REPAIR PARTS
MANUAL
Manufactured 02-01 and after
Part Number 0181971
April 2016
Models AB60J/AB60JRT
Replaces 0181971 March 2014

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the AB60J and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Snorkel AB60J

Summary of Contents for Snorkel AB60J

  • Page 1 REPAIR PARTS MANUAL Manufactured 02-01 and after Part Number 0181971 April 2016 Models AB60J/AB60JRT Replaces 0181971 March 2014...

  • Page 2: Table Of Contents

    Contents GENERAL INFORMATION GENERAL INFORMATION, AB60J REPAIR PARTS CHASSIS AND TURNTABLE MOUNTING DRIVE – REAR STEERING 2WD STEERING – 4 WHEEL DRIVE LIFT AND SWING SWING DRIVE AFTER MARCH 2006 SWING DRIVE, BEFORE MARCH 2006 FUEL TANK HYDRAULIC OIL RESERVOIR MOUNTING...
  • Page 3 2-47 PUMP SUB-ASSEMBLY KUBOTA 2-48 COWLING 2-49 COWLING INSTALLATION 2-50 AIR CLEANER 2-51 AIR CLEANER 2-52 LEGACY SNORKEL GUARD WIRING 2-53 SNORKEL GUARD ASSEMBLY 2-54 BRAKE UNIT 2-55 TIRES AND WHEELS 2-56 PLACARDS AND DECALS 2-57 PLACARDS AND DECALS 2-58...
  • Page 4 CONTROL VALVE – WECO (REXROTH) 3-15 CONTROL VALVE AND FITTINGS – VICKERS AFTER FEBRUARY 1998 3-16 CONTROL VALVE VICKERS 3-17 NON-PROP VALVE ASSY FLUID TECH AFTER SEPTEMBER 2007 3-18 NON-PROPORTIONAL VALVE ASSEMBLY, FLUID TECH 3-19 NON-PROP VALVE ASSEMBLY CE 3-20 CONTROL VALVE AND FITTINGS, DRIVE/LIFT/SWING 3-21 NON-PROP VALVE...
  • Page 5 PUMP SUB ASSEMBLY 3-60 MOTION CONTROL VALVE, 1 0F 2 3-61 EMERGENCY POWER UNIT 3-62 EMERGENCY POWER UNIT ASSEMBLY 3-63 MOTION CONTROL VALVE -- DRIVE 3-64 MOTION CONTROL VALVE, TURNTABLE SWING 3-65 MOTION CONTROL VALVE 3-66 TRANSMISSION VALVE PACKAGE 3-67 HYDRAULIC OIL FILTER 3-68 HYDRAULIC OIL RESERVOIR ASSEMBLY...
  • Page 6 AC GENERATOR HYDRAULIC POWERED BEFORE MARCH 2012 OPTION BUMP GUARD 36X96 W/PADDING-SNORKELGUARD AIRLINE TO PLATFORM 5-10 OPTION, 39 X 96 STL PLAT 500# TRI ENTRY SNORKEL GUARD CE 5-11 COLD START WITH BATTERY – CUMMINS 5-12 DUAL FUEL – FORD-425 5-13 LP FUEL –...
  • Page 7 5-35 GLAZIER PACKAGE INSTALLATION 5-36 GRAVITY GATE SIDE ENTRY 5-37 SWING GATE SIDE MIDRAIL 5-38 220V AC GENERATOR INSTALLATION 5-39 ALL MOTION ALARM 5-40 MAINTENANCE MAINTENANCE, AB60J SCHEMATICS HYDRAULIC SCHEMATICS, AB60J ELECTRICAL SCHEMATICS, AB60J Appendix A:Pages Index Appendix B:Parts Index...
  • Page 8 Wash hands after handling. California Proposition 65 Warning Diesel and gasoline engine exhaust and some of its constituents are known by the State of California to cause cancer, birth defects or other reproductive harm. © Snorkel International, Inc. – all rights reserved...

  • Page 9: General Information

    While Snorkel has attempted in every way to confirm that Underwriters Laboratories Inc. all information in this manual is correct, improvements are being constantly made to the machine that may not Additional Information be reflected in this manual.
  • Page 10 Main Boom Lower Engine Turret Tip Boom Controls Battery Platform Serial Number Placard Lanyard Left Rear of Turntable Anchors Serial Number • Model Number Boom Riser Boom Operator’s Manual Steer Wheels Platform Front Rear Foot Switch Left Side AB60J – 0181971...
  • Page 11 Service and Parts Information Ordering Parts Manuals When placing an order for service or repair parts, please Manuals are available from Snorkel to support any of have the following machine information readily available. the machines that we produce. Model number...
  • Page 12 Parts Order Form Fill out completely and fax attention Parts Department to: Snorkel USA 1-785-989-3077 Snorkel Europe +44 (0) 1952 607 678 Date: Account Number: Company: Purchase Order Number: Address: Model Number: Serial Number: Ship To: Contact Name: Phone Number:...

  • Page 13: Repair Parts

    AB60J PARTS MANUAL CHASSIS AND TURNTABLE MOUNTING REPAIR PARTS CHASSIS AND TURNTABLE MOUNTING Thu May 11 20:26:34 UTC 2017...
  • Page 14 AB60J PARTS MANUAL CHASSIS AND TURNTABLE MOUNTING Item Part No. Name 0180925 CHASSIS AND TURNTABLE MOUNTING SEE NOTE 3 TURNTABLE SEE NOTE 3 TURNTABLE 5033604 FTG ADPTR MALE-4N-4S STL- 2404- 5560169 WASHER HARD FLAT .625 SP 5033704 FTG ELB90 MALE-4N-4S STL...
  • Page 15 AB60J PARTS MANUAL DRIVE – REAR REPAIR PARTS DRIVE – REAR Thu May 11 20:26:35 UTC 2017...

  • Page 16: Drive - Rear

    AB60J PARTS MANUAL DRIVE – REAR Item Part No. Name 0180853 DRIVE – REAR 0180961 POWER WHEEL (CONSIGN) 6030035 HYDRAULIC DRIVE MOTOR, REAR RIGHT HAND 7200024 BRAKE UNIT 0153065 LINING REPAIR KIT Shown 0153066 O-RING REPAIR KIT Shown 0153067 BEARING REPAIR KIT...

  • Page 17: Steering 2Wd

    AB60J PARTS MANUAL STEERING 2WD REPAIR PARTS STEERING 2WD Thu May 11 20:26:35 UTC 2017...
  • Page 18 AB60J PARTS MANUAL STEERING 2WD Item Part No. Name 0180857 STEERING 2WD 0180963 STEERING YOKE, RIGHT HAND 0180962 STEERING YOKE, LEFT HAND 0074732 CYL 3.00 7.00 1.50 STEER 0180699 TIE ROD 0180961 POWER WHEEL (CONSIGN) 0180704 0110320 WELDMENT PIN STEERING...
  • Page 19 AB60J PARTS MANUAL STEERING 2WD Item Part No. Name 2501616 BEARING 5560713 MACH BHNG 1.0ID 2.0OD 14GA 5560660 MACHINE BUSHING 3 INCH OD X 2 INCH ID X 14 GAUGE THICK 5560090 SHIM, .006 INCH THICK 5035303 ADAPTER 90 DEG ELBOW -4...

  • Page 20: Steering - 4 Wheel Drive

    AB60J PARTS MANUAL STEERING – 4 WHEEL DRIVE REPAIR PARTS STEERING – 4 WHEEL DRIVE Thu May 11 20:26:36 UTC 2017...
  • Page 21 AB60J PARTS MANUAL STEERING – 4 WHEEL DRIVE Item Part No. Name 0180854 STEERING – 4 WHEEL DRIVE 0180963 STEERING YOKE, RIGHT HAND 0180962 STEERING YOKE, LEFT HAND 0074732 CYL 3.00 7.00 1.50 STEER 0180699 TIE ROD 0180961 POWER WHEEL (CONSIGN)
  • Page 22 AB60J PARTS MANUAL STEERING – 4 WHEEL DRIVE Item Part No. Name 5569974 MCHRY BSHG 2" ID 3" OD 14 GA 5560090 SHIM, .006 INCH THICK 5035303 ADAPTER 90 DEG ELBOW -4 SAE TO -4 JIC 970449 BLT HEXHD .375-16 .750 GR5 987119 WSHR LOCK .375 SPLIT TYPE...

  • Page 23: Lift And Swing

    AB60J PARTS MANUAL LIFT AND SWING REPAIR PARTS LIFT AND SWING Thu May 11 20:26:36 UTC 2017...
  • Page 24 AB60J PARTS MANUAL LIFT AND SWING Item Part No. Name 0180930 LIFT SWING COUNTERWEIGHT 0180935 CENTERPOST AND FITTINGS 0073026 SWING DRIVE S/A 0180936 RISER BOOM LIFT CYLINDER 0181226 LOWER COUNTERWEIGHT – BEFORE DECEMBER 2010 0180495 COUNTERWEIGHT, UPPER LEFT HAND – BEFORE DECEMBER...
  • Page 25 AB60J PARTS MANUAL LIFT AND SWING Item Part No. Name 984449 JAM NUT 5/8-11 HEX 0111084 BRACKET FITTING HYDROMOTION 5020001 FTG ELBOW HYDROMOTION SWIVEL 5037005 ADAPTER 90 DEG ELBOW SWIVEL -6 JIC 5065805 FTG ADAPTER STRTHDL-6B-6S 5064001 ADAPTER STRAIGHT TUBE...

  • Page 26: Swing Drive After March 2006

    AB60J PARTS MANUAL SWING DRIVE AFTER MARCH 2006 REPAIR PARTS SWING DRIVE AFTER MARCH 2006 Thu May 11 20:26:36 UTC 2017...
  • Page 27 AB60J PARTS MANUAL SWING DRIVE AFTER MARCH 2006 Item Part No. Name 0073026 SWING DRIVE S/A 0070047 SWING DRIVE – PERFECTION 6030020 MOTOR, SWING DRIVE 6019048 MOTION CONTROL VALVE FLUIDTECH PNNA BOLT HEX .313-18 X 3.50 LG GR PNNA WASHER .313 FLAT PNNA WASHER .313 LOCK...

  • Page 28: Swing Drive, Before March 2006

    AB60J PARTS MANUAL SWING DRIVE, BEFORE MARCH 2006 REPAIR PARTS SWING DRIVE, BEFORE MARCH 2006 Thu May 11 20:26:37 UTC 2017...
  • Page 29 AB60J PARTS MANUAL SWING DRIVE, BEFORE MARCH 2006 Item Part No. Name 0073026 SWING DRIVE S/A 0070047 SWING DRIVE – PERFECTION 6030020 MOTOR, SWING DRIVE 8200004 SEAL REPAIR KIT - ROSS/TRW Shown MOTOR 0090352 SEAL REPAIR KIT - CHAR- Shown...

  • Page 30: Fuel Tank

    AB60J PARTS MANUAL FUEL TANK REPAIR PARTS FUEL TANK Thu May 11 20:26:38 UTC 2017...
  • Page 31 AB60J PARTS MANUAL FUEL TANK Item Part No. Name 0180518 FUEL TANK INSTL 0180440 FUEL TANK, 40 GALLON CAPACITY – BEFORE SEPTEMBER 2010 (START #5299) 0182178 FUEL TANK 40 GALLON Shown CAPACITY–AFTER SEPTEMBER 2010 (IFH #211124) 0180520 FUEL GAUGE 0180519...
  • Page 32 AB60J PARTS MANUAL HYDRAULIC OIL RESERVOIR MOUNTING REPAIR PARTS HYDRAULIC OIL RESERVOIR MOUNTING Thu May 11 20:26:38 UTC 2017...

  • Page 33: Hydraulic Oil Reservoir Mounting

    AB60J PARTS MANUAL HYDRAULIC OIL RESERVOIR MOUNTING Item Part No. Name 0180975 HYDRAULIC OIL RESERVOIR MOUNTING 0180517 HYDR OIL RSVR ASSY 970419 BLT HEXHD .375-16 X 1.25 GR5 986299 WSHR FLAT .375 GR5 ZP 5560033 NUT HEX LKG .375-16 HYDRAULIC OIL RESERVOIR MOUNTING...

  • Page 34: Riser Boom And Turret

    AB60J PARTS MANUAL RISER BOOM AND TURRET REPAIR PARTS RISER BOOM AND TURRET Thu May 11 20:26:39 UTC 2017 2-10...
  • Page 35 AB60J PARTS MANUAL RISER BOOM AND TURRET Item Part No. Name 0180912 RISER BOOM AND TURRET 0180677 RISER BOOM 0180549 TURRET 0180685 RISER BOOM LIFT CYLINDER – SEABEE 0180913 MAIN BOOM LIFT CYLINDER 0180914 MASTER LEVEL CYLINDER 0180911 CLAMP 0180880...
  • Page 36 AB60J PARTS MANUAL RISER BOOM AND TURRET RISER BOOM AND TURRET Thu May 11 20:26:39 UTC 2017 2-10...
  • Page 37 AB60J PARTS MANUAL RISER BOOM AND TURRET Item Part No. Name 0110681 CAPSCREW 5/8-11 DRILLED HEAD 987159 WASHER LOCK .625 5569897 CAPSCREW 5/16-18 X 2-1/4 INCH LONG HEX HEAD GRADE 5 987109 WSHR LOCK .313 SPLIT TYPE 0070473 BLT HEXHD .313-18 .75 DR 5560138 BLT HEXHD LKG .500-13 1.00...
  • Page 38 AB60J PARTS MANUAL BOOMS MOUNTING REPAIR PARTS BOOMS MOUNTING Thu May 11 20:26:39 UTC 2017 2-11...

  • Page 39: Booms Mounting

    AB60J PARTS MANUAL BOOMS MOUNTING Item Part No. Name 0181219 BOOMS MOUNTING 0181490 BOOM AND JIB BOOM 0180618 0181450 0070132 PIN LOCK 2.25 DIA 2H 0080023 PIN LOCK, 2.75 DIA 2H 5560009 NUT 1/2-13 SELF LOCKING 0070473 BLT HEXHD .313-18 .75 DR...
  • Page 40 AB60J PARTS MANUAL BOOM & JIB SUB-ASSEMBLY W/OVERLOAD REPAIR PARTS BOOM & JIB SUB-ASSEMBLY W/OVERLOAD Thu May 11 20:26:40 UTC 2017 2-12...

  • Page 41: Boom & Jib Sub-Assembly W/Overload

    AB60J PARTS MANUAL BOOM & JIB SUB-ASSEMBLY W/OVERLOAD Item Part No. Name 0182478 A BOOM & JIB SUB ASSY W/OVERLOAD 0181220 ALUM BOOM & HOSE CARRIER ASSY 0182468 ALUMINUM JIB BOOM ASSEMBLY CE 0150685 WLDMT PIN 1.25 10.50 GRIP 0180612...
  • Page 42 AB60J PARTS MANUAL BOOM W/OVERLOAD SUB-ASSEMBLY ANSI KIT REPAIR PARTS Image does not exist BOOM W/OVERLOAD SUB-ASSEMBLY ANSI KIT Thu May 11 20:26:40 UTC 2017 2-13...

  • Page 43: Boom W/Overload Sub-Assembly Ansi Kit

    AB60J PARTS MANUAL BOOM W/OVERLOAD SUB-ASSEMBLY ANSI KIT Item Part No. Name K-0182478 A BOOM ANSI W/OVERLOAD S/A- KIT 6 0182478 BOOM & JIB SUB-ASSY W/OVERLOAD BOOM W/OVERLOAD SUB-ASSEMBLY ANSI KIT Thu May 11 20:26:40 UTC 2017 2-13...

  • Page 44: Boom Sub-Assembly-Kit 6 Ce

    AB60J PARTS MANUAL BOOM SUB-ASSEMBLY-KIT 6 CE REPAIR PARTS Image does not exist BOOM SUB-ASSEMBLY-KIT 6 CE Thu May 11 20:26:40 UTC 2017 2-14...
  • Page 45 AB60J PARTS MANUAL BOOM SUB-ASSEMBLY-KIT 6 CE Item Part No. Name K0182460 A BOOM CE S/A-KIT 6 0182460 BOM & JIB CE SUB-ASSY AL BOOM SUB-ASSEMBLY-KIT 6 CE Thu May 11 20:26:40 UTC 2017 2-14...

  • Page 46: Boom And Jib Boom

    AB60J PARTS MANUAL BOOM AND JIB BOOM REPAIR PARTS BOOM AND JIB BOOM Thu May 11 20:26:40 UTC 2017 2-15...
  • Page 47 AB60J PARTS MANUAL BOOM AND JIB BOOM Item Part No. Name 0181490 BOOM AND JIB BOOM 0181220 ALUM BOOM & HOSE CARRIER ASSY 0181221 JIB BOOM 0180614 0180608 0180612 WLDMT PIN 0070132 PIN LOCK 2.25 DIA 2H 0070033 PIN LOCK 2.00 DIA 2H 0070473 BLT HEXHD .313-18 .75 DR...
  • Page 48 AB60J PARTS MANUAL ALUMINUM BOOM & JIB SUB-ASSEMBLY CE REPAIR PARTS ALUMINUM BOOM & JIB SUB-ASSEMBLY CE Thu May 11 20:26:40 UTC 2017 2-16...

  • Page 49: Aluminum Boom & Jib Sub-Assembly Ce

    AB60J PARTS MANUAL ALUMINUM BOOM & JIB SUB-ASSEMBLY CE Item Part No. Name 0182460 A ALUMINUM BOOM & JIB SUB- ASSY CE 0070033 PIN LOCK 2.00 DIA 2H 0070132 PIN LOCK 2.25 DIA 2H 0070473 BLT HEXHD .313-18 .75 DR 0150685 WLDMT PIN 1.25 10.50 GRIP...

  • Page 50: Boom And Hose Carrier

    AB60J PARTS MANUAL BOOM AND HOSE CARRIER REPAIR PARTS BOOM AND HOSE CARRIER Thu May 11 20:26:41 UTC 2017 2-17...

