- Page 1 AUTO - SCANNING WITH DIGITAL CONTROL LCD COLOR MEDICAL MONITOR AMM215MWTD Operation Manual For future reference, record the serial number of your display monitor in the space below : Serial Number The serial number is located on the back of the monitor...
- Page 3 ADVAN INT’L CORP.2012 All other trademarks are the property of their reference owners. This document is subject to change without notice. Advan provides this information as reference only. Reference to other vendor’s products does not imply any recommendation or endorsement. Revision Control...
-
Page 4: Table Of Contents
User Function / Messages................. OSD Section ....................Troubleshooting ..................Specification of (AMM215MWTD) ............. Classification ..................... Electromagnetic Compatibility ..............Dimension Drawing (mm) of AC Adapter ........... Dimension Drawing (mm) of AMM215MWTD ..........Connectors ....................Description of Warranty ................Touchscreen User’s Manual .............. -
Page 5: Product Description And Intended Use
• AMM215MWTD LCD Monitor(the equipment that displays information, graphic data, image and video on its LCD screen) and two video cables (1) HD15 VGA cable (1) DVI-D cable •... -
Page 6: Warnings And Cautions
Product(s), therefore, may not agree in detail to the published design or specifications. All specifications are subject to change without notice. Please contact ADVAN Int’l Corp directly or phone your local ADVAN Int’l Corp sales representative or agent for information on changes and new products. - Page 7 AMM215MWTD 5 Warnings 1. Read the operating manual thoroughly and be familiar with its contents prior to using this equipment. 2. Carefully unpack the unit and check if any damage occurred during shipment. 3. Should any solid object or liquid fall into the panel, unplug the unit and have it checked by qualified personnel before operating it any further.
- Page 8 Cautions 1. The AC Adapter must be plugged into a Grounded power outlet. 2. Use only the proprietary AMM215MWTD power supply for the AMM215MWTD monitor. Make a proper connection by ensuring that the shrink tubing completely secures the connection between the DC power cord and the extension cord.
-
Page 9: Symbol Explanations
AMM215MWTD 7 Symbol Definitions Indicates protective earth Dangerous: High Voltage ground. For indoor use only. Direct Current Tested to comply with FCC Serial Number Class B standards. DC power control switch This way up Tested to comply with Japan Fragile, handle with care... -
Page 10: Eu Declaration Of Conformity For Medical Applications
A Declaration of Conformity has been filed for this product. A sample of this document may be found in the addendum which accompanied this manual. For a copy of the Declaration of Conformity document, please contact ADVAN Int’l Corp. and request for AMM215MWTD DOC. Prepare for Unpack Before you unpack your monitor, prepare a suitable workspace. -
Page 11: Safety Precaution
AMM215MWTD 9 SAFETY PRECAUTION · Avoid placing the monitor, or any other heavy object, on the power cord to prevent fire or electrical shock from damage to the power cord. · Do not expose the monitor to rain, excessive moisture, or dust to avoid fire or shock hazard. -
Page 12: Power Management Function
LED blinks for 1 seconds On and 1 second Off. The screen is displayed after the vertical and horizontal sync signals are restored. Power Management System The AMM215MWTD Medical Monitor power management proposal. Provides four phases of power-saving modes by detecting the horizontal sync signal as shown in the table below. -
Page 13: Preset Modes
AMM215MWTD 11 PRESET MODES DVI and VGA input signal formats Horizontal Vertical Pixel clock Resolution frequency frequency ( MHz ) ( KHz ) ( Hz ) 640 x 350 @70Hz 31.469 70.087 25.175 640 x 480 @60Hz 31.469 59.940 25.175 640 x 480 @75Hz 37.500... -
Page 14: Video Signals
User’s Guide Video Signals Format DVI 1/2 480/59.94i 480/59.94p 576/50i 576/50p 720/50p 720/59.94p 720/60p 1080/23.98psf 1080/24psf 1080/23.98p 1080/24p 1080/25p 1080/29.97p 1080/30p 1080/50i 1080/59.94i 1080/60i 1080/50p 1080/60P... -
Page 15: Pip / Pop / Pbp Function
AMM215MWTD 13 PIP / POP / PBP function* The following combination options are available to you: DVI 1 DVI 2 Main DVI 1 DVI 2 *Not available for touch models... -
Page 16: Ddc
User’s Guide To make your installation easier, the monitor is able to Plug and Play with your system if your system also supports DDC protocol. The DDC (Display Data Channel) is a communication protocol through which the monitor automatically informs the host system about its capabilities, for example, supported resolutions and corresponding timing. -
