Operating instructions
Washer-dryer
To avoid the risk of accidents or damage to the machine, it is essential
to read these instructions before it is installed and used for the first time.
en-SA, AE
M.-Nr. 10 612 060

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the WTH 120 WPM and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Miele WTH 120 WPM

Summary of Contents for Miele WTH 120 WPM

  • Page 1 Operating instructions Washer-dryer To avoid the risk of accidents or damage to the machine, it is essential to read these instructions before it is installed and used for the first time. en-SA, AE M.-Nr. 10 612 060...

  • Page 2: Table Of Contents

    Options - overview ...................  47 Detergent....................... 48 Water softeners .................... 48 Miele recommended detergents .............. 49 Recommended detergents in accordance with Directive (EU) No. 1015/2010 ... 50 Dispensing fabric conditioner and liquid starch at the end of the programme .......................  51 Adding fabric conditioner or liquid starch separately........
  • Page 3 Contents DRYING ........................  53 1. Prepare the laundry ................... 53 2. Select a programme ..................54 3. Load the drum ....................55 4. Select programme settings ................56 5. Start the programme ..................57 6. At the end of a programme ................57 Programme chart....................
  • Page 4 The water protection system ................98 Connection to the water supply ................99 Water drainage ....................100 Electrical connection ................... 101 Miele@home.......................  102 Connecting the washer-dryer to your WiFi network..........104 Technical data.................... 105 Consumption data .....................  106 Settings ...................... 107 Language ...
  • Page 5 Water plus level ....................113 Maximum rinse level.................... 113 Suds cooling......................114 Low water pressure ..................... 114 Distribution controller ..................114 Drying levels ......................114 Miele@home ......................115 Remote control....................115 SmartGrid ......................116 Optional accessories .................. 117 Detergent......................117 Specialist detergents................... 117 Fabric care......................

  • Page 6: Caring For The Environment

    Please dispose of it at your local community waste collection / recycling centre or contact your Miele dealer for advice. Ensure that it presents no danger to children while being stored for disposal.

  • Page 7: Warning And Safety Instructions

    – drying textiles which have been washed in water and have a care label stating that they are suitable for tumble drying. Any other usage is not permitted. Miele cannot be held liable for damage resulting from improper use or incorrect operation of the machine.
  • Page 8 Warning and Safety instructions  This washer-dryer can only be used by people with reduced physical, sensory or mental capabilities, or lack of experience or knowledge, if they are supervised whilst using it or have been shown how to use it in a safe way and understand and recognise the consequences of incorrect operation.
  • Page 9 This special lamp must only be used for the purpose it is intended for. It is not suitable for room lighting. Replacement lamps may only be fitted by a Miele authorised person or by your Miele dealer.
  • Page 10 1000 kPa.  Faulty components must only be replaced by genuine Miele original spare parts. Only when these parts are fitted can Miele guarantee the safety standards of the machine.  If the electrical connection cable is faulty it must only be replaced by a Miele authorised service technician to protect the user from danger.

  • Page 11: Correct Use

    Warning and Safety instructions Correct use  Do not install the washer-dryer in a room where there is a risk of frost. Frozen hoses may burst or split. The reliability of the electronic control unit may be impaired at temperatures below freezing point. ...
  • Page 12 If, however, there is large build-up of limescale and you need to descale it, you must use a special non- corrosive descaling agent. A suitable descaling agent is available to order from Miele (see "Optional accessories"). Instructions on the packaging must be strictly observed. ...
  • Page 13 Warning and Safety instructions  To prevent the risk of fire, the following textiles must not be tumble dried: – Items which have been cleaned using chemicals (e.g. professional dry-cleaning agents). – Items which contain a large proportion of rubber, foam rubber or rubber-like materials.
  • Page 14 Miele. If other parts are used, guarantee, performance and product liability claims will be invalidated.  If you order a plinth for this washer-dryer (available from Miele as an optional accessory), make sure it is the correct one. Miele cannot be held liable for damage caused by non-compliance...