  • Page 51: Boom And Hose Carrier

    AB60J PARTS MANUAL BOOM AND HOSE CARRIER Item Part No. Name 0181220 ALUM BOOM & HOSE CARRIER ASSY 0180642 BASE BOOM 0181138 SLIDE PAD UHMW SLIDE PAD 0180900 EXTENSION CYLINDER SUB ASSY 0180901 JIB LIFT CYLINDER SUB ASSY 0180874 ANGLE SWITCH ACTUATOR...
  • Page 52 AB60J PARTS MANUAL BOOM AND HOSE CARRIER BOOM AND HOSE CARRIER Thu May 11 20:26:41 UTC 2017 2-17...
  • Page 53 AB60J PARTS MANUAL BOOM AND HOSE CARRIER Item Part No. Name 0073340 SPCR .250 1.25 6.00 5H STL 987119 WSHR LOCK .375 SPLIT TYPE 5560680 BLT FLSKTHD .375-16 1.75 0070486 SPACER SLIDE PAD 970449 BLT HEXHD .375-16 .750 GR5 0182326...
  • Page 54 AB60J PARTS MANUAL BOOM AND HOSE CARRIER Item Part No. Name 970049 BLT HEXHD .250-20 1.00 GR5 5560004 .250-20UNC HEX LOCK NUT 986019 WASHER, FLAT, .25 STANDARD, PLATED 5560253 SBHCS .375-16 UNC X 1.25, STL, GR 8, PLTD 970029 BLT HEX .250-20 .75 GR5-Z/P 970489 HHCS .375-16 UNC, STL, GR 5,...
  • Page 55 AB60J PARTS MANUAL BOOM AND HOSE CARRIER REPAIR PARTS BOOM AND HOSE CARRIER Thu May 11 20:26:42 UTC 2017 2-18...
  • Page 56 AB60J PARTS MANUAL BOOM AND HOSE CARRIER Item Part No. Name 0181220 ALUM BOOM & HOSE CARRIER ASSY 0180642 BASE BOOM 0181138 SLIDE PAD UHMW SLIDE PAD 0180900 EXTENSION CYLINDER SUB ASSY 0180901 JIB LIFT CYLINDER SUB ASSY 0180874 ANGLE SWITCH ACTUATOR...
  • Page 57 AB60J PARTS MANUAL BOOM AND HOSE CARRIER BOOM AND HOSE CARRIER Thu May 11 20:26:42 UTC 2017 2-18...
  • Page 58 AB60J PARTS MANUAL BOOM AND HOSE CARRIER Item Part No. Name 9980012 .040 SS SAFETY WIRE 0180612 WLDMT PIN 0080294 SL PAD 1.25 6.00 .380 3H 0073340 SPCR .250 1.25 6.00 5H STL 5560679 FLSKTHD .375 X .625 ZINC PLTD 970429 BLT HEXHD .375-16 .500 GR5...
  • Page 59 AB60J PARTS MANUAL BOOM AND HOSE CARRIER Item Part No. Name 0180940 CONDUIT 3/4 X 38" LG 0180947 TUBE ASSEMBLY 5036905 ADAPTER 45 DEG ELBOW SWIVEL -6 JIC 0020267 HOSE-6-6S-6S 31.75 100R2 0180939 CONDUIT .75 X 72.00 LG 0110547 CONDUIT 1/2- X 10 FEET LONG...
  • Page 60 AB60J PARTS MANUAL BOOM AND HOSE CARRIER Item Part No. Name 5560015 THREAD INSERT.375-16 .562 BOOM AND HOSE CARRIER Thu May 11 20:26:42 UTC 2017 2-18...
  • Page 61 AB60J PARTS MANUAL ALUMINUM BOOM AND HOSE CARRIER ASSEMBLY CE REPAIR PARTS ALUMINUM BOOM AND HOSE CARRIER ASSEMBLY CE Thu May 11 20:26:43 UTC 2017 2-19...

  • Page 62: Aluminum Boom And Hose Carrier Assembly Ce

    AB60J PARTS MANUAL ALUMINUM BOOM AND HOSE CARRIER ASSEMBLY CE Item Part No. Name 0182466 A ALUMINUM BOOM AND HOSE CARRIER ASSEMBLY CE 0020267 HOSE-6-6S-6S 31.75 100R2 0070030 SHIM .030 2.00 5.88 5H AL 0070033 PIN LOCK 2.00 DIA 2H 0070043 SHIM .030 1.25 5.88 5H AL...
  • Page 63 AB60J PARTS MANUAL ALUMINUM BOOM AND HOSE CARRIER ASSEMBLY CE ALUMINUM BOOM AND HOSE CARRIER ASSEMBLY CE Thu May 11 20:26:43 UTC 2017 2-19...
  • Page 64 AB60J PARTS MANUAL ALUMINUM BOOM AND HOSE CARRIER ASSEMBLY CE Item Part No. Name 0181023 COVER WELDMENT 0181138 SLIDE PAD UHMW SLIDE PAD 0181177 CLP CUSH .438 RUBBER COATED 7/16 0181138 SLIDE PAD UHMW SLIDE PAD 0181177 CLP CUSH .438 RUBBER...
  • Page 65 AB60J PARTS MANUAL ALUMINUM BOOM AND HOSE CARRIER ASSEMBLY CE Item Part No. Name 5034502 ADAPTER 90 DEG ELBOW BULKHEAD -6 JIC TO -6 JIC 5036905 ADAPTER 45 DEG ELBOW SWIVEL -6 JIC 5063905 ADAPTER, NUT, -6 JIC FEMALE 5064001...
  • Page 66 AB60J PARTS MANUAL EXTENSION CYLINDER REPAIR PARTS EXTENSION CYLINDER Thu May 11 20:26:43 UTC 2017 2-20...

  • Page 67: Extension Cylinder

    AB60J PARTS MANUAL EXTENSION CYLINDER Item Part No. Name 0180900 EXTENSION CYLINDER SUB ASSY 0060089 SL PAD 1.00 2.00 .25 0070141 SL PAD 1.25 3.00 .330 2H 0181912 EXTENSION CYLINDER – ROSENBOOM 972449 BLT FLSKTHD .375-16 .750 5037006 ADAPTER 90 DEG ELBOW...

  • Page 68: Jib Boom

    AB60J PARTS MANUAL JIB BOOM REPAIR PARTS JIB BOOM Thu May 11 20:26:44 UTC 2017 2-21...
  • Page 69 AB60J PARTS MANUAL JIB BOOM Item Part No. Name 0181221 J JIB BOOM 0180873 PLATFORM ROTATOR 0180596 BELLCRANK WELDMENT 0181126 ALUM JIB BOOM 0191324 HOSE CARRIER - JIB 0180640 LEVELING LINK 0180906 SLAVE LEVELING CYL. SUB ASSY 0180521 PIN 1.50 X 1.062 GRIP 0070033 PIN LOCK 2.00 DIA 2H...
  • Page 70 AB60J PARTS MANUAL JIB BOOM Item Part No. Name 987119 WSHR LOCK .375 SPLIT TYPE 987099 WSHR LOCK .250 SPLIT TYPE 5093027 CLAMP 1.188 AEROQUIP HOSE SUPPORT 970029 BLT HEX .250-20 .75 GR5-Z/P 9866019 FLATWASHER 1/4 JIB BOOM Thu May 11 20:26:44 UTC 2017...

  • Page 71: Aluminum Jib Boom Assembly Ce

    AB60J PARTS MANUAL ALUMINUM JIB BOOM ASSEMBLY CE REPAIR PARTS ALUMINUM JIB BOOM ASSEMBLY CE Thu May 11 20:26:44 UTC 2017 2-22...
  • Page 72 AB60J PARTS MANUAL ALUMINUM JIB BOOM ASSEMBLY CE Item Part No. Name 0182468 A ALUMINUM JIB BOOM ASSEMBLY CE 0070033 PIN LOCK 2.00 DIA 2H 0070473 BLT HEXHD .313-18 .75 DR 0180521 PIN 1.50 X 1.062 GRIP 0180596 BELLCRANK WELDMENT...
  • Page 73 AB60J PARTS MANUAL ALUMINUM JIB BOOM ASSEMBLY CE Item Part No. Name 5560213 BLT HEXHD .313-18 1.668 DR 5563309 MACH BUSHING 3.25 OD X 1.75 ID X 14GA PNNA .040 S.S. SAFETY WIRE ALUMINUM JIB BOOM ASSEMBLY CE Thu May 11 20:26:44 UTC 2017...

  • Page 74: Jib Boom Lift Cylinder

    AB60J PARTS MANUAL JIB BOOM LIFT CYLINDER REPAIR PARTS JIB BOOM LIFT CYLINDER Thu May 11 20:26:45 UTC 2017 2-23...

  • Page 75: Jib Boom Lift Cylinder

    AB60J PARTS MANUAL JIB BOOM LIFT CYLINDER Item Part No. Name 0180901 JIB LIFT CYLINDER SUB ASSY 0191811 JIB BOOM LIFT CYLINDER – ROSENBOOM 5035305 ADAPTER 90 DEG ELBOW -6 SAE TO -6 JIC JIB BOOM LIFT CYLINDER Thu May 11 20:26:45 UTC 2017...

  • Page 76: Hose Carrier

    AB60J PARTS MANUAL HOSE CARRIER REPAIR PARTS HOSE CARRIER Thu May 11 20:26:45 UTC 2017 2-24...
  • Page 77 AB60J PARTS MANUAL HOSE CARRIER Item Part No. Name 0180763 HOSE CARRIER 0180718 WLDMT COVER 0180717 SLIDING TUBE 9920014 POWER TRACK LINK 9920015 END BRKT HOSE CARRIER 0060089 SL PAD 1.00 2.00 .25 0170045 SL PAD 1.50 5.00 1.50 1H 0070029 SL PAD 2.00 4.00 .330 3H...
  • Page 78 AB60J PARTS MANUAL HOSE CARRIER Item Part No. Name 3044854 TERM R10I 12/10 Shown 0181487 SL PAD 1.31 5.00 1.50 1H SP 3010005 CABLE 18GA/19 CONDUCTOR 3046972 TERM FEM188I 22/18 Shown 0180765 HOSE-5-6S-6S 337 0180766 HOSE-3-4S-4S 430 0180848 SL PAD 1.50OD .688ID 4.88 0170044 SPCR .530ID .625OD 5.00 STL...

  • Page 79: Hose Carrier Assembly Ce

    AB60J PARTS MANUAL HOSE CARRIER ASSEMBLY CE REPAIR PARTS HOSE CARRIER ASSEMBLY CE Thu May 11 20:26:46 UTC 2017 2-25...
  • Page 80 AB60J PARTS MANUAL HOSE CARRIER ASSEMBLY CE Item Part No. Name 0182467 A HOSE CARRIER ASSEMBLY CE 0060089 SL PAD 1.00 2.00 .25 0070029 SL PAD 2.00 4.00 .330 3H 0070838 SHIM .030 2.00 4.00 3H AL 0071272 SHIM .063 2.00 4.00 3H AL 0071342 SHIM .063 1.00 2.00 2H AL...
  • Page 81 AB60J PARTS MANUAL HOSE CARRIER ASSEMBLY CE Item Part No. Name 5090034 SLEEVE HOSE ABRASION GUARD 5560004 .250-20UNC HEX LOCK NUT 5560033 NUT HEX LKG .375-16 5560039 NUT HEX LKG .500-13 5560329 BLT FLSKTHD .250-20 .50 5560330 BLT FLSKTHD .250-20 .75 5560331 BLT FLSKTHD .250-20 1.00...
  • Page 82 AB60J PARTS MANUAL PLATFORM MOUNTING REPAIR PARTS PLATFORM MOUNTING Thu May 11 20:26:46 UTC 2017 2-26...

  • Page 83: Platform Mounting

    AB60J PARTS MANUAL PLATFORM MOUNTING Item Part No. Name M00232 PLATFORM MOUNTING PNNA PLATFORM WELDMENT PNNA PLATFORM GATE 0071800 FOOT SWITCH ASSEMBLY 0181609 UPPER CONTROL BOX, 2 WHEEL DRIVE 0181610 UPPER CONTROL BOX, 4 Shown WHEEL DRIVE 970529 BLT HEXHD .375-16 2.50 GR5 986299 WSHR FLAT .375 GR5 ZP...

  • Page 84: Global Std Platf Assy W/Guard

    AB60J PARTS MANUAL GLOBAL STD PLATF ASSY W/GUARD REPAIR PARTS GLOBAL STD PLATF ASSY W/GUARD Thu May 11 20:26:46 UTC 2017 2-27...
  • Page 85 AB60J PARTS MANUAL GLOBAL STD PLATF ASSY W/GUARD Item Part No. Name 1431573 D GLOBAL STD PLATF ASSY Shown W/GUARD 0071953 SPCR .451ID .500OD 1.88 STL 102271-082 PANEL PLATFORM FLOOR 0113531 ASSY, SNORKEL GUARD 0150509 ROLLER 300492 LATCH LH TRAY ROTARY...
  • Page 86 AB60J PARTS MANUAL GLOBAL STD PLATF ASSY W/GUARD Item Part No. Name 5010007 HOSE VACUUM .156 ID 4.0MM 5560031 .3125-18UNC HEX LOCK NUT 5560033 NUT HEX LKG .375-16 5560696 BLT HEXHD .375-16 1.125 GR5 5563310 HWH .25-14 Self Drilling Hd x .75 5569865 BLT HEXHD .375-16 2.75 GR5...

  • Page 87: Global Platform Assembly

    AB60J PARTS MANUAL GLOBAL PLATFORM ASSEMBLY REPAIR PARTS GLOBAL PLATFORM ASSEMBLY Thu May 11 20:26:47 UTC 2017 2-28...
  • Page 88 AB60J PARTS MANUAL GLOBAL PLATFORM ASSEMBLY Item Part No. Name 1430100 GLOBAL PLATFORM ASSEMBLY 1430080 GLOBAL STD PLATFORM WELDMENT 0074096 GUARD WELDMENT 0113584 KIT, SNORKEL GUARD TRI ENTRY 8' STEEL 0113581 ASSY SNORKEL GUARD 1430099 WLDMT, GATE SWING SIDE 2572007 BRG .500ID .625OD .625...
  • Page 89 AB60J PARTS MANUAL GLOBAL PLATFORM ASSEMBLY Item Part No. Name 0150509 ROLLER 0071953 SPCR .451ID .500OD 1.88 STL 5569865 BLT HEXHD .375-16 2.75 GR5 5560033 NUT HEX LKG .375-16 986299 WSHR FLAT .375 GR5 ZP 5560696 BLT HEXHD .375-16 1.125 GR5...
  • Page 90 AB60J PARTS MANUAL ASSY SNORKEL GUARD REPAIR PARTS ASSY SNORKEL GUARD Thu May 11 20:26:47 UTC 2017 2-29...

  • Page 91: Assy Snorkel Guard

    AB60J PARTS MANUAL ASSY SNORKEL GUARD Item Part No. Name 0113584 KIT, SNORKEL GUARD TRI ENTRY 8' STEEL 0113531 ASSY, SNORKEL GUARD 986299 WSHR FLAT .375 GR5 ZP 972479 BLT HEXHD .375-16 1.25 GR5 5560033 NUT HEX LKG .375-16 ASSY SNORKEL GUARD...

  • Page 92: Platform Rotator

    AB60J PARTS MANUAL PLATFORM ROTATOR REPAIR PARTS PLATFORM ROTATOR Thu May 11 20:26:47 UTC 2017 2-30...
  • Page 93 AB60J PARTS MANUAL PLATFORM ROTATOR Item Part No. Name 0180873 PLATFORM ROTATOR 0180516 WELDMENT PYLON 0180509 ROTATOR FRAME 0072818 TORQUE PLATE 0110771 PLATFORM ROTATOR 6010541 VALVE DUAL CROSSOVER RELIEF 6029631 HYD PWR - ATB 60PRO66PRO100 1 6091504 RESERVOIR WITH CAP...
  • Page 94 AB60J PARTS MANUAL PLATFORM ROTATOR Item Part No. Name 984409 .50-13UNC HEX NUT 970509 BLT HEXHD .375-16 2.00 GR5 PLTD 986269 WASHER, FLAT, .313 STANDARD, PLATED PNNA GREASE, CONOCO SUPER STA - (CONSULT FACTORY) 5035318 ADAPTER 90 DEG ELBOW -6...
  • Page 95 AB60J PARTS MANUAL PLATFORM ROTATOR ASSEMBLY W/OVERLOAD REPAIR PARTS PLATFORM ROTATOR ASSEMBLY W/OVERLOAD Thu May 11 20:26:47 UTC 2017 2-31...

  • Page 96: Platform Rotator Assembly W/Overload

    AB60J PARTS MANUAL PLATFORM ROTATOR ASSEMBLY W/OVERLOAD Item Part No. Name 0182469 A PLATFORM ROTATOR Shown ASSEMBLY W/OVERLOAD 0020283 HOSE-4-4S-4S 15.25 100R1 0070132 PIN LOCK 2.25 DIA 2H 0070473 BLT HEXHD .313-18 .75 DR 0070570 HYDR ROTARY ACTUATOR PLATF 0070816 0070908 HOSE-4-4S-4S 9.75 100R1...
  • Page 97 AB60J PARTS MANUAL PLATFORM ROTATOR ASSEMBLY W/OVERLOAD Item Part No. Name 6010541 VALVE DUAL CROSSOVER RELIEF 6029631 HYD PWR - ATB 60PRO66PRO100 1 7110348 O-RING 4.38ID 4.75OD .188 70D AS568 -34870 NS00146 .041 DIA SS SAFETY WIRE 1 NS00223 DA REDPLEX #2 GREASE #12519...
  • Page 98 AB60J PARTS MANUAL PLATFORM INSTALLATION REPAIR PARTS PLATFORM INSTALLATION Thu May 11 20:26:48 UTC 2017 2-32...

  • Page 99: Platform Installation

    AB60J PARTS MANUAL PLATFORM INSTALLATION Item Part No. Name A18064A B PLATFORM INSTALLATION 056021-012 WASHER SPRINGWASHER DIN127B M12 ZincPlated 058494-035 BLT HEXHD M12 X 35MM DIN933 GR8.8 ZP 0075840 PLT OVERLOAD TOP 0075842 PLT OVERLOAD ADAPTER 116346-000 PLATFORM OVERLOAD SENSOR UPRIGHT N212 200 970519 BLT HEXHD .375-16 2.25 GR5-...
  • Page 100 AB60J PARTS MANUAL ENGINE MOUNTING – CUMMINS, BEFORE APRIL 2004 REPAIR PARTS ENGINE MOUNTING – CUMMINS, BEFORE APRIL 2004 Thu May 11 20:26:48 UTC 2017 2-33...

