Explanation of Symbols The following symbols are used in this guide or on the equipment: Caution: Risk of danger. Refer to user guide. Warning: Electrical shock hazard. Warning: Hot surface hazard. Protective ground Thermo Fisher Scientific Sarasota SG901 User Guide...
Warning Ensure the power supply is isolated. Take suitable precautions to prevent reinstatement of power while working on the system. Caution The equipment can be impaired if equipment is not used in a manner specified by the manufacturer. Thermo Fisher Scientific Sarasota SG901 User Guide...
(MW), or density at reference conditions (D@ref) can be used in the plant instead of density at-line conditions. In applications where the process gas is too dirty, too hot, or at too high a pressure, the Sarasota SG901 allows for pre-conditioning of the process stream so a measurement can be made.
A calibration tee, fitted to the inlet pipe of the density meter assembly, allows for tapping to the calibration valve. The calibration tee facilitates purging and accurate calibration of the pressure transmitter and SG system. Sarasota SG901 User Guide Thermo Fisher Scientific...
Page 17
Operation With the frequency output option, signal outputs from the transducers are fed to a Thermo Scientific Sarasota density converter, which calculates the density (measured), D@ref, SG, and MW of the gas and provides corresponding 4–20 mA current outputs. All variables and calculated values can be displayed on the front panel of the converter.
1/4-inch bulkhead unions. Inlet piping should be kept as short Tubing as possible to minimize system response time. The pressure available at the inlet to the Sarasota SG901 system should be at least 0.4 bar (6 psi) above the control pressure set in the system to ensure regulation.
Note It is the user’s responsibility to ensure that local requirements are met. Cable Specification The cable specification for the Sarasota SG901 analyzer is: BS5308 part 1 : 1986 : type 2 Polyethylene insulated, bedded, single wire armored, PVC sheathed, five twisted pairs with individual screens, core size 0.5 mm².
1. A switch or circuit breaker must be included in the building installation. 2. It must be in close proximity to the equipment (SG901) and within easy reach of the operator. 3. It must be marked as the disconnecting device for this equipment (SG901). Thermo Fisher Scientific Sarasota SG901 User Guide...
Installation Electrical Installation Frequency Output The connections to the Sarasota SG901 analyzer with the frequency output option include the following: Option Terminals 1 & 2, density meter (24 Vdc) 2-wire current pulse Terminals 2, 3, 4, & 5, PT100 4-wire (W, X, Y, & Z) ...
Page 23
Installation Electrical Installation Figure 2–1. Wiring for optional heater junction box, frequency output version Figure 2–2. Wiring for optional heater junction box, headmount version Thermo Fisher Scientific Sarasota SG901 User Guide...
Chapter 7 troubleshooting. Headmount Option The headmount version of the Sarasota SG901 will have power to each loop provided from a DCS or remote DC power supply. Note The HART signaling requires the supply to be connected to it and will sink 4–20 mA.
If this is the case, it should be set in the 5–10 bar G range, depending on the sample line length to ensure 5 bar A at the input to the Sarasota SG901 system. ...
(specific heat at constant pressure / specific heat at constant volume) and one of the following: Az and Bz (for the Thermo Scientific Sarasota HME900) or critical temperature and critical pressure (for the Thermo Scientific Sarasota CM515).
SG or MW. The error between the system and the certified value should be within the sum of the uncertainties of the validation gas and the Sarasota SG901. If the error is unacceptable, go to Chapter 7 for troubleshooting.
The sample should be passed to the laboratory for analysis. If the error is unacceptable, go to Chapter 7 for troubleshooting. Thermo Fisher Scientific Sarasota SG901 User Guide...
Sarasota SG901 system. For instance, if the acceptable error of the system at the operating point is 0.2% and the uncertainty of the sample is 0.5%, the acceptable error band is ±...
Doff should give better results as long as the span of the system is relatively small. To calculate the Doff, you will need to know the following synchronous data: average SG error and average line density during the test. 5-2 Sarasota SG901 User Guide Thermo Fisher Scientific...
Page 33
0.9248 4 bar A Liquid Liquid Liquid Liquid 0.8968 2 bar A Liquid Liquid Liquid Liquid Liquid 3 bar A Liquid Liquid Liquid Liquid Liquid 4 bar A Liquid Liquid Liquid Liquid Liquid Thermo Fisher Scientific Sarasota SG901 User Guide...
