL Internal Node 19 PSL Int. 19 PSLINT PSL Internal Node 20 PSL Int. 20 PSLINT PSL Internal Node 21 PSL Int.
  • Page 372 Relay Menu Database P341/EN GC/D22 MiCOM P341 Page 122/158 English Text DDB No. Source Description P341 P342 P343 0123456789ABCDEF PSLINT PSL Internal Node 69 PSL Int. 69 PSLINT PSL Internal Node 70 PSL Int. 70 PSLINT PSL Internal Node 71 PSL Int.
  • Page 373 P341/EN GC/D22 Rel ay M enu D at abase Page 123/158 M i C O M P341 Event Record Data Format Modbus Additional Courier Event Text Event Description Event Type Value DDB No. P341 P342 P343 Text Cell Ref Binary Flag (24 bits) Logic Inputs Changes in opto input status 0020...
  • Page 374 P341/EN GC/D22 Rel ay M enu D at abase Page 124/158 M i C O M P341 Modbus Additional Courier Event Text Event Description Event Type Value DDB No. P341 P342 P343 Text Cell Ref Man CB Trip Fail ON/OFF CB Failed to Trip 0022 Man CB Cls Fail...
  • Page 375 P341/EN GC/D22 Rel ay M enu D at abase Page 125/158 M i C O M P341 Modbus Additional Courier Event Text Event Description Event Type Value DDB No. P341 P342 P343 Text Cell Ref Gen Diff Trip B ON/OFF Generator Differential Trip B 0F2D Gen Diff Trip C...
  • Page 376 P341/EN GC/D22 Rel ay M enu D at abase Page 126/158 M i C O M P341 Modbus Additional Courier Event Text Event Description Event Type Value DDB No. P341 P342 P343 Text Cell Ref IN>3 Trip ON/OFF 3rd Stage EF Trip 0F2D IN>4 Trip ON/OFF...
  • Page 377 P341/EN GC/D22 Rel ay M enu D at abase Page 127/158 M i C O M P341 Modbus Additional Courier Event Text Event Description Event Type Value DDB No. P341 P342 P343 Text Cell Ref F<1 Trip ON/OFF Under frequency Stage 1 trip 0F2E F<2 Trip ON/OFF...
  • Page 378 P341/EN GC/D22 Rel ay M enu D at abase Page 128/158 M i C O M P341 Modbus Additional Courier Event Text Event Description Event Type Value DDB No. P341 P342 P343 Text Cell Ref Bfail2 Trip 3ph ON/OFF tBF2 Trip 3Ph 0F2F SPower1 Trip ON/OFF...
  • Page 379 P341/EN GC/D22 Rel ay M enu D at abase Page 129/158 M i C O M P341 Modbus Additional Courier Event Text Event Description Event Type Value DDB No. P341 P342 P343 Text Cell Ref V>1 Start ON/OFF 1st Stage Phase O/V Start 3ph 0F32 V>1 Start A/AB ON/OFF...
  • Page 380 P341/EN GC/D22 Rel ay M enu D at abase Page 130/158 M i C O M P341 Modbus Additional Courier Event Text Event Description Event Type Value DDB No. P341 P342 P343 Text Cell Ref I>4 Start C ON/OFF 4th Stage O/C Start C 0F33 IN>1 Start ON/OFF...
  • Page 381 P341/EN GC/D22 Rel ay M enu D at abase Page 131/158 M i C O M P341 Modbus Additional Courier Event Text Event Description Event Type Value DDB No. P341 P342 P343 Text Cell Ref V/Hz Start ON/OFF Volts per Hz Start 0F33 FFail1 Start ON/OFF...
  • Page 382 P341/EN GC/D22 Rel ay M enu D at abase Page 132/158 M i C O M P341 Modbus Additional Courier Event Text Event Description Event Type Value DDB No. P341 P342 P343 Text Cell Ref RTD 1 Alarm ON/OFF RTD 1 Alarm 0F37 RTD 2 Alarm ON/OFF...
  • Page 383 P341/EN GC/D22 Rel ay M enu D at abase Page 133/158 M i C O M P341 Modbus Additional Courier Event Text Event Description Event Type Value DDB No. P341 P342 P343 Text Cell Ref PW2 Modified F Password Level 2 Modified on Front Port 0002 PW Expired F Password unlock expired Front Port...
  • Page 384 P341/EN GC/D22 Rel ay M enu D at abase Page 134/158 M i C O M P341 Modbus Additional Courier Event Text Event Description Event Type Value DDB No. P341 P342 P343 Text Cell Ref Battery Failure Battery Failure BBRAM Failure Battery Back RAM Failure Field Volt Fail Field Voltage Failure...
  • Page 385 Relay Menu Database P341/EN GC/D22 MiCOM P341 Page 135/158 DNP 3.0 Device Profile Document Alstom T&D Protection & Control Ltd. P340 Generator Protection P341***A4**04** P342****4**04* P343****4**04* Level 2 Level 2 Slave For static (non-change-event) object requests, request qualifier codes 00 and 01 (start-stop), 07 and 08 (limited quantity), and 17 and 28 (index) are supported in addition to request qualifier code 06 (no range).
