Page 2
COREbar™ 4 QRG The COREbar™ 4 Quick Reference Guide (QRG) has basic product About This information such as mounting, menu options, and DMX values. Download Guide the User Manual from www.chauvetlighting.com for more details. The information and specifications contained in this QRG are subject to Disclaimer change without notice.
Unpack your COREbar™ 4 and make sure you have received all parts in To Begin good condition. If the box or contents appear damaged, notify the carrier immediately, not Chauvet. The COREbar™ 4 is a complete wash lighting solution for mobile Description entertainers.
Page 4
COREbar™ 4 QRG This product has an auto-ranging power supply that can work with an input AC Power voltage range of 100–240 VAC, 50/60 Hz. To eliminate wear and improve its lifespan, during periods of non-use completely disconnect from power via breaker or by unplugging it. Power Linking For the maximum number of COREbar™...
COREbar™ 4 QRG Button Function Control Panel <MENU> Exits from the current menu or function Description Navigates upwards through the menu list and increases the <UP> numeric value when in a function Navigates downwards through the menu list and decreases the <DOWN>...
COREbar™ 4 QRG DMX Values 15CH Channel Function Value Percent/Setting 000 ó 009 No function 010 ó 029 Auto program 1 030 ó 049 Auto program 2 050 ó 069 Auto program 3 070 ó 089 Auto program 4 090 ó 109 Auto program 5 110 ó...
COREbar™ 4 GRR Guía de Referencia Rápida (GRR) del COREbar™ 4 contiene información Acerca de básica sobre el producto, como montaje, opciones de menú y valores DMX. Esta Guía Descargue el manual de usuario de www.chauvetlighting.com para información más detallada. Exención de La información y especificaciones contenidas en esta GRR están sujetas a Responsabilidad...
Desembale su COREbar™ 4 y asegúrese de que ha recibido todas las partes Para Empezar en buen estado. Si la caja o los componentes parecen dañados, notifíqueselo al transportista inmediatamente, no a Chauvet. El COREbar™ 4 es una solución completa de baño de luz para artistas en Descripción gira.
COREbar™ 4 GRR Este producto tiene una fuente de alimentación con detección automática que Corriente puede funcionar con un rango de tensión de entrada de 100~240 VCA, Alterna 50/60 Hz. Para evitar un desgaste innecesario y alargar su vida útil, desconecte complemente el producto de la alimentación, mediante el interruptor o desenchufándolo, durante los periodos en los que no se use.
COREbar™ 4 GRR Botón Función Descripción Sale del menú o función actual <MENU> del Panel de Navega hacia arriba por la lista de menú y aumenta el valor <UP> numérico cuando está en una función Control Navega hacia abajo por la lista de menú y disminuye el valor <DOWN>...
COREbar™ 4 GRR Valores DMX 15CH Canal Función Valor Porcentaje/Configuración 000 ó 009 Sin función 010 ó 029 Programa Automático 1 030 ó 049 Programa Automático 2 050 ó 069 Programa Automático 3 070 ó 089 Programa Automático 4 090 ó 109 Programa Automático 5 110 ó...
COREbar™ 4 MR Le Manuel de Référence du COREbar™ 4 (MR) reprend des informations de À Propos de base sur cet appareil notamment en matière de montage, d'options de menu et ce Manuel valeurs DMX. Téléchargez manuel d'utilisation www.chauvetlighting.com pour de plus amples informations. Clause de Non- Les informations et caractéristiques contenues dans ce manuel sont sujettes à...
Déballez votre COREbar™ 4 et assurez-vous d'avoir tout reçu et en bon état. Débuter Si l'emballage ou le contenu semblait être endommagé, indiquez-le immédiatement au transporteur et non à Chauvet. Le COREbar™ 4 est une solution complète d'éclairage de type wash pour Description animateurs itinérants.
COREbar™ 4 MR Cet appareil est doté d'une alimentation universelle prenant en charge toute Alimentation tension d'entrée comprise entre 100 et 240 VCA, 50/60 Hz. Durant les périodes de non-utilisation, pour éviter tout usure inutile et pour prolonger la durée de vie, déconnectez-entièrement l'appareil en le débranchant de l'alimentation électrique ou en coupant le disjoncteur.
COREbar™ 4 MR Bouton Fonction Description du Permet la sortie du menu ou de la fonction en cours <MENU> Tableau de Permet de parcourir les listes de menu vers le haut, dans une <UP> fonction permet d'augmenter les valeurs numériques Commandes Permet de parcourir les listes de menu vers le bas, dans une <DOWN>...
