Page 1 MiCOM P225 Motor Protection Relay Technical Guide P225/EN T/B11...
Page 3 Technical Guide P225/EN T/B11 MiCOM P225 Page 1/2 MOTOR PROTECTION RELAY MiCOM P225 CONTENT Connection Diagram P225/EN CO/B11 Technical Data P225/EN TD/B11 User Guide P225/EN FT/B11 Menu of the HMI P225/EN HI/B11 Commissioning and Maintenance P225/EN CM/B11 Communication P225/EN CT/B11...
Page 4 P225/EN T/B11 Technical Guide Page 2/2 MiCOM P225 BLANK PAGE...
Page 5 Connection Diagrams P225/EN CO/B11 MiCOM P225 CONNECTION DIAGRAMS...
Page 7: Table Of Contents
Connection Diagrams P225/EN CO/B11 MiCOM P225 Page 1/12 CONTENT CONNECTION DIAGRAMS MiCOM P225 typical connection Typical application diagram CONNECTION Earth connection Auxiliary power Current inputs Voltage measurement input Binary inputs Output relays Front port connection (RS232) RS485 rear port 2.8.1 Description 2.8.2...
Page 8 P225/EN CO/B11 Connection Diagrams Page 2/12 MiCOM P225 BLANK PAGE...
Page 9: Connection Diagrams
Connection Diagrams P225/EN CO/B11 MiCOM P225 Page 3/12 CONNECTION DIAGRAMS MiCOM P225 typical connection P0228ENa...
Page 10: Typical Application Diagram
Output RL4 Emergency startup Programmable Input L3 Watchdog Signalling External reset Programmable Input L4 Programmable Signalling Thermal state value reset Programmable Output RL3 Input L6 Fuse blown Programmable Input L5 P0231ENa THE MiCOM P225 IS SHOWN WITH POWER SUPPLY OFF.
Page 11: Connection
The case shall be earthed according to the local standards. Auxiliary power The auxiliary power for the MiCOM P225 relay can be either Direct (range 24 - 60 Vdc, 48- 150Vdc, 130-250Vdc) or Alternating (100-250Vac –50/60Hz). The range of voltage is specified on the relay indicator plate under the top flap of the front face.
Page 12: Front Port Connection (Rs232)
5 to pin 5. The cable between the MiCOM relay and the PC is a standard RS232 shielded cable (male connector on the MiCOM relay side, usually female connector on PC side). MiCOM P225 Relay Laptop 9 pin front port...
Page 13: Rs485 Rear Port
The advantage of this type of connection is that up to 31 relays can be ‘daisy chained’ together using a simple twisted pair electrical connection. 2.8.2 Connection The communication connection (port RS485) is assigned on terminals 31-32 according to the MiCOM P225 relay wiring diagram. communication connections Rear terminals P0180ENa...
Page 14: Rs485 Cable
Analogue outputs The MiCOM P225 relay can include two optional analogue outputs assigned on the 28d-28b- 28z and 32d-32b-32z terminals (green coloured connector) which allow certain data and measuring values to be reassembled on a current loop towards an automatic controller. The selections of the type of analogue outputs (options: 0-20 mA or 4-20 mA) and of the type of data to be reassembled are effected in the CONFIG.
Page 15: Rtds
Connection Diagrams P225/EN CO/B11 MiCOM P225 Page 9/12 2.10 RTDs The P225 relay can, as an option, be connected to 10 RTD's, which enables it to monitor temperature (PROTECTION G1 or PROTECTION G2 menu). The choice of these types of RTD sensors is effected in the CONFIG.
Page 16: Thermistors
P225/EN CO/B11 Connection Diagrams Page 10/12 MiCOM P225 2.11 Thermistors The P225 relay can, as an option, be connected to 3 thermistors which allows it to protect against over-temperature conditions (PROTECTION G1 or PROTECTION G2 menu). The choice between these types of thermistor is effected in the CONFIG. SELCT submenu.
Page 17: Ptc Type Thermistors
Connection Diagrams P225/EN CO/B11 MiCOM P225 Page 11/12 2.11.1 PTC type thermistors For PTC type thermistor, it is usually possible to connect to the same input several thermistors in series as indicated in figure 7. Thermistor placed on phase A winding...
Page 18: Micom P225
P225/EN CO/B11 Connection Diagrams Page 12/12 MiCOM P225 BLANK PAGE...
Page 19 Technical Specifications P225/EN TD/B11 MiCOM P225 TECHNICAL SPECIFICATIONS...
Page 21 Technical Specifications P225/EN TD/B11 MiCOM P225 Page 1/34 CONTENT PROTECTION FUNCTIONS Thermal replica Short-circuit protection Too long start-up protection Locked rotor protection Unbalance protection Earth fault protection Under current protection Undervoltage protection Overvoltage protection AUTOMATION FUNCTIONS Limitation of the number of start-ups...
Page 22 P225/EN TD/B11 Technical Specifications Page 2/34 MiCOM P225 COMMUNICATION MODBUS communication K-bus/Courier communication IEC 60870-5-103 communication Front communication INPUTS AND OUTPUTS Analogue current inputs Analogue voltage input Logic inputs Output relays Auxiliary voltage ACCURACY CT & VT DATA HIGH VOLTAGE WITHSTAND...
Page 23 Technical Specifications P225/EN TD/B11 MiCOM P225 Page 3/34 PROTECTION FUNCTIONS Thermal replica Thermal current threshold Iθ> 0,2 to 1,5 In by steps of 0,01 In Overload time-constant T 1 to 180 min by steps of 1min Start-up time-constant T 1 to 360 min by steps of 1min...
Page 24 P225/EN TD/B11 Technical Specifications Page 4/34 MiCOM P225 Earth fault protection Current threshold Io>, Io>> 0,002 to 1 Ion by steps of 0,001 Ion Time-delays tIo>, tIo>> 0 to 100 s by steps of 0,01 s Operating time < 30 ms Drop-off time <...
Page 25 Technical Specifications P225/EN TD/B11 MiCOM P225 Page 5/34 AUTOMATION FUNCTIONS Limitation of the number of start-ups Reference period T 10 to 120 min by steps of 5 min reference Number of cold starts 1 to 5 by steps of 1...
Page 26 P225/EN TD/B11 Technical Specifications Page 6/34 MiCOM P225 2.11 CB control and monitoring Close command hold 0,2 to 5 s by steps of 0,05 s Open command hold 0,2 to 5 s by steps of 0,05 s Number of operations alarm...
Page 27 Technical Specifications P225/EN TD/B11 MiCOM P225 Page 7/34 OPTIONAL FUNCTIONS Optional 2 analogue outputs Rating 0-20 mA, 4-20 mA Insulation 2 kV 500 Ω for ratings 0-20 mA, Maximum load with active source mode 4-20 mA Maximum voltage with passive source mode...
Page 28 P225/EN TD/B11 Technical Specifications Page 8/34 MiCOM P225 RECORDING FUNCTIONS Event recorder Capacity 75 events Time-tag to 1 millisecond Triggers Any protection alarm & threshold Any logic input change of state Self test events Any setting change Fault recorder Capacity...
Page 29 Technical Specifications P225/EN TD/B11 MiCOM P225 Page 9/34 COMMUNICATION MODBUS communication Mode RTU (standard) Transmission mode Synchronous Interface RS 485, 2 wires + shielding Data rate bauds (programmable) Relay address 1 to 255 Parity Settable Date format IEC format or Private format...
Page 30 P225/EN TD/B11 Technical Specifications Page 10/34 MiCOM P225 Front communication Interface RS232 Protocol MODBUS Data rate 19200 bauds Parity Without Stop bit Data bits Connector Sub-D 9 pin female connector Cable type Screened twisted wire cable, no- crossed...
Page 31 Technical Specifications P225/EN TD/B11 MiCOM P225 Page 11/34 INPUTS AND OUTPUTS Analogue current inputs Phase currents In 1 and 5 Ampere Earth current Ion 1 and 5 Ampere Frequency Range 45 to 65 Hz Nominal 50/60 Hz Burdens Phase current inputs <...
Page 32 P225/EN TD/B11 Technical Specifications Page 12/34 MiCOM P225 Output relays Type Dry contact AgCdO, changeover type Number 6 (5 programmable, 1 watchdog) Commutation capacity Make 30 Amps for 3 s Carry continuously 5 Amps Break 135 Vdc, 0,3 A (L/R=30 ms)
Page 33 Technical Specifications P225/EN TD/B11 MiCOM P225 Page 13/34 ACCURACY Protection thresholds ± 2 % Time delays ± 2 % with a minimum of 10ms Measurements Current Typical ± 0,2 % @ In Voltage Typical ± 0,2 % @ Vn Power Typical ±...
Page 34 P225/EN TD/B11 Technical Specifications Page 14/34 MiCOM P225 CT & VT DATA Phase CTs primary 1 to 3000 by steps of 1 Earth CT primary 1 to 3000 by steps of 1 Phase CTs secondary 1 or 5 Earth CT secondary...
Page 35 Technical Specifications P225/EN TD/B11 MiCOM P225 Page 15/34 HIGH VOLTAGE WITHSTAND Dielectric withstand (50/60Hz) IEC 60255-5 2 kV in common mode BS 142 1 kV in differential mode ANSI C37.90 Impulse voltage (1,2/50 µs) IEC 60255-5 5 kV in common mode...
Page 36 P225/EN TD/B11 Technical Specifications Page 16/34 MiCOM P225 ELECTRICAL ENVIRONMENT High frequency disturbance IEC 611000-4-1 2.5 kV in common mode, class 3 1 kV in differential mode, class 3 Fast transient disturbance IEC 611000-4-4 4 kV auxiliary supply, class 4 ANSI C37.90.1...
Page 37 Technical Specifications P225/EN TD/B11 MiCOM P225 Page 17/34 ENVIRONMENT Temperature IEC 60255-6 Storage and - 40°C to + 70°C transportation Operation - 25°C to + 55 °C Humidity IEC 60068-2-3 56 days at 93% RH and 40°C Enclosure protection IEC 60529...
Page 38 P225/EN TD/B11 Technical Specifications Page 18/34 MiCOM P225 THERMAL OVERLOAD CHARACTERISTIC CURVES Thermal overload characteristic curves Thermal constant times : - overload condition : T = 12 minutes - start-up condition : T = 6 minutes 10 000 1 000...
