16in / 40cm Eco Pedestal Fan
with 30W DC motor, Illuminated IMC
display & Remote Control
Instruction manual
5 fan blades
Illuminated IMC Touch display
Remote Control w. 3V battery (CR2032)
24 Speeds
Horizontal Oscillation
0.5 to 15hr Timer (Off)
0.5 to 15hr Pre-set Timer (On)
3 Modes w. 5 speeds
Height Adjustable Stand
Carry Handle
Please keep safe for future reference
Model: SFDC-4057RC
Parts Description
1.
Front Grille
2.
Blade Cap
3.
Fan Blade
4.
Clip Screw
5.
Locking Clip
6.
Guard Ring
7.
Clamping Nut
8.
Rear Grille
9.
Front Motor Cover
10. Motor Shaft
11. Neck
12. Carry Handle
13. Rear Motor Cover
16. Control Panel
14. Pillar
15. Adjustable Inner Pipe
16. Control Panel
17. Pedestal Front Panel
18. Butterfly Screw for
height adjustment
19. Pedestal Rear Panel
20. Base Plate
21. Remote Control
21. Remote Control
21
2
Advertisement
Table of Contents
Related Manuals for NSA SFDC-4057RC
Summary of Contents for NSA SFDC-4057RC
-
Page 1: Parts Description
16in / 40cm Eco Pedestal Fan Parts Description with 30W DC motor, Illuminated IMC display & Remote Control Model: SFDC-4057RC Front Grille Blade Cap Fan Blade Clip Screw Locking Clip Guard Ring Clamping Nut Rear Grille Front Motor Cover 10. Motor Shaft 11. -
Page 2: Safety Instructions
Thank you for purchasing this Electronic DC Pedestal Fan with illuminated IMD (injection • Please assemble correctly according to the following sequence. Refer to parts description on page 2. moulded display) Touch Display & Remote Control SFDC-4057RC. This elegant, height • Please keep the original packaging for future storage. -
Page 3: Operating Instructions
Operating Instructions (continued) Operating Instructions MODE: This is the air selection button. Press the button once to operate the natural breeze mode. Press again to operate the sleep mode; Press for a third time to operate auto/AI Tilt adjustment: Height adjustment: (artificial intelligence) mode. -
Page 4: Troubleshooting
Troubleshooting Technical Data If any problems occur during use, please check the following: Problem / Solutions Model No: SFDC-4057RC (DC fan) Voltage: 220-240V ~ 50Hz The fan blade does not run when the power is on: Power: Check if the power lead is correctly plugged into the mains socket and the power is on.
