T H E S A V E D W A V E F O R M S M E N U
The options on the Saved Waveforms Menu enable you to freeze a
waveform on the screen and simultaneously save it to a memory
location for later display. There are fifty memory locations available
for this purpose.
Here is an example of a saved waveform. The blue line is the saved
waveform, and the black line is the waveform currently being
monitored.
Use this
option... To...
Save To freeze a waveform on the screen and simultaneously save it
to a memory location.
Load From recall a waveform from a memory location and display it.
Clear Screen clear a frozen waveform from the screen.
Delete Single delete a waveform from memory.
Delete All delete all waveforms from memory.
U S I N G T H E S N G - 2 5 0 0 C

The Saved Waveforms Menu

SNG-2500C User's Guide
3-8
