petMAP + II Operator's Manual page 41

Screen Image Capture in JPG Format (.jpg) to the SD Card
If there is an SD card in the SD card slot, the user can save the screen to a .jpg file by pressing the Save
Screen button at any time or by setting the automatic screen save option (described below). Also,
whenever the petMAP+II unit is switched OFF using the power button on the upper right of the unit
(press and release), just before actually shutting the unit OFF, the screen will display a message at both
the top and bottom of the screen: "Touch screen to save to SD card". When the user sees this message,
if the user then presses any place on the screen within 3 seconds, the press will signify that the user
would like an image of the screen at that time to be written to the SD card. After the press, the unit will
remain ON while copying the image to the SD card, a process that takes about 2-3 seconds. After
creating the screen image .jpg file on the SD card, the unit will automatically switch its power OFF and
the screen will go blank as the unit is now OFF. The file created on the SD card is in .jpg format which is
an image format that is easily read and displayed using a PC/MAC. If the user does not want to copy the
screen image to the SD card, by not touching the screen for 3 seconds, the unit will switch its power
OFF, and the screen image will be lost forever. Note that the option to save the screen image onto the
SD card is available to the user at any time by pressing the "Save Screen" button on the bottom left of
the unit.
Automatic Screen Save
If the petMAP+II has an SD card in the card slot, there will be a very small button on
the lower left of the screen, just above the "Save Screen" button (see figure 1). This
button controls the automatic screen save function and is OFF at power ON. By
pressing the button (since it is so small, a fingernail or the tip of a hemostat or pencil
can be useful if need be), the automatic save intervals are selected.
The button will change sequentially after each press as follows:
Off Default power On condition, no automatic screen saves.
qBP Saves the screen image automatically in JPG format after every BP determination.
q3M Saves the screen image automatically in JPG format every 3 minutes.
q2M Saves the screen image automatically in JPG format every 2 minutes.