  • Page 101: Engine Mounting - Cummins, Before April 2004

    AB60J PARTS MANUAL ENGINE MOUNTING – CUMMINS, BEFORE APRIL 2004 Item Part No. Name 0181839 ENGINE MOUNTING – CUMMINS 0181836 ENGINE, CUMMINS 4B 7630262 RADIATOR HOSE, LOWER 5550038 CLAMP WORM DRV #28 7630239 RADIATOR CAP 13PSI 7630247 RADIATOR 5560179 .420 X 1.5 X 12GA FLAT WASHER 8 970519 BLT HEXHD .375-16 2.25 GR5-...
  • Page 102 AB60J PARTS MANUAL ENGINE MOUNTING – CUMMINS, BEFORE APRIL 2004 Item Part No. Name 0071599 WSHR .650ID 2.63OD .188 5560169 WASHER HARD FLAT .625 SP 5560131 NUT 5/8-11 SELF LOCKING 7630117 MOUNT, ENGINE 0180997 ANGLE, RADIATOR 0181032 FUEL HOSE 3/8 INCH DIAMETER...

  • Page 103: Engine - Cummins, After April 2004

    AB60J PARTS MANUAL ENGINE – CUMMINS, AFTER APRIL 2004 REPAIR PARTS ENGINE – CUMMINS, AFTER APRIL 2004 Thu May 11 20:26:49 UTC 2017 2-34...
  • Page 104 AB60J PARTS MANUAL ENGINE – CUMMINS, AFTER APRIL 2004 Item Part No. Name 0181836 ENGINE, CUMMINS 4B 7624745 ENGINE, CUMMINS 4B 0181822 ENGINE MOUNT, FRONT RIGHT HAND 0181824 ENGINE MOUNT, FRONT LEFT HAND 5560694 CAPSCREW METRIC M12-1.75 X 35MM LONG HEX HEAD...
  • Page 105 AB60J PARTS MANUAL ENGINE – CUMMINS, AFTER APRIL 2004 Item Part No. Name 986019 WASHER, FLAT, .25 STANDARD, PLATED 5560004 .250-20UNC HEX LOCK NUT 972049 BOLT 10MM-1.50P 40MM GR8 5560356 WASHER LOCK M10 5560617 BOLT 10MM-1.50P 35MM CL8.8 0080691 PLATE, ENGINE ADAPTER...
  • Page 106 AB60J PARTS MANUAL ENGINE – CUMMINS, AFTER APRIL 2004 Item Part No. Name 0190694 BRACKET CUMMINS MUFFLER 5550050 CLAMP WORM DRV #52 0081053 HOSE, AIR INTAKE 5560634 CAPSCREW METRIC M8-1.25 X 45MM LONG HEX HEAD 5560355 WASHER METRIC M8 LOCK...
  • Page 107 AB60J PARTS MANUAL EXHAUST – CUMMINS REPAIR PARTS EXHAUST – CUMMINS Thu May 11 20:26:49 UTC 2017 2-35...

  • Page 108: Exhaust - Cummins

    AB60J PARTS MANUAL EXHAUST – CUMMINS Item Part No. Name 0180959 EXHAUST – CUMMINS 0181663 TAIL PIPE 7630004 HOOD AIR INLET 0170611 AIR INLET TUBE 5550039 CLAMP 5550050 CLAMP WORM DRV #52 986299 WSHR FLAT .375 GR5 ZP EXHAUST – CUMMINS...
  • Page 109 AB60J PARTS MANUAL ENGINE ASSEMBLY – CUMMINS REPAIR PARTS ENGINE ASSEMBLY – CUMMINS Thu May 11 20:26:50 UTC 2017 2-36...

  • Page 110: Engine Assembly - Cummins 1

    AB60J PARTS MANUAL ENGINE ASSEMBLY – CUMMINS Item Part No. Name 0182004 ENGINE ASSEMBLY – CUMMINS 1 0070148 WASHER SPCL .531 X 2 X .06 0074622 WELDMENT FRONT BRACKET 0074972 BRACKET, FUEL FILTER (CU) 0083155 THROTTLE LEVER EXTENSION 0083437 KIT CPLG/FLWHEEL CU...
  • Page 111 AB60J PARTS MANUAL ENGINE ASSEMBLY – CUMMINS Item Part No. Name 30070037 TEMP SENSOR 1/2 NPT HIGH 5010005 HOSE .38 #831-6 PUSH LOCK 4.75 FT 5093000 CLP CUSH .438 VINYL COATED 5530017 WASHER SPR CRV .375 5550006 CLAMP WORM DRV #6 5560004 .250-20UNC HEX LOCK NUT...

  • Page 112: Assembly Exhaust-Air Cleaner

    AB60J PARTS MANUAL ASSEMBLY EXHAUST-AIR CLEANER REPAIR PARTS ASSEMBLY EXHAUST-AIR CLEANER Thu May 11 20:26:50 UTC 2017 2-37...
  • Page 113 AB60J PARTS MANUAL ASSEMBLY EXHAUST-AIR CLEANER Item Part No. Name 0182006 ASSEMBLY EXHAUST-AIR CLEANER 0074644 MUFFLER 0074645 TAIL PIPE 0074664 MUFFLER CLAMP TB 42/50 CU 0074687 CLAMP AIR INTAKE TUBE 0074688 ADAPTOR HOSE AIR INTAKE 0082138 PUMP SUB ASSY 0083165 CLAMP T-BOLT 2.75 NOM...
  • Page 114 AB60J PARTS MANUAL ASSEMBLY EXHAUST-AIR CLEANER Item Part No. Name 5560629 WASHER FLAT M6 5560664 WSHR LOCK M6 (USE 056021- 006) 7630015 90 DEGREE ELBOW 76304755 AIR CLEANER NELSON 7630759 BRACKET AIR CLEANER ASSEMBLY EXHAUST-AIR CLEANER Thu May 11 20:26:50 UTC 2017...

  • Page 115: Exhaust Cummins After April 2004

    AB60J PARTS MANUAL EXHAUST CUMMINS AFTER APRIL 2004 REPAIR PARTS EXHAUST CUMMINS AFTER APRIL 2004 Thu May 11 20:26:51 UTC 2017 2-38...
  • Page 116 AB60J PARTS MANUAL EXHAUST CUMMINS AFTER APRIL 2004 Item Part No. Name 0182005 EXHAUST 0180441 SUPPORT BRACKET WELDMENT, RADIATOR 0180832 MTG PLATE OVERFLOW 0180997 ANGLE, RADIATOR 0180998 ANGLE, RADIATOR 0181154 SHIELD, ALTERNATOR ATB-60 0182017 PLATED, FORMED MOUNTING 970029 BLT HEX .250-20 .75 GR5-Z/P 970049 BLT HEXHD .250-20 1.00 GR5...
  • Page 117 AB60J PARTS MANUAL ENGINE MOUNTING, FORD LRG-425 BEFORE JANUARY 2003 REPAIR PARTS ENGINE MOUNTING, FORD LRG-425 BEFORE JANUARY 2003 Thu May 11 20:26:51 UTC 2017 2-39...
  • Page 118 AB60J PARTS MANUAL ENGINE MOUNTING, FORD LRG-425 BEFORE JANUARY 2003 Item Part No. Name 0181802 ENGINE/RADIATOR INSTALL Shown 0181801 ENGINE SUB ASSEMBLY 7630677 RADIATOR 0180441 SUPPORT BRACKET WELDMENT, RADIATOR 0180997 ANGLE, RADIATOR 7630180 RADIATOR CUSHION 5560179 .420 X 1.5 X 12GA FLAT WASHER 8...

  • Page 119: Engine Mounting, Ford Lrg-425 Before January 2003

    AB60J PARTS MANUAL ENGINE MOUNTING, FORD LRG-425 BEFORE JANUARY 2003 Item Part No. Name 986359 WSHR FLAT .500 GR5 ZP 987139 WSHR LOCK .500 SPLIT TYPE 5560639 BLT HEXHD .625-11 4.50 GR5- 5560149 BOLT HEXHD LKG .625-11 2.75 5560036 NUT LKG .625-11 970049 BLT HEXHD .250-20 1.00 GR5...
  • Page 120 AB60J PARTS MANUAL ENGINE MOUNTING, FORD LRG-425 BEFORE JANUARY 2003 Item Part No. Name 7630682 FUEL PUMP 7630683 FUEL FILTER 7630686 HIGH PRESSURE FUEL HOSE 7630685 FUEL PRESSURE REGULATOR CLAMP ENGINE MOUNTING, FORD LRG-425 BEFORE JANUARY 2003 Thu May 11 20:26:51 UTC 2017...

  • Page 121: Engine/Radiator Install Ford 425

    AB60J PARTS MANUAL ENGINE/RADIATOR INSTALL FORD 425 REPAIR PARTS ENGINE/RADIATOR INSTALL FORD 425 Thu May 11 20:26:52 UTC 2017 2-40...
  • Page 122 AB60J PARTS MANUAL ENGINE/RADIATOR INSTALL FORD 425 Item Part No. Name 0181802 ENGINE/RADIATOR INSTALL 0181801 ENGINE SUB ASSEMBLY 7630677 RADIATOR 0180441 SUPPORT BRACKET WELDMENT, RADIATOR 0180997 ANGLE, RADIATOR 7630180 RADIATOR CUSHION 5560179 .420 X 1.5 X 12GA FLAT WASHER 8...
  • Page 123 AB60J PARTS MANUAL ENGINE/RADIATOR INSTALL FORD 425 Item Part No. Name PNNA FLAT WASHER 1/2" PNNA LOCKWASHER 1/2" MED PNNA CAPSCREW 5/18-11 X 4-1/2" LG. H.H. 5560169 WASHER HARD FLAT .625 SP PNNA NUT 5/8-11 ESNA PNNA CAPSCREW 1/4-20 X 1" LG. H.H.
  • Page 124 AB60J PARTS MANUAL ENGINE/RADIATOR INSTALL FORD 425 Item Part No. Name 7630686 HIGH PRESSURE FUEL HOSE 7630685 FUEL PRESSURE REGULATOR CLAMP 7630691 HIGH PRESSURE FUEL LINE HOSE PNNA EPM MODULE 969989 BLT HEXHD .250-20 1.75 GR5 0083783 MOUNT PLATE, EMP (FO)
  • Page 125 AB60J PARTS MANUAL ENGINE SUB ASSEMBLY, FORD LRG-425 REPAIR PARTS ENGINE SUB ASSEMBLY, FORD LRG-425 Thu May 11 20:26:52 UTC 2017 2-41...
  • Page 126 AB60J PARTS MANUAL ENGINE SUB ASSEMBLY, FORD LRG-425 Item Part No. Name 0181801 D ENGINE SUB ASSEMBLY, FORD LRG-425 0181801 ENGINE SUB ASSEMBLY 7630677 RADIATOR 0180441 SUPPORT BRACKET WELDMENT, RADIATOR 0180997 ANGLE, RADIATOR 7630180 RADIATOR CUSHION 5560179 .420 X 1.5 X 12GA FLAT WASHER 8...
  • Page 127 AB60J PARTS MANUAL ENGINE SUB ASSEMBLY, FORD LRG-425 Item Part No. Name PNNA FLAT WASHER 1/2" PNNA LOCKWASHER 1/2" MED PNNA CAPSCREW 5/18-11 X 4-1/2" LG. H.H. 5560169 WASHER HARD FLAT .625 SP PNNA NUT 5/8-11 ESNA PNNA CAPSCREW 1/4-20 X 1" LG. H.H.
  • Page 128 AB60J PARTS MANUAL ENGINE SUB ASSEMBLY, FORD LRG-425 Item Part No. Name 7630686 HIGH PRESSURE FUEL HOSE 7630685 FUEL PRESSURE REGULATOR CLAMP 7630691 HIGH PRESSURE FUEL LINE HOSE PNNA EPM MODULE 969989 BLT HEXHD .250-20 1.75 GR5 0083783 MOUNT PLATE, EMP (FO)

  • Page 129: Exhaust And Air Cleaner

    AB60J PARTS MANUAL EXHAUST AND AIR CLEANER REPAIR PARTS EXHAUST AND AIR CLEANER Thu May 11 20:26:52 UTC 2017 2-42...
  • Page 130 AB60J PARTS MANUAL EXHAUST AND AIR CLEANER Item Part No. Name 0082695 EXHAUST AND AIR CLEANER 7630689 AIR CLEANER MOUNT 8140006 REPLACEMENT PRIMARY Shown FILTER ELEMENT 7630004 HOOD AIR INLET 5560658 POP RIVET #AD36-ABS 0071510 SPCR .465ID .500OD 1.00 STL...

  • Page 131: Fuel Pump Assembly

    AB60J PARTS MANUAL FUEL PUMP ASSEMBLY REPAIR PARTS FUEL PUMP ASSEMBLY Thu May 11 20:26:53 UTC 2017 2-43...
  • Page 132 AB60J PARTS MANUAL FUEL PUMP ASSEMBLY Item Part No. Name 0182276 FUEL PUMP ASSEMBLY 0084126 SPACER, REGULATOR MANIFOLD 0182350 HOSE ASSEMBLY, FUEL .38 ID X 4.50 0182275 BRACKET, FUEL PUMP GM T3 AB60J 970109 CAPSCREW, 1/4-20 X 2-3/4 LG HEXHD GR5 970259 BLT HEXHD .313-18 1.00 GR5-...

  • Page 133: Gm Engine Sub-Assembly

    AB60J PARTS MANUAL GM ENGINE SUB-ASSEMBLY REPAIR PARTS GM ENGINE SUB-ASSEMBLY Thu May 11 20:26:53 UTC 2017 2-44...
  • Page 134 AB60J PARTS MANUAL GM ENGINE SUB-ASSEMBLY Item Part No. Name 0182173 GM ENGINE SUB-ASSEMBLY 0070148 WASHER SPCL .531 X 2 X .06 0172372 MOTOR MOUNT-REAR (GM) 0172373 MOTOR MOUNT-FRONT LH (GM) 0172374 MOTOR MOUNT-FRONT RH (GM) 0181525 PUMP SUB-ASSEMBLY 0182084...
  • Page 135 AB60J PARTS MANUAL GM ENGINE SUB-ASSEMBLY Item Part No. Name 5560168 WSHR FLAT HARD .500 SP 5560362 BLT HEXHD .500-13 X 3.25 GR5 5560625 BOLT 10MM-1.50P 20MM 7624764 ENGINE, GM 2.4 T3 7630001 MOUNTENGINE-BARRY 0075254 EXTENSION POWER STUD 5560357 BLT HEXHD M8-1.25 25MM...

  • Page 136: Gm Engine Installation

    AB60J PARTS MANUAL GM ENGINE INSTALLATION REPAIR PARTS GM ENGINE INSTALLATION Thu May 11 20:26:53 UTC 2017 2-45...
  • Page 137 AB60J PARTS MANUAL GM ENGINE INSTALLATION Item Part No. Name 0182172 GM ENGINE INSTALLATION 0182081 RADIATOR ASSEMBLY AB60J 0182120 BRACKET, HOSE SUPPORT - GM 0182173 GM ENGINE SUB-ASSEMBLY 0192170 TUBE, LOWER RADIATOR 1.75 0192172 TUBE, UPPER RADIATOR 1.50 0192182 ELBOW, MOD 45 DEGREE 1.50 0192192 TUBE UNION 1.75 OD X 2.375 LG...
  • Page 138 AB60J PARTS MANUAL GM ENGINE INSTALLATION Item Part No. Name 7630833 ELBOW 1.75 90 DEGREE 7630835 REDUCER, TUBE END 1.50/1.25 GM ENGINE INSTALLATION Thu May 11 20:26:53 UTC 2017 2-45...

  • Page 139: Lps Air Cleaner Installation

    AB60J PARTS MANUAL LPS AIR CLEANER INSTALLATION REPAIR PARTS LPS AIR CLEANER INSTALLATION Thu May 11 20:26:54 UTC 2017 2-46...
  • Page 140 AB60J PARTS MANUAL LPS AIR CLEANER INSTALLATION Item Part No. Name 0182253 LPS AIR CLEANER INSTALLATION 0182245 AIR CLEANER BRACKET 970469 BLT HEXHD .375-16 1.00 GR5 984109 NUT HEX .375-16 7630005 MOUNTING BAND 970449 BLT HEXHD .375-16 .750 GR5 7630225...
  • Page 141 AB60J PARTS MANUAL ENGINE SUB-ASSEMBLY AFTER APRIL 2015 REPAIR PARTS ENGINE SUB-ASSEMBLY AFTER APRIL 2015 Thu May 11 20:26:54 UTC 2017 2-47...
  • Page 142 AB60J PARTS MANUAL ENGINE SUB-ASSEMBLY AFTER APRIL 2015 Item Part No. Name 0182426 ENGINE SUB-ASSEMBLY 0075737 WELDMENT, ENGINE BRACKET FRONT 0075738 WELDMENT ENGINE MOUNT REAR 0075743 AIR INLET PIPE, 2"OD X 2.5"LG 0182452 PUMP SUB ASSEMBLY 0182418 WELDMENT, KU MOTOR...
  • Page 143 AB60J PARTS MANUAL ENGINE SUB-ASSEMBLY AFTER APRIL 2015 Item Part No. Name 056060-035 BLTHHCS M10 x 35MM DIN931 GR8.8 ZP 056060-070 HHCS M10 X 1.5 X70 G8.8 DIN 056066-006 Nut NylockNut DIN985 M6 8.0 Zi 056066-008 Nut NylockNut DIN985 M8 8.0 Zi 056066-010 Nut, NylockNut DIN985 M10 8.0...
  • Page 144 AB60J PARTS MANUAL ENGINE SUB-ASSEMBLY AFTER APRIL 2015 Item Part No. Name 513133-040 BOLT HEXHD M12X1.25X40MM DIN 960 987139 WSHR LOCK .500 SPLIT TYPE 5010011 HOSE SAE30R2-05 .312 FUEL 5550005 EXHAUST CLAMP 5550007 CLP MUFFLER 1.88 .375-16 HVY 5550028 CLP WORM DRV .25-.63 .31...