Page 17: Connecting The Power Cord
AMM215MWTD 15 CONNECTING the POWER CORD for your area. * This monitor has an universal AC adapter that allows operation in either AC 100 - 240 V ac voltage area. No user-adjustment is required. * Plug one end of the power cord to the AC adapter, plug another end to a proper AC outlet. -
Page 18: User Function / Messages
User’s Guide User Functions / Messages Key Name and Function Power LED : Lights up to indicate the power is turned ON. Power Switch : To power ON or OFF the monitor. Rotary switch : With the OSD menu activated, increases the value of the selected (Ture Right) parameter or moves rightward in OSD menu. -
Page 19: Osd Section
Adjust OSD Position Control, Screen Control, DPMS, Auto Source Select, Smart Select, Restore Factory, Key Lock, Overscan Information Adjust Custom Entry, SN, Run Time, Input Format Exit Exit the menu *Functions not available for AMM215MWTD **Functions not available for touch models... - Page 20 Adjust the chroma of video (Range 0 - 100) Sharpness-V Set the sharpness of vertical image (Range 0 - 20) Sharpness-H Set the sharpness of horizontal image (Range 0 - 20) Exit Exit the menu *Functions not available for AMM215MWTD...
- Page 21 Enable zoom - in and pan function PIP** Enable PIP (Picture In Picture) function POP** Enable POP (Picture On Picture) function PBP** Enable PBP (Picture By Picture) function Exit Exit the menu *Functions not available for AMM215MWTD **Functions not available for touch models...
- Page 22 User’s Guide OSD Section Sub menu of PIP* Mode PIP Mode ON / Off Source PIP sub screen source - VGA, DVI1/2 Position PIP sub screen position - Top L, Top R, Bottom L, Bottom R Size PIP sub screen size - Small, Medium, Large Blending PIP sub screen blending (Range 0 - 20) Swap...
- Page 23 AMM215MWTD 21 OSD Section Sub menu of POP* Mode POP Mode ON / Off Source POP sub screen source - VGA, DVI1/2 Position POP sub screen position - Top L, Top R, Bottom L, Bottom R Size POP sub screen size - Small, Medium, Large...
- Page 24 Smart Select Enable / Disable smart select sub menu Restore Factory Changes the all OSD value to factory outgoing status Key Lock Set to key lock mode Overscan Adjust Overscan ratio Exit Exit the menu *Functions not available for AMM215MWTD...
- Page 25 Adjust frequency (Range 0 - 100) *available for VGA Phase Adjust phase (Range 0 - 100) *available for VGA Noise Noise reduction (Range 0 - 31) Reduction* Motion Offset* Motion offset (Range 0 - 100) Exit Exit the menu *Functions not available for AMM215MWTD...
- Page 26 User’s Guide OSD Section Information Custom Entry Change the user or monitor’s name Display the serial number Run Time Display the total run time Input Format Display the current input resolution and vertical frequency Exit Exit the menu...
-
Page 27: Troubleshooting
AMM215MWTD 25 TROUBLESHOOTING Before sending your LCD monitor for servicing, please check the troubleshooting list below to see if you can self-diagnose the problem. Problems Current Status Remedy No Picture LED ON · Using OSD, adjust brightness and contrast to maximum or reset to their default settings. -
Page 28: Specification Of (Amm215Mwtd)
User’s Guide SPECIFICATION* Model AMM215MWTD LCD Panel Diagonal 21.46 inches a-Si TFT Active Matrix Resolution 1920 (H) x 1080 (V) @ 60Hz Pixel Pitch 0.2475 mm Display Color 16.7M colors Viewing Angle R/L 178°, U/D 178° (CR > 10) Brightness**... -
Page 29: Classification
51LJ Medical Equipment E215822 This monitor is intended for use in Health Care Facilities model AMM215MWTD Equipment is not suitable for use in the presence of flammable anesthetic mixture with air or with oxygen or nitrous oxide. No user serviceable parts inside, ask qualified personnel when accessing inside. -
Page 30: Electromagnetic Compatibility
Consult the tables below for guidance in placing the AMM215MWTD. Manufacturer’s declaration - electromagnetic emission The Model AMM215MWTD is intended for use in the electromagnetic environment specified below. The customer or the user of AMM215MWTD should assure that it is used in such an environment. Emission test Compliance... - Page 31 To assess the electromagnetic environment due to fixed RF transmitters, an electromagnetic site survey should be con- sidered. If the measured field strength in the location in which the AMM215MWTD is used exceeds the applicable RF compliance level above, the AMM215MWTD should be observed to verify normal operation. If abnormal performance is observed, additional measures may be necessary, such as reorienting or relocating the AMM215MWTD.