Page 39 Technical Specifications P225/EN TD/B11 MiCOM P225 Page 19/34 Thermal overload characteristic curves Cold curves Initial thermal state of 0% 100 000 10 000 Te1 = Te2 = 60 mn Te1 = Te2 = 54 mn Te1 = Te2 = 48 mn...
Page 40 P225/EN TD/B11 Technical Specifications Page 20/34 MiCOM P225 Thermal overload characteristic curve Cold curves Initial thermal state of 0% 100 000 10 000 Te1 = Te2 = 62 mn Te1 = Te2 = 56 mn Te1 = Te2 = 50 mn...
Page 41 Technical Specifications P225/EN TD/B11 MiCOM P225 Page 21/34 Thermal overload characteristic curves Cold curves Initial thermal state of 0% 100 000 10 000 Te1 = Te2 = 64 mn Te1 = Te2 = 58 mn 1 000 Te1 = Te2 = 52 mn...
Page 42 P225/EN TD/B11 Technical Specifications Page 22/34 MiCOM P225 Thermal overload characteristic curves Hot curves Initial thermal state of 90% 100 000 10 000 1 000 Te1 = Te2 = 60 mn Te1 = Te2 = 54 mn Te1 = Te2 = 48 mn...
Page 43 Technical Specifications P225/EN TD/B11 MiCOM P225 Page 23/34 Thermal overload characteristic curves Hot curves Initial thermal state of 90% 100 000 10 000 1 000 Te1 = Te2 = 62 mn Te1 = Te2 = 56 mn Te1 = Te2 = 50 mn...
Page 44 P225/EN TD/B11 Technical Specifications Page 24/34 MiCOM P225 Thermal overload characteristic curves Hot curves Initial thermal state of 90% 100 000 10 000 1 000 Te1 = Te2 = 64 mn Te1 = Te2 = 58 mn Te1 = Te2 = 52 mn...
Page 51 Technical Specifications P225/EN TD/B11 MiCOM P225 Page 31/34 Negative phase sequence protection Inverse time characteristic curve I2>> element 100,0 I2>> setting range from 0,04 to 0,8 In 10,0 TMS = 2 TMS = 1 TMS = 0,2 0,01 Ratio "Negative phase sequence current/rated current" : I2 / In...
Page 52 P225/EN TD/B11 Technical Specifications Page 32/34 MiCOM P225 EQUIVALENCE TABLE BETWEEN THE RTD IMPEDANCE MEASURED VALUE AND TEMPERATURE Temperature (°C) 100 OHM 100 OHM 120 OHM 10 OHM Platinum (Ω) Nickel (Ω) Nickel (Ω) Copper (Ω) 84.27 79.13 92.76 7.490 88.22...
Page 53 EQUIVALENCE TABLES BETWEEN ANALOGUE OUTPUT SIGNAL VALUE AND REMOTE MEASUREMENT The hereafter tables provide equivalence data between the current signal issued from the analogue outputs of the MiCOM P225 and the measurement value : Rating 0 – 20 mA : Variation...
Page 54 P225/EN TD/B11 Technical Specifications Page 34/34 MiCOM P225 Rating 4 - 20 mA : Variation Rating Measurement type HMI sign Unit range 4 - 20 mA Phase A current IA RMS Ampere 0 to 2 In (Ias – 4 mA) * 2 In / 16 mA...
Page 55 User Guide P225/EN FT/B11 MiCOM P225 USER GUIDE...
Page 57 User Guide P225/EN FT/B11 MiCOM P225 Page 1/52 CONTENT INTRODUCTION Object of this document Definitions DESCRIPTION OF THE MiCOM P225 MOTOR PROTECTION RELAY THE OPERATOR INTERFACE Description of the front panel The LEDs The keypad 3.3.1 ALARM keys 3.3.2 Programming keypad...
Page 58 P225/EN FT/B11 User Guide Page 2/52 MiCOM P225 4.10.8 The [51LR/50S] BLOCK ROTOR submenu 4.10.9 The [37]LOSS OF LOAD submenu: Protection against undercurrent/loss of load conditions27 4.10.10 The [49/38] RTD submenu: Temperature protection by RTD (optional) 4.10.11 The [49] THERMISTOR submenu: Temperature protection by thermistor (optional) 4.11...
Page 59 ⇒ or by the operator (in this case it is an external tripping command). Alarm The detection of a fault by the MiCOM P225 relay leads to the display of an alarm message. Acknowledgement of an alarm This operation consists of making an alarm message disappear.
Page 60 50 ms. The front panel gives the operator access to the data of the MiCOM P225 relay either via LEDs or via the display unit and the keypad. The various alarms are stored in the memory and made available to the operator on the backlit display device.
Page 61 MiCOM P225 Page 5/52 The MiCOM P225 relay can be withdrawn while it is live. This means that its live parts can be withdrawn from the metal housing while the relay is supplied with power via the auxiliary source. When the relay is drawn out of its housing:...
Page 62 THE OPERATOR INTERFACE Description of the front panel The front panel of the MiCOM P225 relay serves as an interface between the human and the protection relay. It enables the operator to enter settings, to gain access to the display of measured values and alarms, and also to display in a simple manner the different actions performed by the MiCOM P225 relay.
Page 63 (repair of the module, disappearance of the fault). LED 4 Colour: GREEN Wording: HEALTHY This LED indicates that the MiCOM P225 relay is energised within the rated range (0.8 to 1.2 Vaux). LEDs 5 to 8: Colour: RED These LEDs can be programmed by the operator in the CONFIGURATION menu.
Page 64 By default, a value is continuously displayed, and the operator can select this value from a list in the CONFIG. As soon as an alarm is generated by the MiCOM P225 relay, the relay indicates it by an alarm message: this display takes priority and replaces the default value (see the MOTOR ALARMS and HARDW ALARMS menus).
Page 65 All that is required then is to contact AREVA T&D or its agent, stating the serial number of the relay, to receive an emergency password specific to the relay concerned.
Page 66 P225/EN FT/B11 User Guide Page 10/52 MiCOM P225 After each value, press the & key to enter the next digit. At the end of the input, press the ' key to confirm the modification. While the relay is in setting mode, the letter P (Parameter) is displayed at the bottom right of the menus and submenus headers.
Page 67 4.5.1.1 Setting group The MiCOM P225 relay has two configuration groups corresponding to two protection groups (menus PROTECTION G1 and PROTECTION G2). The operator can thus carry out 2 settings for each parameter: one for configuration group 1 and the other for configuration group 2.
Page 68 4.5.1.4 Analogue outputs (optional) The MiCOM P225 relay offers 2 optional analogue outputs to make the data available to a logic controller, at 0-20 mA or 4-20 mA as desired. The current loop support can be used as an active source circuit or a passive source circuit. The values which can be transmitted by these analogue outputs are: −...
Page 69 Four identical sub-menus - LED 5, LED 6, LED 7 and LED 8 are used to configure the 4 programmable LEDs of the MiCOM P225 relay. The user can assign one or several indications to each of these LEDs. These data can originate inside the relay (protection, automatic control, or internal logic state function) or outside the relay (logic input).
Page 70 P225/EN FT/B11 User Guide Page 14/52 MiCOM P225 • The "FORBIDDEN START" information is active if at least one of the 4 pieces of data blocking signals is active: − either thermal blocking start "θ FORBID.START" − or blocking due to limitation of the number of starts "START NB LIMIT "...
Page 71 User Guide P225/EN FT/B11 MiCOM P225 Page 15/52 The MEASUREMENTS1 and MEASUREMENT2 menus • The measurements of the phase currents and the earth current are expressed as true root-mean-square values. For a 50 Hz motor, the harmonics are taken into account up to the 10th order;...
Page 72 P225/EN FT/B11 User Guide Page 16/52 MiCOM P225 The PROCESS menu A set of measurements relating to operation displayed in the PROCESS menu makes it possible to monitor the utilisation and state of the motor. • "%I FULL LOAD" is the percentage ratio of the equivalent thermal current Ieq absorbed by the motor over the thermal current threshold Iθ>...
Page 73 MiCOM P225. It is configured in the TRIP OUTPUT RLY submenu. – Motor shutdowns for which the command was not relayed via the output relay RL1 of the MiCOM P225 are not taken into account in the TRIP STATISTICS menu. The COMMUNICATION menu...
Page 74 P225/EN FT/B11 User Guide Page 18/52 MiCOM P225 4.10 The PROTECTION G1 and PROTECTION G2 menus The menus PROTECTION G1 and PROTECTION G2 are identical and enable the operator to program 2 different configuration groups (CONFIGURATION menu). Each of these 2 menus is divided into 10 submenus corresponding to the different protection functions: •...
Page 75 The [49] THERMAL OVERLOAD submenu: Protection against thermal overload conditions The MiCOM P225 relay produces a thermal image of the motor from the line current and the negative component of the current consumed by the motor, in such a way as to take into account the thermal effects created in the stator and in the rotor.
Page 76 P225/EN FT/B11 User Guide Page 20/52 MiCOM P225 in which: − is the negative sequence current recognition factor (adjustable). − Iθ > is the thermal overload current threshold. − θ is the value of the thermal state calculated above (1 cycle before, ie. 20ms in a 50Hz system).
Page 77 +40°C. The MiCOM P225 relay offers the possibility of taking into account this necessary derating of motors. The thermal image can be modified by the ambient temperature measurement.
Page 78 ALARM. Corrective action can thus be taken before thermal tripping occurs. Once the threshold θ ALARM is exceeded, the MiCOM P225 relay calculates and displays, in the PROCESS menu (cf. chapter 4.7 The PROCESS menu), an estimate of the time remaining before a thermal trip THERM.
Page 79 (motor running, shut down, starting phase, locked rotor condition). – In the event of saturation of the phase CTs, the MiCOM P225 will detect a short-circuit under the following conditions: – Fault current lower than 200 times the limit current value for saturation of the CTs.
Page 80 P225/EN FT/B11 User Guide Page 24/52 MiCOM P225 4.10.4 The [46] UNBALANCE submenu The [46] UNBALANCE function, which protects the motor against unbalance conditions, broken conductor and phase inversions, is based on the measurement of the negative sequence component of the current.
