48" TV Console
Model # LLAVC48C
ADULT ASSEMBLY REQUIRED
If you have any questions regarding assembly or if parts are missing, DO NOT return this item to the store
where it was purchased. Please call our toll-free customer service number and have your instructions and parts
list ready to provide the model name, part name or factory number:
1-866-942-5362
www.whalenfurniture.com
ONLINE:
THIS INSTRUCTION BOOKLET CONTAINS IMPORTANT SAFETY INFORMATION.
PLEASE READ AND KEEP FOR FUTURE REFERENCE.
Whalen Furniture Mfg., Inc.
8:30 a.m. - 4:30 p.m. PST, Monday - Friday
Video Instruction Guides
Go to http://whalen.showuhow.com to view step-by-step instructional videos
for assembling and installing your product. Enter the following product number
on the ShowUhow homepage.
LLAVC48C
LOT NUMBER:
DATE PURCHASED: /
parts@whalenfurniture.com
EMAIL:
Page 1
/
Factory No. 15548
Advertisement
Related Manuals for Whalen LLAVC48C
Summary of Contents for Whalen LLAVC48C
- Page 1 ONLINE: EMAIL: Video Instruction Guides Go to http://whalen.showuhow.com to view step-by-step instructional videos for assembling and installing your product. Enter the following product number on the ShowUhow homepage. LLAVC48C THIS INSTRUCTION BOOKLET CONTAINS IMPORTANT SAFETY INFORMATION. PLEASE READ AND KEEP FOR FUTURE REFERENCE.
- Page 2 M A X I M U M R E C O M M E N D E D W E I G H T L O A D S MANUFACTURER: Whalen Furniture Mfg., Inc. CATALOG: 48" TV Console (LLAVC48C) DATE OF MANUFACTURE: November 2012 MADE IN CHINA FITS UP TO MOST 54”...
- Page 3 Model # LLAVC48C Important Before you begin: Open, identify and count all parts prior to assembly. Lay out parts on a flat and non- abrasive surface. You will need the parts identified on page 4 and 5 of this instruction manual.
- Page 4 Model # LLAVC48C Parts and Hardware List Please read completely through the instructions and verify that all parts listed are present before beginning assembly. A- Top Panel (1) B- Left Side Panel (1) C- Right Side Panel (1) D- Bottom Panel (1)
- Page 5 Model # LLAVC48C Parts and Hardware List Please read completely through the instructions and verify that all parts listed are present before beginning assembly. (1) Small Cam Lock (2) Large Cam Lock (3) Small Cam Bolt (4) Large Cam Bolt...
- Page 6 Model # LLAVC48C Drawer Assembling 1. Unpack the unit and confirm that you have all the hardware and required parts listed. 2. Place the Left and Right Drawer Fronts (Q and U) on a level and protective surface with the holes facing up.
- Page 7 Model # LLAVC48C Drawer Assembling 5. Slide the Left Drawer Bottom Panel (T) all the way into the grooves on the Left Drawer Side Panels (R and S) and the Left Drawer Front (Q) with the finished surface up. 6. Repeat the last step with the Right Drawer Bottom Panel (X).
- Page 8 Model # LLAVC48C Assembly Instructions 8. Attach the Drawer Handles (18) to the outside of the Left and Right Drawer Fronts (Q and U) using two 12 mm Handle Bolts (19) provided. 9. Place the Top Panel (A), the Left and Right Side Panels (B and C) and the Bottom Panel (D) on a level and protective surface with the holes facing up.
- Page 9 Model # LLAVC48C Assembly Instructions 10. Insert four Wood Dowels (5) into the inner end holes of the Back Bottom Stretcher (H). Tap in with a rubber mallet if necessary. Make sure that you use a small amount of glue with both ends of all dowels.
- Page 10 Model # LLAVC48C Assembly Instructions 13. Securely screw one Large Cam Bolt (4) into the middle small hole on the Front Crossbar (E) and Back Crossbar (F) respectively, as shown in the illustration. 14. Align two Magnetic Catches (17) to the pilot holes on the Front Crossbar (E) with the magnetic plates facing the curved edge.
- Page 11 Model # LLAVC48C Assembly Instructions 18. Insert two Wood Dowels (5) into the inner holes on the top end of the Bottom Partition (I). 19. Align the Wood Dowels on the Bottom Partition (I) with the large holes on the Front Crossbar (E) and Back Crossbar (F) ensuring the finished edges face front of the unit.
- Page 12 Model # LLAVC48C Assembly Instructions 21. Insert ten Wood Dowels (5) into the inner holes on both ends of the last assembly. DO NOT insert the Wood Dowels into the Cam Bolt holes. 22. Align the large holes on the Left Side Panel (B) with the inserted Wood Dowels (5) on the assembled unit.
- Page 13 Model # LLAVC48C Assembly Instructions 27. Set the assembled unit so it is upright. 28. Insert six Wood Dowels (5) into the inner holes on the top of the Side Panels (B and C) and the Top Partition (J). 29. Ask for assistance to position Top Panel (A) onto the inserted Wood Dowels (5) making sure the back edges are flush with each other.
- Page 14 Model # LLAVC48C Assembly Instructions 32. Attach 2 Cable Wheels (Z) to the backside of the Console with four M6 x 20 mm Bolts (6) provided. You can use the Cable Wheels to organize your cables and cords. 33. Extend the two Hinge Arms that are pre-attached on Right Door (N) and attach them to the Hinge Bases on the Right Side Panel (C).
- Page 15 Model # LLAVC48C Assembly Instructions 36. Attach one Handle (18) to the front side of each door with the 20 mm Handle Bolt (20) provided. 37. With the doors open, insert four Shelf Pins (14) into the desired holes in the sides of each compartment behind the glass door.
- Page 16 Model # LLAVC48C Assembly Instructions 41. Position the assembled Console at the desired location against a wall. Now, follow the instructions printed on the plastic bag containing the Tipping Restraint Hardware to mount the tipping restraint to the Console and the wall.
-
Page 17: Care And Maintenance
Should this product be defective in workmanship or materials, or fail under normal use, we will repair or replace it for up to one (1) year from date of purchase. Every Whalen Furniture product is designed to meet your highest expectations. We guarantee that you will immediately see the value of our fine furniture.
