- Page 1 Super160 Welding & Cutting Machine Operating Manual...
-
Page 2: Warranty
Introduction The Riland Multipurpose series of Welders is a revolutionary new approach to Welding technology. Riland introduced a more efficient way to manufacture top quality machines while keeping the cost of operation and repairs lower. This was accomplished using several new approaches to the mainstream technology. - Page 3 ·If you have any problems in setting up or operating, please first consult this manual. ·If you still can not understand after reading this manual, please contact your supplier or manufacturer to get professional help. Manual for inverter Super160 - 3 -...
- Page 4 The Super160 series is equipped with foot switch, thus liberating the workers’ hands, and they can adjust the current with their foot freely. As a result, at the very beginning or wire-adding, we can speed up the current;...
-
Page 5: Main Specifications
HF vibration start HF vibration start Efficiency (%) Rated duty cycle (%) Power factor 0.93 0.93 Insulation class Protection class IP21 IP21 Weight (kg) Size (mm) 493*330*320 493*330*320 Max welding thickness 10-14 10-12 (mm) Manual for inverter Super160 - 5 -... - Page 6 Panel board functions & instructions SUPER160 Panel TIG200AC/DC Panel Manual for inverter Super160 - 6 -...
- Page 7 ON position, do not turn it off. Let it cool for 5 minutes. Manual for inverter Super160 - 7 -...
-
Page 8: Installation
7. Adjust your knobs on the panel and switches to the correct settings based upon your work. You are ready to weld. Manual for inverter Super160 - 8 -... - Page 9 After each long duration of use you will need to push the water release button to release water from the water separator section of the regulator. It is designed to remove water from the air. Assembly of the Torch Consumables Cut40 Torch Head Manual for inverter Super160 - 9 -...
- Page 10 Thin = 0-1/8” Thin = 0-1/16” Medium = 1/8” – 3/8” Medium = 1/16” – 3/16” Thick = 3/8” – 1/2” Thick = 3/16” – 3/8” Severance cut = 3/4” Severance cut = 9/16” Manual for inverter Super160 - 10 -...
- Page 11 Your arc curve should not lag more than the thickness of the material being cut. Eg… if your work piece is ½” thick then you will not want your arc curve to lag more than ½” behind your torch. See below picture for details. Manual for inverter Super160 - 11 -...
-
Page 12: Error Codes
2. No sound of electromagnetic b. ask professional to repair the valve board a. valve damaged b. valve-controlled circuit in trouble Adjust the clear width in Manual for inverter Super160 - 12 -... - Page 13 Make sure you are using dry air, moisture in the air will cause malfunctions. Make sure your cables are correct for the function you have chosen. Tig mode requires tig torch, etc… Observe proper torch consumable assembly. Improper assembly of consumables will damage the machine. Manual for inverter Super160 - 13 -...
