Page 1 MiCOM P341 Interconnection Protection Relay Operation Guide P341/EN O/B11...
Page 3 Operation Guide MiCOM P341 Interconnection Protection Relay Volume 2...
Page 5 Operation Guide P341/EN O/A11 Issue Control MiCOM P341 ISSUE B Amendments completed 15.03.2002 Description Chapter Section Page Issue control New section added Safety section Section 6 : Second line of paragraph amended Front panel 3.1.1 Last sentence added to paragraph 2...
Page 6 P341/EN O/A11 Operation Guide Issue Control MiCOM P341...
Page 7 Operation Guide P341/EN O/B11 MiCOM P341 INTERCONNECTION PROTECTION RELAY MICOM P341 CONTENT Handling of Electronic Equipment Safety Section Introduction Chapter 1 Installation Chapter 2 Includes publication P341/EN BR/Bc, P341 Interconnection Protection Relay Commissioning and Maintenance Chapter 3 Problem Analysis Chapter 4...
Page 8 P341/EN O/B11 Operation Guide MiCOM P341...
Page 9 HANDLING OF ELECTRONIC EQUIPMENT A person’s normal movements can easily generate electrostatic potentials of several thousand volts. Discharge of these voltages into semiconductor devices when handling circuits can cause serious damage, which often may not be immediately apparent but the reliability of the circuit will have been reduced. The electronic circuits of ALSTOM T&D Protection &...
Page 11: Table Of Contents
CONTENT SAFETY SECTION Health and Safety Explanation of symbols and labels INSTALLING, COMMISSIONING AND SERVICING EQUIPMENT OPERATING CONDITIONS Current transformer circuits External resistors Battery Replacement Insulation and dielectric strength testing Insertion of modules and pcb cards Fibre optic communication OLDER PRODUCTS DECOMMISSIONING AND DISPOSAL TECHNICAL SPECIFICATIONS...
Page 13: Safety Section
SAFETY SECTION This Safety Section should be read before commencing any work on the equipment. Health and Safety The information in the Safety Section of the product documentation is intended to ensure that products are properly installed and handled in order to maintain them in a safe condition.
Page 14: Equipment Operating Conditions
Voltage and current connections should be made using insulated crimp terminations to ensure that terminal block insulation requirements are maintained for safety. To ensure that wires are correctly terminated, the correct crimp terminal and tool for the wire size should be used. Before energising the equipment it must be earthed using the protective earth terminal, or the appropriate termination of the supply plug in the case of plug connected equipment.
Page 15: Older Products
OLDER PRODUCTS Electrical adjustments Equipments which require direct physical adjustments to their operating mechanism to change current or voltage settings, should have the electrical power removed before making the change, to avoid any risk of electrical shock. Mechanical adjustments The electrical power to the relay contacts should be removed before checking any mechanical settings, to avoid any risk of electric shock.
Page 16: Technical Specifications
TECHNICAL SPECIFICATIONS Protective fuse rating The recommended maximum rating of the external protective fuse for this equipment is 16A, Red Spot type or equivalent, unless otherwise stated in the technical data section of the product documentation. Insulation class: IEC 601010-1 : 1990/A2 : 1995 This equipment requires a Class I protective (safety) earth...
Page 17 Operation Guide P341/EN O/B11 MiCOM P341 CHAPTER 1 Introduction...
Page 18 P341/EN O/B11 Operation Guide MiCOM P341...
Page 19 Operation Guide P341/EN O/B11 Introduction CHAPTER 1 MiCOM P341 Page 1/22 CONTENT INTRODUCTION TO MICOM INTRODUCTION TO MiCOM GUIDES USER INTERFACES AND MENU STRUCTURE Introduction to the relay 3.1.1 Front panel 3.1.2 Relay rear panel Introduction to the user interfaces and settings options Menu structure 3.3.1...
Page 20 P341/EN O/B11 Operation Guide CHAPTER 1 Introduction Page 2/22 MiCOM P341 Figure 1: Relay front view Figure 2: Relay Rear View Figure 3: Menu Structure Figure 4: Front Panel User Interface Figure 5: Front Port Connection Figure 6: Pc – Relay Signal Connection...
Page 21: Introduction To Micom
Operation Guide P341/EN O/B11 Introduction CHAPTER 1 MiCOM P341 Page 3/22 INTRODUCTION TO MICOM MiCOM is a comprehensive solution capable of meeting all electricity supply requirements. It comprises a range of components, systems and services from ALSTOM. Central to the MiCOM concept is flexibility.
Page 22 P341/EN O/B11 Operation Guide CHAPTER 1 Introduction Page 4/22 MiCOM P341 The chapter content within each volume is summarised below: Volume 1 Technical Guide Handling of Electronic Equipment Safety Section Chapter 1 Introduction A guide to the different user interfaces of the protection relay describing how to start using the relay.
Page 23: User Interfaces And Menu Structure
Operation Guide P341/EN O/B11 Introduction CHAPTER 1 MiCOM P341 Page 5/22 Chapter 2 Installation (includes a copy of publication P341/EN BR/Bc) Recommendations on unpacking, handling, inspection and storage of the relay. A guide to the mechanical and electrical installation of the relay is provided incorporating earthing recommendations.
Page 24 P341/EN O/B11 Operation Guide CHAPTER 1 Introduction Page 6/22 MiCOM P341 * , V Ratings Serial N o and Top cover 1/5 A 50/60 Hz SER N o DIAG N o TRIP Fixed ALARM function LEDs OUT OF SERVICE HEALTHY...
Page 25: Relay Rear Panel
Operation Guide P341/EN O/B11 Introduction CHAPTER 1 MiCOM P341 Page 7/22 The fixed function LEDs on the left hand side of the front panel are used to indicate the following conditions: Trip (Red) indicates that the relay has issued a trip signal.
Page 26: Introduction To The User Interfaces And Settings Options
P341/EN O/B11 Operation Guide CHAPTER 1 Introduction Page 8/22 MiCOM P341 Introduction to the user interfaces and settings options The relay has three user interfaces: − the front panel user interface via the LCD and keypad. the front port which supports Courier communication.
Page 27: Menu Structure
Operation Guide P341/EN O/B11 Introduction CHAPTER 1 MiCOM P341 Page 9/22 Column header System data View records Overcurrent Up to 4 protection setting groups Ground fault Overcurrent Ground fault Column header System data View records Up to 4 protection setting groups...
Page 28: Control And Support Settings
P341/EN O/B11 Operation Guide CHAPTER 1 Introduction Page 10/22 MiCOM P341 3.3.3 Control and support settings The control and support settings include: − relay configuration settings open/close circuit breaker* − − CT & VT ratio settings* reset LEDs − −...
Page 29: Relay Configuration
Operation Guide P341/EN O/B11 Introduction CHAPTER 1 MiCOM P341 Page 11/22 the relay’s serial number. The current level of access enabled for an interface can be determined by examining the 'Access level' cell in the 'System data' column. The access level for the front panel User Interface (UI) can also be found as one of the default display options.
Page 30: Default Display And Menu Time-Out
P341/EN O/B11 Operation Guide CHAPTER 1 Introduction Page 12/22 MiCOM P341 System Other default displays 3-phase voltage frequency Alarm messages Date and time Column n Column 1 Column 2 Group 4 Sytem data View records Other column headings Overcurrent Data 1.1 Data 2.1...
