34
NHV4J (JIS flanges)
For body in mild steel and in SS304, ball material is SS304, ball material is SS304. For body in SS316, ball mate-
rial is SS316. Seal material is PTFE.
10
Process Connection ; Body
C11 Flange JIS 10K 80A RF; steel
C12 Flange JIS 10K 150A RF; steel
C21 Flange JIS 20K 80A RF; steel
C22 Flange JIS 20K 150A RF; steel
S11
Flange JIS 10K 80A RF; SS316
S12
Flange JIS 10K 150A RF; SS316
S21
Flange JIS 20K 80A RF; SS316
S22
Flange JIS 20K 150A RF; SS316l
H11 Flange JIS 10K 80A RF; steel
H12 Flange JIS 10K 150A RF; steel
H21 Flange JIS 20K 80A RF; steel
H22 Flange JIS 20K 150A RF; steel
Y99
Special version
20
Ball Type
A full bore
B
reduced bore
9
Special version
NHV4J-
Complete product designation
Proservo
Endress+Hauser