  • Page 15: Operating The Washer-Dryer

    Operating the washer-dryer Control panel a Display with sensor controls g Options buttons See the next page for more Various options can be added to the information. programmes. b Start/Stop button h Programme selector For starting the programme selected For selecting washing and drying and cancelling a programme once it programmes.

  • Page 16: Display With Sensor Controls

    Operating the washer-dryer Standard display Display with sensor controls The standard display for a wash programme shows the following values from left to right: 2:59 60°C 1600 – the programme duration – the selected wash temperature – the selected spin speed The standard display for a drying programme shows the following values from left to right:...

  • Page 17: Examples On How To Operate The Machine

    Operating the washer-dryer Examples on how to operate Applications the machine You can use this washer-dryer to: – wash separately Scrolling through a list Maximum load (depending on The  arrows in the display indicate that programme) 7.0 kg; choices are available: –...

  • Page 18: Before Using For The First Time

    These detergent cartridges are for single use only. Replacement detergent cartridges are available to order from Miele or via the internet at www.miele-shop.com (see end of this booklet for details). Empty cartridges should be disposed of via your local recycling system.
  • Page 19 Before using for the first time  Press the TwinDos access panel.  Push the UltraPhase 1 cartridge into compartment 1 and the The panel will spring open. UltraPhase 2 cartridge into compartment 2, until they lock into position.  Close the panel. The TwinDos system is now ready for use.
  • Page 20 The display indicates that this washer- correctly installed and connected. dryer can be connected to the See "Installation and connection". Miele@home system via a Also check that the drain filter is communication module (only available securely tightened to prevent the risk in selected countries).
  • Page 21 Before using for the first time At the end of the programme the Start the calibration following message will appear in the programme display: The following message will in the   Set-up complete display:   Open  and run Cottons 90°C without laundry.

  • Page 22: Twindos

    Liquid detergent/Fabric conditioner Refillable TwinDos containers are required for liquid detergent and/or fabric conditioner. These are available to order from Miele or via the internet at www.miele-shop.com (see end of this booklet for details).

  • Page 23: Environmentally Friendly Washing And Drying

    Environmentally friendly washing and drying Energy and water consumption Detergent – Water consumption and energy – For precise dispensing use automatic usage are determined by the size of detergent dispensing. the load. To make the most of your – Adjust the dosage to the degree of machine, load the maximum dry load soiling of the laundry.

  • Page 24: Washing

    WASHING Tip: Badly soiled areas can be pre- 1. Prepare the laundry treated with liquid detergent, stain removers etc. first, following the manufacturer's instructions. With particularly stubborn stains ask your dry cleaner for advice.  Solvent-based cleaners (e.g. benzine) can damage plastic parts. When pre-treating garments, make sure that any plastic parts (e.g.

  • Page 25: Select A Programme

    WASHING – with the programme selector dial 2. Select a programme set to the "Further programmes" Switch the washer-dryer on position  Press the  button. The interior drum lighting will come on. The drum lighting will go out automatically after five minutes. Select a programme –...

  • Page 26: Load The Drum

    WASHING Close the door 3. Load the drum Open the door  Make sure that no items are caught between the door and the seal.  Reach under the door grip and pull the door open. Check the drum for pets or foreign objects before loading it with laundry.

  • Page 27: Select Programme Settings

    WASHING Tip: You can alter the default setting for 4. Select programme settings the degree of soiling or switch off the Select the degree of soiling degree of soiling query in Settings (see "Settings - Degree of soiling"). Lightly soiled No visible dirt or stains.
  • Page 28 WASHING Select a temperature Select options You can alter the pre-set temperature You can use the extra options to of a wash programme. augment the wash programmes.  Press the Temperature button. The following will appear in the display: Temperature °C ...

  • Page 29: Add Detergent

     Confirm the message with the OK sensor.  Both agents  Miele 2 Phase system  Confirm or change the selection. UltraPhase 1 and UltraPhase 2 need to The appropriate amount of detergent be dispensed in different ratios and/or fabric conditioner for the depending on the colour mix of the programme will now be dispensed.