COREbar™ 4 MR Valeurs DMX 15CH Canal Fonction Valeur Pourcentage/Configuration 000 ó 009 Pas de fonction 010 ó 029 Programme automatique 1 030 ó 049 Programme automatique 2 050 ó 069 Programme automatique 3 070 ó 089 Programme automatique 4 090 ó...
COREbar™ 4 SAL In der Schnellanleitung des COREbar™ 4 finden Sie die wesentlichen Über diese Produktinformationen, wie etwa über die Montage, Menüoptionen und Schnellan- DMX-Werte des Geräts. Laden Sie für weiterführende Informationen unter leitung www.chauvetlighting.com das Benutzerhandbuch herunter. Die Informationen und Spezifikationen dieser Anleitung können ohne Haftungs- vorherige Ankündigung geändert werden.
Page 18
· · Stativ 2 Tragetaschen · · 2 Befestigungswinkel Fußschalter Packen Sie Ihr COREbar™ 4 aus und überprüfen Sie, ob Sie alle Teile Start unbeschädigt erhalten haben. Wenn die Verpackung beschädigt ist, benachrichtigen Sie umgehend das Transportunternehmen, nicht jedoch Chauvet.
Page 19
COREbar™ 4 SAL Der COREbar™ 4 bietet eine vollständige Wash-Effekt-Beleuchtung für Beschreibung mobile Entertainer. Er erzeugt ein komplettes Lichtspektrum mit hervorragenden Farbmischeigenschaften mittels der COB-Technologie. Eine vollständige Ausleuchtung des Raumes oder Bühnenbereichs wird über 4 individuell einstellbarer Köpfe erreicht. Im Lieferumfang enthalten sind Stativ, Fußschalter und Tragetaschen.
COREbar™ 4 SAL Dieses Gerät verfügt über ein Vorschaltgerät, das automatisch die anliegende Wechselstrom Spannung erkennt, sobald der Netzstecker in die Schukosteckdose gesteckt wird, und kann mit einer Eingangsspannung von 100~240 V AC, 50/60 Hz arbeiten. Um unnötigen Verschleiß zu vermeiden und die Lebensdauer des Geräts verlängern, trennen während...
Page 21
COREbar™ 4 SAL Taste Funktion Beschreibung Damit verlassen Sie das aktuelle Menü oder die Funktion <MENU> Damit navigieren Sie sich durch die Menüpunkte nach oben und <UP> erhöhen den numerischen Wert der entsprechenden Funktionen Bedienfeldes Damit navigieren Sie sich durch die Menüpunkte nach unten und <DOWN>...
Page 22
COREbar™ 4 SAL DMX-Werte 15CH Kanal Funktion Wert Prozent/Einstellung 000 ó 009 Keine Funktion 010 ó 029 Auto-Programm 1 030 ó 049 Auto-Programm 2 050 ó 069 Auto-Programm 3 070 ó 089 Auto-Programm 4 090 ó 109 Auto-Programm 5 110 ó 129 Auto-Programm 6 Auto-Programme 130 ó...
COREbar™ 4 GRR O Guia de Referência Rápida (GRR) do COREbar™ 4 contém informações Sobre este básicas sobre o produto tais como instalação, opções de menu e valores Guia DMX. Transfira o Manual de Utilizador de www.chauvetlighting.com para obter mais informações. Exclusão de As informações e especificações contidas neste GRR estão sujeitas a alteração sem aviso prévio.
Page 24
COREbar™ 4 GRR · A tensão da tomada à qual irá ligar este produto deve estar no intervalo indicado no autocolante ou painel posterior do produto. · Este produto destina-se apenas a ser utilizado no interior! (IP20) Para evitar o risco de incêndio ou choque eléctrico, não exponha este produto à...
Desembale o COREbar™ 4 e certifique-se de que recebeu todas as peças em Para Começar boas condições. Se a caixa ou conteúdos aparentarem estar danificados, notifique imediatamente a transportadora e não a Chauvet. O COREbar™ 4 é uma solução de fonte de luz completa para apresentadores Descrição de espectáculos que se deslocam frequentemente.
Page 26
COREbar™ 4 GRR Este produto possui uma fonte de alimentação de intervalo automático que Alimentação pode funcionar num intervalo de tensão de entrada de 100~240 VCA, 50/60 Hz. Para eliminar desgaste desnecessário e aumentar a respectiva vida útil, durante os períodos de não utilização deve desligar o produto da alimentação através de um disjuntor ou desconectando-o.
COREbar™ 4 GRR Botão Função Descrição do Sai da função ou menu actual <MENU> Painel de Desloca-se para cima na lista de menus e aumenta o valor <UP> numérico numa função Controlo Desloca-se para baixo na lista de menus e diminui o valor <DOWN>...
