Slendertone Bottom Instruction Manual page 5

additional unit functions
Information Button ( i )
Press the information button (Fig. a) any time during a session to
see the highest intensity level you have reached for that session.
Pressing the information button twice shows you the total number
of sessions you have completed. While pressing the information
button three times shows the garment type you are using.
Mute Function ( Mute Function ( ) )
If you want to switch off your unit's sound effects, press and hold
the programme button for two seconds (Fig. b). The mute function
remains active indefinitely unless manually changed. Deactivate
the mute function by again pressing the programme button for
two seconds
Keylock Function ( Keylock Function ( ) )
If you find a comfortable exercise intensity, press and hold the
information button for two seconds to lock that intensity (Fig. c).
This function only remains active during the session in which it is
activated. If you wish to increase the intensity further, deactivate
the keylock function by again pressing the information button for
two seconds.
Error Messages
In the unlikely event of your unit developing a problem, "Err" will
appear on your unit display (Fig. d). If this occurs you should
switch the unit off and then switch it back on again. It should
now operate properly. If the problem persists, please call your
local careline for further assistance (see page 2).
Battery Power / Replacing the Battery
The battery icon on the display will flash when the battery is low
and needs to be recharged. After a period of time, you may find
that your battery will only power your unit for a limited number
of sessions, requiring you to charge the battery more frequently.
This is because rechargeable batteries have a limited number of
charge cycles and may eventually need to be replaced.
Should you need to replace the rechargeable battery, remove the
small rubber plug from the back cover of your unit (Fig. e), unscrew
the back cover and remove it. Replace the existing battery pack
with a new battery pack (Fig. f ) and replace the battery cover. You
can purchase a new battery pack by contacting the
Careline.
8
Fig. a
Fig. b
Fig. c
Fig. d
Fig. e
Fig. f
SLENDERTONE
quick guide to solving problems
Problem Possible Cause
The display doesn't come The battery is low
on and there is no signal
from the unit
The display is on but there The battery is low
is no signal
The battery symbol is The battery is low
flashing
The The symbol has symbol has Unit is not properly
appeared on the display* connected to garment
The covers are still on
the pads
The pads are worn
The pads are not
covering the studs
Unpleasant feeling Poor pad contact with
beneath the pads the skin
The pads are worn
Pads are not covering
the metal studs
Too many consecutive
sessions
The contractions are very The pads are worn
weak even when the toning
intensity is high
The battery is low
Poor pad positioning
Pads are not covering
the studs
"Err" appears on the
Error message
display
* The * The symbol always appears in conjunction with the left/ right intensity indicators. If symbol always appears in conjunction with the left/ right intensity indicators. If
the left indicator appears, there is a problem with one or both of the left-hand pads, the
right indicator acknowledges a problem with one or both of the right-hand pads and if
both indicators appear there is a problem with pads on both sides of the garment.
Solution
Recharge the battery
Recharge the battery
Recharge the battery
Ensure unit and garment are
properly connected
Remove the covers from the pads
Visit the website or your local
retailer for new pads
Make sure the pads fully cover
the metal studs
Press the pads firmly against the
skin. Smear a few drops of water
on the surface of the pads. Make
sure the unit is OFF first
Visit the website or your local
retailer for new pads
Make sure the pads fully cover
the metal studs
You should just do one session
per day on any single body area
Visit the website or your local
retailer for new pads
Recharge the battery
See page 5 for correct pad
positioning
Make sure the pads fully cover
the metal studs
Switch the unit on and off. The
unit should work without any
problem. If the error message
persists call the careline for
further details
9