Page 31: Menu Navigation And Setting Browsing
Operation Guide P341/EN O/B11 Introduction CHAPTER 1 MiCOM P341 Page 13/22 3.6.2 Menu navigation and setting browsing The menu can be browsed using the four arrow keys, following the structure shown in Figure 4. Thus, starting at the default display the key will display the first column heading.
Page 32: Setting Changes
P341/EN O/B11 Operation Guide CHAPTER 1 Introduction Page 14/22 MiCOM P341 Press clear to reset alarms To clear all alarm messages press ; to return to the alarms/faults present display and leave the alarms uncleared, press Depending on the password configuration settings, it may be necessary to enter a password before the alarm messages can be cleared (see section on password entry).
Page 33 Operation Guide P341/EN O/B11 Introduction CHAPTER 1 MiCOM P341 Page 15/22 MiCOM relay Laptop S K 2 S K 1 25 pin download/monitor port 9 pin Battery front comms port Serial communication port (COM 1 or COM 2) Serial data connector...
Page 34: Rear Communication Port User Interface
P341/EN O/B11 Operation Guide CHAPTER 1 Introduction Page 16/22 MiCOM P341 MiCOM relay Serial data connector Pin 2 Tx Pin 2 Rx Pin 3 Rx Pin 3 Tx Pin 5 0V Pin 5 0V Note: PC connection shown assuming 9 Way serial port...
Page 35 P341/EN O/B11 Introduction CHAPTER 1 MiCOM P341 Page 17/22 The relay is a slave unit which is designed to be used with a Courier master unit such as MiCOM S1, MiCOM S10, PAS&T, ACCESS or a SCADA system. MiCOM S1 is a Windows NT4.0/95 compatible software package which is specifically designed for...
Page 36: Modbus Communication
CHAPTER 1 Introduction Page 18/22 MiCOM P341 Having made the physical connection to the relay, the relay’s communication settings must be configured. To do this use the keypad and LCD user interface. In the relay menu firstly check that the ‘Comms settings’ cell in the ‘Configuration’ column is set to ‘Visible’, then move to the ‘Communications’...
Page 37: Iec 60870-5 Cs 103 Communication
Operation Guide P341/EN O/B11 Introduction CHAPTER 1 MiCOM P341 Page 19/22 ‘Communications’ column from the column heading to the first cell down which indicates the communication protocol: Protocol Modbus The next cell down controls the Modbus address of the relay:...
Page 38 CHAPTER 1 Introduction Page 20/22 MiCOM P341 twisted pair connection over distances up to 1000m. As an option for IEC 60870-5- 103, the rear port can be specified to use a fibre optic connection for direct connection to a master station.
Page 39: Dnp 3.0 Communication
Operation Guide P341/EN O/B11 Introduction CHAPTER 1 MiCOM P341 Page 21/22 The default setting is to select the electrical RS485 connection. If the optional fibre optic connectors are fitted to the relay, then this setting can be changed to ‘Fibre optic’.
Page 40: Micom P341
P341/EN O/B11 Operation Guide CHAPTER 1 Introduction Page 22/22 MiCOM P341 DNP 3.0 communication is asynchronous. Six baud rates are supported by the relay ‘1200bits/s’, ‘2400bits/s’, ‘4800bits/s’, ’9600bits/s’, ‘19200bits/s’ ‘38400bits/s’. It is important that whatever baud rate is selected on the relay is the same as that set on the DNP 3.0 master station.
Page 41 Operation Guide P341/EN O/B11 MiCOM P341 CHAPTER 2 Installation...
Page 42 P341/EN O/B11 Operation Guide MiCOM P341...
Page 43 Operation Guide P341/EN O/B11 Installation CHAPTER 2 MiCOM P341 Page 1/10 CONTENT RECEIPT OF RELAYS HANDLING OF ELECTRONIC EQUIPMENT STORAGE UNPACKING RELAY MOUNTING Rack mounting Panel mounting RELAY WIRING Medium and heavy duty terminal block connections RS485 port RTD connections (if applicable)
Page 44 P341/EN O/B11 Operation Guide CHAPTER 2 Installation Page 2/10 MiCOM P341...
Page 45: Receipt Of Relays
Operation Guide P341/EN O/B11 Installation CHAPTER 2 MiCOM P341 Page 3/10 RECEIPT OF RELAYS Protective relays, although generally of robust construction, require careful treatment prior to installation on site. Upon receipt, relays should be examined immediately to ensure no external damage has been sustained in transit.
Page 46: Storage
Operation Guide CHAPTER 2 Installation Page 4/10 MiCOM P341 STORAGE If relays are not to be installed immediately upon receipt, they should be stored in a place free from dust and moisture in their original cartons. Where de-humidifier bags have been included in the packing they should be retained. The action of the...
Page 47: Rack Mounting
Operation Guide P341/EN O/B11 Installation CHAPTER 2 MiCOM P341 Page 5/10 the correct test block to be easily identified during commissioning and maintenance tests. Figure 1: Location of battery isolation strip If it is necessary to test correct relay operation during the installation, the battery isolation strip can be removed but should be replaced if commissioning of the scheme is not imminent.
Page 48 Operation Guide CHAPTER 2 Installation Page 6/10 MiCOM P341 Figure 2: Rack mounting of relays Relays can be mechanically grouped into single tier (4U) or multi-tier arrangements by means of the rack frame. This enables schemes using products from the MiCOM and MiDOS product ranges to be pre-wired together prior to mounting.
Page 49: Panel Mounting
Operation Guide P341/EN O/B11 Installation CHAPTER 2 MiCOM P341 Page 7/10 Part Number Nominal Rating Operative Range GJ0229 006 110Vdc 87 to 150Vdc GJ0229 007 220Vdc 175 to 300Vdc Table 2: External resistor boxes If external resistor boxes are being used, they must be mounted vertically. Each resistor box can be fastened to a suitably drilled blanking plate at least 10TE wide using two M4 screws.
Page 50: Relay Wiring
CHAPTER 2 Installation Page 8/10 MiCOM P341 If it is required to mount a relay assembly on a panel complying to BS EN60529 IP52, it will be necessary to fit a metallic sealing strip between adjoining relays (Part no GN2044 001) and a sealing ring selected from Table 3 around the complete assembly.
Page 51: Rs485 Port
Operation Guide P341/EN O/B11 Installation CHAPTER 2 MiCOM P341 Page 9/10 To maintain the terminal block insulation requirements for safety, an insulating sleeve should be fitted over the ring terminal after crimping. The following minimum wire sizes are recommended: Current Transformers 2.5mm...
Page 52: Rs232 Port
Operation Guide CHAPTER 2 Installation Page 10/10 MiCOM P341 RS232 port Short term connections to the RS232 port, located behind the bottom access cover, can be made using a screened multi-core communication cable up to 15m long, or a total capacitance of 2500pF. The cable should be terminated at the relay end with a 9-way, metal shelled, D-type male plug.
Page 53 Operation Guide P341/EN O/B11 MiCOM P341 CHAPTER 3 Commissioning and Maintenance...
Page 54 P341/EN O/B11 Operation Guide MiCOM P341...
Page 55 Operation Guide P341/EN O/B11 Commissioning and CHAPTER 3 Maintenance Page 1/80 MiCOM P341 CONTENT INTRODUCTION SETTING FAMILIARISATION EQUIPMENT REQUIRED FOR COMMISSIONING Minimum equipment required Optional equipment PRODUCT CHECKS With the relay de-energised 4.1.1 Visual inspection 4.1.2 Current transformer shorting contacts 4.1.3...
