Specifications; Technical Specifications - AVCOM SNG-2500C User Manual

S
PECIFICATIONS
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
S
pecifications are based on Avcom control system and
graphical user interface and may vary depending on the
control system used. Please contact Avcom for specifications
based on the selected platform. Specifications are subject to change.
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
T E C H N I C A L S P E C I F I C A T I O N S
Frequency Coverage:
Span Width:
Resolution Bandwidth: 10kHz, 100kHz, 300kHz, 1MHz
RF Sensitivity:
Reference Levels:
Scale:
Dynamic Range:
Amplitude Accuracy: +/- 1 dB typical
Frequency Accuracy:
Input Connector:
Size:
Weight:
Power Requirements: +15 Volts DC, 3 Amps
Display:
Input Option:
Connector Option:
Revision 001
5 - 2500 MHz
0 - 1300 MHz
Greater than - 85 dBm Typical
Selectable - 10, -30 & - 50 dBm
5 dB/Div & 2dB/Div
40 dB on Application Window
+/- 1kHz typical
"BNC" Type (others available)
Width, Height, Depth 8.0" X 4.75" X 16.5"
5 Lbs.
Full VGA Color LCD
2 standard, 4 or 6 optional
BNC is standard; F, N, SMA, TNC are
optional
4
SNG-2500C User's Guide
4-1