Page 34
3 bar A 0.9933 0.9996 0.9997 0.9998 0.9999 4 bar A 0.9911 0.9994 0.9996 0.9997 0.9998 Table 5–2. Gas compressibility at reference conditions (0°C and 1.01325 bar A) 0.9976 0.9986 0.9588 1.0006 0.9937 0.9995 5-4 Sarasota SG901 User Guide Thermo Fisher Scientific...
Chapter 6 Maintenance In general, the Sarasota SG901 analyzer is low maintenance. This section provides schedules for preventive maintenance. Caution Maintenance should be performed only by qualified personnel. Preventive Preventive maintenance should be done at least once yearly (more often if the process stream is particularly dirty).
The pressure transmitter span and zero can be adjusted by up to five percent independently using the adjusting screws located inside the end of the transmitter (shown in Figure 6–1). 6-2 Sarasota SG901 User Guide Thermo Fisher Scientific...
200 nsec of the Tair published on the sheet. If the Tair is not within specification, the density meter sensor requires cleaning. Refer to the density meter’s manual. If there are no problems, put the system back into service. Thermo Fisher Scientific Sarasota SG901 User Guide...
- Density / Pressure too high: The pressure regulation has failed, or the exhaust return pressure is too high. - Temperature too high / too low: PT100 failure. This alarm may also indicate a process problem. Thermo Fisher Scientific Sarasota SG901 User Guide...
Pressure transmitter Note Users should be familiar with operating the Sarasota CM515 and Sarasota SG901 and with servicing the Sarasota FD900. Refer to the user guides for each instrument (HB-CM515-DG01, HB-SG901, and HB-ID/ FD900). Note It is assumed that the system is in service and has product running through it.
Page 41
Troubleshooting & Service Troubleshooting Sarasota SG901 / CM515 Density Systems Table 7–2. Troubleshooting steps for Sarasota SG901 / CM515 density systems Symptom Possible Fault Resolution / Further Investigation Sarasota CM515 - No power to instrument. - If there is no power to the instrument the RUN LED will not be display is blank or lit.
Page 42
Troubleshooting & Service Troubleshooting Sarasota SG901 / CM515 Density Systems Symptom Possible Fault Resolution / Further Investigation System gives wrong - One of the three inputs - Check that displayed density (D ) is the expected value for (Line) value for SG.
Troubleshooting & Service Warranty Warranty Thermo Scientific products are warranted to be free from defects in material and workmanship at the time of shipment and for one year thereafter. Any claimed defects in Thermo Scientific products must be reported within the warranty period. Thermo Fisher shall have the right to inspect such products at Buyer’s plant or to require Buyer to return such...
Basic specific gravity analyzer with frequency output, no local display. Includes density meter FD900F, cabinet (IP65 - NEMA 4X), thermometer element, and pressure transmitter for compensation using Thermo Scientific Sarasota CM515 density convertor (other convertors can be used). Notes: Maximum inlet sample pressure of 4 bar. Ambient temperature electronics -20°C to 60°C (gas sample must remain above the dew point within this...
Page 46
Filter elements for coalescing filter (NACE, wet and dry gas systems), 10 each SSG**** Spare spool: consult Thermo Fisher HD-B0070 Spool lock ring H90-0030/A Preset torque spanner ZR20-0220/B Viton O-rings for 1.5” BSP end caps, 10 each A-2 Sarasota SG901 User Guide Thermo Fisher Scientific...
Page 47
CM515 (set of 4 barriers): 2x MTL787S/28V-300 ohm + diode return for power to density meter 2x MTL755/3V 10 ohm AC barriers for 4-wire Platinum resistance thermometer. For use where explosive rating required Thermo Fisher Scientific Sarasota SG901 User Guide...
Dry or wet gas system: 200 bar (2900 psi) maximum. Exhaust pressure Must be less than 4 bar A (58 psi A) and less than the regulated inlet pressure by 0.4 bar A (5.8 psi A). Environmental rating IP65 (NEMA 4X) Thermo Fisher Scientific Sarasota SG901 User Guide...
Page 50
Frequency option: Frequency related to density on 2-wire current modulated loop, 6–18 mA; 4-wire PT100; 4–20 mA pressure. Headmount option: Analog 4–20 mA related to SG, density, or density derived variable; HART protocol. B-2 Sarasota SG901 User Guide Thermo Fisher Scientific...