-
Page 32: Dimension Drawing (Mm) Of Ac Adapter
Recommended Separation Distances Between Portable and Mobile RF Communications Equi- pement and the AMM215MWTD System The AMM215MWTD system is intended for use in an electromagnetic environment in which radiated RF disturbances are controlled. The user of the AMM215MWTD system can help prevent electromagnetic... -
Page 33: Dimension Drawing (Mm) Of Amm215Mwtd
AMM215MWTD 31 Dimension Drawing (mm) of AMM215MWTD... -
Page 34: Connectors
User’s Guide Connectors DC Input Connector Jack Power Input Description Description 13V Input 13 V Input Video Input 24 pin DVI-I connector. DDWG or equivalent connector. Description Description Description T.M.D.S. Data2- T.M.D.S. Data1- T.M.D.S. Data0- T.M.D.S. Data2+ T.M.D.S. Data1+ T.M.D.S. Data0+ T.M.D.S. -
Page 35: Description Of Warranty
ADVAN standards, quality and specifications. Subject to the conditions and limitations set forth below, ADVAN will, at its option, either repair any component of its products that prove defective by reason of improper workmanship or materials or ADVAN has the exclusive right to replace with refurbished units or with an equivalent product. - Page 36 ADVAN or its ASC without prior authorization. Buyer will be responsible for packaging (preferably original container) and shipping the defective goods to ADVAN or its ASC, shipping charges prepaid. ADVAN or its ASC will return the in warranty product, at no cost to the buyer.
- Page 37 (out-of-warranty). Buyer must notify ADVAN or its ASC of the defect and request an RMA number. If the configuration has been modified in any manner, the product must be returned to its original configuration before any service will be performed by ADVAN or its ASC.
- Page 38 ARE THE SOLE AND EXCLUSIVE REMEDIES FOR BREACH OF WARRANTY OR ANY OTHER LEGAL THEORY. TO THE FULLEST EXTENT PERMITTED BY APPLICABLE LAW, ADVAN SHALL NOT BE LIABLE TO THE PURCHASER OR END USER CUSTOMER OF AN ADVAN PRODUCT FOR ANY DAMAGES,...
-
Page 39: Touchscreen User's Manual
User’s Guide Touchscreen User’s Manual (Optional) Touch Software Installation for Microsoft Windows 7 and Windows XP (Plug and Play) Windows touch and multi-touch gestures are supported in Microsoft Windows 7 Home Premium, Professional, Enterprise, and Ultimate Operating System Editions only. Multi-touch is not supported in Windows 7 Home Basic and Starter Editions and Windows XP Editions. -
Page 40: Calibrate Touch Screen
AMM215MWTD 38 Touchscreen User’s Manual Calibrate touch screen 1. Make sure a USB cable is connected from the computer to the monitor. 2. Select Start > Control Panel and change View by: to Large icons or Small icons 3. Select the Tablet PC Settings control panel. The Tablet PC Settings control panel will only appear after Microsoft Windows 7 recognizes a connected touch monitor. - Page 42 EIZO GmbH, Display Technologies Siemensallee 84, D-76187 Karlsruhe, Germany Tel: +49 721 20321 0 Fax: +49 721 20321 474 Web Page : http://www.Eizo.eu ADVAN INT’L CORP 47817 Fremont Blvd. Fremont, CA 94538, USA Tel : 510-490-1005 Fax : 510-490-1151 Web Page : http://www.advancorp.com...
