Johnson Controls DHW18CMB21S Service Manual page 41

"w" series 18k - 24k inverter-driven air conditioning units
Hide thumbs
Table of Contents

Advertisement

Steps
5.Remove right side plate
support and grille guard, to remove the right side
plate.
6.Remove guard grille
plate to remove grille guard.
7.Remove left side plate
support, to remove the left side plate.
33
Procedure
gaurd
left side plate
Service Manual
right side plate
grille guard