Page 81 . This threshold and this time delay can be adjusted to allow the starting current to pass. start This function is activated (time delay tI initiated) as soon as the MiCOM P225 relay detects start a start (the criterion for detection of a start is selected in the CONFIGURATION menu). It is...
Page 82 , the stalled rotor time. stall The MiCOM P225 relay detects the overcurrent caused by stalling and generates information that the rotor has stalled while the motor is running if the phase current exceeds the threshold I for a length of time greater than tI...
Page 83 User Guide P225/EN FT/B11 MiCOM P225 Page 27/52 4.10.8.2 Locked rotor at start This function, which makes it possible to detect that the motor is locked at the start, is activated only during the starting phase, that is during the course of the starting time delay...
Page 84 P225/EN FT/B11 User Guide Page 28/52 MiCOM P225 4.10.10 The [49/38] RTD submenu: Temperature protection by RTD (optional) The [49/38] RTD SENSORS [49/38] function is intended to detect abnormal temperature rises of the motor by direct temperature monitoring. This is achieved by monitoring 10 RTDs (Remote Temperature Detectors).
Page 85 User Guide P225/EN FT/B11 MiCOM P225 Page 29/52 4.11 The AUTOMAT. CTRL menu The AUTOMAT. CTRL menu comprises the following 14 sub-menus: • [66] START NUMBER • MIN TIME BETW 2 START • RE-ACCEL AUTHORIZ • INPUTS • AND LOGIC EQUATION •...
Page 86 P225/EN FT/B11 User Guide Page 30/52 MiCOM P225 Case n°1: The number of cold starts limit has been reached and the motor is stopped before the end of the T period: the T time delay is therefore initiated when the motor stops. A new...
Page 87 User Guide P225/EN FT/B11 MiCOM P225 Page 31/52 Case n°3: Particular cases where at the end of the T time delay, the number of starts counter is interdiction still reached (the T time delay period is completed before the end of T...
Page 88 The MiCOM P225 relay can detect and measure the duration of a voltage drop. By comparing how long this voltage reduction lasts with an adjustable time delay T...
Page 89 User Guide P225/EN FT/B11 MiCOM P225 Page 33/52 • Before the end of the T time-delay (duration of the voltage sag shorter than T reacc reacc the voltage is back (voltage greater than "Restoration V Dip"), but the current absorbed by the motor does not cross the I...
Page 90 P225/EN FT/B11 User Guide Page 34/52 MiCOM P225 Case n°2: The duration of the voltage sag is shorter than the T time-delay, but the motor does not reacc reaccelerate within 5 seconds after the voltage has returned. The P225 operation does not change.
Page 91 If PICK UP has been selected in the INPUT CONFIG. sub-menu Upon receipt of a pick-up (minimum duration 15ms) of the logic input set to "SET GROUP", the MiCOM P225 relay switches between setting groups. The change from one configuration to another can also be achieved via the operator menu or the communication network (see section 4.5.1.1.
Page 92 P225/EN FT/B11 User Guide Page 36/52 MiCOM P225 A parameter setting group change is not possible if one of the following protection functions is in progress (that is to say if the current threshold of these functions is exceeded): −...
Page 93 User Guide P225/EN FT/B11 MiCOM P225 Page 37/52 4.11.4.2.7 Auxiliary 3 and auxiliary 4 data The “ EXT3 ” and “ EXT4 ” assignments operate similarly to “ EXT1 ” and “ EXT2 ”, but when the associated timers expire: −...
Page 94 P225/EN FT/B11 User Guide Page 38/52 MiCOM P225 Programming in the AND LOGIC EQUAT menu is carried out as follows. In this example, the first equation will be the A equation and the second B: Allocation of the “ t lo> ” data to equation A.
Page 95 User Guide P225/EN FT/B11 MiCOM P225 Page 39/52 Below, a logic diagram shows the different possibilities offered by the MiCOM P225 relay: operation reset & PROTECTION functions operation reset & Output External and relays internal allocation: AUTOMAT. logic signals operation reset &...
Page 96 The AUX OUTPUT RLY submenu : Auxiliary programmable output relays In this menu the user assigns the MiCOM P225 internal and external data to the auxiliary output relays (relays RL2, RL3, RL4 or RL5). These are changeover type relays (1 common, 1 normally open contact, 1 normally close contact).
Page 97 User Guide P225/EN FT/B11 MiCOM P225 Page 41/52 4.11.10 The LATCH TRIP ORDER submenu: Latching of the trip output relay In this menu, the user selects which functions are to maintain the output relays energised when an order is generated by these functions.
Page 98 P225/EN FT/B11 User Guide Page 42/52 MiCOM P225 Trip order t BF timer 20 samples 20 samples 20 samples 20 samples 20 samples 20 samples I< threshold I< threshold 20 samples 20 samples 20 samples 20 samples 20 samples 20 samples...
Page 99 User Guide P225/EN FT/B11 MiCOM P225 Page 43/52 Case n°2: In the figure below the circuit-breaker does not open before the end of the tBF time-delay. In this case the relay issues a CB FAIL indication. CB failed « CB FAIL » signal «...
Page 100 P225/EN FT/B11 User Guide Page 44/52 MiCOM P225 4.11.12 The ABS sub-menu: Minimum time between a stop and a start The ABS (anti-backspin) function imposed a waiting time between a stop and a re-start of the motor. This waiting time makes it possible to stop rotating before the motor is re-started.
Page 101 This application diagram requires that 2 logic inputs are assigned to "TRIP CIRC", that the auxiliary contacts 52a (o/o) and 52b (c/o) are available. The MiCOM P225 relay checks the trip circuit wiring continuity whatever the position of the circuit-breaker poles: open or closed.
Page 102 (relays RL2, RL3, RL4 or RL5). So as to adapt the MiCOM P225 to any type of cut-off device, the user can also configure 2 time delays: One maintenance of tripping order TRIP T time delay: For each tripping order sent on the relay RL1, the latter is kept switched on for a time TRIP T (if the “...
Page 103 User Guide P225/EN FT/B11 MiCOM P225 Page 47/52 4.12 The RECORD menu The RECORD menu comprises 3 sub menus: • FAULT RECORD • DISTURB RECORD • CB MONITORING 4.12.1 The FAULT RECORD submenu A collection of data on each of the 5 last faults registered is displayed in the FAULT RECORD sub menu.
Page 104 4.12.2 The DISTURBANCE RECORD submenu The MiCOM P225 relay offers the possibility of saving 5 disturbance records. The data are acquired at a frequency of 32 samples per electrical cycle, ie. 1600Hz in a 50Hz system or 1920 Hz in 60Hz system, and allows for a very faithful reconstruction of the analogue signals.
Page 105 (selected in CONFIG. SELECT submenu), so that as soon as an alarm is detected by the, the message is displayed on the MiCOM P225 relay screen. The alarm messages are classified into 2 categories: •...
Page 106 4.13.2 The HARDWARE ALARM messages The safety and availability of the MiCOM P225 relay can be improved by a cyclic autotest procedure of both hardware and software. Each time the P225 relay is switched on, auto- diagnostic tests are initiated: these tests deal with the output relays (engaging/triggering tests), the microprocessor, the memories (EEPROM checksum calculation, RAM tests) and the acquisition circuit of each analogue input.
Page 107 Recording of the form of the starting current and voltage The MiCOM P225 relay records the form of current and voltage of the latest start. In order to do this, it records every 5 cycles (every 100 ms if the frequency is at 50 Hz) the maximum value of one of the three line currents, and the value of the line-line voltage V .
Page 108 User Guide Page 52/52 MiCOM P225 PC CONNECTION – LOCAL COMMUNICATIONS Connection configuration Configuration is indicated in the figure below: MiCOM P225 Relay Laptop 9 pin front port Battery Serial communication port (COM1 or COM2) Serial data connector (up to 15m)
Page 109 Menu of the HMI P225/EN HI/B11 MiCOM P225 MENU OF THE HMI...
Page 111 Menu of the HMI P225/EN HI/B11 MiCOM P225 Page 1/48 CONTENT THE OP. PARAMETERS MENU THE CONFIGURATION MENU The CONFIG. SELECT submenu The CT/VT RATIO submenu The LED submenus The ALARM CONFIG. submenu The INPUT CONFIG. submenu THE MEASUREMENTS 1 & MEASUREMENTS 2 SUBMENUS...
Page 112 P225/EN HI/B11 Menu of the HMI Page 2/48 MiCOM P225 8.10 The LATCH TRIP ORDER submenu 8.11 The CB FAIL submenu 8.12 The ABS submenu 8.13 The BUS VOLTAGE CTRL submenu 8.14 The CB SUPERVISION submenu THE RECORD MENU The FAULT RECORD submenu...
Page 113 Menu of the HMI P225/EN HI/B11 MiCOM P225 Page 3/48 THE OP. PARAMETERS MENU Press the ! and " keys to move around in the OP OP. PARAMETERS PARAMETERS menu. Modification of the password : key in the old password PASSWORD = and confirm it.
Page 114 P225/EN HI/B11 Menu of the HMI Page 4/48 MiCOM P225 THE CONFIGURATION MENU The CONFIG. SELECT submenu Press the ! and " keys to enter the CONFIGURATION CONFIGURATION menu. To move about in the CONFIG. SELECT submenu, use CONFIG. SELECT the ! and "...
Page 115 Menu of the HMI P225/EN HI/B11 MiCOM P225 Page 5/48 The CT/VT RATIO submenu Press the ! and " keys to enter the CONFIGURATION CONFIGURATION menu To move about in the CT/VT RATIO submenu, press the CT/VT RATIO ! and " keys. To go into the CONFIG. SELECT, LED 5, LED 6, LED 7 and LED 8, ALARM CONFIG.
Page 116 P225/EN HI/B11 Menu of the HMI Page 6/48 MiCOM P225 The LED submenus Press the ! and " keys to enter the CONFIGURATION CONFIGURATION menu. To move about in the LED 5 submenu, press the ! and LED 5 " keys. To go into the CONFIG. SELECT, CT/VT RATIO, LED 6, LED 7 and LED 8, ALARM CONFIG.
Page 117 Menu of the HMI P225/EN HI/B11 MiCOM P225 Page 7/48 This links LED 5 to the time delayed thresholds t t RTD 7, 8, 9, 10 RTD7 TRIP and t (temperature protection : TRIP ? RTD8 TRIP RTD9 TRIP RTD10 TRIP...