Page 56 P341/EN O/B11 Operation Guide CHAPTER 3 Commissioning and Page 2/80 Maintenance MiCOM P341 SETTING CHECKS Apply application-specific settings Check application-specific settings Demonstrate correct relay operation 5.3.1 Connect the test circuit 5.3.2 Perform the test 5.3.3 Check the operating time ON-LOAD CHECKS...
Page 57 Operation Guide P341/EN O/B11 Commissioning and CHAPTER 3 Maintenance Page 3/80 MiCOM P341 COMMISSIONING TEST RECORD SETTING RECORD Figure 1: Rear terminal blocks on size 40TE case Figure 2: Location of securing screws for heavy duty terminal blocks Figure 3:...
Page 58 P341/EN O/B11 Operation Guide CHAPTER 3 Commissioning and Page 4/80 Maintenance MiCOM P341...
Page 59: Introduction
RATING LABEL. SETTING FAMILIARISATION When commissioning a MiCOM P341 relay for the first time, sufficient time should be allowed to become familiar with the method by which the settings are applied. Chapter 1 contains a detailed description of the menu structure of P341 relays.
Page 60: Equipment Required For Commissioning
Commissioning and Page 6/80 Maintenance MiCOM P341 Removing the secondary front cover allows access to all keys so that settings can be changed, LEDs and alarms reset, and fault and event records cleared. However, menu cells that have access levels higher than the default level will require the appropriate password to be entered before changes can be made.
Page 61: With The Relay De-Energised
CHAPTER 3 Maintenance Page 7/80 MiCOM P341 which the relay is supplied have been applied the default settings should be restored prior to commissioning. This could be done by: Obtaining a setting file on a diskette from the customer (this requires a portable •...
Page 62: Visual Inspection
Operation Guide CHAPTER 3 Commissioning and Page 8/80 Maintenance MiCOM P341 4.1.1 Visual inspection Carefully examine the relay to see that no physical damage has occurred since installation. The rating information given under the top access cover on the front of the relay should be checked to ensure it is correct for the particular installation.
Page 63: Insulation
Commissioning and CHAPTER 3 Maintenance Page 9/80 MiCOM P341 Note: The use of a magnetic bladed screwdriver is recommended to minimise the risk of the screws being left in the terminal block or lost. Pull the terminal block away from the rear of the case and check with a continuity tester that all the shorting switches being used are closed.
Page 64: External Wiring
Operation Guide CHAPTER 3 Commissioning and Page 10/80 Maintenance MiCOM P341 The insulation resistance should be greater than 100Mý at 500V. On completion of the insulation resistance tests, ensure all external wiring is correctly reconnected to the unit. 4.1.4 External wiring Check that the external wiring is correct to the relevant relay diagram or scheme diagram.
Page 65: With The Relay Energised
CHAPTER 3 Maintenance Page 11/80 MiCOM P341 Energise the relay only if the auxiliary supply is within the operating range. If an MMLG test block is provided, it may be necessary to link across the front of the test plug to connect the auxiliary supply to the relay.
Page 66: 4.2.2.2 Without An Irig-B Signal
CHAPTER 3 Commissioning and Page 12/80 Maintenance MiCOM P341 4.2.2.2 Without an IRIG-B signal If the time and date is not being maintained by an IRIG-B signal, ensure that cell [0804: DATE and TIME, IRIG-B Sync] is set to ‘Disabled’.
Page 67 Operation Guide P341/EN O/B11 Commissioning and CHAPTER 3 Maintenance Page 13/80 MiCOM P341 Supply Rail Terminals F7 & F8 –ve F9 & F10 Table 4: Field voltage terminals 4.2.5 Input opto-isolators This test checks that all the opto-isolated inputs are functioning correctly. The P341 relays have 8 opto-isolated inputs.
Page 68 Operation Guide CHAPTER 3 Commissioning and Page 14/80 Maintenance MiCOM P341 4.2.6 Output relays This test checks that all the output relays are functioning correctly. The P341 and P342 relays have 7 output relays while P343 relays have 14 output relays.
Page 69 Commissioning and CHAPTER 3 Maintenance Page 15/80 MiCOM P341 4.2.7.1 Courier communications If a K-Bus to RS232 KITZ protocol convertor is installed, connect a portable PC running the appropriate software to the incoming (remote from relay) side of the protocol converter.
Page 70 Operation Guide CHAPTER 3 Commissioning and Page 16/80 Maintenance MiCOM P341 4.2.8 Current inputs This test verifies that the accuracy of current measurement is within the acceptable tolerances. All relays will leave the factory set for operation at a system frequency of 50Hz. If operation at 60Hz is required then this must be set in cell [0009: SYSTEM DATA, Frequency].
Page 71 Operation Guide P341/EN O/B11 Commissioning and CHAPTER 3 Maintenance Page 17/80 MiCOM P341 Corresponding CT Ratio Menu Cell (in ‘VT and CT RATIO column (0A) of menu) [0A09: E/F CT Primary] [0207: MEASUREMENTS 1, N Measured Mag] [0A0A: E/F CT Sec'y]...
Page 72 P341/EN O/B11 Operation Guide CHAPTER 3 Commissioning and Page 18/80 Maintenance MiCOM P341 Corresponding VT Ratio Menu Cell (in ‘VT and CT RATIO column (0A) of menu) [021A: MEASUREMENTS 1, VAN Magnitude] [0A01: Main VT Primary] [021C: MEASUREMENTS 1, VBN Magnitude]...
Page 73 P341/EN O/B11 Commissioning and CHAPTER 3 Maintenance Page 19/80 MiCOM P341 • Step through the settings using the relay’s operator interface and compare them with the original application-specific setting record. Unless previously agreed to the contrary, the application-specific programmable scheme logic will not be checked as part of the commissioning tests.
Page 74 P341/EN O/B11 Operation Guide CHAPTER 3 Commissioning and Page 20/80 Maintenance MiCOM P341 5.3.2 Perform the test Ensure that the timer is reset. Apply a current of twice the setting in cell [3503: GROUP 1 OVERCURRENT, >1 Current Set] to the relay and note the time displayed when the timer stops.
Page 75 CHAPTER 3 Maintenance Page 21/80 MiCOM P341 If it has been necessary to disconnect any of the external wiring from the relay in order to perform any of the foregoing tests, it should be ensured that all connections are replaced in accordance with the relevant external connection or scheme diagram.
Page 76 Operation Guide CHAPTER 3 Commissioning and Page 22/80 Maintenance MiCOM P341 Compare the values of the secondary phase currents and phase angle with the relay’s measured values, which can be found in the MEASUREMENTS 1 menu column. Note: Under normal load conditions the earth fault function will measure little, if any, current.
Page 77 ALSTOM protective relays are designed for a life in excess of 20 years. MiCOM P341 Interconnection Protection Relays are self-supervising and so require less maintenance than earlier designs of relay. Most problems will result in an alarm so that remedial action can be taken. However, some periodic tests should be done to ensure that the relay is functioning correctly and the external wiring is intact.
Page 78 CHAPTER 3 Commissioning and Page 24/80 Maintenance MiCOM P341 8.2.4 Measurement accuracy If the power system is energised, the values measured by the relay can be compared with known system values to check that they are in the approximate range that is expected.
Page 79 P341/EN O/B11 Commissioning and CHAPTER 3 Maintenance Page 25/80 MiCOM P341 Heavy duty terminal block Medium duty terminal block Figure 3: Location of securing screws for terminal blocks There are three types of terminal block used on the relay, RTD input, heavy duty and medium duty, which are fastened to the rear panel using screws (crosshead on the heavy and medium duty blocks, slotted on RTD input blocks), as in Figure 3.