Page 28
COREbar™ 4 GRR Valores DMX 15CH Canal Função Valor Percentagem/Definição 000 ó 009 Sem função 010 ó 029 Programa automático 1 030 ó 049 Programa automático 2 050 ó 069 Programa automático 3 070 ó 089 Programa automático 4 090 ó 109 Programa automático 5 110 ó...
Page 29
COREbar™ 4 GR La Guida Rapida di COREbar™ 4 contiene informazioni di base sul prodotto Informazioni quali montaggio, opzioni menù e valori DMX. Per maggiori dettagli, sulla Guida scaricare il Manuale Utente dal sito www.chauvetlighting.com. Esclusione di Le informazioni e le specifiche contenute in questa guida possono essere modificate senza preavviso.
Disimballare COREbar™ 4 ed accertarsi di aver ricevuto tutti i componenti Per Iniziare integri. Se l'imballo appare danneggiato, farlo immediatamente presente al trasportatore e non a Chauvet. COREbar™ 4 è una soluzione completa di illuminazione radente (wash) per Descrizione intrattenitori itineranti. Produzione di uno spettro completo di luce con eccellente mixaggio colore grazie alla tecnologia COB.
COREbar™ 4 GR Questa apparecchiatura è dotata di alimentatore a commutazione automatica Alimentazione con tensione in ingresso di 100~240 V CA - 50/60 Hz. Per evitare un consumo inutile ed aumentare la durata, durante i periodi utilizzo disconnettere completamente prodotto dall'alimentazione con l'interruttore o scollegando il cavo.
COREbar™ 4 GR Pulsante Funzione Descrizione Consente di uscire dal menù o dalla funzione corrente <MENU> del Pannello di Consente di spostarsi verso l'alto nell'elenco menù e di aumentare <UP> il valore numerico all'interno di una funzione Controllo Consente di spostarsi verso il basso nell'elenco menù e di <DOWN>...
COREbar™ 4 GR Valori DMX 15CH Canale Funzione Valore Percentuale/Impostazione 000 ó 009 Nessuna funzione 010 ó 029 Programma automatico 1 030 ó 049 Programma automatico 2 050 ó 069 Programma automatico 3 070 ó 089 Programma automatico 4 090 ó 109 Programma automatico 5 110 ó...
Page 34
COREbar™ 4 QRG COREbar™ 4 Quick Reference Guide (QRG) zawiera podstawowe informacje o produkcie takie jak montaż, opcje menu oraz wartości DMX. Szczegółowe Przewodniku informacje znajdują się w instrukcji obsługi na stronie www.chauvetlighting.com. Oświadczenie Informacje i specyfikacje zawarte w niniejszym dokumencie (QRG) podlegają zmianie bez powiadomienia.
W przypadku, gdy Montażem opakowanie lub jego zawartość noszą ślady uszkodzenia, należy natychmiast poinformować o tym fakcie dostawcę, a nie firmę CHAUVET®. COREbar™ 4 jest kompletnym zestawem oświetleniowym typu wash, Opis idealnym dla mobilnych DJ-ów.
Page 36
COREbar™ 4 QRG Produkt posiada automatyczne przełączanie zakresu zasilania, które pozwala Moc AC na działanie produktu przy napięciu wejściowym 100~240 VAC, 50/60 Hz. W celu wyeliminowania niepotrzebnego zużycia oraz wydłużenia trwałości urządzenia, należy odłączyć je całkowicie od źródła zasilania poprzez przełączenie bezpiecznika lub wyciągnięcie wtyczki z gniazda zasilania w czasie, gdy urządzenie nie jest używane.
COREbar™ 4 QRG Przycisk Funkcja Opis Panelu Wyjście z bieżącej opcji menu lub funkcji <MENU> Sterowania Przejście w górę po liście menu oraz zwiększenie wartości <UP> numerycznej w funkcji Przejście w dół po liście oraz obniżenie wartość numerycznej w <DOWN> funkcji <ENTER>...
COREbar™ 4 QRG Wartości DMX Kanał Wartość Procent/Ustawienie 15CH Funkcja 000 ó 009 Brak funkcji 010 ó 029 Programy automatyczny 1 030 ó 049 Program automatyczny 2 050 ó 069 Program automatyczny 3 070 ó 089 Program automatyczny 4 090 ó 109 Program automatyczny 5 110 ó...
Page 39
COREbar™ 4 BH De COREbar™ 4 Beknopte Handleiding (BH) bevat basisinformatie over het Over deze product, zoals montage, menu-opties en DMX-waarden. Download de handleiding gebruikershandleiding op www.chauvetlighting.com voor meer informatie. De informatie en specificaties in deze BH kunnen zonder voorafgaande Disclaimer kennisgeving worden gewijzigd.