Page 118 P225/EN HI/B11 Menu of the HMI Page 8/48 MiCOM P225 The ALARM CONFIG. submenu Press the ! and " keys to enter into the CONFIGURATION CONFIGURATION menu. To move about in the ALARM CONFIG. Submenu, press ALARM CONFIG. the ! and " keys. To go into the CONFIG. SELECT, CT/VT RATIO, LED 5, LED 6, LED 7, LED 8 and INPUT CONFIG., press the % and $ keys.
Page 119 Menu of the HMI P225/EN HI/B11 MiCOM P225 Page 9/48 The INPUT CONFIG. submenu Press the ! and " keys to enter into the CONFIGURATION CONFIGURATION menu. To move about in the INPUT CONFIG. menu, press the INPUT CONFIG. ! and " keys. To go to the CONFIG. SELECT, CT/VT RATIO, LED 5, LED 6, LED 7, LED 8 and ALARM CONFIG.
Page 120 P225/EN HI/B11 Menu of the HMI Page 10/48 MiCOM P225 THE MEASUREMENTS 1 & MEASUREMENTS 2 SUBMENUS Press the ! and " keys to move about in the MEASUREMENTS 1 MEASUREMENTS 1 menu. Display of the current of phase A (true RMS value)
Page 121 Menu of the HMI P225/EN HI/B11 MiCOM P225 Page 11/48 Press the ! and " keys to move about in the MEASUREMENTS 2 MEASUREMENTS 2 menu Display of the active power taking into account the CT WATTs = and VT phase ratio (CT/VT RATIO submenu) 0.00...
Page 122 P225/EN HI/B11 Menu of the HMI Page 12/48 MiCOM P225 THE PROCESS MENU Press the ! and " keys to move about in the PROCESS PROCESS menu. Display of the current flowing into the motor as a % I FLC percentage of the thermal current threshold Iθ>...
Page 123 Menu of the HMI P225/EN HI/B11 MiCOM P225 Page 13/48 THE TRIP STATISTICS MENU Press the ! and " keys to move about in the TRIP TRIP STATISTICS STATISTICS menu. To reset all the tripping statistics to zero, press key &...
Page 124 Selection and display of the number of stop bits. STOP BITS = Choice : 1 or 2. Selection and display of the address of the MiCOM P225 RELAY ADDRESS = relay in the network. Choice from : 1 to 255.
Page 125 Menu of the HMI P225/EN HI/B11 MiCOM P225 Page 15/48 THE PROTECTION G1 AND G2 MENUS The [49] THERMAL OVERLOAD submenu Press the ! and " keys to enter the PROTECTION G1 PROTECTION G1 menu. To move about in the [49] THERMAL OVERLOAD [49] THERMAL OVERLOAD submenu, press the ! and "...
Page 126 P225/EN HI/B11 Menu of the HMI Page 16/48 MiCOM P225 The [50/51] SHORT-CIRCUIT submenu Press the ! and " keys to enter the PROTECTION G1 PROTECTION G1 menu. To move about in the [50/51] SHORT-CIRCUIT [50/51] SHORT - submenu, press the ! and " keys. To enter the others CIRCUIT submenus, press the % an $ keys.
Page 127 Menu of the HMI P225/EN HI/B11 MiCOM P225 Page 17/48 The [50N/51N] EARTH FAULT submenu Press the ! and " keys to enter the PROTECTION G1 PROTECTION G1 menu. To move about in the [50N/51N] EARTH FAULT [50N/51N] EARTH submenu, press the ! and " keys. To enter the other FAULT submenus, press the % and $ keys.
Page 128 P225/EN HI/B11 Menu of the HMI Page 18/48 MiCOM P225 The [46] UNBALANCE submenu Press the ! and " keys to enter the PROTECTION G1 PROTECTION G 1 menu. To move about in the [46] UNBALANCE submenu, press [46] UNBALANCE the ! and "...
Page 129 Menu of the HMI P225/EN HI/B11 MiCOM P225 Page 19/48 The [27] UNDERVOLTAGE submenu Press the ! and " keys to enter the PROTECTION G1 PROTECTION G1 menu. To move about in the [27] UNDERVOLTAGE submenu, [27] UNDERVOLTAGE press the ! and " keys. To enter the other submenus, press the %and $ keys .
Page 130 P225/EN HI/B11 Menu of the HMI Page 20/48 MiCOM P225 The [59] OVERVOLTAGE submenu Press the ! and " keys to enter the PROTECTION G1 PROTECTION G1 menu. To move about in the [59] OVERVOLTAGE submenu, [59] OVERVOLTAGE press the ! and " keys. To enter the other submenus, press the % and $ keys.
Page 131 Menu of the HMI P225/EN HI/B11 MiCOM P225 Page 21/48 The [48] EXCES LONG START submenu Press the ! and " keys to enter the PROTECTION G1 PROTECTION G 1 menu. To move about in the [48] EXCES LONG START [48] EXCES LONG submenu, press the ! and "...
Page 132 P225/EN HI/B11 Menu of the HMI Page 22/48 MiCOM P225 The [51LR/50S] BLOCK ROTOR submenu Press the ! and " keys to enter the PROTECTION G1 PROTECTION G 1 menu. To move about in the [51LR/50S] BLOCK ROTOR [51LR-50S] BLOCK submenu, press the ! and "...
Page 133 Menu of the HMI P225/EN HI/B11 MiCOM P225 Page 23/48 The [37] LOSS OF LOAD submenu Press the ! and " keys to enter the PROTECTION G1 PROTECTION G 1 menu. To move about in the [37] LOSS OF LOAD submenu, [37] LOSS OF LOAD press the ! and "...
Page 134 P225/EN HI/B11 Menu of the HMI Page 24/48 MiCOM P225 7.10 The [49/38] RTD submenu Press the ! and " keys to enter the PROTECTION G1 PROTECTION G 1 menu. To move about in the [49/38] RTD submenu, press the [49/38] RTD ! and "...
Page 135 Menu of the HMI P225/EN HI/B11 MiCOM P225 Page 25/48 7.11 The [49] THERMISTOR submenu Press the ! and " keys to enter the PROTECTION G1 PROTECTION G 1 menu. To move about in the [49] THERMISTOR submenu, [49] THERMISTOR press the ! and "...
Page 136 P225/EN HI/B11 Menu of the HMI Page 26/48 MiCOM P225 THE AUTOMAT. CTRL MENU The [66] START NUMBER submenu Press the ! and " keys to enter the AUTOMAT. CTRL AUTOMAT. CTRL menu. To move about in the [66] START NUMBER submenu, [66] START NUMBER press the ! and "...
Page 137 Menu of the HMI P225/EN HI/B11 MiCOM P225 Page 27/48 The MIN TIME BETW 2 START submenu Press the ! and " keys to enter the AUTOMAT. CTRL AUTOMAT. CTRL menu. To move about in the MIN TIME BETW 2 START MIN TIME BETW 2 submenu, press the ! and "...
Page 138 P225/EN HI/B11 Menu of the HMI Page 28/48 MiCOM P225 The REACCEL AUTHORIZ submenu Press the ! and " keys to enter the AUTOMAT. CTRL AUTOMAT. CTRL menu. To move about in the RE-ACCEL AUTHORIZ submenu, REACCEL AUTHORIZ press the ! and " keys. To enter the other submenus, press the % and $ keys.
Page 139 Menu of the HMI P225/EN HI/B11 MiCOM P225 Page 29/48 The INPUTS submenu Press the ! and " keys to enter the AUTOMAT. CTRL AUTOMAT. CTRL menu. To move about in the INPUTS submenu, press the ! INPUTS and " keys.
Page 140 P225/EN HI/B11 Menu of the HMI Page 30/48 MiCOM P225 The AND LOGIC EQUAT submenu Press the ! and " keys to enter the AUTOMAT. CTRL AUTOMAT. CTRL menu. To move about in the AND LOGIC EQUAT submenu, AND LOGIC EQUAT press the ! and "...
Page 141 Menu of the HMI P225/EN HI/B11 MiCOM P225 Page 31/48 Allocation of the function « trip circuit wiring TRIP CIRC. D C B A supervision ». FAIL 0 0 0 0 Allocation of the t time-delayed threshold t RTD 1...
Page 142 P225/EN HI/B11 Menu of the HMI Page 32/48 MiCOM P225 The AND LOGIC EQUAT T DELAY submenu Press the ! and " keys to enter the AUTOMAT. CTRL AUTOMAT. CTRL menu. To move about in the AND LOGIC EQUAT T DELAY AND LOGIC EQUAT submenu, press the ! and "...
Page 143 Menu of the HMI P225/EN HI/B11 MiCOM P225 Page 33/48 The AUX OUTPUT RLY submenu Press the ! and " keys to enter the AUTOMAT. CTRL AUTOMAT. CTRL menu. To move about in the AUX OUTPUT RLY, press the ! AUX OUTPUT RLY and "...
Page 144 P225/EN HI/B11 Menu of the HMI Page 34/48 MiCOM P225 Allocation of the t time-delayed threshold t RTD1 5 4 3 2 RTD1 TRIP (temperature protection : optional) TRIP 0 0 0 0 …and so on for the RTD2, RTD3, RTD4, RTD5, RTD6, RTD7, RTD8, RTD9 and RTD10 probes (optional).
Page 145 Menu of the HMI P225/EN HI/B11 MiCOM P225 Page 35/48 Allocation of the threshold of the number of operations CB OPER 5 4 3 2 performed by the circuit breaker. 0 0 0 0 Allocation of the threshold of the sum of amperes to the...
Page 146 P225/EN HI/B11 Menu of the HMI Page 36/48 MiCOM P225 The LATCH AUX OUTPUT RLY submenu Press the ! and " keys to enter the AUTOMAT. CTRL AUTOMAT. CTRL menu. To move about in the LATCH AUX RLY submenu, press LATCH AUX the ! and "...
Page 147 Menu of the HMI P225/EN HI/B11 MiCOM P225 Page 37/48 The TRIP OUTPUT RLY submenu Press the ! and " keys to enter the AUTOMAT. CTRL AUTOMAT. CTRL menu. To move about in the TRIP OUTPUT RLY submenu, TRIP OUTPUT RLY press the ! and "...