  • Page 30: Detergent Dispenser Drawer

    WASHING  Detergent dispenser drawer Too little detergent results in: – Laundry not getting properly clean and with time it may become grey and hard to the touch. – Greasy particles clinging to laundry. – Limescale deposits on the heater elements.
  • Page 31 Each capsule contains the correct amount for one wash cycle. Caps are available to order from Miele  Open the lid of the / or from the Miele Webshop (see the end compartment. of this booklet for contact details). ...
  • Page 32 WASHING  Remove the empty capsule at the end of the programme. For technical reasons a small amount of water will remain in the capsule. Deactivating/changing CapDosing  Touch the Cap  sensor and follow the instructions in the display. ...

  • Page 33: Start The Programme

    WASHING 6. Start the programme Items left in the drum could discolour other items in the next wash or  Press the flashing Start/Stop button. become discoloured themselves. The door will lock (the  symbol will Check that all items have been appear in the display to show this) and removed from the drum.

  • Page 34: Spin Speeds

    WASHING Final spin speed in the programme Spin speeds When a programme is selected the Programme optimum spin speed for that Cottons 1600 programme will appear in the display. Minimum iron 1200 For programmes marked with a * in the chart, the optimum spin speed is not Delicates the maximum spin speed.
  • Page 35 WASHING To omit the final spin (Rinse hold) To omit rinse and interim spin and the final spin  Use the Spin speed button to select  Press the Spin speed button. the  (rinse hold) setting.  Select the The laundry is not spun after the final setting.

  • Page 36: Programme Chart

    WASHING Programme chart Cottons cold to 90°C Max. load 7.0 kg Use for Cotton, linen or mixed fibre fabric, e.g. table linen, towelling, underwear, T-shirts etc. The settings 60 °C/40 °C differ from / as follows: Note – Shorter programme durations – Longer temperature holding times –...
  • Page 37 WASHING Shirts cold to 60°C Max. load 1.0 kg/2.0 kg Use for Shirts and blouses made of cotton and mixed fibre. Note – Pre-treat soiled cuffs and collars if necessary. – Turn shirts and blouses inside out, do up buttons and turn collars and cuffs inwards.
  • Page 38 WASHING Further programmes Denim cold to 60°C Max. load 3.0 kg Note – Wash denim inside-out. – Denim often contains excess dye and may run during the first few washes. Wash light and dark coloured items separately. – Close any zips, do up buttons etc. before washing. Dark garments cold to 60°C Max.
  • Page 39 WASHING Sportswear cold to 60°C Max. load 2.5 kg Use for Sportswear such as singlets and leggings as well as microfibre and fleece garments. Note – Do not use fabric conditioner. – Observe the manufacturer's care label. Trainers cold to 40°C Max.
  • Page 40 WASHING Curtains cold to 40°C Max. load 2.0 kg Use for Curtains specified as machine-washable by the manufacturer. Note – Select the pre-wash option to remove dust. – For curtains which crease easily, reduce the spin speed or deselect the spin. –...
  • Page 41 Cleaning the washer-dryer will significantly reduce bacteria, mould and biofilm and prevent the build-up of unpleasant odours. Note – Optimum results can be achieved by using Miele machine cleaner. Alternatively, a universal powder detergent can be used. – Dispense the machine cleaner or universal detergent directly into the drum.

  • Page 42: Programme Sequence

    WASHING Programme sequence Main wash Rinses Spinning Water level Wash Water level Rinses rhythm 1)2)     Cottons     Minimum iron     Delicates     Woollens     Shirts ...

  • Page 43: Special Features In The Programme Sequence

    WASHING Special features in the programme  = Low water level sequence  = Medium water level Anti-crease  = High water level At the end of the programme the drum  = Intensive rhythm continues to turn at intervals for up to 30 minutes to help prevent creasing.

  • Page 44: Cottons And Minimum Iron

    Cottons and Minimum iron Special features PowerWash 2.0, the washing technique – Drenching phase developed by Miele, is activated in the The washer-dryer will spin a few Cottons programme with small and times at the beginning of the medium-sized loads and in the programme.

  • Page 45: Options

    WASHING ProgrammeManager Options The ProgrammeManager option can be Options are selected and deselected used to customise the washing with the ProgrammeManager, Stains or programmes to suit your requirements. Further options buttons. Short For light soiling without visible stains. The duration of the main wash is reduced.