  • Page 145: Pump Sub-Assembly Kubota

    AB60J PARTS MANUAL PUMP SUB-ASSEMBLY KUBOTA REPAIR PARTS PUMP SUB-ASSEMBLY KUBOTA Thu May 11 20:26:55 UTC 2017 2-48...
  • Page 146 AB60J PARTS MANUAL PUMP SUB-ASSEMBLY KUBOTA Item Part No. Name 0182452 A PUMP SUB-ASSEMBLY KUBOTA 5036503 ADAPTER TEE SWIVEL -4 JIC TO -4 JIC TO -4 JIC FEMALE 5036604 FTG. ELB90SWVLTUBE-16S-16S 5037006 ADAPTER 90 DEG ELBOW SWIVEL -8 JIC 5037010...

  • Page 147: Cowling

    AB60J PARTS MANUAL COWLING REPAIR PARTS COWLING Thu May 11 20:26:55 UTC 2017 2-49...
  • Page 148 AB60J PARTS MANUAL COWLING Item Part No. Name 0180937 COWLING 0180736 DOOR- RH 0180737 DOOR- LH 0180747 TOP RAIL, RIGHT HAND 0181679 TOP RAIL -LH 0180749 COUNTERWEIGHTCOVER -RH 0180750 COUNTERWEIGHT COVER -LH 0180773 REAR COWLING -RH 0180774 REAR COWLING -LH...
  • Page 149 AB60J PARTS MANUAL COWLING Item Part No. Name 970469 BLT HEXHD .375-16 1.00 GR5 970479 CAPSCREW 3/8-16 X 1-1/4 INCH LONG HEX HEAD GRADE 5 970259 BLT HEXHD .313-18 1.00 GR5- PLATED 5560683 BLT HEXHD .375-16 .625 GR5 5569902 CAPSCREW 3/8-16 X 5-1/4"LG H.H.

  • Page 150: Cowling Installation

    AB60J PARTS MANUAL COWLING INSTALLATION REPAIR PARTS COWLING INSTALLATION Thu May 11 20:26:56 UTC 2017 2-50...
  • Page 151 AB60J PARTS MANUAL COWLING INSTALLATION Item Part No. Name 0182132 COWLING INSTALLATION 0180736 DOOR- RH 0180737 DOOR- LH 0182127 TOP RAIL -RH 0181679 TOP RAIL -LH 0180749 COUNTERWEIGHTCOVER -RH 0180750 COUNTERWEIGHT COVER -LH 0180773 REAR COWLING -RH 0180774 REAR COWLING -LH...
  • Page 152 AB60J PARTS MANUAL COWLING INSTALLATION Item Part No. Name 970419 BLT HEXHD .375-16 X 1.25 GR5 9701259 CAPSCREW 5/16-18 X 1"LG H.H. 970439 BOLT HEXHD .375-16 .625 5569902 CAPSCREW 3/8-16 X 5-1/4"LG H.H. 5560609 SCR TRHD 10-24 .50 986299 WSHR FLAT .375 GR5 ZP 986269 WASHER, FLAT, .313...

  • Page 153: Air Cleaner

    AB60J PARTS MANUAL AIR CLEANER REPAIR PARTS AIR CLEANER Thu May 11 20:26:56 UTC 2017 2-51...

  • Page 154: Air Cleaner

    AB60J PARTS MANUAL AIR CLEANER Item Part No. Name 7630003 AIR CLEANER PNNA HOUSING - (NOT SOLD SEPERATELY) 8040106 PRIMARY FILTER ELEMENT 8040107 SECONDARY FILTER ELEMENT 8040112 CLEANER CAP BAFFLE 8040114 CLAMP 8040111 DUST CAP 8040115 VACUATOR VALVE AIR CLEANER...
  • Page 155 AB60J PARTS MANUAL AIR CLEANER REPAIR PARTS AIR CLEANER Thu May 11 20:26:56 UTC 2017 2-52...
  • Page 156 AB60J PARTS MANUAL AIR CLEANER Item Part No. Name 7630755 AIR CLEANER Shown 8140011 PRIMARY ELEMENT – NELSON – ITEM NOT SHOWN 8140014 CLIP AIR CLEANER – NELSON – ITEM NOT SHOWN 068903 DUST EJECTOR CUMMINS # 3946457S - NELSON ONLY 8140013 COVER REPLACEMENT –...

  • Page 157: Legacy Snorkel Guard Wiring

    AB60J PARTS MANUAL LEGACY SNORKEL GUARD WIRING REPAIR PARTS LEGACY SNORKEL GUARD WIRING Thu May 11 20:26:56 UTC 2017 2-53...
  • Page 158 AB60J PARTS MANUAL LEGACY SNORKEL GUARD WIRING Item Part No. Name 0113536 LEGACY SNORKEL GUARD WIRING 3040469 RELAY SPDT 12V 30AMP SONG 3020080 SWITCH TOGGLE SPDT MOM/ON 0113540 ASSY, DIODE WIRE 0113541 ASSY, SWITCH WIRE COMMON 0113542 ASSY, SWITCHED WIRE...

  • Page 159: Snorkel Guard Assembly

    AB60J PARTS MANUAL SNORKEL GUARD ASSEMBLY REPAIR PARTS SNORKEL GUARD ASSEMBLY Thu May 11 20:26:56 UTC 2017 2-54...
  • Page 160 AB60J PARTS MANUAL SNORKEL GUARD ASSEMBLY Item Part No. Name 0113531 ASSY, SNORKEL GUARD 0113519 WLDMT, SNORKEL GUARD 0113529 WLDMT, ACTIVATION BAR 0113528 PIN, .375 X 2.31 GRIP 056058-070 HHCS M6 X 1 X 70 G8.8 ISO 4014 DIN 931 056066-006 Nut NylockNut DIN985 M6 8.0 Zi...

  • Page 161: Brake Unit

    AB60J PARTS MANUAL BRAKE UNIT REPAIR PARTS BRAKE UNIT Thu May 11 20:26:57 UTC 2017 2-55...
  • Page 162 AB60J PARTS MANUAL BRAKE UNIT Item Part No. Name 7200024 C BRAKE UNIT 7200029 GASKET KIT Shown 7200030 O-RING KIT Shown 7200031 STACK KIT Shown 7200032 BEARING KIT Shown BRAKE UNIT Thu May 11 20:26:57 UTC 2017 2-55...

  • Page 163: Tires And Wheels

    AB60J PARTS MANUAL TIRES AND WHEELS REPAIR PARTS TIRES AND WHEELS Thu May 11 20:26:57 UTC 2017 2-56...
  • Page 164 AB60J PARTS MANUAL TIRES AND WHEELS Item Part No. Name 0080365 TIRE AND WHEEL, FOAM FILLED RIGHT HAND 15-19.5 14 PLY STEER (STANDARD ON 4X2, FOAM FILLED LUGGED TIRES) 0181013 TIRE AND WHEEL, FOAM FILLED RIGHT HAND 15-19.5 12 PLY DRIVE (STANDARD ON...

  • Page 165: Placards And Decals

    AB60J PARTS MANUAL PLACARDS AND DECALS REPAIR PARTS PLACARDS AND DECALS Thu May 11 20:26:57 UTC 2017 2-57...

  • Page 166: Placards And Decals

    AB60J PARTS MANUAL PLACARDS AND DECALS Item Part No. Name 0180948 PLACARDS AND DECALS 7030004 DECAL, OMNIQUIP LOGO 0074311 DECAL DNGR CYLINDER FAILURE- 0181041 DECAL CAUTN SECURE CROSSBARS 0181970 DECAL, AB60J LOGO 569295 DECAL, SNOKEL BRAND LOGO 3.00 7030003 DECAL LUBE...
  • Page 167 AB60J PARTS MANUAL PLACARDS AND DECALS Item Part No. Name 0150602 DECAL DNGR DESCENDING BOOM 9980022 PLUG HOLE 4.00 DIA PLASTIC 0070921 PLACARD, 110 VOLT POWER 0073492 DECAL ROTATE WHILE GREASING 0073491 DECAL SAFE OPERATION INFO 0323899 *DECAL DANGER ELECTROCUTION HAZARD 9980021 PLUG, HOLE 3.50 DIA PLASTIC...
  • Page 168 AB60J PARTS MANUAL PLACARDS AND DECALS REPAIR PARTS PLACARDS AND DECALS Thu May 11 20:26:58 UTC 2017 2-58...
  • Page 169 AB60J PARTS MANUAL PLACARDS AND DECALS Item Part No. Name 0180948 PLACARDS AND DECALS 0181041 DECAL CAUTN SECURE CROSSBARS 0181685 DECAL ATB60 LOGO 15.75 560239 DECAL SNORKEL BRAND LOGO 2.35 in 0073298 *DECAL DANGER FOAM/SOLID TIRES 0070901 PLAC CAUTN SERIAL NUMBER...
  • Page 170 AB60J PARTS MANUAL PLACARDS AND DECALS PLACARDS AND DECALS Thu May 11 20:26:58 UTC 2017 2-58...
  • Page 171 AB60J PARTS MANUAL PLACARDS AND DECALS Item Part No. Name 0323899 *DECAL DANGER ELECTROCUTION HAZARD 0072531 DECAL, DNGR ELECTRICAL HAZARD SPANISH 0071425 PLAC PLATF IDENTIFICATION PNNA PLAC PLATF CAPACITY (CONSULT FACTORY) 5560655 POP RIVET #AD32-ABS 0150448 DECAL ATTACH FALL RESTRAINT 5569876 RVT POP .094 DIA .250 DMD STL...
  • Page 172 AB60J PARTS MANUAL PLACARDS AND DECALS Item Part No. Name 0072541 DECAL DANGER DO NOT Shown OPERATE (DECAL LISTED IN BOM NOT ID WITH DWG REV N 0180948) 0073668 DECAL CAUTN DO NOT USE Shown BOOM 0151885 DECAL SNORKELIFT LOGO 12.5...
  • Page 173 AB60J PARTS MANUAL PLACARDS AND DECALS INSTALL AFTER FEBRUARY 2014 REPAIR PARTS PLACARDS AND DECALS INSTALL AFTER FEBRUARY 2014 Thu May 11 20:26:59 UTC 2017 2-59...
  • Page 174 PLACARDS AND DECALS INSTALL AFTER FEBRUARY 2014 AB60J PARTS MANUAL PLACARDS AND DECALS INSTALL AFTER FEBRUARY 2014 Thu May 11 20:26:59 UTC 2017 2-59...
  • Page 175 PLACARDS AND DECALS INSTALL AFTER FEBRUARY 2014 AB60J PARTS MANUAL PLACARDS AND DECALS INSTALL AFTER FEBRUARY 2014 Thu May 11 20:26:59 UTC 2017 2-59...
  • Page 176 AB60J PARTS MANUAL PLACARDS AND DECALS INSTALL AFTER SEPTEMBER 2014 REPAIR PARTS PLACARDS AND DECALS INSTALL AFTER SEPTEMBER 2014 Thu May 11 20:27:00 UTC 2017 2-60...
  • Page 177 PLACARDS AND DECALS INSTALL AFTER SEPTEMBER 2014 AB60J PARTS MANUAL PLACARDS AND DECALS INSTALL AFTER SEPTEMBER 2014 Thu May 11 20:27:00 UTC 2017 2-60...
  • Page 178 PLACARDS AND DECALS INSTALL AFTER SEPTEMBER 2014 AB60J PARTS MANUAL PLACARDS AND DECALS INSTALL AFTER SEPTEMBER 2014 Thu May 11 20:27:00 UTC 2017 2-60...

  • Page 179: Decal/Plac Com Ce

    AB60J PARTS MANUAL DECAL/PLAC COM CE REPAIR PARTS Image does not exist DECAL/PLAC COM CE Thu May 11 20:27:00 UTC 2017 2-61...
  • Page 180 0162366 DECAL ELEC HAZARD SYM CE ONLY 018104105 DECAL SECURE CROSSBARS 0181562 DECAL MACH COMPLIES WITH ANSI- 0182072E DECAL WHEEL LOADING AB60J 4 0182077E DECAL CE NOISE LEVEL 0090589E PLACARD DECAL/PLAC COM CE Thu May 11 20:27:00 UTC 2017 2-61...

  • Page 181: Decal/Plac Platf Ce

    AB60J PARTS MANUAL DECAL/PLAC PLATF CE REPAIR PARTS Image does not exist DECAL/PLAC PLATF CE Thu May 11 20:27:00 UTC 2017 2-62...
  • Page 182 AB60J PARTS MANUAL DECAL/PLAC PLATF CE Item Part No. Name 0182472 A DECAL/PLAC PLATF CE 0075680 PLAC CAUTN SERIAL NUMBER CE ONLY 0071425 PLAC PLATF IDENTIFICATION 0075235 DECAL, SIDE LOAD 150 LB 0072531 DECAL, DNGR ELECTRICAL HAZARD SPANISH 0075372 PLAC PLAT CAP 500LBS 2...

  • Page 183: Decal/Plac Ku 4X4 Ce

    AB60J PARTS MANUAL DECAL/PLAC KU 4X4 CE REPAIR PARTS Image does not exist DECAL/PLAC KU 4X4 CE Thu May 11 20:27:00 UTC 2017 2-63...
  • Page 184 AB60J PARTS MANUAL DECAL/PLAC KU 4X4 CE Item Part No. Name 0182470 A DECAL/PLAC KU 4X4 CE 0071926 DECAL DIESEL FUEL 0074913 DECAL 4X4 LOGO 0075563 DECAL DO NOT USE ETHER CU 0075564 PLAC COLDSTART GLOW PLUG (GROUND) 0084213 PLAC COLDSTART GLOW...

  • Page 185: Language Kit - Spanish

    AB60J PARTS MANUAL LANGUAGE KIT - SPANISH REPAIR PARTS Image does not exist LANGUAGE KIT - SPANISH Thu May 11 20:27:01 UTC 2017 2-64...
  • Page 186 AB60J PARTS MANUAL LANGUAGE KIT - SPANISH Item Part No. Name 0182386 C LANGUAGE KIT - SPANISH Shown 0182365 DECAL KIT AB60J NON ANSI NON CE 0182367 MANUAL DEL OPERADOR AB60J OPERATORS MANUAL SPANISH 7030067 SPANISH SHIPPING INFO 0072530P DECAL DANGER ELECTRICAL...
  • Page 187 AB60J PARTS MANUAL LANGUAGE KIT - SPANISH Item Part No. Name 0075563P DECAL DO NOT USE ETHER CU T3 SPANISH 0074372P PLAC ENGINE RPM SPANISH 0070901P PLAC CAUTN SERIAL NUMBER SPANI 0323899P DECAL DANGER ELECTRICAL HAZARD 018104105 DECAL SECURE CROSSBARS...

  • Page 188: Power Wheel (Consign)

    AB60J PARTS MANUAL POWER WHEEL (CONSIGN) REPAIR PARTS POWER WHEEL (CONSIGN) Thu May 11 20:27:02 UTC 2017 2-65...
  • Page 189 AB60J PARTS MANUAL POWER WHEEL (CONSIGN) Item Part No. Name 0180961 F GEAR HUB - OMNI GEAR Shown 0181890 SPINDLE 8010027 OILSEAL 8010030 BEARING CONE 8010029 BEARING CUP 0112217 BEARING CUP 0112218 BEARING CONE 8010275 THRUST WASHER 8010276 LOCK WASHER...
  • Page 190 AB60J PARTS MANUAL POWER WHEEL (CONSIGN) Item Part No. Name 0112226 INPUT SHAFT 110175 WHEEL STUD. 3/4''-16UNF-2A 8011891 COUPLING 0112227 PIPE PLUG 8010028 MAGNETIC PLUG 8010021 DRAIN PLUG POWER WHEEL (CONSIGN) Thu May 11 20:27:02 UTC 2017 2-65...

  • Page 191: Swing Drive Perfection

    AB60J PARTS MANUAL SWING DRIVE PERFECTION REPAIR PARTS SWING DRIVE PERFECTION Thu May 11 20:27:03 UTC 2017 2-66...
  • Page 192 AB60J PARTS MANUAL SWING DRIVE PERFECTION Item Part No. Name 0110837 SWING DRIVE ASSEMBLY Shown 0112233 SWING DRIVE ASSEMBLY 6030017 MTRTRW ROSS MOTOR SWING DRIVE 0071089 SEAL REPAIR KIT, TRW MOTOR Shown 8230073 SEAL REPAIR KIT, WHITE Shown MOTOR 6010216...

  • Page 193: Swing Drive – Tulsa Winch

    AB60J PARTS MANUAL SWING DRIVE – TULSA WINCH REPAIR PARTS SWING DRIVE – TULSA WINCH Thu May 11 20:27:03 UTC 2017 2-67...
  • Page 194 AB60J PARTS MANUAL SWING DRIVE – TULSA WINCH Item Part No. Name 0070047 SWING DRIVE – PERFECTION Shown 8010232 OUTPUT SHAFT 8010260 OIL SEAL 8010227 BEARING CONE 8010226 BRG ROLLER/CUP- 8010235 BEARING CUP 8010221 WASHER, FLAT 8010225 BEARING CONE 8010224...
  • Page 195 AB60J PARTS MANUAL SWING DRIVE – TULSA WINCH Item Part No. Name 8010237 CARRIER 8010233 8010218 HUB FLANGE 8010268 PIPE PLUG 8010269 PIPE PLUG 8010270 BOLT, HEX HEAD 8010271 PIPE PLUG 8010239 PISTON KIT – ITEM NOT SHOWN 1 8010240 FRICTION DISC KIT –...

  • Page 196: Swing Drive – Auburn Gear

    AB60J PARTS MANUAL SWING DRIVE – AUBURN GEAR REPAIR PARTS SWING DRIVE – AUBURN GEAR Thu May 11 20:27:03 UTC 2017 2-68...
  • Page 197 AB60J PARTS MANUAL SWING DRIVE – AUBURN GEAR Item Part No. Name 0070047 SWING DRIVE – PERFECTION Shown 8010232 OUTPUT SHAFT 8010260 OIL SEAL 8010227 BEARING CONE 8010226 BRG ROLLER/CUP- 8010235 BEARING CUP 8010221 WASHER, FLAT 8010225 BEARING CONE 8010224...
  • Page 198 AB60J PARTS MANUAL SWING DRIVE – AUBURN GEAR Item Part No. Name 8010237 CARRIER 8010233 8010218 HUB FLANGE 8010268 PIPE PLUG 8010269 PIPE PLUG 8010270 BOLT, HEX HEAD 8010271 PIPE PLUG 8010239 PISTON KIT – ITEM NOT SHOWN 1 8010240 FRICTION DISC KIT –...