Page 148 P225/EN HI/B11 Menu of the HMI Page 38/48 MiCOM P225 Allocation of the logic equation D. EQUATION D ? Allocation of the tV< time-delayed threshold t V< ? (undervoltage). Allocation of the load shedding information VOLTAGE VOLTAGE DIP (re-acceleration function).
Page 149 Menu of the HMI P225/EN HI/B11 MiCOM P225 Page 39/48 8.10 The LATCH TRIP ORDER submenu Press the ! and " keys to enter the AUTOMAT. CTRL AUTOMAT. CTRL menu. To move about in the LATCH TRIP ORDER submenu, LATCH TRIP ORDER press the ! and "...
Page 150 P225/EN HI/B11 Menu of the HMI Page 40/48 MiCOM P225 Latching on validation of equation D. LATCH EQUA. D ? Latching on exceeding the t V< time-delayed threshold LATCH t V< ? (undervoltage). Latching on VOLTAGE DIP load-shedding information LATCH VOLTAGE (re-acceleration function).
Page 151 Menu of the HMI P225/EN HI/B11 MiCOM P225 Page 41/48 8.11 The CB FAIL submenu Press the ! and " keys to enter the AUTOMAT. CTRL AUTOMAT. CTRL menu. To move about in the CB FAIL submenu, press the ! CB FAIL and "...
Page 152 P225/EN HI/B11 Menu of the HMI Page 42/48 MiCOM P225 8.12 The ABS submenu Press the ! and " keys to enter the AUTOMAT. CTRL AUTOMAT. CTRL menu. To move about in the ABS submenu, press the ! and " keys.
Page 153 Menu of the HMI P225/EN HI/B11 MiCOM P225 Page 43/48 8.13 The BUS VOLTAGE CTRL submenu Press the ! and " keys to enter the AUTOMAT. CTRL AUTOMAT. CTRL menu. To move about in the BUS VOLTAGE CTRL submenu, BUS VOLTAGE CTRL press the ! and "...
Page 154 P225/EN HI/B11 Menu of the HMI Page 44/48 MiCOM P225 8.14 The CB SUPERVISION submenu Press the ! and " keys to enter the AUTOMAT. CTRL AUTOMAT. CTRL menu. To move about in the CB SUPERVISION submenu, CB SUPERVISION press the ! and " keys. To enter the other submenus, press the % and $ keys.
Page 155 Menu of the HMI P225/EN HI/B11 MiCOM P225 Page 45/48 THE RECORD MENU The FAULT RECORD submenu Press the ! and " keys to enter the RECORD menu. RECORD To move about in the FAULT RECORD submenu, press FAULT RECORD the ! and "...
Page 156 P225/EN HI/B11 Menu of the HMI Page 46/48 MiCOM P225 The DISTURB RECORD submenu Press the ! and " keys to enter the RECORD menu. RECORD To move about in the DISTURB RECORD submenu, DISTURB RECORD press the ! and " keys. To enter the FAULT RECORD and CB MONITORING submenus, press the % and $ keys.
Page 157 Menu of the HMI P225/EN HI/B11 MiCOM P225 Page 47/48 The CB MONITORING submenu Press the ! and " keys to enter the RECORD menu. RECORD To move about in the CB MONITORING submenu, CB MONITORING press the ! and " keys. To enter the other submenus, press the % and $ keys.
Page 158 P225/EN HI/B11 Menu of the HMI Page 48/48 MiCOM P225 BLANK PAGE...
Page 159 Maintenance P225/EN CM/B11 MiCOM P225 MAINTENANCE...
Page 161 Maintenance P225/EN CM/B11 MiCOM P225 Page 1/18 CONTENT INTRODUCTION MAINTENANCE PERIOD MAINTENANCE CHECKS Alarms Logic inputs Output relays 3.3.1 Maintenance mode 3.3.2 Testing the output relays EXCHANGING THE RELAY Remove the withdrawable part Exchanging the relay and the case CHANGING THE BATTERY...
Page 162 P225/EN CM/B11 Maintenance Page 2/18 MiCOM P225 BLANK PAGE...
Page 163 MiCOM P225 Page 3/18 INTRODUCTION The MiCOM P225 relays are fully numerical in design and employ a high degree of self- checking. Any fault affecting a hardware or software component is instantly detected and signalled as a device fault. BEFORE CARRYING OUT ANY WORK ON THE EQUIPMENT, THE USER SHOULD BE FAMILIAR WITH THE CONTENTS OF THE "HANDLING AND...
Page 164 MiCOM P225 MAINTENANCE PERIOD It is recommended that products supplied by AREVA T&D receive regular monitoring after installation. As with all products some deterioration with time is inevitable. In view of the critical nature of protective relays and their infrequent operation, it is desirable to confirm that they are operating correctly at regular intervals.
Page 165 The logic inputs (opto-isolators) can be checked to ensure that the relay responds on energisation. This test checks that all 6 opto-isolated outputs of the MiCOM P225 are functioning correctly. Energise the logic inputs one at a time with voltage V, with the terminal numbers in accordance with the table below.
Page 166 P225/EN CM/B11 Maintenance Page 6/18 MiCOM P225 • While the MiCOM relay is in Maintenance mode: − All protective functions are disabled − All automation functions are disabled − All output relays are off (including the watchdog relay) − The ALARM LED flashes −...
Page 167 Before replacing the withdrawable part in the case, reset the 2 opposing cams. N. B.: MiCOM P225 relays have integral current transformer shorting switches which will close when the withdrawable part is removed. In case of fuse-contactor controlled by a voltage loss coil, do not remove the withdrawable part if the contactor is closed.
Page 168 P225/EN CM/B11 Maintenance Page 8/18 MiCOM P225 Exchanging the relay and the case BEFORE WORKING AT THE REAR OF THE RELAY, ISOLATE ALL VOLTAGE AND CURRENT SUPPLIES TO THE RELAY. DISCONNECT THE RELAY EARTH CONNECTION FROM THE REAR OF THE CASE.
Page 169 Page 9/18 CHANGING THE BATTERY MiCOM P225 relays have a battery to maintain status data and the correct time if the auxiliary supply voltage fails. The data maintained includes event, fault and disturbance records and the thermal state at the time of failure.
Page 170 P225/EN CM/B11 Maintenance Page 10/18 MiCOM P225 EQUIPMENT FAILURE: HARDWARE ALARMS Types of equipment failure As soon as an internal fault (i.e. an equipment failure) is detected in the MiCOM relay: • An alarm is displayed as a priority on the front panel display.
Page 171 Maintenance P225/EN CM/B11 MiCOM P225 Page 11/18 Equipment failures and solutions 6.2.1 COMM. ERROR Communication module failure via RS485 port. This can be a hardware or software failure. Action: − If communication is not being used, declare communication OFF in the COMMUNICATION menu.
Page 172 P225/EN CM/B11 Maintenance Page 12/18 MiCOM P225 6.2.5 BATTERY ERROR This alarm appears if the 3.6 V Lithium battery located on the front panel is flat, missing or incorrectly positioned. Action: Check that the battery is present. Check the state of the battery (voltage higher than 3.5 V?).
Page 173 (under the upper flap on the front panel). Contact your AREVA local dealer or the AREVA T&D After Sales Department with the serial number (phone: 33 (0)4 67 20 55 55).
Page 174 P225/EN CM/B11 Maintenance Page 14/18 MiCOM P225 7.1.2.3 A remote control signal is not taken into account Problem: Communication between the relay and the PC is OK but the MiCOM relay will not accept remote control signals nor setting file downloads.
Page 175 Maintenance P225/EN CM/B11 MiCOM P225 Page 15/18 LIST OF THE RELAY ALARM MESSAGES Heading of the HARDW ALARMS messages, default display in HARDW ALARMS case of either relay error alarm or RTDs/thermistor failure. To display the alarms messages, press the key.
Page 176 P225/EN CM/B11 Maintenance Page 16/18 MiCOM P225 LIST OF THE MOTOR ALARM MESSAGES Heading of the MOTOR ALARMS messages, default display in MOTOR ALARMS case of motor alarm. To display the alarms messages, press the ! key. Operation of the « thermal overload » function.
Page 177 Maintenance P225/EN CM/B11 MiCOM P225 Page 17/18 Operation of the auxiliary timer EXT 2. EXT 2 And logic equation A active EQUATION A …and so on for the AND logic equations B, C and D Circuit breaker opening time has reached (or it has exceeded) CB OPENING the “...
Page 178 P225/EN CM/B11 Maintenance Page 18/18 MiCOM P225 PAGE BLANCHE...
Page 179 Communication P225/EN CT/B11 MiCOM P225 COMMUNICATION...
Page 181 MODBUS functions of the MiCOM relays Presentation of the MODBUS protocol 1.3.1 Frame size received by the MiCOM P225 relay 1.3.2 Format of frames sent by the MiCOM P225 relay 1.3.3 Messages validity check Modbus request definition used to retrieve the disturbance records 1.4.1 Request to know the number of available disturbance records in the Saved RAM.
Page 182 Page 3 : Remote settings for protection functions group No2 1.8.6 Page 4 : Remote controls 1.8.7 Pages 5 and 6 : Reserved 1.8.8 Page 7 : MiCOM P225 relay status word 1.8.9 Page 8 : Synchronisation 1.8.10 Page 9h to 21h : Disturbance record data (25 pages) 1.8.11 Page 22h : Index frame for the disturbance records 1.8.12...
Page 183 MODBUS communication characteristics 1.1.1 MODBUS network characteristics The MODBUS protocol is based on the master-slave principle with the MiCOM P225 relay as slave. The MODBUS protocol allows the master to read and to write one or several bits, one or several words and to remote the event logging data.
Page 184 P225/EN CT/B11 Communication Page 4/52 MiCOM P225 1.1.2 Parameters of the MODBUS connection The different parameters of the MODBUS connection are as follows : − Isolated two-point RS485 connection (2kV 50Hz). − MODBUS line protocol in RTU mode. − The baud rate can be configured by operator dialogue in the front panel of the relay :...
Page 185 Presentation of the MODBUS protocol MODBUS is a master-slave protocol whereby every exchange involves a master query and a slave response. 1.3.1 Frame size received by the MiCOM P225 relay Frame transmitted by the master (query) : Slave number Function code...