  • Page 46: Stains

    WASHING AllergoWash Further options This option should be used where high Steam smoothing standards of hygiene are required. More Steam is injected into the drum at the energy is used to lengthen temperature end of the wash process to reduce holding times and more water is used to creasing.

  • Page 47: Options - Overview

    WASHING Options - overview ProgrammeManager Further options           Cottons           Minimum iron           Delicates ...

  • Page 48: Detergent

    WASHING Water softeners Detergent A water softener can be used to cut All detergents produced for automatic down on the use of detergents in areas washing machines are suitable. Follow with water hardness levels II and III. the manufacturer's instructions and Dispense according to the amount dosage recommendations on the specified on the packaging.

  • Page 49: Miele Recommended Detergents

    WASHING Miele recommended detergents Miele detergents and care products have been specially designed for Miele washing machines. They are available to order via the Miele Webshop or from Miele. Miele Miele Miele Miele Cap  Cap  Cap  UltraPhase 1 / 2 ...

  • Page 50: Recommended Detergents In Accordance With Directive (Eu) No. 1015/2010

    WASHING Recommended detergents in accordance with Directive (EU) No. 1015/2010 The recommendations apply to the temperature ranges given in the WASHING Programme chart. Universal Coloureds Delicates Specialist and woollens detergent   Cottons – –  Minimum iron – – –...

  • Page 51: Dispensing Fabric Conditioner And Liquid Starch At The End Of The Programme

    WASHING Dispensing fabric conditioner and Manual dispensing liquid starch at the end of the programme Fabric conditioner makes garments soft to handle and helps prevent static cling when tumble drying. You can dispense fabric conditioner either by using automatic dispensing or via the detergent dispenser compartment.

  • Page 52: Adding Fabric Conditioner Or Liquid Starch Separately

    WASHING Adding fabric conditioner or liquid Colour run and dye removers/dyes starch separately  Colour run and dye removers are Prepare the starch in accordance with corrosive. the manufacturer's instructions on the Do not use them in this washer- packaging. dryer.

  • Page 53: Drying

    DRYING – Loopknit garments (e.g. T-shirts and Separate drying underwear) tend to shrink depending The separate drying programme on their quality. Do not over-dry these should be run if the load in the wash textiles. When purchasing these programme is greater than the garments it is advisable to take their maximum load permitted for drying, or shrinkage properties into account.

  • Page 54: Select A Programme

    DRYING - with the programme selector dial 2. Select a programme set to the "Further programmes" Switch the washer-dryer on position  Press the  button. The interior drum lighting will come on. The drum lighting will go out automatically after five minutes. Select a programme - with the programme selector dial ...

  • Page 55: Load The Drum

    DRYING Select "Drying". 3. Load the drum  Touch the Washing and Drying sensor Open the door until just the  Drying indicator light  Reach under the door grip and pull remains on. the door open. The Washing indicator light must not Check the drum for pets or foreign be lit up, as this would mean that the objects before loading it with...

  • Page 56: Select Programme Settings

    DRYING Select options 4. Select programme settings You can select extra options to Select the drying level augment drying programmes. The pre-set drying level for a programme can be changed if required.  Press the Drying level button. The following will appear in the display: Normal ...

  • Page 57: Start The Programme

    DRYING 5. Start the programme 6. At the end of a programme  Press the flashing Start/Stop button. The door is still locked during the anti- crease phase and the following will The door will lock (the  symbol will appear alternately in the display: appear in the display to show this) and the drying programme will start.