Page 80 Operation Guide CHAPTER 3 Commissioning and Page 26/80 Maintenance MiCOM P341 8.3.2 Replacing a PCB If the relay fails to operate correctly refer to Chapter 4, ‘Problem Analysis’, to help determine which PCB has become faulty. To replace any of the relay’s PCBs it is necessary to first remove the front panel.
Page 81 Operation Guide P341/EN O/B11 Commissioning and CHAPTER 3 Maintenance Page 27/80 MiCOM P341 Relay board Input board Transformer board Not used IRIG-B board Power supply board Input module Power supply module Figure 4: P341 PCB/module locations (viewed from front) The PCBs within the relay are now accessible. Figure 4 shows the PCB locations for the relays in size 40TE cases.
Page 82 CHAPTER 3 Commissioning and Page 28/80 Maintenance MiCOM P341 8.3.2.1 Replacement of the main processor board The main processor board is located in the front panel, not within the case as with all the other PCBs. Place the front panel with the user interface face-down and remove the six screws from the metallic screen, as shown in Figure 5.
Page 83 Commissioning and CHAPTER 3 Maintenance Page 29/80 MiCOM P341 8.3.2.2 Replacement of the IRIG-B board Depending on the model number of the relay, the IRIG-B board may have connections for IRIG-B signals, IEC 60870-5-103 (VDEW) communications, both or not be present at all.
Page 84 P341/EN O/B11 Operation Guide CHAPTER 3 Commissioning and Page 30/80 Maintenance MiCOM P341 IC14 IC13 IC11 IC12 IC10 ZN0007 IC16 R31 R37 SERIAL No. IC15 Figure 7: Typical IRIG-B board Before fitting the replacement PCB check that the number on the round label adjacent to the front edge of the PCB matches the slot number into which it will be fitted.
Page 85 Operation Guide P341/EN O/B11 Commissioning and CHAPTER 3 Maintenance Page 31/80 MiCOM P341 Input module Handle Figure 8: Location of securing screws for input module On the right-hand side of the analogue input module in P341 relays there is a small metal tab which brings out a handle.
Page 86 Commissioning and Page 32/80 Maintenance MiCOM P341 8.3.2.4 Replacement of the power supply board The power supply board is fastened to a relay board to form the power supply module and is located on the extreme left-hand side of all MiCOM generator relays.
Page 87 CHAPTER 3 Maintenance Page 33/80 MiCOM P341 Once the relay has been reassembled after repair, it should be recommissioned in accordance with the instructions in sections 1 to 7 inclusive of this chapter. 8.3.2.5 Replacement of the relay board in the power supply module Remove and replace the relay board in the power supply module as described in 8.3.2.4 above.
Page 88 Operation Guide CHAPTER 3 Commissioning and Page 34/80 Maintenance MiCOM P341 Changing the battery Each relay has a battery to maintain status data and the correct time when the auxiliary supply voltage fails. The data maintained includes event, fault and disturbance records and the thermal state at the time of failure.
Page 89 Operation Guide P341/EN O/B11 Commissioning and CHAPTER 3 Maintenance Page 35/80 MiCOM P341 COMMISSIONING TEST RECORD Date Engineer Station Circuit System Frequency Front Plate Information Generator Protection Relay P34__ Model Number Serial Number Rated Current Ιn Rated Voltage Vn Auxiliary Voltage Vx...
Page 90 P341/EN O/B11 Operation Guide CHAPTER 3 Commissioning and Page 36/80 Maintenance MiCOM P341 PRODUCT CHECKS With the relay de-energised 4.1.1 Visual inspection Relay damaged? Yes/No* Rating information correct for installation? Yes/No* Case earth installed? Yes/No* 4.1.2 Current transformer shorting contacts close? Yes/No/Not checked* 4.1.3...
Page 91: Input Opto-Isolators
Operation Guide P341/EN O/B11 Commissioning and CHAPTER 3 Maintenance Page 37/80 MiCOM P341 4.2.3 Light emitting diodes Relay healthy (green) LED working? Yes/No* Alarm (yellow) LED working? Yes/No* Yes/No* Out of service (yellow) LED working? Yes/No* Trip (red) LED working?
Page 92: Rear Communications Port
P341/EN O/B11 Operation Guide CHAPTER 3 Commissioning and Page 38/80 Maintenance MiCOM P341 Working? Yes/No* Relay 4 Contact resistance (N/C) ____Ω/Not measured* (N/O) ____Ω/Not measured* Working? Yes/No* Relay 5 Contact resistance (N/C) ____Ω/Not measured* (N/O) ____Ω/Not measured* Yes/No* Working? Relay 6...
Page 93: Current Inputs
Operation Guide P341/EN O/B11 Commissioning and CHAPTER 3 Maintenance Page 39/80 MiCOM P341 4.2.8 Current inputs Displayed Current Primary/Secondary* æ ö [Phase CT Primary] ç ÷ _______A/na* Phase CT Ratio ç ÷ [Phase CT Sec'y] è ø æ ö [E/F CT Primary] ç...
Page 94 P341/EN O/B11 Operation Guide CHAPTER 3 Commissioning and Page 40/80 Maintenance MiCOM P341 SETTING CHECKS Application-specific function settings applied? Yes/No* Application-specific programmable scheme logic Yes/No/na* settings applied? Application-specific function settings verified? Yes/No/na* Application-specific programmable scheme logic Yes/No/na* tested? Yes/No* Protection function timing tested? Directional Overcurrent type (set in cell [Ι>1 Direction])
Page 95 Operation Guide P341/EN O/B11 Commissioning and CHAPTER 3 Maintenance Page 41/80 MiCOM P341 Yes/No/na* CT wiring checked? Yes/No* CT polarities correct? Displayed Current Primary/Secondary* æ ö [Phase CT Primary] ç ÷ Phase CT Ratio _______A/na* ç ÷ [Phase CT Sec'y] è...
Page 96 P341/EN O/B11 Operation Guide CHAPTER 3 Commissioning and Page 42/80 Maintenance MiCOM P341 Commissioning Engineer Customer Witness Date Date...
Page 97 Operation Guide P341/EN O/B11 Commissioning and CHAPTER 3 Maintenance Page 43/80 MiCOM P341 SETTING RECORD Date Engineer Station Circuit System Frequency Front Plate Information Generator Protection Relay P34__ Model Number Serial Number Rated Current Ιn Rated Voltage Vn Auxiliary Voltage Vx...
Page 98 P341/EN O/B11 Operation Guide CHAPTER 3 Commissioning and Page 44/80 Maintenance MiCOM P341 0600 CB CONDITION 0601 CB Operations 0602 Total ΙA Broken 0603 Total ΙB Broken 0604 Total ΙC Broken 0605 CB Operate Time 0700 CB CONTROL Disabled/Local/Remote/Local+Remote/ 0701...
Page 99 Operation Guide P341/EN O/B11 Commissioning and CHAPTER 3 Maintenance Page 45/80 MiCOM P341 091A V Vector Shift Disabled/Enabled* 091C Reconnect Delay Disabled/Enabled* 091D Volt Protection Disabled/Enabled* 091E Freq Protection Disabled/Enabled* 0920 CB Fail Disabled/Enabled* 0921 Supervision Disabled/Enabled* 0924 Pole Slipping...
