Calibration Chamber
30
Accessories
Calibration chamber is recommended for use with tank level gauges in order to allow maintenance (removing
displacers), while tank is in service.
Standard chamber is 6" flange, with bolts & packing for NMS connection.
Note!
The dimensions differ depending on material, flange size. Please contact Endress+Hauaser for details.
NHC4HP (high pressure version)
10
Process Connection
A Flange JIS 10K 150A RF
C Flange JIS 10K 150A FF
E
Flange JIS 20K 150A RF
G Flange ANSI 6" 150lbs RF
J
Flange ANSI 6" 300lbs RF
L
Flange DIN DN 150 PN 10 RF
N Flange DIN DN 150 PN 25 RF
Q Flange JPI 6" 150lbs RF
S
Flange JPI 6" 300lbs RF
9
Special version
20
Material
2
Carbon steel (STPG370/SS400)
3
Stainless steel / SUS304
9
Special version
30
Bolts, Packing
0
not used
1
Stainless steel 304 + Valker #6502
9
Special versiond
40
Pressure Gauge, Relief Valve
1
used
9
Special version
NHC4HP-
Complete product designation
CALIBRATION CHAMBER
Flange
Flange
Ø150
8 hole
172
Endress+Hauser
Proservo
