STAND-ALONE OPERATION
PRESET COLOR MODE
Press MENU button until C-- is displayed
Press ENTER
Press UP or DOWN to select C1 - C63
Press ENTER
AUTO PROGRAM MODE
Press MENU button until P-- is displayed
Press ENTER
Press UP or DOWN to select P1 - P4
Press ENTER
SELECTING PROGRAM SPEED
Press MENU button until S-- is displayed
Press ENTER
Press UP or DOWN to select speed
Press ENTER
SOUND-ACTIVE MODE
Press MENU button until Snd is displayed
Press ENTER
Press UP or DOWN to select Snd1 or Snd2
Press ENTER
ADJUSTING SOUND SENSIVITY
Press MENU button until Sens is displayed
Press ENTER
Press UP or DOWN to adjust mic sensitivity
Press ENTER
COLOR MIXING MODE
Press MENU button until U-- is displayed
Press ENTER to scroll to each color setting for amber, cool white, and warm white
Press UP or DOWN to adjust output (r---, g---, b---, A---, W---, P---)
SELECTING DIMMER CURVES
Press MENU button until dIM is displayed
Press ENTER
Press UP or DOWN to select dimmer curve (OFF, dIM1, dIM2, dIM3)
Press ENTER
ACTIVATING INFRARED REMOTE MODE
Press MENU button until SEr is displayed
Press ENTER
Press UP or DOWN to select On or OFF
Press ENTER

CONTROL MENU OVERVIEW

CONTROL PANEL

BUTTON
FUNCTION
Menu
Selects operating mode or exits submenus
Up
Scrolls up through option lists or selects higher value
Down
Scrolls down through option lists or selects lower value
Enter
Activates displayed menu option or selected value

FUNCTION MENU

MODE OPTIONS / VALUES
6-CH d001–512
11-CH d001–512
C-- C1–63
P1
P--
P2
(automatic)
P3
P4
S-- S--1–100
Snd Snd1
(sound-active)
Snd2
Sens u--0–100
R000–255 (Red)
G000–255 (Green)
B000–255 (Blue)
U--
A000–255 (Amber)
W000–255 (White)
P000–255 (UV)
OFF
dIM1
dIM
dIM2
dIM3
On
SEr
OFF
DESCRIPTION
6-channel DMX mode
11-channel DMX mode
Static color selection
Auto Program 1
Auto Program 2
Auto Program 3
Auto Program 4
Program speed for P1–P4
Sound-active Program 1
Sound-active Program 2
Sound sensitivity
Custom static colors
Mix red, green, blue, amber, white and UV
Dimmer speed settings
Turns infrared on or off