  • Page 386 P341/EN GC/D22 Relay Menu Database Page 136/158 MiCOM P341 Fixed at 100ms None Fixed at 1s None Inter-character Delay: 4 character times at selected baud rate. Select/Operate Arm Timeout: default 10s. Need Time Interval: configurable, 0 or 30min. Never Always...
  • Page 387 Relay Menu Database P341/EN GC/D22 MiCOM P341 Page 137/158 Object Request Response Object Variation Description Function Qualifier Function Qualifier Number Number Codes (dec) Codes (hex) Codes (dec) Codes (hex)
  • Page 388 P341/EN GC/D22 Relay Menu Database Page 138/158 MiCOM P341 Object Request Response Object Variation Description Function Qualifier Function Qualifier Number Number Codes (dec) Codes (hex) Codes (dec) Codes (hex)
  • Page 389 Relay Menu Database P341/EN GC/D22 MiCOM P341 Page 139/158 Binary Input Points 1 (Binary Input without status) 2 (Binary Input Change with Time) P341 P342 P343 Name / Description Change Event Initial Point Point Point Assigned Value Index Index Index...
  • Page 390 P341/EN GC/D22 Relay Menu Database Page 140/158 MiCOM P341 P341 P342 P343 Name / Description Change Event Initial Point Point Point Assigned Value Index Index Index Class (1, 2, 3) Alarm & Event indications...
  • Page 391 Relay Menu Database P341/EN GC/D22 MiCOM P341 Page 141/158 P341 P342 P343 Name / Description Change Event Initial Point Point Point Assigned Value Index Index Index Class (1, 2, 3) Miscellaneous Indications Protection Operation Signals...
  • Page 392 P341/EN GC/D22 Relay Menu Database Page 142/158 MiCOM P341 P341 P342 P343 Name / Description Change Event Initial Point Point Point Assigned Value Index Index Index Class (1, 2, 3)
  • Page 393 Relay Menu Database P341/EN GC/D22 MiCOM P341 Page 143/158 P341 P342 P343 Name / Description Change Event Initial Point Point Point Assigned Value Index Index Index Class (1, 2, 3)
  • Page 394 P341/EN GC/D22 Relay Menu Database Page 144/158 MiCOM P341 P341 P342 P343 Name / Description Change Event Initial Point Point Point Assigned Value Index Index Index Class (1, 2, 3)
  • Page 395 Relay Menu Database P341/EN GC/D22 MiCOM P341 Page 145/158 P341 P342 P343 Name / Description Change Event Initial Point Point Point Assigned Value Index Index Index Class (1, 2, 3)
  • Page 396 P341/EN GC/D22 Relay Menu Database Page 146/158 MiCOM P341 P341 P342 P343 Name / Description Change Event Initial Point Point Point Assigned Value Index Index Index Class (1, 2, 3) CB Status...
  • Page 397 Relay Menu Database P341/EN GC/D22 MiCOM P341 Page 147/158 Binary Output Status Points 1(read) 2 (Binary Output Status) Control Relay Output Blocks 3 (select), 4 (operate), 5 (direct operate), 6 (direct operate, noack) P341 P342 P343 Name / Description Supported Control...
  • Page 398 P341/EN GC/D22 Relay Menu Database Page 148/158 MiCOM P341 P341 P342 P343 Name / Description Supported Control Point Point Point Relay Output Block Index Index Index Fields Pulse Latch · · · ·...
  • Page 399 Relay Menu Database P341/EN GC/D22 MiCOM P341 Page 149/158 Binary Counter Points 1(read), 7(freeze), 8(freeze noack), 9(freeze and clear), 10(freeze and clear, noack) (32-Bit Binary Counter without Flag) Frozen Counter Points 1 (read) (32-Bit Binary Counter without Flag) P341 P342...
  • Page 400 P341/EN GC/D22 Relay Menu Database Page 150/158 MiCOM P341 Analog Inputs P341 P342 P343 Name / Description Data Valid Range Default Change Event Point Point Point Type Deadband Assigned Index Index Index Class (1, 2, 3) Active Group MEASUREMENTS 1...
  • Page 401 Relay Menu Database P341/EN GC/D22 MiCOM P341 Page 151/158 P341 P342 P343 Name / Description Data Valid Range Default Change Event Point Point Point Type Deadband Assigned Index Index Index Class (1, 2, 3) MEASUREMENTS 2...
  • Page 402 P341/EN GC/D22 Relay Menu Database Page 152/158 MiCOM P341 P341 P342 P343 Name / Description Data Valid Range Default Change Event Point Point Point Type Deadband Assigned Index Index Index Class (1, 2, 3) MEASUREMENTS 3...
  • Page 403 Data Types Data Name / Description Scaling Default Change Event Change Event Change Event Standard Numeric Units Type Change Deadband Min Deadband Max Deadband Step Range Event Deadband...