  • Page 199: Ac Generator Sub-Assembly

    AB60J PARTS MANUAL AC GENERATOR SUB-ASSEMBLY REPAIR PARTS AC GENERATOR SUB-ASSEMBLY Thu May 11 20:27:04 UTC 2017 2-69...
  • Page 200 AB60J PARTS MANUAL AC GENERATOR SUB-ASSEMBLY Item Part No. Name 0151471 L 110V AC GENERATOR Shown 3080001 GENERATOR, AC HYDRAULIC POWERED 0151457 MOUNT PLATE 7240012 COUPLING 0151458 MOTOR MOUNTING ANGLE 6030029 HYDRAULIC MOTOR, AC GENERATOR 0151469 BRACKET, VALVE MOUNTING 0152831...

  • Page 201: Chassis Hydraulics – 2 Wd

    AB60J PARTS MANUAL CHASSIS HYDRAULICS – 2 WD HYDRAULICS CHASSIS HYDRAULICS – 2 WD Thu May 11 20:27:04 UTC 2017...
  • Page 202 AB60J PARTS MANUAL CHASSIS HYDRAULICS – 2 WD Item Part No. Name 0181008 CHASSIS HYDRAULICS – 2 WD 0181084 MOTION CONTROL VALVE, 2 WHEEL DRIVE 0180817 L.H. STEER SWITCH VALVE S/A 0180816 R.H. STEER SWITCH VALVE S/A 0181083 ASSY ACCUMULATOR...
  • Page 203 AB60J PARTS MANUAL CHASSIS HYDRAULICS – 2 WD CHASSIS HYDRAULICS – 2 WD Thu May 11 20:27:05 UTC 2017...
  • Page 204 AB60J PARTS MANUAL CHASSIS HYDRAULICS – 2 WD Item Part No. Name 0151213 HOSE-8-8S-8S 16 100R2 0180781 HOSE-16-16S45-16S 24 100R12 0180778 HOSE-10-10S-35 SEE DWG 0180777 HOSE-10-10S-10S 28.5 0070789 3/8 INCH HYDRAULIC HOSE 0070764 3/8 INCH HYDRAULIC HOSE 0070772 HOSE-4-4S-4S 54 100R1 0020280 HOSE-4-4S-4S 23.5...

  • Page 205: Chassis Hydraulics Hoses 4 Wheel Drive

    AB60J PARTS MANUAL CHASSIS HYDRAULICS HOSES 4 WHEEL DRIVE HYDRAULICS CHASSIS HYDRAULICS HOSES 4 WHEEL DRIVE Thu May 11 20:27:05 UTC 2017...
  • Page 206 AB60J PARTS MANUAL CHASSIS HYDRAULICS HOSES 4 WHEEL DRIVE Item Part No. Name 0180852 CHASSIS HYDRAULICS HOSES 4 WHEEL DRIVE 0180807 FLOW DIV. MOTION CTRL VALVE S/ 0180855 FRONT TRANSMISSION VALVE ASSY. 0180856 RR TRANS VLV S/A ATB60 4X4 0180817 L.H.
  • Page 207 AB60J PARTS MANUAL CHASSIS HYDRAULICS HOSES 4 WHEEL DRIVE CHASSIS HYDRAULICS HOSES 4 WHEEL DRIVE Thu May 11 20:27:05 UTC 2017...
  • Page 208 AB60J PARTS MANUAL CHASSIS HYDRAULICS HOSES 4 WHEEL DRIVE Item Part No. Name 5060034 SLEEVE HOSE ABRASION 8.5FT GUARD 970469 BLT HEXHD .375-16 1.00 GR5 5093014 CLP CUSH 2.25 VINYL COATED 0180784 HOSE-8-8S-8S 72 SP 0181163 HOSE-4-4S-4S 103 100R2 0080360...

  • Page 209: Chassis Hydraulics 4 Wd

    AB60J PARTS MANUAL CHASSIS HYDRAULICS 4 WD HYDRAULICS CHASSIS HYDRAULICS 4 WD Thu May 11 20:27:05 UTC 2017...
  • Page 210 AB60J PARTS MANUAL CHASSIS HYDRAULICS 4 WD Item Part No. Name 0180852 CHASSIS HYDRAULICS HOSES 4 Shown WHEEL DRIVE 0180807 FLOW DIV. MOTION CTRL VALVE S/ 0180855 FRONT TRANSMISSION VALVE ASSY. 0180856 RR TRANS VLV S/A ATB60 4X4 0180817 L.H. STEER SWITCH VALVE S/A 0180816 R.H.
  • Page 211 AB60J PARTS MANUAL CHASSIS HYDRAULICS 4 WD Item Part No. Name 970469 BLT HEXHD .375-16 1.00 GR5 CHASSIS HYDRAULICS 4 WD Thu May 11 20:27:05 UTC 2017...
  • Page 212 AB60J PARTS MANUAL CHASSIS HYDRAULICS 4 WD, BEFORE JANUARY 2004 HYDRAULICS CHASSIS HYDRAULICS 4 WD, BEFORE JANUARY 2004 Thu May 11 20:27:05 UTC 2017...
  • Page 213 AB60J PARTS MANUAL CHASSIS HYDRAULICS 4 WD, BEFORE JANUARY 2004 Item Part No. Name 0180852 CHASSIS HYDRAULICS HOSES 4 Shown WHEEL DRIVE 0180807 FLOW DIV. MOTION CTRL VALVE S/ 0180855 FRONT TRANSMISSION VALVE ASSY. 0180856 RR TRANS VLV S/A ATB60 4X4 0180817 L.H.
  • Page 214 AB60J PARTS MANUAL CHASSIS HYDRAULICS 4 WD, BEFORE JANUARY 2004 Item Part No. Name 970469 BLT HEXHD .375-16 1.00 GR5 CHASSIS HYDRAULICS 4 WD, BEFORE JANUARY 2004 Thu May 11 20:27:05 UTC 2017...

  • Page 215: Turntable Hydraulics Hoses 2 Wheel Drive

    AB60J PARTS MANUAL TURNTABLE HYDRAULICS HOSES 2 WHEEL DRIVE HYDRAULICS TURNTABLE HYDRAULICS HOSES 2 WHEEL DRIVE Thu May 11 20:27:06 UTC 2017...
  • Page 216 AB60J PARTS MANUAL TURNTABLE HYDRAULICS HOSES 2 WHEEL DRIVE Item Part No. Name 0181512 TURNTABLE HYDRAULICS HOSES 2 WHEEL DRIVE 0181538 CONTROL VALVE AND FITTINGS, WECO 0180864 CHECK VALVE PNNA DUAL RELIEF/ANTI- CAVITATION VALVE 0181671 HYDRAULIC OIL FILTER – BEFORE MARCH 2015...
  • Page 217 AB60J PARTS MANUAL TURNTABLE HYDRAULICS HOSES 2 WHEEL DRIVE TURNTABLE HYDRAULICS HOSES 2 WHEEL DRIVE Thu May 11 20:27:06 UTC 2017...
  • Page 218 AB60J PARTS MANUAL TURNTABLE HYDRAULICS HOSES 2 WHEEL DRIVE Item Part No. Name 0072940 EM. POWER UNIT S/A 5093013 CLP CUSH 2.00 VINYL COATED 970479 CAPSCREW 3/8-16 X 1-1/4 INCH LONG HEX HEAD GRADE 5 986299 WSHR FLAT .375 GR5 ZP 987119 WSHR LOCK .375 SPLIT TYPE...
  • Page 219 AB60J PARTS MANUAL TURNTABLE HYDRAULICS HOSES 2 WHEEL DRIVE Item Part No. Name 0050401 HOSE-6-6S-6S 43 100R2 0020270 HOSE-6-6S-6S 22 100R2 0060305 HOSE-6-6S-6S 60 100R2 0070772 HOSE-4-4S-4S 54 100R1 0020281 HOSE-4-4S-4S 27.63 100R2 0180781 HOSE-16-16S45-16S 24 100R12 0180805 HOSE-16-16S-16S 42 100R12-SP 0180943 HOSE-20-20S-20S 25.5 SP...

  • Page 220: Turntable Hydraulics Hoses 4 Wheel Drive

    AB60J PARTS MANUAL TURNTABLE HYDRAULICS HOSES 4 WHEEL DRIVE HYDRAULICS TURNTABLE HYDRAULICS HOSES 4 WHEEL DRIVE Thu May 11 20:27:07 UTC 2017...
  • Page 221 AB60J PARTS MANUAL TURNTABLE HYDRAULICS HOSES 4 WHEEL DRIVE Item Part No. Name 0181511 TURNTABLE HYDRAULICS HOSES 4 WHEEL DRIVE 0181538 CONTROL VALVE AND FITTINGS, WECO 0180864 CHECK VALVE PNNA DUAL RELIEF/ANTI- CAVITATION VALVE 0181671 HYDRAULIC OIL FILTER – BEFORE MARCH 2015...
  • Page 222 AB60J PARTS MANUAL TURNTABLE HYDRAULICS HOSES 4 WHEEL DRIVE TURNTABLE HYDRAULICS HOSES 4 WHEEL DRIVE Thu May 11 20:27:07 UTC 2017...
  • Page 223 AB60J PARTS MANUAL TURNTABLE HYDRAULICS HOSES 4 WHEEL DRIVE Item Part No. Name 5058824 CLAMP 0072940 EM. POWER UNIT S/A 5093013 CLP CUSH 2.00 VINYL COATED 970719 BLT HEXHD .438-14 X 1.25 GR5 986179 WSHR FLAT .438 987129 WSHR LOCK .438...
  • Page 224 AB60J PARTS MANUAL TURNTABLE HYDRAULICS HOSES 4 WHEEL DRIVE Item Part No. Name 0050401 HOSE-6-6S-6S 43 100R2 0020270 HOSE-6-6S-6S 22 100R2 0060305 HOSE-6-6S-6S 60 100R2 0070772 HOSE-4-4S-4S 54 100R1 0020281 HOSE-4-4S-4S 27.63 100R2 0180781 HOSE-16-16S45-16S 24 100R12 0180805 HOSE-16-16S-16S 42 100R12-SP...

  • Page 225: Turntable Hydraulics 4 Wheel Drive

    TURNTABLE HYDRAULICS 4 WHEEL DRIVE, AFTER JUNE 1991 AB60J PARTS MANUAL HYDRAULICS TURNTABLE HYDRAULICS 4 WHEEL DRIVE, AFTER JUNE 1991 Thu May 11 20:27:07 UTC 2017...
  • Page 226 TURNTABLE HYDRAULICS 4 WHEEL DRIVE, AFTER JUNE 1991 AB60J PARTS MANUAL Item Part No. Name 0180862 TURNTABLE HYDRAULICS 4 WHEEL DRIVE, AFTER JUNE 1991 0180863 CONTROL VALVE AND FITTINGS – VICKERS AFTER FEBRUARY 1998 0180864 CHECK VALVE 0180865 DUAL RELIEF/ANTI CAV.
  • Page 227 TURNTABLE HYDRAULICS 4 WHEEL DRIVE, AFTER JUNE 1991 AB60J PARTS MANUAL TURNTABLE HYDRAULICS 4 WHEEL DRIVE, AFTER JUNE 1991 Thu May 11 20:27:08 UTC 2017...
  • Page 228 TURNTABLE HYDRAULICS 4 WHEEL DRIVE, AFTER JUNE 1991 AB60J PARTS MANUAL Item Part No. Name 5058824 CLAMP 0072940 EM. POWER UNIT S/A 5093019 CLP CUSH .375 VINYL COATED PNNA BOLT HEXHD .348-14 1.25 GR5 PNNA WASHER FLAT .438 PNNA WASHER LOCK .438...
  • Page 229 TURNTABLE HYDRAULICS 4 WHEEL DRIVE, AFTER JUNE 1991 AB60J PARTS MANUAL Item Part No. Name 0070926 HOSE-8-10S-10S 24 100R2 0050401 HOSE-6-6S-6S 43 100R2 0020270 HOSE-6-6S-6S 22 100R2 0060305 HOSE-6-6S-6S 60 100R2 0070772 HOSE-4-4S-4S 54 100R1 0020281 HOSE-4-4S-4S 27.63 100R2 0180781...
  • Page 230 TURNTABLE HYDRAULICS 4 WHEEL DRIVE, AFTER MARCH 2015 AB60J PARTS MANUAL HYDRAULICS TURNTABLE HYDRAULICS 4 WHEEL DRIVE, AFTER MARCH 2015 Thu May 11 20:27:08 UTC 2017...
  • Page 231 TURNTABLE HYDRAULICS 4 WHEEL DRIVE, AFTER MARCH 2015 AB60J PARTS MANUAL Item Part No. Name 0180862 TURNTABLE HYDRAULICS 4 Shown WHEEL DRIVE, AFTER JUNE 1991 0180863 CONTROL VALVE AND FITTINGS – VICKERS AFTER FEBRUARY 1998 0180864 CHECK VALVE 0180865 DUAL RELIEF/ANTI CAV.
  • Page 232 TURNTABLE HYDRAULICS 4 WHEEL DRIVE, AFTER MARCH 2015 AB60J PARTS MANUAL TURNTABLE HYDRAULICS 4 WHEEL DRIVE, AFTER MARCH 2015 Thu May 11 20:27:09 UTC 2017...
  • Page 233 TURNTABLE HYDRAULICS 4 WHEEL DRIVE, AFTER MARCH 2015 AB60J PARTS MANUAL Item Part No. Name 0072940 EM. POWER UNIT S/A 5093013 CLP CUSH 2.00 VINYL COATED 5560031 .3125-18UNC HEX LOCK NUT 5034501 FTG ELB90BHD-4S-4S STL 5074401 FTG LKNT BHD-4 STL 5070005 FTG NIP DIGN-4S FEM –...
  • Page 234 TURNTABLE HYDRAULICS 4 WHEEL DRIVE, AFTER MARCH 2015 AB60J PARTS MANUAL Item Part No. Name 0060305 HOSE-6-6S-6S 60 100R2 0070772 HOSE-4-4S-4S 54 100R1 0020281 HOSE-4-4S-4S 27.63 100R2 0180781 HOSE-16-16S45-16S 24 100R12 0180805 HOSE-16-16S-16S 42 100R12-SP 0180943 HOSE-20-20S-20S 25.5 SP 0180944...
  • Page 235 TURNTABLE HYDRAULICS 4 WHEEL DRIVE, BEFORE JANUARY 1990 AB60J PARTS MANUAL HYDRAULICS TURNTABLE HYDRAULICS 4 WHEEL DRIVE, BEFORE JANUARY 1990 Thu May 11 20:27:09 UTC 2017...
  • Page 236 TURNTABLE HYDRAULICS 4 WHEEL DRIVE, BEFORE JANUARY 1990 AB60J PARTS MANUAL Item Part No. Name 0182198 TURNTABLE HYDRAULICS 4 WHEEL DRIVE 0182196 NON-PROP VALVE ASSY FLUID TECH 0180864 CHECK VALVE 0180865 DUAL RELIEF/ANTI CAV. VALVE 0181671 HYDRAULIC OIL FILTER –...
  • Page 237 TURNTABLE HYDRAULICS 4 WHEEL DRIVE, BEFORE JANUARY 1990 AB60J PARTS MANUAL TURNTABLE HYDRAULICS 4 WHEEL DRIVE, BEFORE JANUARY 1990 Thu May 11 20:27:09 UTC 2017...
  • Page 238 TURNTABLE HYDRAULICS 4 WHEEL DRIVE, BEFORE JANUARY 1990 AB60J PARTS MANUAL Item Part No. Name 5093013 CLP CUSH 2.00 VINYL COATED PNNA BOLT HEXHD .348-14 1.25 GR. 5 PNNA WASHER FLAT .438 PNNA WASHER LOCK .438 5034501 FTG ELB90BHD-4S-4S STL...
  • Page 239 TURNTABLE HYDRAULICS 4 WHEEL DRIVE, BEFORE JANUARY 1990 AB60J PARTS MANUAL Item Part No. Name 0060305 HOSE-6-6S-6S 60 100R2 0070772 HOSE-4-4S-4S 54 100R1 0020281 HOSE-4-4S-4S 27.63 100R2 0180781 HOSE-16-16S45-16S 24 100R12 0180805 HOSE-16-16S-16S 42 100R12-SP 0180943 HOSE-20-20S-20S 25.5 SP 0180944...
  • Page 240 AB60J PARTS MANUAL TURNTABLE HYDRAULICS 4 WHEEL DRIVE HYDRAULICS TURNTABLE HYDRAULICS 4 WHEEL DRIVE Thu May 11 20:27:10 UTC 2017 3-10...
  • Page 241 AB60J PARTS MANUAL TURNTABLE HYDRAULICS 4 WHEEL DRIVE Item Part No. Name 0182198 TURNTABLE HYDRAULICS 4 Shown WHEEL DRIVE 0182196 NON-PROP VALVE ASSY FLUID TECH 0180864 CHECK VALVE 0180865 DUAL RELIEF/ANTI CAV. VALVE 0181671 HYDRAULIC OIL FILTER – BEFORE MARCH 2015...
  • Page 242 AB60J PARTS MANUAL TURNTABLE HYDRAULICS 4 WHEEL DRIVE TURNTABLE HYDRAULICS 4 WHEEL DRIVE Thu May 11 20:27:10 UTC 2017 3-10...
  • Page 243 AB60J PARTS MANUAL TURNTABLE HYDRAULICS 4 WHEEL DRIVE Item Part No. Name 5093013 CLP CUSH 2.00 VINYL COATED PNNA BOLT HEXHD .348-14 1.25 GR. 5 PNNA WASHER FLAT .438 PNNA WASHER LOCK .438 5034501 FTG ELB90BHD-4S-4S STL 5074401 FTG LKNT BHD-4 STL 5070005 FTG NIP DIGN-4S FEM –...
  • Page 244 AB60J PARTS MANUAL TURNTABLE HYDRAULICS 4 WHEEL DRIVE Item Part No. Name 0060305 HOSE-6-6S-6S 60 100R2 0070772 HOSE-4-4S-4S 54 100R1 0020281 HOSE-4-4S-4S 27.63 100R2 0180781 HOSE-16-16S45-16S 24 100R12 0180805 HOSE-16-16S-16S 42 100R12-SP 0180943 HOSE-20-20S-20S 25.5 SP 0180944 HOSE-20-20S-20S 33 SP 0020280 HOSE-4-4S-4S 23.5...
  • Page 245 AB60J PARTS MANUAL HYDRALUIC SUB-ASSEMBLY KU/CE -KIT1 HYDRAULICS Image does not exist HYDRALUIC SUB-ASSEMBLY KU/CE -KIT1 Thu May 11 20:27:11 UTC 2017 3-11...
  • Page 246 AB60J PARTS MANUAL HYDRALUIC SUB-ASSEMBLY KU/CE -KIT1 Item Part No. Name K0182457 A HYDRALUIC SUB-ASSEMBLY KU/CE -KIT1 0072940 EM. POWER UNIT S/A 0082055 ASSY ACCUMULATOR 300 PSI 0180517 HYDR OIL RSVR ASSY 0180807 FLOW DIV. MOTION CTRL VALVE S/ 0180816 R.H.