Page 186 P225/EN CT/B11 Communication Page 6/52 MiCOM P225 1.3.2 Format of frames sent by the MiCOM P225 relay Frame sent by the MiCOM relay (response) : Slave number Function code Data CRC16 1 byte 1 byte n bytes 2 bytes 1 to FFh...
Page 187 Communication P225/EN CT/B11 MiCOM P225 Page 7/52 Modbus request definition used to retrieve the disturbance records To retrieve a disturbance record, the following requests must be done in the exact given order : (optional) : Send a request to know the number of disturbance records available in the saved RAM.
Page 188 P225/EN CT/B11 Communication Page 8/52 MiCOM P225 1.4.4 Request to retrieve an index frame Slave number Function code Word address Word number xx....xx This event request may be answered an error message with the error code : CODE_SERV_NOK (05) : The record number and the channel number have not been specified by a service request.
Page 189 Communication P225/EN CT/B11 MiCOM P225 Page 9/52 Modbus request definition used to retrieve the fault records Two ways can be followed to retrieve a fault record : − Send a request to retrieve the oldest non-acknowledge fault record. − Send a request to retrieve a dedicated fault record.
Page 190 P225/EN CT/B11 Communication Page 10/52 MiCOM P225 Modbus request definition used to retrieve both start-up current & voltage form record To retrieve both start-up current & voltage form record, process as described below : Send a request to know the number of values stored into the saved RAM.
Page 191 Description of the MODBUS application mapping The MODBUS mapping contains 60 pages. Pages 0 to 8 : Contain the MiCOM P225 parameters. Pages 9 to 51h : Contain the data of the event records, data of the fault value records, data of the disturbance records and data of both start-up current &...
Page 192 P225/EN CT/B11 Communication Page 12/52 MiCOM P225 1.8.2 Page 0 : Information of product, remote signalling, remote measurements Access only for reading Values Default Address Group Description Step Unit Format range value 0000 Product Description of the relay 32 -127...
Page 193 Communication P225/EN CT/B11 MiCOM P225 Page 13/52 Values Default Address Group Description Step Unit Format range value 0022 Display alarm message : t I>> PHASE 0023 Display alarm message: t I< PHASE (Mini I) 0024 Display alarm messages 0025 Display alarm messages F41’...
Page 194 P225/EN CT/B11 Communication Page 14/52 MiCOM P225 Values Default Address Group Description Step Unit Format range value 0050 Process Load current as % Iθ> 0051 Thermal status value 0052 Reserved 0053 Time before thermal trip Seconds 0054 RTD1 temperature value -400 to 2000 1/10 °C...
Page 195 Communication P225/EN CT/B11 MiCOM P225 Page 15/52 Values Default Address Group Description Step Unit Format range value 0077 Stalled rotor trip number (whilst running – tIstall)) 0078 Locked rotor trip number (at start) 0079 Loss of load trip number (tI<)
Page 196 P225/EN CT/B11 Communication Page 16/52 MiCOM P225 Values Default Address Group Description Step Unit Format range value 009D Fourier Angle VAC voltage angle 009E - 009F Reserved 1.8.3 Page 1 : Remote settings for general parameters Access for reading and writing...
Page 197 Communication P225/EN CT/B11 MiCOM P225 Page 17/52 Values Default Address Group Description Step Unit Format range value 0117 Configuration of both RAM ERROR & BATTERY ERROR alarm message 0118 Configuration of the way to switch of active setting group 0119 to 011F...
Page 198 P225/EN CT/B11 Communication Page 18/52 MiCOM P225 Values Default Address Group Description Step Unit Format range value 015B t RTD10 TRIP 0 to 15 F14’ 015C Reserved 015D GROUP 2 ACTIVE 0 to 15 Auxiliary output relays allocation 015E Logic inputs...
Page 199 Communication P225/EN CT/B11 MiCOM P225 Page 19/52 Values Default Address Group Description Step Unit Format range value 017E Loss of load : t I< (time 0 to 15 delayed) 017F Start number limitation 0 to 15 START NB LIMIT 0180...
Page 200 P225/EN CT/B11 Communication Page 20/52 MiCOM P225 Values Default Address Group Description Step Unit Format range value 01A0 Thermal overload : 0 to 15 F14’ « AND » logical THERM OV. gates allocation 01A1 Thermal alarm : 0 to 15 F14’...
Page 201 Communication P225/EN CT/B11 MiCOM P225 Page 21/52 Values Default Address Group Description Step Unit Format range value 01C7 t RTD8 TRIP 0 to 15 F14’ 01C8 t RTD9 ALARM 0 to 15 F14’ 01C9 t RTD9 TRIP 0 to 15 F14’...
Page 202 P225/EN CT/B11 Communication Page 22/52 MiCOM P225 Values Default Address Group Description Step Unit Format range value 01E5 Logic inputs EXT1 time delay 0 to 20000 1/100 sec 01E6 EXT2 time delay 0 to 20000 1/100 sec 01E7 Disturbance Pre-time...
Page 203 Communication P225/EN CT/B11 MiCOM P225 Page 23/52 Values Default Address Group Description Step Unit Format range value 01FE Function : BUS VOLTAGE CONTROL ? 01FF V BUS threshold 50 to 1300 1/10 V 50 or or 200 to 4800 1.8.4...
Page 204 P225/EN CT/B11 Communication Page 24/52 MiCOM P225 Values Default Address Group Description Step Unit Format range value 0233 I2>> function 0234 I2>> threshold 40 to 800 1/1000 In 0235 V< function 0236 V< threshold 50 to 1300 1/10V 50 or 200...
Page 205 Communication P225/EN CT/B11 MiCOM P225 Page 25/52 Values Default Address Group Description Step Unit Format range value 0260 RTD1 function 0261 RTD1 ALARM threshold 0-200 °C 0262 t RTD1 ALARM time 0 to 1000 1/10 sec delay 0263 RTD1 TRIP threshold 0-200 °C...
Page 206 P225/EN CT/B11 Communication Page 26/52 MiCOM P225 Values Default Address Group Description Step Unit Format range value 0285 RTD7 ALARM threshold 0-200 °C 0286 t RTD7 ALARM time 0 to 1000 1/10 sec delay 0287 RTD7 TRIP threshold 0-200 °C...
Page 207 Communication P225/EN CT/B11 MiCOM P225 Page 27/52 Values Default Address Group Description Step Unit Format range value 0324 I0>> threshold 2 to 1000 1/1000 Ion F1 0325 tI0>> time delay 0 to 10000 1 1/100 s 0326 to 032E Reserved 032F TMS I2>>...
Page 208 P225/EN CT/B11 Communication Page 28/52 MiCOM P225 Values Default Address Group Description Step Unit Format range value 0359 RTD10 TRIP threshold 0-200 °C 035A t RTD10 TRIP time delay 0 to 1000 1/10 sec 035B RTD9 function 035C RTD9 ALARM threshold 0-200 °C...
Page 209 0 to 63 Remote control of the output relays – under Maintenance mode only 1.8.7 Pages 5 and 6 : Reserved 1.8.8 Page 7 : MiCOM P225 relay status word Access for quick reading Values Default Address Group Description Step...
Page 210 P225/EN CT/B11 Communication Page 30/52 MiCOM P225 1.8.9 Page 8 : Synchronisation Access in writing. It exists 2 possible date format configurations : − IEC format : Inverted IEC 870-5-4 CP56Time2a − Private format 1.8.9.1 Mapping for IEC format : The format of the clock synchronisation is coded on 8 bytes (4 words).
Page 211 Communication P225/EN CT/B11 MiCOM P225 Page 31/52 1.8.9.2 Mapping for PRIVATE format : The format of the clock synchronisation is coded on 8 bytes (4 words). Clock @page byte number Value range Unit Year LSB + MSB Year Months 1 - 12...
Page 212 P225/EN CT/B11 Communication Page 32/52 MiCOM P225 1.8.11 Page 22h : Index frame for the disturbance records Access in reading. Address Contents Format 2200h Index frame for the disturbance records 1.8.12 Page 23h to 33h : Start-up current form record data Access in reading.
Page 213 Communication P225/EN CT/B11 MiCOM P225 Page 33/52 1.8.14 Page 35h : Event record data Access in reading. Address Contents Format Address Contents Format Address Contents Format 3500h EVENT n°1 3519h EVENT n°26 F52 3532h EVENT n°51 F52 3501h EVENT n°2 351Ah EVENT n°27 F52...
Page 214 P225/EN CT/B11 Communication Page 34/52 MiCOM P225 1.8.16 Page 37h : Fault value record data Access in reading. Address Contents Format 3700h Data of the fault value record n°1 3701h Data of the fault value record n°2 3702h Data of the fault value record n°3 3703h Data of the fault value record n°4...
Page 215 Communication P225/EN CT/B11 MiCOM P225 Page 35/52 Disturbance record Address Channel Format number 3B06h V AC (phase A–phase C voltage) F54 3C00h I A (phase A current) 3C01h I B (phase B current) 3C02h I C (phase C current) 3C03h...
Page 216 P225/EN CT/B11 Communication Page 36/52 MiCOM P225 Address Contents Format 4E00 to 4EF8h 124 values 4F00 to 4FF8h 124 values 5000 to 500Fh 16 values 1.8.22 Page 51h : Index frame for the start-up voltage form record Access in reading.
Page 217 Communication P225/EN CT/B11 MiCOM P225 Page 37/52 CODE DESCRIPTION Unsigned long : Trip output relay assignment (RL1) bit 0 : tI>> bit 1 : tI0> Bit 2 : tI0>> Bit 3 : tI2> Bit 4 : tI< (loss of load)
Page 218 P225/EN CT/B11 Communication Page 38/52 MiCOM P225 CODE DESCRIPTION Bit 8 : LOCKED ROTOR (locked rotor at start) Bit 9 : t RTD1 TRIP or Thermist1 Bit 10 : t RTD2 TRIP or Thermist2 Bit 11 : t RTD3 TRIP or Thermist3...
Page 219 Communication P225/EN CT/B11 MiCOM P225 Page 39/52 CODE DESCRIPTION Unsigned integer : Auxiliary output relays allocation Bit 0 : Allocation to relay 2 Bit 1 : Allocation to relay 3 Bit 2 : Allocation to relay 4 Bit 3 : Allocation to relay 5 Bits 4 to 15 : reserved F14’...
