This user's guide describes the characteristics, operation, and use of the
TLC5940EVM-106 evaluation module (EVM). This EVM is designed to help the user
evaluate and test the various operating modes of the TLC5940. This user's guide
includes setup instructions for the hardware and software, a schematic diagram, a bill
of materials (BOM), and PCB layout drawings for the evaluation module