  • Page 247: Turntable-Kit4 Ku/Ce

    AB60J PARTS MANUAL TURNTABLE-KIT4 KU/CE HYDRAULICS Image does not exist TURNTABLE-KIT4 KU/CE Thu May 11 20:27:11 UTC 2017 3-12...
  • Page 248 AB60J PARTS MANUAL TURNTABLE-KIT4 KU/CE Item Part No. Name K0182459 A TURNTABLE-KIT4 KU/CE 0020270 HOSE-6-6S-6S 22 100R2 0020276 HOSE-6-6S-6S 27.625 100R2 0020279 HOSE-6-6S-6S 45.75 100R2 0020280 HOSE-4-4S-4S 23.5 0020281 HOSE-4-4S-4S 27.63 100R2 0020283 HOSE-4-4S-4S 15.25 100R1 0050401 HOSE-6-6S-6S 43 100R2...
  • Page 249 AB60J PARTS MANUAL TURNTABLE-KIT4 KU/CE Item Part No. Name 0180946 HOSE-4-4S-4S 18.5 100R2 0181188 WIRE ASSY 110V POWER CORD 110 in 0182044 ASSY CONT BOX MTG BRKT 480652 ALARM97DBA DUAL TONE 12/24V 969989 BLT HEXHD .250-20 1.75 GR5 970049 BLT HEXHD .250-20 1.00 GR5 970239 BLT HEXHD .313-18 .750 GR5...
  • Page 250 AB60J PARTS MANUAL TURNTABLE-KIT4 KU/CE Item Part No. Name 987109 WSHR LOCK .313 SPLIT TYPE 987119 WSHR LOCK .375 SPLIT TYPE 987129 WSHR LOCK .438 987139 WSHR LOCK .500 SPLIT TYPE 3040046 TERM MALE250FI 22/18 3040070 NUT LKG HUB .500 3040187 CONN .500 .313-.438...
  • Page 251 AB60J PARTS MANUAL TURNTABLE-KIT4 KU/CE Item Part No. Name 5560031 .3125-18UNC HEX LOCK NUT 5560033 NUT HEX LKG .375-16 5560034 10-24UNC HEX LOCK NUT 5560038 NUT HEX LKG 10-32 5560039 NUT HEX LKG .500-13 5560082 HOSE GUIDE .250 RUBBER EDGE 5560138 BLT HEXHD LKG .500-13 1.00...
  • Page 252 AB60J PARTS MANUAL TURNTABLE-KIT4 KU/CE Item Part No. Name 967359 HOSESAE30R2-03 TYPE 3 3/16 in IDFUEL LINE HOSE 5010011 HOSE SAE30R2-05 .312 FUEL 010178-001 FITTING BARBED WEATHERHEAD 1541 7630286 FILTER IN-LINE FUEL- 5550028 CLP WORM DRV .25-.63 .31 BAND 0192289...
  • Page 253 AB60J PARTS MANUAL TURNTABLE-KIT4 KU/CE Item Part No. Name 5070028 FTG NIP DIGN-4S FEM METRIC TURNTABLE-KIT4 KU/CE Thu May 11 20:27:11 UTC 2017 3-12...

  • Page 254: Flow Divider/Motion Control Valve Assembly

    AB60J PARTS MANUAL FLOW DIVIDER/MOTION CONTROL VALVE ASSEMBLY HYDRAULICS FLOW DIVIDER/MOTION CONTROL VALVE ASSEMBLY Thu May 11 20:27:11 UTC 2017 3-13...
  • Page 255 AB60J PARTS MANUAL FLOW DIVIDER/MOTION CONTROL VALVE ASSEMBLY Item Part No. Name 0180807 FLOW DIV. MOTION CTRL VALVE S/ 0151728 PLT TRANSMISSION VALVE 6030036 FLOW DIVIDER 6010570 VALVE PACKAGE 0180809 6019052 VALVE MOTION CONTROL 0181077 ORIFICE 0181161 HOSE-4-4S-4S 15.25 100R2...

  • Page 256: Control Valve And Fittings, Weco

    AB60J PARTS MANUAL CONTROL VALVE AND FITTINGS, WECO HYDRAULICS CONTROL VALVE AND FITTINGS, WECO Thu May 11 20:27:12 UTC 2017 3-14...
  • Page 257 AB60J PARTS MANUAL CONTROL VALVE AND FITTINGS, WECO Item Part No. Name 0181538 CONTROL VALVE AND FITTINGS, WECO 6010577 PACKAGE VALVE AB60 0181449 ANGLE, PACKAGE VALVE MOUNTING 6010591 SOLENOID VALVE AND COIL ASSEMBLY 0180802 SEAL REPAIR KIT 6010392 REPLACEMENT CARTRIDGE...
  • Page 258 AB60J PARTS MANUAL CONTROL VALVE AND FITTINGS, WECO Item Part No. Name 5569906 CAPSCREW 5/16-18 X 5-1/4 INCH LONG HEX HEAD GRADE CONTROL VALVE AND FITTINGS, WECO Thu May 11 20:27:12 UTC 2017 3-14...
  • Page 259 AB60J PARTS MANUAL CONTROL VALVE – WECO (REXROTH) HYDRAULICS CONTROL VALVE – WECO (REXROTH) Thu May 11 20:27:12 UTC 2017 3-15...

  • Page 260: Control Valve - Weco (Rexroth)

    AB60J PARTS MANUAL CONTROL VALVE – WECO (REXROTH) Item Part No. Name 0180788 CONTROL VALVE – WECO (REXROTH) 6010577 PACKAGE VALVE AB60 6010580 MANIFOLD BODY 6010581 INLET BODY 6010621 SANDWICH RELIEF VALVE 6010582 REPLACEMENT VALVE BODY 6010322 PRESSURE RELIEF VALVE...
  • Page 261 AB60J PARTS MANUAL CONTROL VALVE – WECO (REXROTH) Item Part No. Name 3040430 REPLACEMENT SOLEMOID COIL 6010590 DIRECTIONALCONTROL COIL 3040430 REPLACEMENT SOLEMOID COIL 6010322 PRESSURE RELIEF VALVE (FACTORY PRESET, DO NOT RESET) 0150563 SEAL REPAIR KIT 6010328 PRESSURE RELIEF VALVE -...
  • Page 262 AB60J PARTS MANUAL CONTROL VALVE – WECO (REXROTH) Item Part No. Name 6010587 SHUTTLE VALVE 0150563 SEAL REPAIR KIT 6010591 SOLENOID VALVE AND COIL ASSEMBLY 0180802 SEAL REPAIR KIT 6010392 REPLACEMENT CARTRIDGE 3040496 REPLACEMENT COIL, 12 VOLT CONTROL VALVE – WECO (REXROTH)
  • Page 263 CONTROL VALVE AND FITTINGS – VICKERS AFTER FEBRUARY 1998 AB60J PARTS MANUAL HYDRAULICS CONTROL VALVE AND FITTINGS – VICKERS AFTER FEBRUARY 1998 Thu May 11 20:27:12 UTC 2017 3-16...

  • Page 264: Control Valve And Fittings - Vickers After February 1998

    CONTROL VALVE AND FITTINGS – VICKERS AFTER FEBRUARY 1998 AB60J PARTS MANUAL Item Part No. Name 0180863 CONTROL VALVE AND FITTINGS – VICKERS AFTER FEBRUARY 1998 6010577 PACKAGE VALVE AB60 0181449 ANGLE, PACKAGE VALVE MOUNTING 5065805 FTG ADAPTER STRTHDL-6B-6S 5065806...

  • Page 265: Control Valve Vickers

    AB60J PARTS MANUAL CONTROL VALVE VICKERS HYDRAULICS CONTROL VALVE VICKERS Thu May 11 20:27:13 UTC 2017 3-17...
  • Page 266 AB60J PARTS MANUAL CONTROL VALVE VICKERS Item Part No. Name 6010577 PACKAGE VALVE AB60 6010694 MANIFOLD BODY 6010695 EXTEND CONTROL VALVE ASSY (REGEN) 3040551 REPLACEMENT SOLENOID, 12 VOLT DC 6010696 LEVELCONTROL VALVE 3040551 REPLACEMENT SOLENOID, 12 VOLT DC 6010697 STEER CONTROL VALVE...
  • Page 267 AB60J PARTS MANUAL CONTROL VALVE VICKERS Item Part No. Name 6010705 CHECK VALVE CARTRIDGE 565666 SEAL REPAIR KIT 6010706 RELIEF VALVE CARTRIDGE 565666 SEAL REPAIR KIT 6010591 SOLENOID VALVE AND COIL ASSEMBLY 0180802 SEAL REPAIR KIT 6010392 REPLACEMENT CARTRIDGE 3040496...
  • Page 268 NON-PROP VALVE ASSY FLUID TECH AFTER SEPTEMBER 2007 AB60J PARTS MANUAL HYDRAULICS NON-PROP VALVE ASSY FLUID TECH AFTER SEPTEMBER 2007 Thu May 11 20:27:13 UTC 2017 3-18...

  • Page 269: Non-Prop Valve Assy Fluid Tech After September 2007

    NON-PROP VALVE ASSY FLUID TECH AFTER SEPTEMBER 2007 AB60J PARTS MANUAL Item Part No. Name 0182196 NON-PROP VALVE ASSY FLUID TECH 6019058 VALVE NON-PROP (FUILD TECH) 0181449 ANGLE, PACKAGE VALVE MOUNTING 970239 BLT HEXHD .313-18 .750 GR5 986269 WASHER, FLAT, .313...
  • Page 270 NON-PROP VALVE ASSY FLUID TECH AFTER SEPTEMBER 2007 AB60J PARTS MANUAL Item Part No. Name 5065707 FTG, HYD -6 MB TO -6 MJIC 5070005 FTG NIP DIGN-4S FEM – NON CE MACHINES ONLY NON-PROP VALVE ASSY FLUID TECH AFTER SEPTEMBER 2007...
  • Page 271 AB60J PARTS MANUAL NON-PROPORTIONAL VALVE ASSEMBLY, FLUID TECH HYDRAULICS NON-PROPORTIONAL VALVE ASSEMBLY, FLUID TECH Thu May 11 20:27:13 UTC 2017 3-19...

  • Page 272: Non-Proportional Valve Assembly, Fluid Tech

    AB60J PARTS MANUAL NON-PROPORTIONAL VALVE ASSEMBLY, FLUID TECH Item Part No. Name 6019058 VALVE NON-PROP (FUILD TECH) 6019189 3.5 FLOW REGULATOR 6019190 3-WAY SOL VALVE 3220126 10VDC DRZ COIL 6019192 3 WAY SOL VALVE 6019041 SHUTTLE VALVE 6091701 SEAL KIT...

  • Page 273: Non-Prop Valve Assembly Ce

    AB60J PARTS MANUAL NON-PROP VALVE ASSEMBLY CE HYDRAULICS NON-PROP VALVE ASSEMBLY CE Thu May 11 20:27:14 UTC 2017 3-20...
  • Page 274 AB60J PARTS MANUAL NON-PROP VALVE ASSEMBLY CE Item Part No. Name 0182462 A NON-PROP VALVE ASSY CE Shown 0075379 DECAL LEVEL RELIEF PRESSURE 0082010 DECAL SET 0181449 ANGLE, PACKAGE VALVE MOUNTING 970239 BLT HEXHD .313-18 .750 GR5 986269 WASHER, FLAT, .313...
  • Page 275 AB60J PARTS MANUAL CONTROL VALVE AND FITTINGS, DRIVE/LIFT/SWING HYDRAULICS CONTROL VALVE AND FITTINGS, DRIVE/LIFT/SWING Thu May 11 20:27:14 UTC 2017 3-21...

  • Page 276: Control Valve And Fittings, Drive/Lift/Swing

    AB60J PARTS MANUAL CONTROL VALVE AND FITTINGS, DRIVE/LIFT/SWING Item Part No. Name 0180869 PROP. DRIVE VALVE SUBASSY 6010576 CONTROL VALVE, DRIVE/LIFT/SWING 0110156 PRESSURE MANIFOLD 5025002 STR THD ADAPTER/37 DEGREE SWIVEL (-16) 5035710 STRAIGHT THREAD 45° ELBOW 5065718 FTG, HYD -16 MB TO -16 MJIC...
  • Page 277 AB60J PARTS MANUAL CONTROL VALVE AND FITTINGS, DRIVE/LIFT/SWING Item Part No. Name 5035324 STRAIGHT THREAD 90° ELBOW CONTROL VALVE AND FITTINGS, DRIVE/LIFT/SWING Thu May 11 20:27:14 UTC 2017 3-21...

  • Page 278: Non-Prop Valve

    AB60J PARTS MANUAL NON-PROP VALVE HYDRAULICS NON-PROP VALVE Thu May 11 20:27:15 UTC 2017 3-22...
  • Page 279 AB60J PARTS MANUAL NON-PROP VALVE Item Part No. Name 6019059 NON-PROP VALVE 6019189 3.5 FLOW REGULATOR 6019190 3-WAY SOL VALVE 3220126 10VDC DRZ COIL 6019192 3 WAY SOL VALVE 6019041 SHUTTLE VALVE 561176 CHECK VALVE 6019194 PROPORTIONAL 2-WAY 6019195 12 VDC DIN COIL...
  • Page 280 AB60J PARTS MANUAL NON-PROP VALVE Item Part No. Name PNNA #10-24 X 3.00 HEX SOCKET HEAD CAPSCREW PNNA #10 HI-COLLAR LOCK WASHER PNNA -6SAE O-RING FLUSH HEAD PLUG PNNA H/F CP10-40N CAVITY PLUG PNNA H/F RV10-20A-0-NC-33/17.00 PNNA H/F CP10-20-N CAVITY PLUG...

  • Page 281: Control Valve, Drive/Lift/Swing, Before March 1994

    AB60J PARTS MANUAL CONTROL VALVE, DRIVE/LIFT/SWING, BEFORE MARCH 1994 HYDRAULICS CONTROL VALVE, DRIVE/LIFT/SWING, BEFORE MARCH 1994 Thu May 11 20:27:16 UTC 2017 3-23...
  • Page 282 AB60J PARTS MANUAL CONTROL VALVE, DRIVE/LIFT/SWING, BEFORE MARCH 1994 Item Part No. Name 6010576 CONTROL VALVE, DRIVE/LIFT/SWING 181171 VALVE SECTION SEAL REPAIR 181253 CONTROL SECTION O-RING SEAL KIT 6010648 INLET SECTION 6010649 DRIVE CONTROL VALVE SECTION 6010650 LIFT CONTROL VALVE...

  • Page 283: Control Valve - Apitech

    AB60J PARTS MANUAL CONTROL VALVE – APITECH HYDRAULICS CONTROL VALVE – APITECH Thu May 11 20:27:16 UTC 2017 3-24...
  • Page 284 AB60J PARTS MANUAL CONTROL VALVE – APITECH Item Part No. Name 6010576 CONTROL VALVE, DRIVE/LIFT/SWING 6010648 INLET SECTION 0190920 INLET TO DRIVE SEAL KIT 6010649 DRIVE CONTROL VALVE SECTION 6010650 LIFT CONTROL VALVE SECTION 6010651 SWING CONTROL VALVE SECTION 6010652...
  • Page 285 AB60J PARTS MANUAL AC GENERATOR VALVE HYDRAULICS AC GENERATOR VALVE Thu May 11 20:27:16 UTC 2017 3-25...

  • Page 286: Ac Generator Valve

    AB60J PARTS MANUAL AC GENERATOR VALVE Item Part No. Name 0152831 AC GENERATOR VALVE 6010489 AC GENERATOR VALVE 6010508 CARTRIDGE VALVE WITH COIL 6010509 REPLACEMENT CARTRIDGE Shown VALVE 3040457 REPLACEMENT COIL, 12 VOLT Shown 6018901 FLOW CONTROL VALVE CARTRIDGE 6010510...
  • Page 287 AB60J PARTS MANUAL ACCUMULATOR SUB-ASSEMBLY HYDRAULICS ACCUMULATOR SUB-ASSEMBLY Thu May 11 20:27:16 UTC 2017 3-26...

  • Page 288: Accumulator Sub-Assembly

    AB60J PARTS MANUAL ACCUMULATOR SUB-ASSEMBLY Item Part No. Name 0082055B ACCUMULATOR SUB- Shown ASSEMBLY 6070005 ACCUMULATOR 5065711 FTG ADPTR STRTHD-12B-8S STL 1 5064002 FTG RDCR TUBE END-8S-4S STL 6063906 FITTING NUT ACCUMULATOR SUB-ASSEMBLY Thu May 11 20:27:17 UTC 2017 3-26...
  • Page 289 AB60J PARTS MANUAL TURNTABLE ACCUMULATOR, AFTER MARCH 2006 HYDRAULICS TURNTABLE ACCUMULATOR, AFTER MARCH 2006 Thu May 11 20:27:17 UTC 2017 3-27...

  • Page 290: Turntable Accumulator, After March 2006

    AB60J PARTS MANUAL TURNTABLE ACCUMULATOR, AFTER MARCH 2006 Item Part No. Name 0052055 TURNTABLE ACCUMULATOR 5037003 ADAPTER 90 DEG ELBOW SWIVEL -4 JIC 5063906 FTG NUT-8S STL 5064002 FTG RDCR TUBE END-8S-4S STL 5065711 FTG ADPTR STRTHD-12B-8S STL 1 6070005...