Page 40
COREbar™ 4 BH · De spanning van het stopcontact waarop u dit product aansluit moet binnen het vermelde bereik op de sticker of achterkant van het product zijn. · Het product is alleen voor gebruik binnenshuis! (IP20) Om risico op brand of elektrische schokken te voorkomen, mag dit product niet aan regen of vocht worden blootgesteld.
Pak uw COREbar™ 4 uit en zorg ervoor dat u alle onderdelen in goede staat Om te hebt ontvangen. Als de doos of inhoud beschadigd lijkt, stel dan de beginnen vervoerder onmiddellijk op de hoogte, niet Chauvet. De COREbar™ 4 is een volledig wash-verlichtingsoplossing voor mobiele Beschrijving entertainers. Produceer een volledig lichtspectrum zonder robuuste kleurmenging door middel van COB-technologie.
Page 42
COREbar™ 4 BH Dit product heeft een voeding met automatisch bereik die werkt met een AC-stroom ingangsspanning van 100–240 VAC, 50/60 Hz. Om onnodige slijtage te elimineren en zijn levensduur te verlengen, gedurende perioden wanneer het product niet wordt gebruikt, moet u het product van de stroom afsluiten door een aardlekschakelaar om te zetten of door het te ontkoppelen.
COREbar™ 4 BH Toets Functie Beschrijving <MENU> Sluit het huidige menu of functie af bedieningspaneel Navigeert omhoog via het menu of verhoogt de numerieke <UP> waarde wanneer in een functie Navigeert omlaag via het menu of verlaagt de numerieke <DOWN> waarde wanneer in een functie Activeert het huidige getoonde menu of plaatst de huidige <ENTER>...
COREbar™ 4 BH DMX-waarden 15CH Kanaal Functie Waarde Percentage/instelling 000 ó 009 Geen functie 010 ó 029 Automatisch programma 1 030 ó 049 Automatisch programma 2 050 ó 069 Automatisch programma 3 070 ó 089 Automatisch programma 4 090 ó 109 Automatisch programma 5 110 ó...
COREbar™ 4 QRG данном Краткое руководство (QRG) по COREbar™ 4 содержит базовую информацию об устройстве, включая вопросы монтажа, настроек меню и руководстве значений Загрузите Руководство пользователя на сайте DMX. www.chauvetlighting.com. Отказ от Информация и спецификации, приведенные в этом руководстве, могут ответственности...
Page 46
COREbar™ 4 QRG · Напряжение розетки, к которой подключается это устройство, должно находиться в диапазоне, указанном на наклейке на задней панели устройства. · Данное устройство предназначено только для использования в помещениях (IP 20)! Чтобы уменьшить риск возгорания и поражения электрическим током, не...
Начало Распакуйте устройство COREbar™ 4 и проверьте исправное состояние всех полученных деталей. Если коробка или ее содержимое имеют работы признаки повреждения, немедленно сообщите об этом не CHAUVET®, а перевозчику. Описание Устройство COREbar™ 4 – это комплексное решение по омывающему освещению для мобильных артистов. Оно создает полный спектр...
Page 48
COREbar™ 4 QRG Питание Это устройство имеет функцию автоматического выбора диапазона электропитания и может работать со входным напряжением в диапазоне переменного 100~240 В пер. т, 50/60 Гц. тока Во избежание ненужного износа и для продления срока службы неиспользуемое устройство следует полностью отключить от питания...
COREbar™ 4 QRG Кнопка Функция Описание Выход из текущего меню или функции <MENU> панели Перемещение вверх по списку меню и увеличение числового <UP> управления значения при работе Перемещение вниз по списку меню и уменьшение числового <DOWN> значения при работе Текущее отображаемое...
COREbar™ 4 QRG Значения DMX Канал Функция Значение Процент/уставка 15CH 000 ó 009 Нет действия 010 ó 029 Автопрограмма 1 030 ó 049 Автопрограмма 2 050 ó 069 Автопрограмма 3 070 ó 089 Автопрограмма 4 090 ó 109 Автопрограмма 5 110 ó...
Page 51
COREbar™ 4 QRG Значения DMX (прод.) Канал Функция Значение Процент/уставка 3-CH Красный 000 ó 255 0–100% Зеленый 000 ó 255 0–100% Синий 000 ó 255 0–100%...
Page 52
(954) 577-4455 Email: tech@chauvetlighting.com Fax: (954) 929-5560 World Wide Web Toll free:(800) 762-1084 www.chauvetlighting.com UNITED KINGDOM AND IRELAND - Chauvet Europe Ltd. General Information Technical Support Address:Unit 1C Email: uktech@chauvetlighting.com Brookhill Road Industrial Estate Pinxton, Nottingham, UK World Wide Web NG16 6NT www.chauvetlighting.co.uk...