Page 100 P341/EN O/B11 Operation Guide CHAPTER 3 Commissioning and Page 46/80 Maintenance MiCOM P341 0B0C DDB 63 - 32 0B0D DDB 95 - 64 0B0E DDB 127 - 96 0B0F DDB 159 - 128 0B10 DDB 191 - 160 0B11 DDB 223 - 192...
Page 101 Operation Guide P341/EN O/B11 Commissioning and CHAPTER 3 Maintenance Page 47/80 MiCOM P341 0C14 Digital Input 5 0C15 Input 5 Trigger No Trigger/Trigger L-H/Trigger H-L* 0C16 Digital Input 6 0C17 Input 6 Trigger No Trigger/Trigger L-H/Trigger H-L* 0C18 Digital Input 7...
Page 102 P341/EN O/B11 Operation Guide CHAPTER 3 Commissioning and Page 48/80 Maintenance MiCOM P341 0C38 Digital Input 23 0C39 Input 23 Trigger No Trigger/Trigger L-H/Trigger H-L* 0C3A Digital Input 24 0C3B Input 24 Trigger No Trigger/Trigger L-H/Trigger H-L* 0C3C Digital Input 25...
Page 103 Operation Guide P341/EN O/B11 Commissioning and CHAPTER 3 Maintenance Page 49/80 MiCOM P341 0E04 Baud Rate 1200/2400/4800/9600/19200/38400* 0E05 Parity Odd/Even/None* 0E06 Measure’t Period 0E07 Physical Link RS485/Fibre Optic* 0E08 Time Synch Disabled/Enabled* 0E09 Function Type 0F00 COMMISSION TESTS 0F05 Monitor Bit 1...
Page 104 P341/EN O/B11 Operation Guide CHAPTER 3 Commissioning and Page 50/80 Maintenance MiCOM P341 GROUP 1 PROTECTION SETTINGS 3100 GROUP 1 POWER 3101 Power1 Function Disabled/Reverse/Low Forward/Over* 3102 -P>1 Setting 3103 P<1 Setting 3104 P>1 Setting 3105 Power 1 Time Delay...
Page 105 Operation Guide P341/EN O/B11 Commissioning and CHAPTER 3 Maintenance Page 51/80 MiCOM P341 350F Ι>2 Reset Char DT/Inverse* 3510 Ι>2 tRESET 3511 Disabled/Enabled* Ι>3 Status Non-Directional/Directional 3512 Ι>3 Direction Fwd/Directional Rev* 3513 Ι>3 Current 3514 Ι>3 Time Delay 3516 Disabled/Enabled* Ι>4 Status...
Page 106 P341/EN O/B11 Operation Guide CHAPTER 3 Commissioning and Page 52/80 Maintenance MiCOM P341 3812 Disabled/Enabled* ΙN>3 Status Non-Directional/Directional 3813 ΙN>3 Direction Fwd/Directional Rev* 3814 ΙN>3 Current 3815 ΙN>3 Time Delay 3816 Disabled/Enabled* ΙN>4 Status Non-Directional/Directional 3817 ΙN>4 Direction Fwd/Directional Rev* 3818 ΙN>4 Current...
Page 107 Operation Guide P341/EN O/B11 Commissioning and CHAPTER 3 Maintenance Page 53/80 MiCOM P341 Non-Directional/Directional Fwd/Directional 390B ΙSEF>2 Direction Rev* 390C ΙSEF>2 Current 390D ΙSEF>2 Delay 390E ΙSEF>2 TMS 390F ΙSEF>2 Time Dial 3910 ΙSEF>2 Reset Char DT/Inverse* 3911 ΙSEF>2 tRESET 3912 ΙSEF>3 Status...
Page 108 P341/EN O/B11 Operation Guide CHAPTER 3 Commissioning and Page 54/80 Maintenance MiCOM P341 3B05 VN>1 TMS 3B06 VN>1 tReset 3B07 VN>2 Status Disabled/Enabled* 3B08 VN>2 Voltage Set 3B09 VN>2 Time Delay 3E00 GROUP 1 DF/DT 3E01 df/dt Status Disabled/Enabled* 3E02...
Page 109 Operation Guide P341/EN O/B11 Commissioning and CHAPTER 3 Maintenance Page 55/80 MiCOM P341 420F V> Operate Mode Any Phase/Three Phase* 4210 V>1 Function Disabled/DT/IDMT* 4211 V>1 Voltage Set 4212 V>1 Time Delay 4213 V>1 TMS 4214 V>2 Status Disabled/Enabled* 4215 V>2 Voltage Set...
Page 110 P341/EN O/B11 Operation Guide CHAPTER 3 Commissioning and Page 56/80 Maintenance MiCOM P341 4504 CB Fail 2 Status Disabled/Enabled* 4505 CB Fail 2 Timer 4506 CBF Non Ι Reset Ι< Only/CB Open & Ι</Prot Reset & Ι<* 4507 CBF Ext Reset Ι<...
Page 111 Operation Guide P341/EN O/B11 Commissioning and CHAPTER 3 Maintenance Page 57/80 MiCOM P341 470A Sen-P>2 Setting 470B Sen P<2 Setting 470C Sen P>2 Setting 470D Sen Power 2 Delay 470E Power 2 DO Timer 470F P2 Pole dead Inhibit Disabled/Enabled*...
Page 112 P341/EN O/B11 Operation Guide CHAPTER 3 Commissioning and Page 58/80 Maintenance MiCOM P341 5109 -P>2 Setting 510A P<2 Setting 510B P>2 Setting 510C Power 2 Time Delay 510D Power 2 DO Timer 510E P2 Poledead Inhibit Disabled/Enabled* 5500 GROUP 2 OVERCURRENT...
Page 113 Operation Guide P341/EN O/B11 Commissioning and CHAPTER 3 Maintenance Page 59/80 MiCOM P341 5519 Ι>4 Time Delay 551A Ι> Char Angle 551B Ι > Func Link 5800 GROUP 2 EARTH FAULT Disabled/DT/IEC S Inverse/IEC V Inverse/IEC E Inverse/ 5802 ΙN>1 Function...
Page 114 P341/EN O/B11 Operation Guide CHAPTER 3 Commissioning and Page 60/80 Maintenance MiCOM P341 581B Directional 581C ΙN> Char Angle 581D ΙN> Pol Zero Sequence/Neg Sequence* 581E ΙN> VNpol Input Measured/Derived* 581F ΙN> VNpol Set 5820 ΙN> V2pol Set 5821 ΙN> Ι2pol Set 5900 GROUP 2 SEF/REF PROT’N...
Page 115 Operation Guide P341/EN O/B11 Commissioning and CHAPTER 3 Maintenance Page 61/80 MiCOM P341 5916 ΙSEF>4 Status Disabled/Enabled * Non-Directional/Directional Fwd/Directional 5917 ΙSEF>4 Direction Rev* 5918 ΙSEF>4 Current 5919 ΙSEF>4 Delay 591A ΙSEF> Func Link 5A1B ΙSEF Directional 5A1C ΙSEF> Char Angle 5A1D ΙSEF>...
Page 116 P341/EN O/B11 Operation Guide CHAPTER 3 Commissioning and Page 62/80 Maintenance MiCOM P341 5F00 GROUP 2 V VECTOR SHIFT V Shift Status Disabled/Enabled* 5F01 5F02 V Shift Angle 6100 GROUP 2 V RECONNECT DELAY 6101 Reconnect Status Disabled/Enabled* 6102 Reconnect Delay...
