- Page 1 User Guide IR Remote Controls and Control Panels IR 102 Remote Control Kit 68-663-01 Rev. F 07 17...
-
Page 2: Safety Instructions
Safety Instructions Safety Instructions • English Istruzioni di sicurezza • Italiano WARNING: This symbol, , when used on the product, is intended to AVVERTENZA: Il simbolo, , se usato sul prodotto, serve ad alert the user of the presence of uninsulated dangerous voltage within avvertire l’utente della presenza di tensione non isolata pericolosa the product’s enclosure that may present a risk of electric shock. - Page 3 ついては、 エクス トロンのウェブサイ ト より 『Extron Safety www.extron.com and Regulatory Compliance Guide』 (P/N 68-290-01) をご覧ください。 Copyright © 2017 Extron Electronics. All rights reserved. Trademarks All trademarks mentioned in this guide are the properties of their respective owners. The following registered trademarks( ®...
- Page 4 FCC Class A Notice This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to part 15 of the FCC rules. The Class A limits provide reasonable protection against harmful interference when the equipment is operated in a commercial environment.
- Page 5 Conventions Used in this Guide Notifications The following notifications are used in this guide: CAUTION: Risk of minor personal injury. ATTENTION : Risque de blessure mineure. ATTENTION: • Risk of property damage. • Risque de dommages matériels. NOTE: A note draws attention to important information. Specifications Availability Product specifications are available on the Extron website, www.extron.com.
-
Page 7: Table Of Contents
About the IR 102 Remote Control Kit ....1 Features ............. 1 Rear Panel Connections — IR 102 Rx Receiver ............2 Connecting the IR 102 Rx to a Switcher ... 4 Installing Batteries in the IR 102 Remote Control .............. 4 Operation ............5 Front Panel ............ - Page 8 IR 102 User Guide • Contents viii...
-
Page 9: Installation And Operation
The IR 102 Kit includes an IR 102 handheld remote control (transmitter), an IR sensor, and an IR receiver unit. The IR 102 Rx Receiver is housed in a compact enclosure for mounting on a rack shelf or under a desk. The IR 102 hand-held remote... -
Page 10: Rear Panel Connections - Ir 102 Rx Receiver
Rear Panel Connections — IR 102 Rx Receiver IR 102 Rx UNIVERSAL IR REMOTE RECEIVER IR IN CONTROL OUT POWER RS-232 .5A MAX CONTACT RS-232 1 2 3 4 5 Tx Rx +12V RS-232/ CONTACT Power Connector Control Out RS-232 Connector IR In Connector RS-232/Contact –... - Page 11 IR Sensor this 9-pin D connector and the contact closure or RS-232 control port of the switcher or SMD 202. This permits the IR 102 Rx remote receiver to control the device. The pin assignments are shown in figure 3.
-
Page 12: Connecting The Ir 102 Rx To A Switcher
Connecting the IR 102 Rx to a Switcher To use the IR 102 to control a switcher, connect the IR 102 receiver to the switcher rear panel as follows: Power down the switcher. -
Page 13: Operation
For example, to select input 17, press the +10 button, then the 7 button. For input 10, press +10, then 0. The maximum operating range of the IR 102 remote control is 30 feet (9.1 meters). IR 102 Universal Remote Figure 6. -
Page 14: Using The Ir 102 With A Control System
Figure 7. A Typical IR 102 Switcher Application To use the IR 102 with a control system to control a switcher, use an RS-232 cable to connect the IR 102 Rx remote receiver to the RS-232 connector on the switcher rear panel. -
Page 15: Mounting
Mounting The IR 102 Rx remote receiver can be placed on a tabletop (attach the provided four rubber feet) or mounted to a rack shelf, under furniture, or to a projector pole. Mounting Options Extron offers optional kits for the following types of mounting: •... - Page 16 Extron Electronics makes no further warranties either expressed or implied with respect to the product and its quality, performance, merchantability, or fitness for any particular use. In no event will Extron Electronics be liable for direct, indirect, or consequential damages resulting from any defect in this product even if Extron Electronics has been advised of such damage.