Page 51
Calibration certification Calibration traceable to national standards. Calibration certificates supplied as standard. Optional traceable calibration equipment listing available. Material traceability Wetted parts traceability to EN 10204. Type 3.1 (tubing and density meter only) Thermo Fisher Scientific Sarasota SG901 User Guide...
General assembly drawing, HT wet gas system (3 C–11 sheets) SG91-6004 General assembly drawing, HT dry gas system (3 C–14 sheets) SG91-6005 General assembly drawing, HT basic gas system (3 C–17 sheets) AD_6502 Wiring diagrams, barrier options (2 sheets) C–20 Thermo Fisher Scientific Sarasota SG901 User Guide...
Page 54
Drawings Figure C–1. SG91-6000: General assembly drawing, wet gas system (sheet 1 of 3) C-2 Sarasota SG901 User Guide Thermo Fisher Scientific...
Page 55
Drawings Figure C–2. SG91-6000: General assembly drawing, wet gas system (sheet 2 of 3) Thermo Fisher Scientific Sarasota SG901 User Guide...
Page 56
Drawings Figure C–3. SG91-6000: General assembly drawing, wet gas system (sheet 3 of 3) C-4 Sarasota SG901 User Guide Thermo Fisher Scientific...
Page 57
Drawings Figure C–4. SG91-6001: General assembly drawing, dry gas system (sheet 1 of 3) Thermo Fisher Scientific Sarasota SG901 User Guide...
Page 58
Drawings Figure C–5. SG91-6001: General assembly drawing, dry gas system (sheet 2 of 3) C-6 Sarasota SG901 User Guide Thermo Fisher Scientific...
Page 59
Drawings Figure C–6. SG91-6001: General assembly drawing, dry gas system (sheet 3 of 3) Thermo Fisher Scientific Sarasota SG901 User Guide...
Page 60
Drawings Figure C–7. SG91-6002: General assembly drawing, basic gas system (3 sheets) C-8 Sarasota SG901 User Guide Thermo Fisher Scientific...
Page 61
Drawings Figure C–8. SG91-6002: General assembly drawing, basic gas system (sheet 2 of 3) Thermo Fisher Scientific Sarasota SG901 User Guide...
Page 62
Drawings Figure C–9. SG91-6002: General assembly drawing, basic gas system (sheet 3 of 3) C-10 Sarasota SG901 User Guide Thermo Fisher Scientific...
Page 63
Drawings Figure C–10. SG91-6003: General assembly drawing, HT wet gas system (sheet 1 of 3) Thermo Fisher Scientific Sarasota SG901 User Guide C-11...
Page 64
Drawings Figure C–11. SG91-6003: General assembly drawing, HT wet gas system (sheet 2 of 3) C-12 Sarasota SG901 User Guide Thermo Fisher Scientific...
Page 65
Drawings Figure C–12. SG91-6003: General assembly drawing, HT wet gas system (sheet 3 of 3) C-13 Thermo Fisher Scientific Sarasota SG901 User Guide...
Page 66
Drawings Figure C–13. SG91-6004: General assembly drawing, HT dry gas system (sheet 1 of 3) C-14 Sarasota SG901 User Guide Thermo Fisher Scientific...
Page 67
Drawings Figure C–14. SG91-6004: General assembly drawing, HT dry gas system (sheet 2 of 3) Thermo Fisher Scientific Sarasota SG901 User Guide C-15...
Page 68
Drawings Figure C–15. SG91-6004: General assembly drawing, HT dry gas system (sheet 3 of 3) C-16 Sarasota SG901 User Guide Thermo Fisher Scientific...
Page 69
Drawings Figure C–16. SG91-6005: General assembly drawing, HT basic gas system (sheet 1 of 3) C-17 Thermo Fisher Scientific Sarasota SG901 User Guide...
Page 70
Drawings Figure C–17. SG91-6005: General assembly drawing, HT basic gas system (sheet 2 of 3) C-18 Sarasota SG901 User Guide Thermo Fisher Scientific...
Page 71
Drawings Figure C–18. SG91-6005: General assembly drawing, HT basic gas system (sheet 3 of 3) C-19 Thermo Fisher Scientific Sarasota SG901 User Guide...
Appendix D Health & Safety Clearance Form The Health & Safety (COSHH) Clearance form can be found on the following page. Failure to return this form may result in the meter being returned. Thermo Fisher Scientific Sarasota SG901 User Guide...