Page 117 Operation Guide P341/EN O/B11 Commissioning and CHAPTER 3 Maintenance Page 63/80 MiCOM P341 6304 F<1 Time Delay 6305 F<2 Status Disabled/Enabled* 6306 F<2 Setting 6307 F<2 Time Delay 6308 F<3 Status Disabled/Enabled* 6309 F<3 Setting 630A F<3 Time Delay 630B F<4 Status...
Page 118 P341/EN O/B11 Operation Guide CHAPTER 3 Commissioning and Page 64/80 Maintenance MiCOM P341 6600 GROUP 2 SUPERVISION 6601 VT SUPERVISION 6602 VTS Status Blocking/Indication* 6603 VTS Reset Mode Manual/Auto* 6604 VTS Time Delay 6605 VTS Ι> Inhibit 6606 VTS Ι2> Inhibit...
Page 119 Operation Guide P341/EN O/B11 Commissioning and CHAPTER 3 Maintenance Page 65/80 MiCOM P341 6A05 Opto Input 5 6A06 Opto Input 6 6A07 Opto Input 7 6A08 Opto Input 8 6B00 GROUP 2 OUTPUT LABELS 6B01 Relay 1 6B02 Relay 2...
Page 120 P341/EN O/B11 Operation Guide CHAPTER 3 Commissioning and Page 66/80 Maintenance MiCOM P341 Non-Directional/Directional 7502 Ι>1 Direction Fwd/Directional Rev* 7503 Ι>1 Current 7504 Ι>1 Time Delay 7505 Ι>1 TMS 7506 Ι>1 Time Dial 7507 DT/Inverse* Ι>1 Reset Char 7508 Ι>1 tRESET...
Page 121 Operation Guide P341/EN O/B11 Commissioning and CHAPTER 3 Maintenance Page 67/80 MiCOM P341 7805 ΙN>1 Time Delay 7806 ΙN>1 TMS 7807 ΙN>1 Time Dial 7808 ΙN>1 Reset Char DT/Inverse* 7809 ΙN>1 tRESET 780A Disabled/DT* ΙN>2 Function Non-Directional/Directional 780B ΙN>2 Directional...
Page 122 P341/EN O/B11 Operation Guide CHAPTER 3 Commissioning and Page 68/80 Maintenance MiCOM P341 7900 GROUP 3 SEF/REF PROT’N 7901 SEF/REF Options SEF/SEF cos(PHI)/SEF sin(PHI)/Hi Z REF * Disabled/DT/IEC S Inverse/IEC V Inverse/IEC E Inverse/UK LT Inverse/IEEE M 7902 ΙSEF>1 Function...
Page 123 Operation Guide P341/EN O/B11 Commissioning and CHAPTER 3 Maintenance Page 69/80 MiCOM P341 7A1D ΙSEF> VNpol Input Measured/Derived* 7A1E ΙSEF> VNpol Set 7A1F Wattmetric SEF 7A20 PN> Setting 7A21 Restricted E/F 7A22 ΙREF> k1 7A23 ΙREF> k2 7A24 ΙREF> Ιs1 7A25 ΙREF>...
Page 124 P341/EN O/B11 Operation Guide CHAPTER 3 Commissioning and Page 70/80 Maintenance MiCOM P341 8103 Reconnect tPULSE 8200 GROUP 3 VOLT PROTECTION 8201 UNDERVOLTAGE 8202 V< Measur’t Mode Phase-Phase/Phase-Neutral* 8203 V< Operate Mode Any Phase/Three Phase* 8204 V<1 Function Disabled/DT/IDMT* 8205 V<1 Voltage Set...
Page 125 Operation Guide P341/EN O/B11 Commissioning and CHAPTER 3 Maintenance Page 71/80 MiCOM P341 830A F<3 Time Delay 830B F<4 Status Disabled/Enabled* 830C F<4 Setting 830D F<4 Time Delay 830E F< Function Link 830F Over Frequency 8310 F>1 Status Disabled/Enabled* 8311 F>1 Freq Set...
Page 126 P341/EN O/B11 Operation Guide CHAPTER 3 Commissioning and Page 72/80 Maintenance MiCOM P341 8607 CT SUPERVISION 8608 CTS Status Disabled/Enabled* 8609 CTS VN Inhibit Measured/Derived* 860A CTS VN< Inhibit 860B CTS ΙN> Set 860C CTS Time Delay 8700 GROUP 3 SENSITIVE POWER...
Page 127 Operation Guide P341/EN O/B11 Commissioning and CHAPTER 3 Maintenance Page 73/80 MiCOM P341 8B00 GROUP 3 OUTPUT LABELS 8B01 Relay 1 8B02 Relay 2 8B03 Relay 3 8B04 Relay 4 8B05 Relay 5 8B06 Relay 6 8B07 Relay 7 GROUP 4 PROTECTION SETTINGS...
Page 128 P341/EN O/B11 Operation Guide CHAPTER 3 Commissioning and Page 74/80 Maintenance MiCOM P341 9507 Ι>1 Reset Char DT/Inverse* 9508 Ι>1 tRESET 9509 Ι>2 Function Disabled/DT* Non-Directional/Directional 950A Ι>2 Directional Fwd/Directional Rev* 950B Ι>2 Current 950C Ι>2 Time Delay 950D Ι>2 TMS 950E Ι>2 Time Dial...
Page 129 Operation Guide P341/EN O/B11 Commissioning and CHAPTER 3 Maintenance Page 75/80 MiCOM P341 980A ΙN>2 Function Disabled/DT* Non-Directional/Directional 980B ΙN>2 Directional Fwd/Directional Rev* 980C ΙN>2 Current 980D ΙN>2 Time Delay 980E ΙN>2 TMS 980F ΙN>2 Time Dial 9810 DT/Inverse* ΙN>2 Reset Char 9811 ΙN>2 tRESET...
Page 130 P341/EN O/B11 Operation Guide CHAPTER 3 Commissioning and Page 76/80 Maintenance MiCOM P341 9906 ΙSEF>1 TMS 9907 ΙSEF>1 Time Dial 9908 ΙSEF>1 Reset Char DT/Inverse* 9909 ΙSEF>1 tRESET Disabled/DT/IEC S Inverse/IEC V Inverse/IEC E Inverse/UK LT Inverse/IEEE M 990A ΙSEF>2 Function...
Page 131 Operation Guide P341/EN O/B11 Commissioning and CHAPTER 3 Maintenance Page 77/80 MiCOM P341 9A25 ΙREF> Ιs2 9A26 ΙREF> Ιs 9B00 GROUP 4 RESIDUAL O/V NVD 9B01 VN Input Measured/Derived* 9B02 VN>1 Function Disabled/DT/IDMT* 9B03 VN>1 Voltage Set 9B04 VN>1 Time Delay 9B05 VN>1 TMS...
Page 132 P341/EN O/B11 Operation Guide CHAPTER 3 Commissioning and Page 78/80 Maintenance MiCOM P341 A207 V<1 TMS A208 V<1 Poledead Inhibit Disabled/Enabled* A209 V<2 Status Disabled/Enabled* A20A V<2 Voltage Set A20B V<2 Time Delay A20C V<2 Poledead Inhibit Disabled/Enabled* A20D OVERVOLTAGE A20E V>...
Page 133 Operation Guide P341/EN O/B11 Commissioning and CHAPTER 3 Maintenance Page 79/80 MiCOM P341 A313 F>2 Status Disabled/Enabled* A314 F>2 Freq Set A315 F>2 Time Delay A500 GROUP 4 CB FAIL & Ι Ι Ι Ι < A501 BREAKER FAIL A502...
