T
o avoid the need for a large and complicated front panel, the
SNG-2500C uses a system of menus and sub-menus to
provide access to most of its features. You can navigate this
menu system by using the column of buttons above the
button. Each of these buttons is described in detail in Chapter 1.
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
T H E D I S P L A Y S C R E E N
Below is an example of what the screen might look like:
Frequency at
center of display
Revision 001
LO Offset feature Span, in MHz. This is the "scale"
is on of the Y axis.
Signal Strength (X axis)
Frequency (Y axis)
Current settings are stored in Preset 1
Signal is from RF Input 1
Resolution Bandwidth is 1MHz
3
<POWER>
SNG-2500C User's Guide
3-1