  • Page 58: Programme Chart

    DRYING Programme chart Cottons Max. load 4.0 kg* Extra dry, Normal+, Normal Use for Single and multi-layered cotton fabric such as towelling, jerseywear, T-shirts, underwear, workwear, covers, flannelette bed linen and baby clothes. Note Do not use Extra dry for jersey fabric (e.g. T-shirts, underwear), as they have a tendency to shrink.
  • Page 59 DRYING Woollens Max. load 1.0 kg* 3 minutes Use for Woollen garments and fabric containing wool blends, e.g. pullovers, jackets and socks. Note – Wool and wool blend fabrics; woollen garments are only fluffed up, they are not dried completely. –...
  • Page 60 DRYING Express Max. load 3.5 kg* Extra dry, Normal+, Normal, Hand iron , Hand iron , Machine iron, Smoothing Timed drying Use for Garments suitable for the Cottons programme. Note The programme duration is particularly short when washing and drying lightly soiled laundry in a continuous sequence. Freshen up Max.
  • Page 61 DRYING Timed drying warm Max. load 4.0 kg* Timed drying Use for – Multi-layered items whose layers have different drying characteristics, e.g. jackets, pillows, sleeping bags and other voluminous items. – For drying and airing individual items. Note Do not select the longest drying time to start with. Check the items as you are drying them to find the optimum time.
  • Page 62 DRYING Trainers Max. 2 pairs Timed drying Use for Trainers that are specified as suitable for tumble drying by their manufacturer. Note – The drum does not rotate. – Insoles should be removed and placed in the drum with the shoes. Silks Max.
  • Page 63 DRYING Cottons hygiene Max. load 3.0 kg* Normal Use for Cottons and linen fabric that are not sensitive to heat and which will be in direct contact with the skin, e.g. underwear, baby clothes, bed linen, towelling. Note The laundry will feel drier because of the longer temperature holding time.

  • Page 64: Options

    DRYING Further options Options Options are selected and deselected Steam smoothing with the ProgrammeManager and To reduce creasing, laundry is Further options buttons. smoothed with steam at the end of the programme. The thermospin spin speed is reduced. For optimum results the maximum load for the programme should be reduced by 50%.

  • Page 65: Overview Of Options And The Thermospin

    DRYING Overview of options and the thermospin None of the options can be selected with programmes which are not listed in the chart below. Extra Steam Thermo Extra gentle quiet smoothing spin Cottons        ...

  • Page 66: Washing And Drying

    WASHING AND DRYING Washing and drying in one 3. Load the drum continuous sequence  Open the door. It is advisable to wash and dry in a Check the drum for pets or foreign continuous sequence when the objects before loading it with amount of laundry to be washed does laundry.

  • Page 67: Select Programme Settings

    WASHING AND DRYING 4. Select programme settings 5. Add detergent  Select the degree of soiling level.  Dispense detergent either via TwinDos, Cap dosing or the detergent  Select the temperature, spin speed dispenser drawer. and drying level and confirm each with OK.

  • Page 68: After Each Washing Or Drying Programme

    WASHING AND DRYING After each washing or drying "Rinse out fluff" programme programme During drying fluff can collect in the drum and also in the suds container.  Open the drum door fully. Run the Rinse out fluff programme  before the machine is used again so Caution! The metal cap is hot that fluff cannot be deposited on the...

  • Page 69: Changing The Programme Sequence

    Changing the programme sequence Cancelling a programme Interrupting a programme  Switch the washer-dryer off with the You can cancel a programme at any  button. time after it has started.  Press the Start/Stop button.  To continue the programme switch the washer-dryer back on with the ...

  • Page 70: Safety Lock

    Changing the programme sequence Altering the spin speed Safety lock The final spin speed for a wash The safety lock prevents the machine programme can be altered up until the being opened or a programme being spin starts. cancelled or changed during a washing or drying programme.

  • Page 71: Adding Or Removing Laundry

    Changing the programme sequence Adding or removing laundry You can add or remove items during the first few minutes after the programme has started.  Press the Start/Stop button. The following will appear in the display:  Cancel programme  Scroll up the list with the  or  sensor to: ...

  • Page 72: Delay Start

    Delay start With delay start you can choose when To alter Delay start you want the programme to start. You You can change delay start at any time. can delay the start of the programme from 15 minutes up to a maximum of 24 ...

  • Page 73: Garment Care Label Symbols

    Garment care label symbols Drying Washing The number of dots indicates the The figure quoted in the bucket is the drying temperature maximum temperature the garment can be washed at. The number of  Normal temperature bars under the symbol indicates the ...