Page 220 P225/EN CT/B11 Communication Page 40/52 MiCOM P225 CODE DESCRIPTION Unsigned long : LED allocation Bit 0 : θ ALARM (thermal alarm) Bit 1 : THERM OVERLOAD (thermal overload) Bit 2 : tI0> Bit 3 : tI0>> Bit 4 : t I >>...
Page 221 Communication P225/EN CT/B11 MiCOM P225 Page 41/52 CODE DESCRIPTION Unsigned integer : Quick reading byte Bit 0 : General MiCOM relay status Bit 1 : Minor relay failure Bit 2 : Presence of a non-acknowledged event record Bit 3 : Clock synchronisation status...
Page 222 P225/EN CT/B11 Communication Page 42/52 MiCOM P225 CODE DESCRIPTION Unsigned integer : Start sequence and stalled/locked rotor information Bit 0 : Start sequence in progress signal Bit 1 : Successful start signal Bit 2 : Excessive long start signal Bit 3 : Stalled rotor whilst running signal...
Page 223 Communication P225/EN CT/B11 MiCOM P225 Page 43/52 CODE DESCRIPTION Display alarm messages Bit 0 a : TH OVERLOAD (thermal overload) Bit 1 a : t Io> Bit 2 a : t Io>> Bit 3 a : t I2> Bit 4 a : t I2>>...
Page 224 P225/EN CT/B11 Communication Page 44/52 MiCOM P225 CODE DESCRIPTION RTD status Bit 0 : RTD1 failure or thermistance 1 failure Bit 1 : RTD2 failure or thermistance 2 failure Bit 2 : RTD3 failure or thermistance 3 failure Bit 3 : RTD4 failure...
Page 225 Communication P225/EN CT/B11 MiCOM P225 Page 45/52 CODE DESCRIPTION word : event type : Refer to format F56 word : associated value type : Refer to format F56 word : mapping address of the associated value word : reserved word : event occurrence date (second) : number of seconds since the 01/01/1994…lsb...
Page 226 P225/EN CT/B11 Communication Page 46/52 MiCOM P225 CODE DESCRIPTION word : Number of disturbance record available word : Oldest disturbance record number word : Oldest disturbance record date (sec) : number of seconds since the 01/01/1994 …..lsb (low significant bit) word : Oldest disturbance record date (sec) : number of seconds since the 01/01/1994: number of seconds since the 01/01/1994 …..msb (most significant bit)
Page 227 Communication P225/EN CT/B11 MiCOM P225 Page 47/52 Associated value Code Event type type "No EVENT" "REMOTE CLOSING" "REMOTE TRIPPING" «DISTURBANCE RECORD TRIGGING» «SETTING CHANGE» MODBUS address of the modified value ↑ ↓ "I >>" (instantaneous signal) ↑ ↓ "I0 >"...
Page 228 P225/EN CT/B11 Communication Page 48/52 MiCOM P225 Associated value Code Event type type ↑ ↓ "t RTD1 TRIP" ↑ ↓ "t RTD2 TRIP" ↑ ↓ "t RTD3 TRIP" "t RTD4 TRIP" ↑ ↓ "t RTD5 TRIP" ↑ ↓ "t RTD6 TRIP"...
Page 229 Communication P225/EN CT/B11 MiCOM P225 Page 49/52 Associated value Code Event type type ↑ ↓ "CHANGE OF THE LOGIC OUTPUTS STATUS" ↑ ↓ "EXT 3" ↑ ↓ "EXT 4" Reserved "V <" (instantaneous signal) ↑ ↓ Reserved "V >" (instantaneous signal) ↑...
Page 230 P225/EN CT/B11 Communication Page 50/52 MiCOM P225 Code Fault origin " NO FAULT " REMOTE TRIPPING" " TRIPPING : t I >>" (time delayed signal) " TRIPPING : t I0 >" (time delayed signal) " TRIPPING : t I0 >>" (time delayed signal) "...
Page 231 Communication P225/EN CT/B11 MiCOM P225 Page 51/52 Conversion rules for the current values of the disturbance record * In order to obtain the phase current value at phase CT primary, apply the following formula : «Primary phase current value (in Amps)» = «Remote value» x «Primary phase CT value» x √2 / * In order to obtain the earth current value at the earth CT primary, apply the following formula : «Primary earth current value (in Amps)»...
Page 232 P225/EN CT/B11 Communication Page 52/52 MiCOM P225 BLANK PAGE...
Page 233 Setting P225/EN SV/B11 MiCOM P225 SETTING...
Page 235 Setting P225/EN SV/B11 MiCOM P225 Page 1/16 CONTENT DEFAULT SETTING VALUES OP PARAMETERS menu CONFIGURATION menu 1.2.1 CONFIG. SELECT submenu 1.2.2 CT/VT RATIO submenu 1.2.3 LED 5, LED 6, LED 7 and LED 8 sub-menu 1.2.4 ALARM CONFIG. submenu 1.2.5 INPUT CONFIG.
Page 236 P225/EN SV/B11 Setting Page 2/16 MiCOM P225 1.5.9 TRIP OUTPUT RLY submenu 1.5.10 LATCH TRIP ORDER submenu (RL1 relay latching on) 1.5.11 CB FAIL submenu 1.5.12 ABS (anti backspin) submenu 1.5.13 BUS VOLTAGE CTRL submenu 1.5.14 CB SUPERVISION submenu CONSIGNATION Menu 1.6.1...
Page 237 Setting P225/EN SV/B11 MiCOM P225 Page 3/16 DEFAULT SETTING VALUES The MiCOM P225 relay leaves the factory with the following default setting values : OP PARAMETERS menu Password AAAA Reference ALST Frequency 50 Hz CONFIGURATION menu 1.2.1 CONFIG. SELECT submenu...
Page 238 P225/EN SV/B11 Setting Page 4/16 MiCOM P225 1.2.3 LED 5, LED 6, LED 7 and LED 8 sub-menu LED 5 LED 6 LED 7 LED 8 Allocation : Thermal overload : THERM OVERLOAD Allocation : Thermal alarm : θ ALARME Allocation : tI>>...
Page 239 Setting P225/EN SV/B11 MiCOM P225 Page 5/16 1.2.5 INPUT CONFIG. submenu EL 6 EL 5 EL 4 EL 3 EL 2 EL 1 Configuration of the logic input active state : INPUT PICK-UP (1 : active state when a control voltage is applied on)
Page 240 P225/EN SV/B11 Setting Page 6/16 MiCOM P225 1.4.2 [50/51] SHORT-CIRCUIT submenu PROTECTION G 1 PROTECTION G 2 Short-circuit function enabled ? Threshold I>> 0,2 In 0,2 In tI>> 0 second 0 second 1.4.3 [50/51] EARTH FAULT submenu PROTECTION G 1 PROTECTION G 2 Io>...
Page 241 Setting P225/EN SV/B11 MiCOM P225 Page 7/16 1.4.8 [51LR/50S] BLOCK ROTOR submenu PROTECTION G 1 PROTECTION G 2 Block rotor function enabled ? 0,1 second 0,1 second stall Stalled rotor while running function enabled ? Threshold I 1 Iθ 1 Iθ...
Page 242 P225/EN SV/B11 Setting Page 8/16 MiCOM P225 PROTECTION G 1 PROTECTION G 2 0 second 0 second RTD5 TRIP RTD6 supervision function enabled ? RTD6 ALARM 0 °C 0 °C 0 second 0 second RTD6 ALARM RTD6 TRIP 0 °C 0 °C...
Page 243 Setting P225/EN SV/B11 MiCOM P225 Page 9/16 AUTOMAT. CTRL MENU 1.5.1 [66] START NUMBER submenu Start Number Limitation function enabled ? 10 minutes reference Hot start number Cold start number 1 minute interdiction 1.5.2 MIN TIME BETW 2 START submenu...
Page 244 P225/EN SV/B11 Setting Page 10/16 MiCOM P225 Allocation : tI2>> Allocation : Excessive long start : EXCES LONG START Allocation : Start rotor while running : tI stall Allocation : Locked rotor at start : LOCKED ROTOR Allocation : tI<...
Page 245 Setting P225/EN SV/B11 MiCOM P225 Page 11/16 1.5.6 AND LOGIC EQUAT T DELAY submenu EQU. A T 0 second operat EQU. A T 0 second reset EQU. B T 0 second operat EQU. B T 0 second reset EQU. C T...
Page 246 P225/EN SV/B11 Setting Page 12/16 MiCOM P225 Allocation : t (optional) RTD6 TRIP Allocation : t (optional) RTD7 ALARM Allocation : t (optional) RTD7 TRIP Allocation : t (optional) RTD8 ALARM Allocation : t (optional) RTD8 TRIP Allocation : t...
Page 247 Setting P225/EN SV/B11 MiCOM P225 Page 13/16 1.5.8 LATCH AUX OUTPUT RLY submenu Latching of RL2 relay : LATCH RL2 Latching of RL3 relay : LATCH RL3 Latching of RL4 relay : LATCH RL4 Latching of RL5 relay : LATCH RL5 1.5.9...
Page 248 P225/EN SV/B11 Setting Page 14/16 MiCOM P225 1.5.10 LATCH TRIP ORDER submenu (RL1 relay latching on) LATCH THERM OVERLOAD LATCH tI>> LATCH tI0> LATCH tI0>> LATCH tI2> LATCH tI2>> LATCH EXCES LONG START LATCH tI stall LATCH LOCKED ROTOR LATCH tI<...
Page 249 Setting P225/EN SV/B11 MiCOM P225 Page 15/16 1.5.14 CB SUPERVISION submenu Trip circuit supervision function enabled ? t SUP 0,1 second CB opening time function enabled ? CB OPENING TIME 0 ,05 second CB operation number function enabled ? CB operation number...
Page 250 P225/EN SV/B11 Setting Page 16/16 MiCOM P225 BLANK PAGE...
Page 251 Installation Guide P225/EN IN/B11 MiCOM P225 INSTALLATION GUIDE...
