Wheel Locks- As tires wear, adjust locks to prevent rear wheels from turning when locks are
engaged. To adjust, loosen the locknuts located behind the clamp bracket. Slide clamp on rail to
the proper position. Retighten the locknuts. If wheel locks become worn, replace them.
Caution!
ALWAYS ENGAGE WHEEL LOCKS WHEN ENTERING OR EXITING CHAIR.
UNLOCKED
RAIL
Reclining Back Models- Open wheelchair,
install headrest and push bar shown below.
Make sure spring buttons are fully extended
through handles before use. This chair must
never be used without both headrest and
push bar installed.
grasp both pusher handles securely and pull
both release levers at the same time. Gently
lower or raise the back to the desired height,
then release the levers.
HEADREST
LOCKED
LOCKNUTS
To adjust back angle,
Armrests- Cushioned armrests are designed to be
comfortable and durable. To maintain appearance
and comfort, replace armrest if they become
cracked, worn, or discolored.
adjustable from front to rear along the rail by
loosening the two locknuts behind the clamp
bracket shown to the left. To adjust the height on
the optional adjustable armrest, pull the pull knob
and move upper armrest up or down. Release knob
when desired height is achieved and make sure it
clicks into place. To remove the armrests push the
spring button and pull the arm out of the socket.
The spring button adjustment on the lower arm is
set at the factory and should not be changed. All
chairs EXCEPT for those with 16" seat to floor
height use lower spring button hole.
SPRING BUTTON
RELEASE LEVER
PUSH BAR
All armrests are
PULL KNOB