  • Page 404 P341/EN GC/D22 Relay Menu Database Page 154/158 MiCOM P341 MiCOM P341 PROGRAMMABLE SCHEME LOGIC Opto Input Mappings IN>3 Timer Blk DDB #360 L3 Block IN>3&4 DDB #034 IN>4 Timer Blk DDB #361 I>3 Timer Block DDB #356 L4 Block I>3&4 DDB #035 I>4 Timer Block...
  • Page 405 Relay Menu Database P341/EN GC/D22 MiCOM P341 Page 155/158 MiCOM P341 PROGRAMMABLE SCHEME LOGIC Output Relay Mappings df/dt Trip DDB #440 V Shift Trip DDB #441 IN>1 Trip DDB #442 IN>2 Trip DDB #443 IN>3 Trip DDB #444 IN>4 Trip DDB #445 IREF>...
  • Page 406 P341/EN GC/D22 Relay Menu Database Page 156/158 MiCOM P341 MiCOM P341 PROGRAMMABLE SCHEME LOGIC Output Relay Mappings IN/SEF>Blk Start R1 IN>1 Start Straight DDB #629 DDB #000 I> BlockStart R2 I>1 Start Straight DDB #628 DDB #001 SG-opto Invalid DDB #290...
  • Page 407 Relay Menu Database P341/EN GC/D22 MiCOM P341 Page 157/158 MiCOM P341 PROGRAMMABLE SCHEME LOGIC LED Mappings IN>1 Trip DDB #442 IN>2 Trip DDB #443 IN>3 Trip DDB #444 IN>4 Trip DDB #445 ISEF>1 Trip DDB #447 Latching LED 1 ISEF>2 Trip...
  • Page 408 P341/EN GC/D22 Relay Menu Database Page 158/158 MiCOM P341...
  • Page 409 External Connection P341/EN CO/D22 Diagrams MiCOM P341 EXTERNAL CONNECTION DIAGRAMS...
  • Page 410 P341/EN CO/D22 External Connection Diagrams MiCOM P341...
  • Page 411 External Connection P341/EN CO/D22 Diagrams MiCOM P341 Page 1/8 P2139ENb Figure 1: Comms Options MiCOM Px40 Platform...
  • Page 412 P341/EN CO/D22 External Connection Diagrams Page 2/8 MiCOM P341 P2234ENa Figure 2: Interconnection Protection Relay (40TE) for Embedded Generation Using VEE Connected VT's (8 I/P & 7 O/P)
  • Page 413 External Connection P341/EN CO/D22 Diagrams MiCOM P341 Page 3/8 P2232ENa Figure 3: Interconnection Protection Relay (40TE) Embedded Generation (8 I/P & 7 O/P)
  • Page 414 P341/EN CO/D22 External Connection Diagrams Page 4/8 MiCOM P341 P2233ENa Figure 4: Interconnection Protection Relay (40TE) Embedded Generation (8 I/P & 7 O/P)
  • Page 415 External Connection P341/EN CO/D22 Diagrams MiCOM P341 Page 5/8 P2236ENa Figure 5: Interconnection Protection Relay (40TE) Embedded Generation (8 I/P & 15 O/P)
  • Page 416 P341/EN CO/D22 External Connection Diagrams Page 6/8 MiCOM P341 P2235ENa Figure 6: Interconnection Protection Relay (40TE) Embedded Generation (16 I/P & 7 O/P)
  • Page 417 External Connection P341/EN CO/D22 Diagrams MiCOM P341 Page 7/8 P2237ENa Figure 7: Interconnection Protection Relay (40TE) Embedded Generation (12 I/P & 11 O/P)
  • Page 418 P341/EN CO/D22 External Connection Diagrams Page 8/8 MiCOM P341...
  • Page 419 Hardware/Software Version P341/EN VC/C22 History and Compatibility MiCOM P341 HARDWARE / SOFTWARE VERSION HISTORY AND COMPATIBILITY (Note: Includes versions released and supplied to customers only)
  • Page 420 P341/EN VC/C22 Hardware/Software Version History and Compatibility MiCOM P341...
  • Page 421 Relay type: P341….. Backward Compatibility Software Date of Full Description of Changes S1 Compatibility Menu Text Version Issue Setting Files Files 11/10/1999 First release to Production V1.09 Refer to manual reference TG8617A for software version 01. 19/10/2000 Released to production V1.10 ü...
  • Page 422 Relay type: P341….. Backward Compatibility Software Date of Full Description of Changes S1 Compatibility Menu Text Version Issue Setting Files Files 04/12/01 Released to production V2.02a ü Includes sensitive reverse power ü Neutral voltage displacement threshold, VN>1/2, increased from 50 to 80 V (100/120 V), 200 to 320 (380/480V) ü...
  • Page 423 Relay type: P341….. Backward Compatibility Software Date of Full Description of Changes S1 Compatibility Menu Text Version Issue Setting Files Files ü PSL Data menu included with PSL Reference information for version history ü Optional additional opto inputs and output contacts with a larger case size option available ü...
  • Page 424 P341/EN VC/C22 Hardware/Software Version History and Compatibility Page 4 MiCOM P341...
  • Page 425 TRANSMISSION & DISTRIBUTION Energy Automation & Information energy.automation-information@areva-td.com www.areva.com...

Table of Contents

Save PDF