Page 253 INSTALLATION, COMMISSIONING AND MAINTENANCE Connection of the MiCOM P225 relay Operating conditions of the MiCOM P225 relay Replacement of the batteries Current transformer circuits Dielectric withstand test Removal and destruction of the MiCOM P225 relay 7.6.1 Removal 7.6.2 Destruction Technical specifications...
Page 254 P225/EN IN/B11 Installation Guide Page 2/12 MiCOM P225 BLANK PAGE...
Page 255 As soon as they arrive, the relays should be examined immediately, looking for any deterioration which could have occurred during transport. If there is any deterioration, make a claim against the forwarding company and inform AREVA T&D as soon as possible.
Page 256 P225/EN IN/B11 Installation Guide Page 4/12 MiCOM P225 HANDLING ELECTRONIC EQUIPMENT The usual movements of a person easily generate electrostatic energy which may reach several thousand volts. The discharging of this voltage into devices comprising semiconductors, when handling electronic circuits, can cause severe deterioration. Such damage is not necessarily visible immediately.
Page 257 Installation Guide P225/EN IN/B11 MiCOM P225 Page 5/12 INSTALLING THE RELAYS The relays are supplied either individually or mounted in a cubicle. If separate relays have to be installed according to a particular drawing, please follow the mounting details indicated in publication R7012.
Page 258 P225/EN IN/B11 Installation Guide Page 6/12 MiCOM P225 UNPACKING When unpacking and installing relays, take great care to avoid damaging the parts and changing the settings. Relays must be handled only by people who are experts in this field. As far as possible, the installation must remain clean, dry, free from dust and free from excessive vibration.
Page 259 Installation Guide P225/EN IN/B11 MiCOM P225 Page 7/12 STORAGE If the relays do not have to be installed immediately on reception, they must be stored protected against dust and humidity in their original carton. If dehumidifying crystals are placed in the relay packaging, it is advisable not to remove them.
Page 260 The safety instructions described in this document are intended to guarantee correct installation and use of the MiCOM P225 relay and to avoid any damage. All persons directly or indirectly concerned with the use of these devices must be familiar with these safety instructions.
Page 261 Access to the connectors at the rear of the relays can present risks of electrocution and thermal shock. Before you consider energization, the MiCOM P225 relay must be connected to earth via the terminal provided for this purpose. Unless otherwise indicated in the technical data chapter of the product documentation, the minimum size recommended for the earth wire is 2.5 mm...
Page 262 P225/EN IN/B11 Installation Guide Page 10/12 MiCOM P225 7.6.2 Destruction It is recommended that the relay should not be incinerated nor thrown into a river. MiCOM relays and their components should be disposed of and recycled strictly in compliance with regulations on safety and the environment.
Page 263 AREVA T&D reference: ZB9128 016 P0166ENb M4 90˚ Ring Tongue terminal (wire size 0.25 - 1.65mm²) AREVA T&D reference, Stafford part number ZB9124 901 M4 90˚ Ring Tongue terminal (wire size 1.5 - 2.5mm²) AREVA T&D reference, Stafford part number ZB9124 900...
Page 264 P225/EN IN/B11 Installation Guide Page 12/12 MiCOM P225 CASE DIMENSIONS MiCOM P225 relays are available in a 4U metal case for panel or flush mounting. Weight : about 3.7 Kg External size : Height Case 156 mm Front panel 177 mm...
Page 265 Test Report P225/EN RS/B11 MiCOM P225 TEST REPORT...
Page 267 Test Report P225/EN RS/B11 MiCOM P225 Page 1/20 CONTENT RELAY IDENTIFICATION INSPECTION MEASUREMENT VALUE VERIFICATION PARAMETERS OP. PARAMETERS menu CONFIGURATION menu 4.2.1 CONFIG. SELECT submenu 4.2.2 CT/VT RATIO submenu COMMUNICATION MODBUS Menu COMMUNICATION Courier Menu COMMUNICATION IEC 60870-5-103 Menu PROTECTION G1 and G2 Menus AUTOMAT.
Page 268 P225/EN RS/B11 Test Report Page 2/20 MiCOM P225 BLANK PAGE...
Page 269 Test Report P225/EN RS/B11 MiCOM P225 Page 3/20 RELAY IDENTIFICATION Commissioning date : Engineer : Motor reference : Circuit-breaker/Fuse-contactor reference : MiCOM relay type P225 Serial number Earth current setting range Voltage input range Auxiliary voltage supply Communication protocol Language...
Page 270 P225/EN RS/B11 Test Report Page 4/20 MiCOM P225 INSPECTION Put a cross after each inspection stage. Serial number check ? All current transformer shorting switches closed ? Wiring checked against diagram (if available) ? Case earthing link ? Current circuit wirings ?
Page 271 Test Report P225/EN RS/B11 MiCOM P225 Page 5/20 MEASUREMENT VALUE VERIFICATION Applied value Relay value Phase A current input Phase B current input Phase C current input Earth current input Phase A - phase C voltage input...
Page 272 P225/EN RS/B11 Test Report Page 6/20 MiCOM P225 PARAMETERS OP. PARAMETERS menu Password Reference Frequency Date Time CONFIGURATION menu 4.2.1 CONFIG. SELECT submenu Way to switch over active setting group Active setting group Default display Start detection criterion Analogue output type (optional)
Page 273 Test Report P225/EN RS/B11 MiCOM P225 Page 7/20 LED 5, LED 6, LED 7 and LED 8 submenus LED 5 LED 6 LED 7 LED 8 Allocation : Thermal overload : THERM OVERLOAD Allocation : Thermal alarm : θ ALARM Allocation : tI>>...
Page 274 P225/EN RS/B11 Test Report Page 8/20 MiCOM P225 ALARM CONFIG. submenu Presence of alarm message on RAM/battery Yes / error : BATTERY ALARM INPUT CONFIG. submenu EL 6 EL 5 EL 4 EL 3 EL 2 EL 1 Configuration of the logic input active state :...
Page 275 Test Report P225/EN RS/B11 MiCOM P225 Page 9/20 PROTECTION G1 and G2 Menus [49] THERMAL OVERLOAD submenu PROTECTION G 1 PROTECTION G 2 Thermal overload function enabled ? Yes / Yes / “ Thermal inhibition on starting ” function Yes /...
Page 276 P225/EN RS/B11 Test Report Page 10/20 MiCOM P225 [27] UNDERVOLTAGE submenu PROTECTION G 1 PROTECTION G 2 Undervoltage function enabled ? Yes / Yes / Threshold V< tV< Inhibition V< at start Yes / Yes / [59] OVERVOLTAGE submenu PROTECTION G 1...
Page 277 Test Report P225/EN RS/B11 MiCOM P225 Page 11/20 [49/38] RTD submenu (optional) PROTECTION G 1 PROTECTION G 2 RTD1 enabled ? Yes / Yes / RTD1 ALARM °C °C RTD1 ALARM RTD1 TRIP °C °C RTD1 TRIP RTD2 enabled ?
Page 278 P225/EN RS/B11 Test Report Page 12/20 MiCOM P225 RTD8 enabled ? Yes / Yes / RTD8 ALARM °C °C RTD8 ALARM RTD8 TRIP °C °C RTD8 TRIP RTD9 enabled ? Yes / Yes / RTD9 ALARM °C °C RTD9 ALARM RTD9 TRIP °C...
Page 279 Test Report P225/EN RS/B11 MiCOM P225 Page 13/20 4.7.4 INPUTS submenu Allocation : input n°2 Allocation : input n°3 Allocation : input n°4 Allocation : input n°5 Allocation : input n°6 Time delay EXT 1 Time delay EXT 2 Time delay EXT 3 Time delay EXT 4 4.7.5...
Page 280 P225/EN RS/B11 Test Report Page 14/20 MiCOM P225 Allocation : t (optional) RTD5 ALARM Allocation : t (optional) RTD5 TRIP Allocation : t (optional) RTD6 ALARM Allocation : t (optional) RTD6 TRIP Allocation : t (optional) RTD7 ALARM Allocation : t...
Page 281 Test Report P225/EN RS/B11 MiCOM P225 Page 15/20 4.7.6 AND LOGIC EQUAT T DELAY submenu EQU. A T operat EQU. A T reset EQU. B T operat EQU. B T reset EQU. C T operat EQU. C T reset EQU. D T operat EQU.
Page 282 P225/EN RS/B11 Test Report Page 16/20 MiCOM P225 Allocation : t (optional) RTD4 TRIP Allocation : t (optional) RTD5 ALARM Allocation : t (optional) RTD5 TRIP Allocation : t (optional) RTD6 ALARM Allocation : t (optional) RTD6 TRIP Allocation : t...
Page 283 Test Report P225/EN RS/B11 MiCOM P225 Page 17/20 Allocation : CB OPEN TIME Allocation : CB OPER NB Allocation : S A n Allocation : CB failure : CB FAIL. Allocation : Open trip circuit : TRIP CIRCUIT FAIL Allocation : « Group 2 » active setting group : GROUP 2 ACTIVE 4.7.8...
Page 284 P225/EN RS/B11 Test Report Page 18/20 MiCOM P225 Allocation output relay n°1 : Thermist 2 Yes / (optional) Allocation output relay n°1 : Thermist 3 Yes / (optional) Allocation output relay n°1 : EXT 1 Yes / Allocation output relay n°1 : EXT 2 Yes / Allocation output relay n°1 : t EQU.
Page 285 Test Report P225/EN RS/B11 MiCOM P225 Page 19/20 4.7.10 LATCH TRIP ORDER submenu (RL1 relay latching on) LATCH THERM OVERLOAD Yes / LATCH tI>> Yes / LATCH tI0> Yes / LATCH tI0>> Yes / LATCH tI2> Yes / LATCH tI2>>...
Page 286 P225/EN RS/B11 Test Report Page 20/20 MiCOM P225 4.7.11 CB SUPERVISION submenu Trip circuit supervision function enabled ? Yes / t SUP CB opening time function enabled ? Yes / CB opening time CB operation number function enabled ? Yes /...
Page 288 AREVA T&D's Automation & Information Systems Business www.areva-td.com T&D Worldwide Contact Centre online 24 hours a day: +44 (0) 1785 25 00 70 http://www.areva-td.com/contactcentre/...

Areva MiCOM P225 Technical Manual

Quick Links

Need help?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Areva MiCOM P225

Summary of Contents for Areva MiCOM P225

Table of Contents
