REVELL 24056 Instruction Manual

24056
Main Features
Helicopter The Big One:
• Sturdy aerodynamic aluminium fuselage
• Replaceable, rechargeable LiPo (lithium-polymer) battery
• New coaxial rotor system with electronic gyro for
excellent fl ying
• Easy battery recharging with the supplied charger
Controller:
• 3-channel MHz controller
• Trim function for fi ne tuning
• LED indicator
Care and Maintenance:
• Use a clean, damp cloth to wipe the helicopter.
• Keep the helicopter and batteries away from direct sunlight and/or
direct heat sources.
• Never let the helicopter come into contact with water, as this may
damage the electronics.
Controller Battery Safety Advice:
• Do not charge non-rechargeable batteries.
• Rechargeable batteries must be removed from the controller before charging.
• Rechargeable batteries must only be charged under adult supervision.
• Do not use different types of batteries or mix old and new batteries.
• Only use the recommended batteries or batteries of an equivalent type.
• To help the environment, consider replacing the disposable batteries for
this controller and for other household electronic items with rechargeable
batteries. We recommend eneloop rechargeable batteries from Sanyo.
• Insert batteries following the correct polarity (+ and -).
• Remove dead batteries from the controller.
• Do not short-circuit the supply terminals. Remove batteries from the
controller when it is not used for a long period of time.
WEEE: At the end of this device's useful life, please
remove all the batteries and dispose of them separately.
Take electrical appliances to the local collection points
for waste electrical and electronic equipment. Other
components can be disposed of in domestic refuse.
Thank you for your co-operation!
6
Big_Heli_MHz_Anleitung_06.indd 6 Big_Heli_MHz_Anleitung_06.indd 6
Contents
Instruction Manual Instruction Manual
Safety Precautions:
• This product is designed to be used indoors only. Do not use it
outdoors unless there is absolutely no wind and no gusts.
• This helicopter is suitable for ages 15 and above. Parental
supervision is necessary while fl ying.
• Keep hands, face, hair and loose clothing away from the
rotor blades.
• Turn off the controller and helicopter when not in use.
• Remove batteries from the controller when not in use.
• Always keep the helicopter in sight to avoid loss of control.
• We recommend using new alkaline-manganese batteries
or eneloop rechargeable batteries for the controller.
• Insert new batteries in the controller as soon as any function
becomes diminished.
The helicopter comes with a rechargeable lithium-polymer battery.
Always follow these safety instructions:
• Never dispose of LiPo batteries in a fi re or store near sources of heat.
• Only use the supplied Revell LiPo charger to recharge this LiPo battery. Using
a different charger may result in permanent damage to the battery and adjacent
parts, and may also cause injury!
• Never use a charger designed for NiCd/NiMH batteries!
• Always charge the battery on a fi reproof surface and in a fi re-resistant
environment.
• Never leave the battery unattended during the charging and discharging processes.
• Always make sure that the battery is fully charged, but do not charge it for
longer than 180 minutes.
• Batteries must be discharged or fully exhausted before being disposed of.
Cover exposed poles with adhesive tape to prevent short-circuiting!
• Keep the battery out of the reach of children.
Safety Precautions:
• Never carry out any modifi cations or alterations to the product as this
may result in damage or injury.
• To avoid risk of injury, never operate the helicopter while sitting on the
fl oor or on a chair. Always ensure you are able to move quickly out of
the helicopter's fl ight path.
• Always turn the helicopter and controller off completely after use and
disconnect the helicopter's fl ight cable.
Never touch the spinning rotor
blades! Do not fl y the helicopter
near people, animals, water or
power cables – always fl y under
adult supervision.
www.revell-control.de
© 2010 Revell GmbH & Co.KG,
Henschelstraße 20 – 30, D-32257 Bünde,
REVELL IS THE REGISTERED TRADEMARK REVELL IS S THE REGISTERED TRADEMA
OF REVELL GMBH & Co. KG, GERMANY OF REVEL L GMBH & Co. KG, GERMANY
27 MHz RADIO CONTROL
• Keep these instructions for future reference.
• Always follow these instructions when operating the helicopter.
• Do not fl y the helicopter near people, animals, water or power cables.
• The LiPo battery charger is made specifi cally for charging the
helicopter battery. Only use it for this purpose. Do not use it to
charge other batteries.
• This appliance is not intended for use by persons (including children)
with reduced physical, sensory or mental capabilities, or lack of
experience and knowledge, unless they have been given supervision
or instruction concerning use of the appliance by a person
responsible for their safety.
• The helicopter should not be used in temperatures above
45°C/113°F or below 10°C/50°F.
Battery Requirements
for the Helicopter:
Power Supply:
Rating: DC 7,4V / 1300 mAh
Batteries: One 7.4 V rechargeable
LiPo battery (included)
Battery Requirements
for the Controller:
Power Supply:
DC 12 V
Batteries: 8 x 1.5 V "AA"
(included)
Revell GmbH & Co. KG hereby declares that this
product complies with the basic requirements and
other relevant provisions of Directive 1999/5/EC.
The declaration of conformity is available at
www.revell-control.de.