  • Page 74: Cleaning And Care

    Cleaning and care Cleaning the detergent  Disconnect the machine from the dispenser drawer mains electricity supply before cleaning or maintenance. Washing at low temperatures and the use of liquid detergent can lead to a  Do not use solvents, abrasive build-up of mould and bacteria in the cleaners, glass cleaners or all- detergent dispenser drawer.

  • Page 75: Cleaning The Drum

    Cleaning and care Cleaning the siphon tube and the Cleaning the detergent dispenser channel drawer housing  Use a bottle brush to remove  Clean the siphon. detergent residues and limescale 1. Remove the siphon from the  from the jets inside the detergent compartment and rinse under hot dispenser drawer housing.

  • Page 76: Cleaning The Twindos System

    Cleaning and care Starting the maintenance programme Cleaning the TwinDos system  Switch on the washer-dryer on and The washer-dryer has a cleaning wait until the standard display lights programme for cleaning the TwinDos system containers and the hoses inside the machine.
  • Page 77 Cleaning and care Cleaning the compartments The following will appear in the display: Detergent residue can cause clogging.  Fill to the mark with water  Use a damp cloth to clean the compartment interior when you change the cartridge or container. ...

  • Page 78: Cleaning The Water Inlet Filter

    Cleaning and care  Put the filter and seal back in the Cleaning the water inlet filter reverse order and reconnect the This washer-dryer has a filter to protect hose. the water inlet valve. The filter in the  Turn on the stopcock and check the union in the open end of the inlet hose connection is watertight.

  • Page 79: What To Do If

    Miele dealer. This will save time and money. The following guide may help you to find the reason for a fault, and to correct it.

  • Page 80: The Following Fault Messages Appear In The Display And The Programme Stops

     Call Service. There is a fault.   Service Fault F  Start the programme again. If the fault message appears again, contact your Miele dealer. To switch off the fault messages: switch the washer-dryer off with the  button.

  • Page 81: A Message Appears In The Display At The End Of The Programme

     Start the programme again after cleaning the jet. If the fault message appears again, contact your Miele dealer. The washer-dryer can still be used but with reduced functionality. A programme using a temperature above 60 °C has ...
  • Page 82  Check whether the maximum delivery height of 1.0 m has been exceeded. If the fault message appears again, contact your Miele dealer. The washer-dryer can still be used but with reduced functionality. There is no laundry in the drum.

  • Page 83: Problems With Twindos

    Automatic dispensing will be activated. No detergent/fabric conditioner was dispensed even though automatic dispensing was activated.  Try again.  If detergent is still not dispensed, call your Miele dealer. There are dark specks Mould has developed in the detergent.

  • Page 84: General Problems With The Washer-Dryer

    What to do if ... General problems with the washer-dryer Issue Cause and remedy The washer-dryer is not The machine feet are not level. steady during a spin  Level the washer-dryer and secure the feet. cycle. Unusual pumping This is not a fault. These slurping noises occur at the noises.
  • Page 85 What to do if ... General problems with the washer-dryer Issue Cause and remedy At the end of the The small pipe in the detergent dispenser drawer onto programme there is still which the capsule is placed is blocked. liquid in the capsule. ...

  • Page 86: An Unsatisfactory Wash Result

    They do not remove fruit, coffee and tea result. stains.  Use the Miele 2 Phase System. The targeted addition of UltraPhase 2 during the wash process removes stains effectively.  Use a general purpose powder detergent containing a bleaching agent.

  • Page 87: Unsatisfactory Drying Results

    What to do if ... Unsatisfactory drying results Issue Cause and remedy The laundry is too damp The load is too small for the electronics to correctly after drying and calculate the residual moisture content. Check load appears in the  Start the programme again and instead of a drying display.

  • Page 88: The Door Will Not Open

     Wait until the temperature in the drum has Cooling down Comfort decreased and the message has gone out in the cooling appears in the display. display. The following appears The door lock has jammed. in the display:  Call your Miele dealer.  Service Door release...

