5. Electrical Parts

5.1 Wiring Diagram

● Description
Symbol
WH White
YE Yellow
RD Red
YEGN Yellow/Green
VT Violet
Note: Jumper cap is used to determine fan speed and the swing angle of horizontal louver for this model.
● Indoor Unit
DHP09NWB21S
11
Symbol Color Symbol
GN
BN
BU
BK
OG
DCP09NWB21S DHP12NWB21S
Symbol Color
Green
Brown
Blue
Black
Orange
DCP12NWB21S
`
Symbol Name
CAP Jumper cap
COMP Compressor
Grounding wire
/ /
/ /
ZONE