Page 134 P341/EN O/B11 Operation Guide CHAPTER 3 Commissioning and Page 80/80 Maintenance MiCOM P341 A700 GROUP 4 SENSITIVE POWER A701 Comp Angle A702 Sen Power 1 Func Disabled/Reverse/Low Forward/Over* A703 Sen-P>1 Setting A704 Sen P<1 Setting A705 Sen P>1 Setting A706...
Page 135 Operation Guide P341/EN O/B11 MiCOM P341 CHAPTER 4 Problem Analysis...
Page 136 P341/EN O/B11 Operation Guide MiCOM P341...
Page 137 Operation Guide P341/EN O/B11 Problem Analysis CHAPTER 4 MiCOM P341 Page 1/8 CONTENT INTRODUCTION INITIAL PROBLEM IDENTIFICATION POWER UP ERRORS ERROR MESSAGE/CODE ON POWER-UP OUT OF SERVICE LED ILLUMINATED ON POWER UP ERROR CODE DURING OPERATION MIS-OPERATION OF THE RELAY DURING TESTING...
Page 138 P341/EN O/B11 Operation Guide CHAPTER 4 Problem Analysis Page 2/8 MiCOM P341...
Page 139: Introduction
Operation Guide P341/EN O/B11 Problem Analysis CHAPTER 4 MiCOM P341 Page 3/8 INTRODUCTION Before carrying out any work on the equipment, the user should be familiar with the contents of the safety and technical data sections and the ratings on the equipment’s rating label The purpose of this chapter of the service manual is to allow an error condition on the relay to be identified so that appropriate corrective action can be taken.
Page 140: Power Up Errors
CHAPTER 4 Problem Analysis Page 4/8 MiCOM P341 POWER UP ERRORS If the relay does not appear to power up then the following procedure can be used to determine whether the fault is in the external wiring, auxiliary fuse, power supply module of the relay or the relay front panel.
Page 141 Operation Guide P341/EN O/B11 Problem Analysis CHAPTER 4 MiCOM P341 Page 5/8 Test Check Action Record displayed error, then Record whether the same error remove and re-apply relay auxiliary code is displayed when the relay is supply. re-booted. If no error code is...
Page 142: Out Of Service Led Illuminated On Power Up
P341/EN O/B11 Operation Guide CHAPTER 4 Problem Analysis Page 6/8 MiCOM P341 Test Check Action Other error codes will relate to software errors on the main processor board, contact ALSTOM T&D P&C Ltd. Table 3: Power-up self-test error OUT OF SERVICE LED ILLUMINATED ON POWER UP...
Page 143: Error Code During Operation
Operation Guide P341/EN O/B11 Problem Analysis CHAPTER 4 MiCOM P341 Page 7/8 Test Check Action The VT type field in the model number is incorrect (no VTs fitted) Table 4: Out of service LED illuminated ERROR CODE DURING OPERATION The relay performs continuous self-checking, if an error is detected then an error message will be displayed, a maintenance record will be logged and the relay will reset (after a 1.6 second delay).
Page 144: Failure Of Opto-Isolated Inputs
P341/EN O/B11 Operation Guide CHAPTER 4 Problem Analysis Page 8/8 MiCOM P341 Test Check Action Verify by examination of the fault If the protection element does not record, or by using the test port operate, verify whether the test is whether the protection element is being correctly applied.
Page 145 Operation Guide P341/EN O/B11 MiCOM P341 APPENDIX A Relay Menu Database...
Page 146 P341/EN O/B11 Operation Guide MiCOM P341 MiCOM P341 Guide Interconnection Protection Relay Appendix A Relay Menu Database This version of Appendix A is specific to the following models Model Number Software Number P341------0040A P341------0040-A/B/C For other models / software versions, please contact ALSTOM T&D Ltd - Protection and Control for the relevant information.
Page 147 Operation Guide P341/EN O/B11 Relay Menu Database APPENDIX A MiCOM P341 Page 1/126 APPENDIX A This Appendix is split into several sections, these are as follows: Menu Database for Courier, User Interface and Modbus • • Menu Datatype Definition •...
Page 148 APPENDIX A Relay Menu Database Page 2/126 MiCOM P341 Internal digital signals This table defines all of the relay internal digital signals (opto inputs, output contacts and protection inputs and outputs). A relay may have up to 512 internal signals each referenced by a numeric index as shown in this table.
Page 232 =>?@ Operation Guide P341/EN O/B11 Relay Menu Database APPENDIX A MiCOM P341 Page 86/126 Digital Data Bus DDB No Source Description English Text P341 P342 P343 Output Condition Output Relay 1 Output Label 1 (Setting) Output Condition Output Relay 2...
Page 233 =>?@ Operation Guide P341/EN O/B11 Relay Menu Database APPENDIX A MiCOM P341 Page 87/126 DDB No Source Description English Text P341 P342 P343 Output Condition Programmable LED 8 LED 8 Input to Relay Output Condition Relay 1 Input to Relay Output Condition...
Page 234 =>?@ Operation Guide P341/EN O/B11 Relay Menu Database APPENDIX A MiCOM P341 Page 88/126 DDB No Source Description English Text P341 P342 P343 Block Phase Overcurrent Stage 2 time delay I>2 Timer Block Block Phase Overcurrent Stage 3 time delay I>3 Timer Block...
Page 235 =>?@ Operation Guide P341/EN O/B11 Relay Menu Database APPENDIX A MiCOM P341 Page 89/126 DDB No Source Description English Text P341 P342 P343 Under Voltage 1st Stage Phase U/V Trip 3ph V<1 Trip Under Voltage 1st Stage Phase U/V Trip A/AB V<1 Trip A/AB...
Page 236 =>?@ Operation Guide P341/EN O/B11 Relay Menu Database APPENDIX A MiCOM P341 Page 90/126 DDB No Source Description English Text P341 P342 P343 Over Current 4th Stage O/C Start 3ph I>4 Start Over Current 4th Stage O/C Start A I>4 Start A...
Page 237 =>?@ Operation Guide P341/EN O/B11 Relay Menu Database APPENDIX A MiCOM P341 Page 91/126 DDB No Source Description English Text P341 P342 P343 VT Supervision Superimposed Ic over threshold (Hidden from PSL) CB Failure CBF current prot SEF stage trip...
Page 238 =>?@ Operation Guide P341/EN O/B11 Relay Menu Database APPENDIX A MiCOM P341 Page 92/126 DDB No Source Description English Text P341 P342 P343 PSL Internal Node 24 PSL Internal Node 25 PSL Internal Node 26 PSL Internal Node 27 PSL Internal Node 28...
Page 239 =>?@ Operation Guide P341/EN O/B11 Relay Menu Database APPENDIX A MiCOM P341 Page 93/126 DDB No Source Description English Text P341 P342 P343 PSL Internal Node 97 PSL Internal Node 98 PSL Internal Node 99 PSL Internal Node 100...
Page 252 P341/EN O/B11 Operation Guide APPENDIX A Relay Menu Database Page 106/126 MiCOM P341 DNP 3.0 Device Profile Document Alstom T&D Protection & Control Ltd. P340 Generator Protection P341***A4**04** P342****4**04* P343****4**04* Level 2 Level 2 Slave For static (non-change-event) object requests, request qualifier codes 00 and 01 (start-stop), 07 and 08 (limited quantity), and 17 and 28 (index) are supported in addition to request qualifier code 06 (no range).