  • Page 89: Opening The Door In The Event Of A Blocked Drain Outlet And/Or Power Cut

     Switch the washer-dryer off. out.  Place a suitable container, e.g. a Miele universal oven tray under the access panel.  Press the drain pump access panel. The panel will spring open. Blocked drain outlet ...
  • Page 90 What to do if ... Clean the drain filters. Open the door  Reaching into a moving drum is extremely dangerous. Danger of injury. Always make sure that the drum is stationary before reaching in to remove laundry.  Clean them thoroughly. ...

  • Page 91: After Sales Service

    Miele Dealer. please contact your Miele dealer. See end of this booklet for contact details. Contact details for Miele are given at the end of this booklet. N.B. A call- Optional accessories out fee will be charged for service...

  • Page 92: Installation And Connection

    Installation and connection Front view a Waterproof-Metal inlet hose (braided) e Detergent dispenser drawer b Electrical connection f Door c Flexible drain hose (with detachable g Access to drain filter, drain pump and elbow) emergency release d Control panel h Access panel for TwinDos containers i Four height adjustable feet...

  • Page 93: Rear View

    Rear view a Protruding lid for holding when e Transport clips for inlet and drain moving the machine hoses b Drain hose f Electrical connection c Waterproof-Metal inlet hose (braided) g Miele@home communication module slot d Safety caps for transit bars...

  • Page 94: Installation Surface

    (concrete or catches at the top and bottom. brick), there is a danger of the machine falling off the plinth during the spin cycle. The washer-dryer must be secured with an MTS floor mounting kit (available from Miele).
  • Page 95 Installation and connection  Using the spanner supplied, turn the  Turn the right-hand transit bar 90°, left-hand transit bar 90°, then then  pull the transit bar out.  pull the transit bar out.

  • Page 96: Re-Fitting The Transit Bars

    Installation and connection Installing under a continuous  If the holes are not covered, worktop there is a risk of injury. To avoid the risk of injury the holes Building under kits* must only be for the transit bars must be covered installed/dismantled by a suitably after they have been removed.

  • Page 97: Aligning The Washer-Dryer

    Installation and connection Aligning the washer-dryer The washer-dryer must stand perfectly level on all four feet to ensure safe and proper operation. Incorrect installation may increase electricity and water consumption and may cause the washer-dryer to move about. Screwing out and adjusting the feet The four adjustable screw feet are used to level the washer-dryer.

  • Page 98: The Water Protection System

    Installation and connection Electronic unit and casing The water protection system – Sump The Miele water protection system protects all parts of the washer-dryer Any leaking water is collected in a from water damage. sump in the base of the washer- dryer.

  • Page 99: Connection To The Water Supply

    Installation and connection Maintenance Connection to the water supply Only use a genuine Miele hose that has The washer-dryer should be connected been tested to withstand pressure of at to the mains water supply in least 14,000 kPa should you ever need accordance with current local and a replacement.

  • Page 100: Water Drainage

    (up to a max. of 1.8 m) a replacement drain pump will need to be fitted. b Nut Please contact Miele or your Miele Dealer for advice. If necessary, the c Hose clip drain hose can be extended to a length d End of the hose of 2.5 m.

  • Page 101: Electrical Connection

    Installation and connection Non-rewireable plugs BS 1363 Electrical connection The fuse cover must be refitted when The appliance is supplied with a mains changing the fuse, and if the fuse cover cable with moulded plug for is lost, the plug must not be used until a connection.

  • Page 102: Miele@Home

    Miele@home a Miele@home communication enabled appliance b Miele@home communication enabled Master appliance with SuperVision functionality c Wi-Fi Router d Mobile device (Smartphone, Tablet PC, Notebook) e Connection to a Home automation system f Internet connection...
  • Page 103 Further information regarding Displaying information and Miele@home is available on the internet controlling appliances and in the instruction manuals of the – Mobile devices  with Miele@mobile various Miele@home components. Please note that the Miele@home and...

  • Page 104: Connecting The Washer-Dryer To Your Wifi Network

    WiFi network. Pre-requisites: 1. Connect via the Miele@mobile App – You must have a WPS compatible The Miele@mobile App can be used to router. connect to your network.  Install the Miele@mobile App on your – The WiFi module must be inserted in the module shaft.