  • Page 291: Accumulator - (Shipped Charged)

    AB60J PARTS MANUAL ACCUMULATOR – (SHIPPED CHARGED) HYDRAULICS ACCUMULATOR – (SHIPPED CHARGED) Thu May 11 20:27:17 UTC 2017 3-28...
  • Page 292 AB60J PARTS MANUAL ACCUMULATOR – (SHIPPED CHARGED) Item Part No. Name 0181083 ASSY ACCUMULATOR 6070005 ACCUMULATOR 5076003 ADAPTER STRAIGHT-12SAE TO- 8SAE FEMALE 6010635 CHECK VALVE, ORIFICED 5065709 FTG, HYD -8 MB TO -8 MJIC ACCUMULATOR – (SHIPPED CHARGED) Thu May 11 20:27:17 UTC 2017...
  • Page 293 AB60J PARTS MANUAL TURNTABLE ACCUMULATOR BEFORE MARCH 2006 HYDRAULICS TURNTABLE ACCUMULATOR BEFORE MARCH 2006 Thu May 11 20:27:17 UTC 2017 3-29...

  • Page 294: Turntable Accumulator Before March 2006

    AB60J PARTS MANUAL TURNTABLE ACCUMULATOR BEFORE MARCH 2006 Item Part No. Name 0082055 ASSY ACCUMULATOR 300 PSI 6070005 ACCUMULATOR 5065711 FTG ADPTR STRTHD-12B-8S STL 1 5064002 FTG RDCR TUBE END-8S-4S STL 6063906 FITTING NUT TURNTABLE ACCUMULATOR BEFORE MARCH 2006 Thu May 11 20:27:17 UTC 2017...

  • Page 295: Centerpost Sub-Assembly

    AB60J PARTS MANUAL CENTERPOST SUB-ASSEMBLY HYDRAULICS CENTERPOST SUB-ASSEMBLY Thu May 11 20:27:17 UTC 2017 3-30...
  • Page 296 AB60J PARTS MANUAL CENTERPOST SUB-ASSEMBLY Item Part No. Name 0110465 CENTERPOST 0110465_A 0110466 CENTERPOST MANIFOLD 0110467 CENTERPOST HOUSING 970919 BLT HEXHD .500-13 1.75 GR5 5560039 NUT HEX LKG .500-13 5590003 RETAINING RING 7110155 O-RING 4 OD X 4.19 ID X .10 DIA 7110346 O-RING 4.125 ID 4.5 OD .1875 DIA 2...

  • Page 297: Centerpost Sub-Assembly 4Wd

    AB60J PARTS MANUAL CENTERPOST SUB-ASSEMBLY 4WD HYDRAULICS CENTERPOST SUB-ASSEMBLY 4WD Thu May 11 20:27:17 UTC 2017 3-31...
  • Page 298 AB60J PARTS MANUAL CENTERPOST SUB-ASSEMBLY 4WD Item Part No. Name A18048 CENTERPOST SUB-ASSEMBLY 0110465 CENTERPOST 0111084 BRACKET FITTING HYDROMOTION 970269 BLT HEXHD .313-18 1.25 GR5- 984089 .3125-18UNC HEX NUT 987109 WSHR LOCK .313 SPLIT TYPE 5020001 FTG ELBOW HYDROMOTION SWIVEL...
  • Page 299 AB60J PARTS MANUAL CENTERPOST SUB-ASSEMBLY 4WD Item Part No. Name 5590003 RETAINING RING CENTERPOST SUB-ASSEMBLY 4WD Thu May 11 20:27:17 UTC 2017 3-31...

  • Page 300: Centerpost Sub-Assembly 2Wd

    AB60J PARTS MANUAL CENTERPOST SUB-ASSEMBLY 2WD HYDRAULICS CENTERPOST SUB-ASSEMBLY 2WD Thu May 11 20:27:18 UTC 2017 3-32...
  • Page 301 AB60J PARTS MANUAL CENTERPOST SUB-ASSEMBLY 2WD Item Part No. Name A18048 CENTERPOST SUB-ASSEMBLY 0110465 CENTERPOST 5035305 ADAPTER 90 DEG ELBOW -6 SAE TO -6 JIC 5035311 FTG ELB90STRTHD-12B16 STL 5035316 FTG ELB90STRTHD-10B-8S STL- 5035318 ADAPTER 90 DEG ELBOW -6 SAE TO -4 JIC...

  • Page 302: Centerpost And Fittings

    AB60J PARTS MANUAL CENTERPOST AND FITTINGS HYDRAULICS CENTERPOST AND FITTINGS Thu May 11 20:27:18 UTC 2017 3-33...
  • Page 303 AB60J PARTS MANUAL CENTERPOST AND FITTINGS Item Part No. Name 0180935 CENTERPOST AND FITTINGS 0110465 CENTERPOST 0070991 SEAL REPAIR KIT – ITEM NOT Shown SHOWN 0110466 CENTERPOST MANIFOLD 0110467 CENTERPOST HOUSING 5590003 RETAINING RING KIT ITEM PARBAK SEAL - (NOT SOLD...

  • Page 304: Check Valve

    AB60J PARTS MANUAL CHECK VALVE HYDRAULICS CHECK VALVE Thu May 11 20:27:18 UTC 2017 3-34...
  • Page 305 AB60J PARTS MANUAL CHECK VALVE Item Part No. Name 0180864 CHECK VALVE 6010579 CHECK VALVE MANIFOLD 6010605 SEAL REPAIR KIT 6010565 CHECK VALVE CARTRIDGE 6010656 CHECK VALVE 6010605 SEAL REPAIR KIT 5035710 STRAIGHT THREAD 45° ELBOW 5065707 FTG, HYD -6 MB TO -6 MJIC...
  • Page 306 AB60J PARTS MANUAL CHECK VALVE SUB-ASSEMBLY HYDRAULICS CHECK VALVE SUB-ASSEMBLY Thu May 11 20:27:18 UTC 2017 3-35...

  • Page 307: Check Valve Sub-Assembly

    AB60J PARTS MANUAL CHECK VALVE SUB-ASSEMBLY Item Part No. Name 0182461 A CHECK VALVE SUB-ASSEMBLY 6010579 CHECK VALVE MANIFOLD 5065718 FTG, HYD -16 MB TO -16 MJIC 5065707 FTG, HYD -6 MB TO -6 MJIC 5065709 FTG, HYD -8 MB TO -8 MJIC...
  • Page 308 AB60J PARTS MANUAL EXTENSION CYLINDER – ROSENBOOM HYDRAULICS EXTENSION CYLINDER – ROSENBOOM Thu May 11 20:27:19 UTC 2017 3-36...

  • Page 309: Extension Cylinder - Rosenboom

    AB60J PARTS MANUAL EXTENSION CYLINDER – ROSENBOOM Item Part No. Name 0181912 EXTENSION CYLINDER – ROSENBOOM PNNA TUBE - (NOT SOLD SEPARATELY) 6091316 6091317 HEAD GLAND 6091318 PISTON 6091319 ROD SPACER 6010794 CARTRIDGE, HOLDING VALVE - (FACTORY PRESET, DO NOT...

  • Page 310: Jib Boom Lift Cylinder

    AB60J PARTS MANUAL JIB BOOM LIFT CYLINDER HYDRAULICS JIB BOOM LIFT CYLINDER Thu May 11 20:27:19 UTC 2017 3-37...

  • Page 311: Jib Boom Lift Cylinder

    AB60J PARTS MANUAL JIB BOOM LIFT CYLINDER Item Part No. Name 0180901 JIB LIFT CYLINDER SUB ASSY 0191811 JIB BOOM LIFT CYLINDER – ROSENBOOM 5035305 ADAPTER 90 DEG ELBOW -6 SAE TO -6 JIC JIB BOOM LIFT CYLINDER Thu May 11 20:27:19 UTC 2017...
  • Page 312 AB60J PARTS MANUAL JIB BOOM LIFT CYLINDER – ROSENBOOM HYDRAULICS JIB BOOM LIFT CYLINDER – ROSENBOOM Thu May 11 20:27:19 UTC 2017 3-38...

  • Page 313: Jib Boom Lift Cylinder - Rosenboom

    AB60J PARTS MANUAL JIB BOOM LIFT CYLINDER – ROSENBOOM Item Part No. Name 0191811 JIB BOOM LIFT CYLINDER – ROSENBOOM PNNA TUBE - (NOT SOLD SEPARATELY) 6091292 6091288 HEAD GLAND CAP 6091289 PISTON 6091291 ROD SPACER 6091246 SPRING 6091241 POPPET...
  • Page 314 AB60J PARTS MANUAL JIB BOOM LIFT CYLINDER – ROSENBOOM Item Part No. Name KIT ITEM ROD WIPER - (NOT SOLD SEPARATELY) KIT ITEM WEARBAND - (NOT SOLD SEPARATELY) KIT ITEM WEARBAND - (NOT SOLD SEPARATELY) KIT ITEM LOCKING INSERT - (NOT SOLD SEPARATELY) JIB BOOM LIFT CYLINDER –...
  • Page 315 AB60J PARTS MANUAL MAIN BOOM LIFT CYLINDER HYDRAULICS MAIN BOOM LIFT CYLINDER Thu May 11 20:27:19 UTC 2017 3-39...

  • Page 316: Main Boom Lift Cylinder

    AB60J PARTS MANUAL MAIN BOOM LIFT CYLINDER Item Part No. Name 0180913 MAIN BOOM LIFT CYLINDER 0181915 CYLINDER MAIN BOOM LIFT 5035305 ADAPTER 90 DEG ELBOW -6 SAE TO -6 JIC MAIN BOOM LIFT CYLINDER Thu May 11 20:27:19 UTC 2017...
  • Page 317 AB60J PARTS MANUAL MAIN BOOM LIFT CYLINDER - ROSENBOOM HYDRAULICS MAIN BOOM LIFT CYLINDER - ROSENBOOM Thu May 11 20:27:19 UTC 2017 3-40...

  • Page 318: Main Boom Lift Cylinder - Rosenboom

    AB60J PARTS MANUAL MAIN BOOM LIFT CYLINDER - ROSENBOOM Item Part No. Name 0181915 CYLINDER MAIN BOOM LIFT PNNA TUBE - (NOT SOLD SEPARATELY) 6091328 6091243 HEAD GLAND 6091242 PISTON 6010606 CARTRIDGE HOLDING VALVE - (FACTORY PRESET, DO NOT RESET)
  • Page 319 AB60J PARTS MANUAL MAIN BOOM LIFT CYLINDER - ROSENBOOM Item Part No. Name KIT ITEM ROD WIPER - (NOT SOLD SEPARATELY) KIT ITEM WEARBAND - (NOT SOLD SEPARATELY) KIT ITEM WEARBAND - (NOT SOLD SEPARATELY) KIT ITEM LOCKING INSERT - (NOT SOLD...
  • Page 320 AB60J PARTS MANUAL MASTER LEVEL CYLINDER HYDRAULICS MASTER LEVEL CYLINDER Thu May 11 20:27:20 UTC 2017 3-41...

  • Page 321: Master Level Cylinder

    AB60J PARTS MANUAL MASTER LEVEL CYLINDER Item Part No. Name 0180914 MASTER LEVEL CYLINDER 0180664 MASTER LEVEL CYLINDER PRINCE 0180645 BRACKET 0180631 0150179 PIN LOCK 5065703 FTG, HYD -4 MB TO -4 MJIC 5036703 ADAPTER TEE SWIVEL -4 JIC TO...

  • Page 322: Master Level Cylinder - Gbi

    AB60J PARTS MANUAL MASTER LEVEL CYLINDER – GBI HYDRAULICS MASTER LEVEL CYLINDER – GBI Thu May 11 20:27:20 UTC 2017 3-42...

  • Page 323: Master Level Cylinder Prince

    AB60J PARTS MANUAL MASTER LEVEL CYLINDER – GBI Item Part No. Name 0180664 MASTER LEVEL CYLINDER Shown PRINCE PNNA TUBE - (NOT SOLD SEPARATELY) 8070776 8070238 RETAINER 8070587 HEAD GLAND 8070667 PISTON 8070775 SPACER 8070774 SPACER 8070663 BUSHING 8070773 BUSHING...
  • Page 324 AB60J PARTS MANUAL MASTER LEVEL CYLINDER PRINCE HYDRAULICS MASTER LEVEL CYLINDER PRINCE Thu May 11 20:27:20 UTC 2017 3-43...
  • Page 325 AB60J PARTS MANUAL MASTER LEVEL CYLINDER PRINCE Item Part No. Name 0180664 MASTER LEVEL CYLINDER PRINCE 8160258 PISTON ROD PNNA BUTT AND TUBE - (NOT SOLD SEPARATELY) 8160188 BUSHING 8160260 SPACER 8160261 BUSHING 6091102 PISTON 8160262 GLAND 8160263 SPACER 6091104...

  • Page 326: Master Level Cylinder - Texas

    AB60J PARTS MANUAL MASTER LEVEL CYLINDER – TEXAS HYDRAULICS MASTER LEVEL CYLINDER – TEXAS Thu May 11 20:27:20 UTC 2017 3-44...
  • Page 327 AB60J PARTS MANUAL MASTER LEVEL CYLINDER – TEXAS Item Part No. Name 0180664 MASTER LEVEL CYLINDER PRINCE PNNA CYLINDER TUBE - (NOT SOLD SEPARATELY) 8200119 8200118 PISTON 8200168 HEAD 8200110 LOCK NUT 8200167 SPACER 8200149 SET SCREW 8200112 PORT PLUG...
  • Page 328 AB60J PARTS MANUAL RISER BOOM LIFT CYLINDER HYDRAULICS RISER BOOM LIFT CYLINDER Thu May 11 20:27:21 UTC 2017 3-45...

  • Page 329: Riser Boom Lift Cylinder

    AB60J PARTS MANUAL RISER BOOM LIFT CYLINDER Item Part No. Name 0180936 RISER BOOM LIFT CYLINDER PNNA CYLINDER, RISER BOOM LIFT 5035305 ADAPTER 90 DEG ELBOW -6 SAE TO -6 JIC 5065703 FTG, HYD -4 MB TO -4 MJIC RISER BOOM LIFT CYLINDER...
  • Page 330 AB60J PARTS MANUAL RISER BOOM LIFT CYLINDER – GBI HYDRAULICS RISER BOOM LIFT CYLINDER – GBI Thu May 11 20:27:21 UTC 2017 3-46...

  • Page 331: Riser Boom Lift Cylinder - Gbi

    AB60J PARTS MANUAL RISER BOOM LIFT CYLINDER – GBI Item Part No. Name 0180665 RISER BOOM LIFT CYLINDER – PNNA TUBE - (NOT SOLD SEPARATELY) 8070791 8070790 RETAINER 8070789 BEARING 8070788 PISTON 8070787 SPACER 8070786 SPACER 8070785 SPACER 8070012 POPPET...
  • Page 332 AB60J PARTS MANUAL RISER BOOM LIFT CYLINDER – GBI Item Part No. Name KIT ITEM O-RING - (NOT SOLD SEPARATELY) KIT ITEM WEAR RING - (NOT SOLD SEPARATELY) KIT ITEM U-RING - (NOT SOLD SEPARATELY) KIT ITEM WIPER - (NOT SOLD SEPARATELY) RISER BOOM LIFT CYLINDER –...

  • Page 333: Riser Boom Lift Cylinder - Prince, Before May 2000

    AB60J PARTS MANUAL RISER BOOM LIFT CYLINDER – PRINCE, BEFORE MAY 2000 HYDRAULICS RISER BOOM LIFT CYLINDER – PRINCE, BEFORE MAY 2000 Thu May 11 20:27:21 UTC 2017 3-47...
  • Page 334 AB60J PARTS MANUAL RISER BOOM LIFT CYLINDER – PRINCE, BEFORE MAY 2000 Item Part No. Name 0180665 RISER BOOM LIFT CYLINDER – 8160294 PISTON ROD PNNA BUTT AND TUBE - (NOT SOLD SEPARATELY) 8160296 PISTON 8160297 PISTON 8160298 GLAND 8160299...
  • Page 335 AB60J PARTS MANUAL RISER BOOM LIFT CYLINDER – PRINCE, BEFORE MAY 2000 Item Part No. Name KIT ITEM BU-WASHER - (NOT SOLD SEPARATELY) KIT ITEM U-CUP - (NOT SOLD SEPARATELY) KIT ITEM WIPER - (NOT SOLD SEPARATELY) 8160315 ROD AND WIPER COVER RISER BOOM LIFT CYLINDER –...
  • Page 336 AB60J PARTS MANUAL RISER BOOM LIFT CYLINDER – ROSENBOOM HYDRAULICS RISER BOOM LIFT CYLINDER – ROSENBOOM Thu May 11 20:27:22 UTC 2017 3-48...

  • Page 337: Riser Boom Lift Cylinder - Rosenboom

    AB60J PARTS MANUAL RISER BOOM LIFT CYLINDER – ROSENBOOM Item Part No. Name 0181913 RISER BOOM LIFT CYLINDER – ROSENBOOM PNNA TUBE - (NOT SOLD SEPARATELY) 6091322 6091324 HEAD GLAND 6091323 PISTON 6010606 CARTRIDGE HOLDING VALVE - (FACTORY PRESET, DO NOT...
  • Page 338 AB60J PARTS MANUAL RISER BOOM LIFT CYLINDER – ROSENBOOM Item Part No. Name KIT ITEM ROD WIPER - (NOT SOLD SEPARATELY) KIT ITEM WEARBAND - (NOT SOLD SEPARATELY) KIT ITEM WEARBAND - (NOT SOLD SEPARATELY) KIT ITEM LOCKING INSERT - (NOT SOLD SEPARATELY) RISER BOOM LIFT CYLINDER –...

  • Page 339: Slave Level Cylinder

    AB60J PARTS MANUAL SLAVE LEVEL CYLINDER HYDRAULICS SLAVE LEVEL CYLINDER Thu May 11 20:27:22 UTC 2017 3-49...