Page 253 Operation Guide P341/EN O/B11 Relay Menu Database APPENDIX A MiCOM P341 Page 107/126 Fixed at 100ms None Fixed at 1s None Inter-character Delay: 4 character times at selected baud rate. Select/Operate Arm Timeout: default 10s. Need Time Interval: configurable, 0 or 30min.
Page 254 P341/EN O/B11 Operation Guide APPENDIX A Relay Menu Database Page 108/126 MiCOM P341 Object Request Response Object Variation Description Function Qualifier Function Qualifier Number Number Codes (dec) Codes (hex) Codes (dec) Codes (hex)
Page 255 Operation Guide P341/EN O/B11 Relay Menu Database APPENDIX A MiCOM P341 Page 109/126 Object Request Response Object Variation Description Function Qualifier Function Qualifier Number Number Codes (dec) Codes (hex) Codes (dec) Codes (hex)
Page 256 P341/EN O/B11 Operation Guide APPENDIX A Relay Menu Database Page 110/126 MiCOM P341 Binary Input Points 1 (Binary Input without status) 2 (Binary Input Change with Time) P341 P342 P343 Name / Description Change Event Initial Point Point Point Assigned...
Page 257 Operation Guide P341/EN O/B11 Relay Menu Database APPENDIX A MiCOM P341 Page 111/126 P341 P342 P343 Name / Description Change Event Initial Point Point Point Assigned Value Index Index Index Class (1, 2, 3) Miscellaneous Indications...
Page 258 P341/EN O/B11 Operation Guide APPENDIX A Relay Menu Database Page 112/126 MiCOM P341 P341 P342 P343 Name / Description Change Event Initial Point Point Point Assigned Value Index Index Index Class (1, 2, 3) Protection Operation Signals...
Page 259 Operation Guide P341/EN O/B11 Relay Menu Database APPENDIX A MiCOM P341 Page 113/126 P341 P342 P343 Name / Description Change Event Initial Point Point Point Assigned Value Index Index Index Class (1, 2, 3)
Page 260 P341/EN O/B11 Operation Guide APPENDIX A Relay Menu Database Page 114/126 MiCOM P341 P341 P341 P341 P341 P341 P342 P342 P342 P342 P342 P343 P343 P343 P343 P343 Name / Description Name / Description Name / Description Name / Description...
Page 261 Operation Guide P341/EN O/B11 Relay Menu Database APPENDIX A MiCOM P341 Page 115/126 P341 P341 P342 P342 P343 P343 Name / Description Name / Description Change Event Change Event Initial Initial Point Point Point Point Point Point Assigned Assigned Value...
Page 262 P341/EN O/B11 Operation Guide APPENDIX A Relay Menu Database Page 116/126 MiCOM P341 P341 P342 P343 Name / Description Change Event Initial Point Point Point Assigned Value Index Index Index Class (1, 2, 3) New Protection Functions (for revision 04A)
Page 263 Operation Guide P341/EN O/B11 Relay Menu Database APPENDIX A MiCOM P341 Page 117/126 Binary Output Status Points 1(read) 2 (Binary Output Status) Control Relay Output Blocks 3 (select), 4 (operate), 5 (direct operate), 6 (direct operate, noack) P341 P342 P343...
Page 264 P341/EN O/B11 Operation Guide APPENDIX A Relay Menu Database Page 118/126 MiCOM P341 Binary Counter Points 1(read), 7(freeze), 8(freeze noack), 9(freeze and clear), 10(freeze and clear, noack) (32-Bit Binary Counter without Flag) Frozen Counter Points 1 (read) (32-Bit Binary Counter without Flag)
Page 265 Operation Guide P341/EN O/B11 Relay Menu Database APPENDIX A MiCOM P341 Page 119/126 Analog Inputs P341 P342 P343 Name / Description Data Valid Range Default Change Event Point Point Point Type Deadband Assigned Index Index Index Class (1, 2, 3)
Page 266 P341/EN O/B11 Operation Guide APPENDIX A Relay Menu Database Page 120/126 MiCOM P341 P341 P342 P343 Name / Description Data Valid Range Default Change Event Point Point Point Type Deadband Assigned Index Index Index Class (1, 2, 3) MEASUREMENTS 2...
Page 267 Operation Guide P341/EN O/B11 Relay Menu Database APPENDIX A MiCOM P341 Page 121/126 P341 P342 P343 Name / Description Data Valid Range Default Change Event Point Point Point Type Deadband Assigned Index Index Index Class (1, 2, 3) MEASUREMENTS 3...
Page 269 Operation Guide P341/EN O/B11 Relay Menu Database APPENDIX A MiCOM P341 Page 123/126 MiCOM P341 PROGRAMMABLE SCHEME LOGIC Opto Input Mappings IN>3 Timer Blk DDB #148 L3 Block IN>3&4 DDB #034 IN>4 Timer Blk DDB #149 I>3 Timer Block DDB #144 L4 Block I>3&4...
Page 270 P341/EN O/B11 Operation Guide APPENDIX A Relay Menu Databases Page 124/126 MiCOM P341 MiCOM P341 PROGRAMMABLE SCHEME LOGIC Output Relay Mappings df/dt Trip DDB #202 V Shift Trip DDB #203 IN>1 Trip DDB #204 IN>2 Trip DDB #205 IN>3 Trip DDB #206 IN>4 Trip...
Page 271 Operation Guide P341/EN O/B11 Relay Menu Database APPENDIX A MiCOM P341 Page 125/126 MiCOM P341 PROGRAMMABLE SCHEME LOGIC Output Relay Mappings IN/SEF>Blk Start R1 IN>1 Start Straight DDB #317 DDB #000 I> BlockStart R2 I>1 Start Straight DDB #316 DDB #001...
Page 272 P341/EN O/B11 Operation Guide APPENDIX A Relay Menu Databases Page 126/126 MiCOM P341 MiCOM P341 PROGRAMMABLE SCHEME LOGIC (04) LED Mappings IN>1 Trip DDB #204 IN>2 Trip DDB #205 IN>3 Trip DDB #206 IN>4 Trip DDB #207 ISEF>1 Trip DDB #209...
Page 273 Operation Guide P341/EN O/B11 MiCOM P341 APPENDIX B External Connection Diagrams...
Page 274 P341/EN O/B11 Operation Guide MiCOM P341...
Page 275 )*+, Operation Guide P341/EN O/B11 External Connection Diagrams APPENDIX B MiCOM P341 Page 1/2...
Page 276 )*+, P341/EN O/B11 Operation Guide APPENDIX B External Connection Diagrams Page 2/2 MiCOM P341...
Page 277 Operation Guide P341/EN O/A11 MiCOM P341 APPENDIX C Hardware / Software Version History and Compatibility (Note: Includes versions released and supplied to customers only)
Page 278 P341/EN O/A11 Operation Guide MiCOM P341...
Page 279 Operation Guide P341/EN O/A11 Hardware/Software Version APPENDIX C History and Compatibility Page 1/2 MiCOM P341...
Page 280 P341/EN O/A11 Operation Guide APPENDIX C Hardware/Software Version Page 2/2 History and Compatibility MiCOM P341...
Page 282 AREVA T&D's Automation & Information Systems Business www.areva-td.com T&D Worldwide Contact Centre online 24 hours a day: +44 (0) 1785 25 00 70 http://www.areva-td.com/contactcentre/...

Areva MiCOM P341 Operation Manual

Table of Contents

Table of Contents

Table of Contents

Table of Contents

Table of Contents

Quick Links

Chapters

Need help?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Areva MiCOM P341

Summary of Contents for Areva MiCOM P341

Table of Contents