  • Page 105: Technical Data

    Technical data Height 850 mm Width 596 mm Depth 637 mm Depth with door open 1055 mm Height for building under 820 (+8/-2) mm Width for building under 600 mm Weight approx. 98 kg Capacity, washing 7.0 kg dry laundry Capacity, drying 4.0 kg dry laundry Voltage...
  • Page 106 Consumption data Load Energy Water Duration Litres h:min Washing Cottons 90 °C 2.10 2:29 60 °C 1.10 2:29 0.93 2:59   0.75 2:59 40 °C 0.75 2:39 40 °C 0.54 2:29 20 °C 0.35 2:39 Minimum iron 30 °C 0.34 1:59 Delicates 30 °C 0.30 1:09 Woollens ...

  • Page 107: Settings

    Settings Selecting a setting The settings are used to alter the washer-dryer's electronics to suit  Touch the  or  sensor until the different requirements. Settings can setting you want appears in the be altered at any time. display. –...

  • Page 108: Language

    Compartment 1 as a guide to prevent a language which will not be understood from being set.  Touch the OK sensor. The selected language will be stored in Miele UltraPhase 1   memory.  Touch the OK sensor.
  • Page 109 Settings Changing the detergent type  Not defined  Dosage amounts for Miele products  Select the detergent you want using (e.g. UltraColor, Miele fabric the  and  sensors and confirm conditioner) are pre-set for water your selection with the OK sensor.

  • Page 110: Degree Of Soiling

    If you forget the code the machine chart. At the lowest setting, the buzzer will have to be unlocked by your is switched off. Miele dealer. Keypad tone Make a note of the new code. Each touch of a sensor or press of a...

  • Page 111: Display Brightness

    Settings Display brightness Machine switch-off There are seven different display The washer-dryer will switch off brightness settings. automatically after the end of the programme/anti-crease phase or after The brightness changes as soon as you being switched on if no further select a different setting.

  • Page 112: Memory

    Settings Memory Soak duration The washer-dryer will save the last You can set a duration for the soak settings selected for a programme process of between 30 minutes and 5 (temperature, spin speed and some of hours. the options) after the programme has You can select the duration in 30 minute started.

  • Page 113: Temperature Reduction

    The boiling point for water is lower at There are four different water levels high altitudes. In order to avoid water which can be selected with Water boiling, Miele recommend activating plus. the reduce temperature setting at Level altitudes of more than 2000 m above sea level.

  • Page 114: Suds Cooling

    Settings Suds cooling Distribution controller When this is activated, additional The maximum final spin speed can be water flows into the drum at the end of limited to prevent laundry forming a the main wash to cool the suds down. ring around the drum.

  • Page 115: Miele@Home

    Remote control optional accessories). visible when the WiFi module is fitted and signed on. Miele@home Once the Miele@mobile App has been The  Miele@home setting is only visible installed on your mobile device, you when the WiFi module is fitted.

  • Page 116: Smartgrid

    Settings SmartGrid setting is only visible SmartGrid when the WiFi module is fitted and signed on. This  function can be used for starting your washer-dryer automatically at a time when your energy costs are most economical. Activating SmartGrid , gives the Delay start button a new function.

  • Page 117: Optional Accessories

    Miele washing garments machines. – protects bright colours from fading These and many other useful products can be ordered from your Miele dealer – effective stain removal even at low (see end of this booklet for contact temperatures details).

  • Page 118: Fabric Care

    Optional accessories Down items Fabric care – liquid detergent suitable for pillows, Fabric care agents are available as sleeping bags and down filled items capsules  in convenient single dose amounts or in a handy bottle. – retains the elasticity of down and feather filled items Proofing agent –...
  • Page 119 Tel. +966 11 2013501, Fax. +966 11 2013502 Dubai Taif Hadiya Street Tel. +966 12 7327001, Fax. +966 12 7369596 Khobar Al Zahran Road Tel. +966 13 8646150, Fax. +966 13 8646190 Manufacturer: Miele & Cie. KG, Carl-Miele-Straße 29, 33332 Gütersloh, Germany...
  • Page 120 WTH 120 WPM  en-SA, AE M.-Nr. 10 612 060 / 00...

Table of Contents