Page 77
1410 Gillingham Lane Sugar Land, TX 77478 USA Tel: 713.272.0404 Fax: 713.272.2272 HEALTH AND SAFETY (COSHH) CLEARANCE FORM Failure to comply with this procedure will result in equipment service delays. This form must be completed for all equipment returned to Thermo Fisher Scientific (Thermo Fisher) – Sugar Land Depot Repair.
Page 80
P = measured/fixed line pressure in bar A [psi A] = calibration pressure of densitometer, 1.01325 bar A [14.696 psi A] L = speed of sound factor, 100000 pa/bar (4633.05567 lbdw/ft /psi) R = VOS correction to density 1000 (10 /12). E-2 Sarasota SG901 User Guide Thermo Fisher Scientific...
Page 81
Pref = reference pressure in bar (psi) Tref = reference temperature in K (°R) T = absolute temperature in K (°R) P = absolute pressure in bar (psia) Z = gas compressibility factor Zref = reference compressibility factor Thermo Fisher Scientific Sarasota SG901 User Guide...
Page 82
Tref = reference temperature K (°R) Gravity / Relative Density (Gas) ρ ρ G = relative density (SG) ρ = density of gas at reference pressure and temperature = density or air at reference pressure and temperature E-4 Sarasota SG901 User Guide Thermo Fisher Scientific...
Page 83
For Sarasota HME900 with imperial units: × 683931 × 0185 MW = molecular weight = R-K fluid constant for Z in K /kg (°R /lb) = R-K fluid constant for Z in m /kg (ft /lb) Thermo Fisher Scientific Sarasota SG901 User Guide...
Configuration Considerations when Using Sarasota CM515 Purpose When the Sarasota CM515 density converter is used in a Sarasota SG901 with frequency output system, the density converter can be configured to use different formula schemes to deal with gas compressibility, Critical Pressure, and Critical Temperature parameters.
Page 86
The Acentric factor can be adjusted to fit the normal proportions of the mix by taking the sum of the products of the gas constituent Acentric factor and the volume percent of each constituent. F-2 Sarasota SG901 User Guide Thermo Fisher Scientific...
12.9 Acentric factor 0.0775 Isentropic exp Critical Unlike the Thermo Scientific Sarasota HC900 and Sarasota HME900, the Sarasota CM515 calculates compressibility using Critical Pressure and Temperature and Critical Temperature rather than Az and Bz, which are derived (partially Critical Pressure calculated) constants for the RK equation of state.
Page 88
+ C. CT Entered and CP Entered relate the constants A, B, and C to the Entered CT or CP constants for the Sarasota CM515. Note that A = b/base and B = A/base in each case. F-4 Sarasota SG901 User Guide Thermo Fisher Scientific...
In the Sarasota CM515, configure the items for the menus listed below as shown in the tables on the following pages. Variables menu Parameters menu Input menu Output menu Alarms menu Comms menu TM/LOG menu Setup menu Thermo Fisher Scientific Sarasota SG901 User Guide...
Page 90
Kelvin 0.001 K Critical Pressure bar A 0.001 bar Critical Pressure is normally only described to 1 DP. User input No options User output A No options User output B No options F-6 Sarasota SG901 User Guide Thermo Fisher Scientific...
Page 91
Enter in ns. Cal cert. value is in 1000 µs. Spool Presco ns/bar VIBDIM 15.8 Gas Isentropic Exponent Gas Critical Single gas Ct or gas Units of Ct (°C or K) Temperature Base mix quasi Ct 12.901 Thermo Fisher Scientific Sarasota SG901 User Guide...
Page 92
Gas Cp Coefficient B -17.72 No choice, but from equation that gives bar Gas Acentric Factor Single Gas Acentric No units Factor or Quasi Acentric Factor for 0.0775 No units F-8 Sarasota SG901 User Guide Thermo Fisher Scientific...
Page 93
4–20 mA Signal Type Analog Input 2 bar A Set to the regulator pressure Default setting. Analog Input 2 bar A Minimum Point Analog Input 2 bar A Maximum Point Values on Exception Default Thermo Fisher Scientific Sarasota SG901 User Guide...
Page 94
Setting not important, as this is the equipment fail alarm. Alarm 3 Type AL-NC Equipment alarm, Normally Closed contacts. Alarm 3 Setpoint Ignored during running. Alarm 3 Hysteresis Ignored during running. Alarm 4 Assignment Period F-10 Sarasota SG901 User Guide Thermo Fisher Scientific...