  • Page 340: Slave Level Cylinder - Gbi

    AB60J PARTS MANUAL SLAVE LEVEL CYLINDER Item Part No. Name 0180906 SLAVE LEVELING CYL. SUB ASSY 0180522 SLAVE LEVEL CYLINDER – GBI 5035303 ADAPTER 90 DEG ELBOW -4 SAE TO -4 JIC 5035303 ADAPTER 90 DEG ELBOW -4 Shown SAE TO -4 JIC...
  • Page 341 AB60J PARTS MANUAL SLAVE LEVEL CYLINDER – PRINCE, before may 2000 HYDRAULICS SLAVE LEVEL CYLINDER – PRINCE, before may 2000 Thu May 11 20:27:22 UTC 2017 3-50...
  • Page 342 AB60J PARTS MANUAL SLAVE LEVEL CYLINDER – PRINCE, before may 2000 Item Part No. Name 0180522 SLAVE LEVEL CYLINDER – GBI 28160079 PISTON ROD PNNA BUTT AND TUBE - (NOT SOLD SEPARATELY) 6091102 PISTON 28160080 GLAND 6091104 LOCKNUT 8160171 PORT PLUG...
  • Page 343 AB60J PARTS MANUAL SLAVE LEVEL CYLINDER – GBI HYDRAULICS SLAVE LEVEL CYLINDER – GBI Thu May 11 20:27:22 UTC 2017 3-51...
  • Page 344 AB60J PARTS MANUAL SLAVE LEVEL CYLINDER – GBI Item Part No. Name 0180522 SLAVE LEVEL CYLINDER – GBI PNNA CASE - (NOT SOLD SEPARATELY) 8070239 8070238 RETAINER 8070587 HEAD GLAND 8070667 PISTON 8070801 BUSHING 8070542 PORT PLUG 8070362 LOCK WASHER...

  • Page 345: Steering Cylinder -Rosenboom

    AB60J PARTS MANUAL STEERING CYLINDER –ROSENBOOM HYDRAULICS STEERING CYLINDER –ROSENBOOM Thu May 11 20:27:22 UTC 2017 3-52...
  • Page 346 AB60J PARTS MANUAL STEERING CYLINDER –ROSENBOOM Item Part No. Name 0074732 CYL 3.00 7.00 1.50 STEER 6091313 SEAL REPAIR KIT -(KIT INCLUDES ITEMS 9 - 19) PNNA TUBE - (NOT SOLD SEPARATELY) 6091309 6091312 HEAD GLAND CAP 6091310 PISTON 6091290...

  • Page 347: Dual Crossover Relief Valve

    AB60J PARTS MANUAL DUAL CROSSOVER RELIEF VALVE HYDRAULICS DUAL CROSSOVER RELIEF VALVE Thu May 11 20:27:23 UTC 2017 3-53...
  • Page 348 AB60J PARTS MANUAL DUAL CROSSOVER RELIEF VALVE Item Part No. Name 6010541 VALVE DUAL CROSSOVER RELIEF 6010111 CARTRIDGE RELIEF DUAL CROSSOVER RELIEF VALVE Thu May 11 20:27:23 UTC 2017 3-53...
  • Page 349 AB60J PARTS MANUAL DUAL RELIEF/ANTI CAVITATION VALVE HYDRAULICS DUAL RELIEF/ANTI CAVITATION VALVE Thu May 11 20:27:23 UTC 2017 3-54...

  • Page 350: Dual Relief/Anti Cavitation Valve

    AB60J PARTS MANUAL DUAL RELIEF/ANTI CAVITATION VALVE Item Part No. Name 6010598 DUAL RELIEF/ANTI CAVITATION VALVE 6010328 PRESSURE RELIEF VALVE - (FACTORY PRESET, DO NOT RESET) 0180801 SEAL REPAIR KIT 6010307 CHECK VALVE CARTRIDGE 5035705 FTG ELB45STRTHD-6B-6S STL- PH 6...

  • Page 351: Emergency Power Unit

    AB60J PARTS MANUAL EMERGENCY POWER UNIT HYDRAULICS EMERGENCY POWER UNIT Thu May 11 20:27:23 UTC 2017 3-55...
  • Page 352 AB60J PARTS MANUAL EMERGENCY POWER UNIT Item Part No. Name 0072940 EM. POWER UNIT S/A 6020058 EMERGENCY POWER MOTOR/PUMP 5037006 ADAPTER 90 DEG ELBOW SWIVEL -8 JIC 5035305 ADAPTER 90 DEG ELBOW -6 SAE TO -6 JIC 5065709 FTG, HYD -8 MB TO -8 MJIC...
  • Page 353 AB60J PARTS MANUAL FLOW DIVIDER/COMBINER VALVE 2 WHEEL DRIVE HYDRAULICS FLOW DIVIDER/COMBINER VALVE 2 WHEEL DRIVE Thu May 11 20:27:23 UTC 2017 3-56...

  • Page 354: Flow Divider/Combiner Valve 2 Wheel Drive

    AB60J PARTS MANUAL FLOW DIVIDER/COMBINER VALVE 2 WHEEL DRIVE Item Part No. Name 6010639 FLOW DIVIDER/COMBINER VALVE 2 WHEEL DRIVE 6010561 SEAL KIT 6010655 RELIEF VALVE CARTRIDGE 6010551 SEAL REPAIR KIT 6010626 FLOW DIVIDER/COMBINER 0150561 SEAL REPAIR KIT 8060281 PIPE PLUG WITH .060...
  • Page 355 AB60J PARTS MANUAL FLOW DIVIDER FOUR WHEEL DRIVE FLUID TECH HYDRAULICS FLOW DIVIDER FOUR WHEEL DRIVE FLUID TECH Thu May 11 20:27:23 UTC 2017 3-57...

  • Page 356: Flow Divider Four Wheel Drive Fluid Tech

    AB60J PARTS MANUAL FLOW DIVIDER FOUR WHEEL DRIVE FLUID TECH Item Part No. Name 6010570 VALVE PACKAGE 6010560 CARTRIDGE CHECK VALVE 565666 SEAL REPAIR KIT 6010604 CARTRIDGE 6010561 SEAL KIT 8060281 PIPE PLUG WITH .060 DIAMETER ORIFICE FLOW DIVIDER FOUR WHEEL DRIVE FLUID TECH...
  • Page 357 AB60J PARTS MANUAL FRONT TRANSMISSION VALVE HYDRAULICS FRONT TRANSMISSION VALVE Thu May 11 20:27:23 UTC 2017 3-58...

  • Page 358: Front Transmission Valve

    AB60J PARTS MANUAL FRONT TRANSMISSION VALVE Item Part No. Name 0180855 FRONT TRANSMISSION VALVE ASSY. 6010569 TRANSMISSION VALVE PACKAGE 5065807 FTG, HYD -10 MB TO -10 MJIC LONG 5037007 ADAPTER 90 DEG ELBOW SWIVEL -10 JIC 5035307 STRAIGHT THREAD 90° ELBOW...

  • Page 359: Pump Sub-Assembly, 1 Of 2

    AB60J PARTS MANUAL PUMP SUB-ASSEMBLY, 1 of 2 HYDRAULICS PUMP SUB-ASSEMBLY, 1 of 2 Thu May 11 20:27:24 UTC 2017 3-59...

  • Page 360: Pump Sub Assembly

    AB60J PARTS MANUAL PUMP SUB-ASSEMBLY, 1 of 2 Item Part No. Name 0181525 PUMP SUB-ASSEMBLY Shown 6020065 PUMP PISTON 2.7 8220119 SEAL REPAIR KIT - VICKERS Shown PUMP 8220120 REPLACEMENT COMPENSATOR Shown - VICKERS PUMP 8220088 GASKET Shown 5038005 FTG. BEADED 90° ELBOW...
  • Page 361 AB60J PARTS MANUAL PUMP SUB ASSEMBLY HYDRAULICS PUMP SUB ASSEMBLY Thu May 11 20:27:24 UTC 2017 3-60...
  • Page 362 AB60J PARTS MANUAL PUMP SUB ASSEMBLY Item Part No. Name 0181426 PUMP SUB ASSEMBLY Shown 6020065 PUMP PISTON 2.7 8220119 SEAL REPAIR KIT - VICKERS Shown PUMP 8160100 SEAL KIT – PARKER Shown 8180021 SEAL KIT – REXROTH Shown 8220120...

  • Page 363: Motion Control Valve, 1 0F 2

    AB60J PARTS MANUAL MOTION CONTROL VALVE, 1 0F 2 HYDRAULICS MOTION CONTROL VALVE, 1 0F 2 Thu May 11 20:27:24 UTC 2017 3-61...

  • Page 364: Motion Control Valve, 1 0F

    AB60J PARTS MANUAL MOTION CONTROL VALVE, 1 0F 2 Item Part No. Name 6010634 MOTION CONTROL VALVE 0110683 SEAL REPAIR KIT 6010836 COUNTERBALANCE VALVE CARTRIDGE - (FACTORY PRESET, DO NOT RESET) 6010269 CARTRIDGE SEQUENCE VALVE, WECO 6010531 SHUTTLE VALVE 0150562...

  • Page 365: Emergency Power Unit

    AB60J PARTS MANUAL EMERGENCY POWER UNIT HYDRAULICS EMERGENCY POWER UNIT Thu May 11 20:27:24 UTC 2017 3-62...

  • Page 366: Emergency Power Unit

    AB60J PARTS MANUAL EMERGENCY POWER UNIT Item Part No. Name 0072940 A EMERGENCY POWER UNIT 6020058 EMERGENCY POWER MOTOR/PUMP 5037006 ADAPTER 90 DEG ELBOW SWIVEL -8 JIC 5035305 ADAPTER 90 DEG ELBOW -6 SAE TO -6 JIC 5065709 FTG, HYD -8 MB TO -8 MJIC...

  • Page 367: Emergency Power Unit Assembly

    AB60J PARTS MANUAL EMERGENCY POWER UNIT ASSEMBLY HYDRAULICS EMERGENCY POWER UNIT ASSEMBLY Thu May 11 20:27:24 UTC 2017 3-63...
  • Page 368 AB60J PARTS MANUAL EMERGENCY POWER UNIT ASSEMBLY Item Part No. Name 6020058 EMERGENCY POWER MOTOR/PUMP 459986 COUPLING EMERGENCY POWER UNIT ASSEMBLY Thu May 11 20:27:24 UTC 2017 3-63...
  • Page 369 AB60J PARTS MANUAL MOTION CONTROL VALVE -- DRIVE HYDRAULICS MOTION CONTROL VALVE -- DRIVE Thu May 11 20:27:25 UTC 2017 3-64...
  • Page 370 AB60J PARTS MANUAL MOTION CONTROL VALVE -- DRIVE Item Part No. Name 6019052 VALVE MOTION CONTROL 6019168 SEQUANCE VALVE 565715 SEAL KIT 6019321 COUNTER BALANCE VALVE (CBGA-LHN 3000) 8190159 SEAL KIT 6019041 SHUTTLE VALVE 6091701 SEAL KIT PNNA -4 SAE O-RING FLUSH HEAD...
  • Page 371 AB60J PARTS MANUAL MOTION CONTROL VALVE, TURNTABLE SWING HYDRAULICS MOTION CONTROL VALVE, TURNTABLE SWING Thu May 11 20:27:25 UTC 2017 3-65...

  • Page 372: Motion Control Valve, Turntable Swing

    AB60J PARTS MANUAL MOTION CONTROL VALVE, TURNTABLE SWING Item Part No. Name 6010250 MOTION CONTROL VALVE ROSS/CHAR-LYNN 6010256 COUNTERBALANCE VALVE CARTRIDGE 6010321 CARTRIDGE RELIEF VALVE 0150563 SEAL REPAIR KIT 6010531 SHUTTLE VALVE 0150562 SEAL REPAIR KIT MOTION CONTROL VALVE, TURNTABLE SWING...
  • Page 373 AB60J PARTS MANUAL MOTION CONTROL VALVE HYDRAULICS MOTION CONTROL VALVE Thu May 11 20:27:25 UTC 2017 3-66...

  • Page 374: Motion Control Valve

    AB60J PARTS MANUAL MOTION CONTROL VALVE Item Part No. Name 6019048 MOTION CONTROL VALVE FLUIDTECH 514411-000 RELIEF VALVE 565666 SEAL REPAIR KIT 6019341 COUNTERBALANCE VALVE 6091702 SEAL KIT 6019041 SHUTTLE VALVE 6091701 SEAL KIT PNNA -4 SAE O-RING FLUSH HEAD...
  • Page 375 AB60J PARTS MANUAL TRANSMISSION VALVE PACKAGE HYDRAULICS TRANSMISSION VALVE PACKAGE Thu May 11 20:27:25 UTC 2017 3-67...

  • Page 376: Transmission Valve Package

    AB60J PARTS MANUAL TRANSMISSION VALVE PACKAGE Item Part No. Name 6010569 TRANSMISSION VALVE PACKAGE 6010595 VALVE 3-WAY CARTRIDGE- (HYDRAFORCE) 6010561 SEAL KIT Shown 6010797 VALVE CARTRIDGE DIVIDER/COMBINER (HYDRAFORCE) 6010561 SEAL KIT Shown 6010596 RELIEF VALVE (HYDRAFORCE) 6010602 SEAL KIT Shown...
  • Page 377 AB60J PARTS MANUAL TRANSMISSION VALVE PACKAGE TRANSMISSION VALVE PACKAGE Thu May 11 20:27:25 UTC 2017 3-67...
  • Page 378 AB60J PARTS MANUAL HYDRAULIC OIL FILTER HYDRAULICS HYDRAULIC OIL FILTER Thu May 11 20:27:25 UTC 2017 3-68...

  • Page 379: Hydraulic Oil Filter

    AB60J PARTS MANUAL HYDRAULIC OIL FILTER Item Part No. Name 0181671 HYDRAULIC OIL FILTER – BEFORE MARCH 2015 0181672 RETURN OIL FILTER ASSY 5080044 FILTER RETURN LINE- W/GAUGE 6010080 CHECK VALVE 5035312 ADAPTER 90 DEG ELBOW -20 SAE TO -20 JIC...
  • Page 380 AB60J PARTS MANUAL HYDRAULIC OIL RESERVOIR ASSEMBLY HYDRAULICS HYDRAULIC OIL RESERVOIR ASSEMBLY Thu May 11 20:27:26 UTC 2017 3-69...

  • Page 381: Hydraulic Oil Reservoir Assembly

    AB60J PARTS MANUAL HYDRAULIC OIL RESERVOIR ASSEMBLY Item Part No. Name 0180517 HYDR OIL RSVR ASSY 0180439 HYD OIL RESERVOIR W/COVER 5033038 ADAPTER TEE SWIVEL -8 JIC TO -8 JIC FEMALE TO 8 JIC FEMALE 5033614 MALE ADAPTER (-8) 5035312...
  • Page 382 AB60J PARTS MANUAL PLATFORM ROTATOR HYDRAULICS PLATFORM ROTATOR Thu May 11 20:27:26 UTC 2017 3-70...

  • Page 383: Platform Rotator

    AB60J PARTS MANUAL PLATFORM ROTATOR Item Part No. Name 0110771 PLATFORM ROTATOR 0071275 SEAL REPAIR KIT - (KIT INCLUDES 13 - 21) 8080018 RACK BOLT 8080016 END CAP 8080015 PISTON 8080040 CYLINDER 8080060 RACK BOLT 8080039 HOUSING 0073281 TIE ROD...

  • Page 384: Rear Transmission Valve

    AB60J PARTS MANUAL REAR TRANSMISSION VALVE HYDRAULICS REAR TRANSMISSION VALVE Thu May 11 20:27:26 UTC 2017 3-71...
  • Page 385 AB60J PARTS MANUAL REAR TRANSMISSION VALVE Item Part No. Name 0180856 RR TRANS VLV S/A ATB60 4X4 6010569 TRANSMISSION VALVE PACKAGE 5065807 FTG, HYD -10 MB TO -10 MJIC LONG 5037007 ADAPTER 90 DEG ELBOW SWIVEL -10 JIC 5065316 FTG. ELB90 STRTHD -10S-8S STL 2...

  • Page 386: Sense Line Dump Valve

    AB60J PARTS MANUAL SENSE LINE DUMP VALVE HYDRAULICS SENSE LINE DUMP VALVE Thu May 11 20:27:26 UTC 2017 3-72...
  • Page 387 AB60J PARTS MANUAL SENSE LINE DUMP VALVE Item Part No. Name 0181541 SENSE LINE DUMP VALVE SUB ASSY 6010499 DUMP VALVE 0073620 SEAL REPAIR KIT Shown 6010472 CARTRIDGE 3040473 SOLENOID, 10 VOLT DC 5065705 FTG, HYD -6 MB TO -4 MJIC...
  • Page 388 AB60J PARTS MANUAL SPEED SHIFT VALVE HYDRAULICS SPEED SHIFT VALVE Thu May 11 20:27:26 UTC 2017 3-73...

  • Page 389: Speed Shift Valve

    AB60J PARTS MANUAL SPEED SHIFT VALVE Item Part No. Name 0180890 SPEED SHIFT VALVE 6010499 DUMP VALVE 0073620 SEAL REPAIR KIT Shown 6010472 CARTRIDGE 3040473 SOLENOID, 10 VOLT DC 5065705 FTG, HYD -6 MB TO -4 MJIC 5035305 ADAPTER 90 DEG ELBOW -6...
  • Page 390 AB60J PARTS MANUAL SPEED SHIFT VALVE HYDRAULICS SPEED SHIFT VALVE Thu May 11 20:27:27 UTC 2017 3-74...
  • Page 391 AB60J PARTS MANUAL SPEED SHIFT VALVE Item Part No. Name 0180866 SHIFT SPEED VALVE SUB. ASSY. 6010610 VALVE ASSY 3-WAY 10V DOUBLE - 6010500 VALVE 3 WAY CART WITH 10V Shown COIL 3040473 SOLENOID, 10 VOLT DC Shown 0073620 SEAL REPAIR KIT...

  • Page 392: Steer Switch Valve

    AB60J PARTS MANUAL STEER SWITCH VALVE HYDRAULICS STEER SWITCH VALVE Thu May 11 20:27:27 UTC 2017 3-75...
  • Page 393 AB60J PARTS MANUAL STEER SWITCH VALVE Item Part No. Name 0180817 L.H. STEER SWITCH VALVE S/A 6010611 STEER SHIFT VALVE 6010551 SEAL REPAIR KIT Shown 0180811 MOUNT BRACKET 0180814 MOUNT PLATE 0180769 TRUNNION 0180815 970169 BLT HEXHD .250-20 2.00 GR5 986019 WASHER, FLAT, .25 STANDARD,...
  • Page 394 AB60J PARTS MANUAL STEER SWITCH VALVE HYDRAULICS STEER SWITCH VALVE Thu May 11 20:27:27 UTC 2017 3-76...
  • Page 395 AB60J PARTS MANUAL STEER SWITCH VALVE Item Part No. Name 0180816 R.H. STEER SWITCH VALVE S/A 6010611 STEER SHIFT VALVE 6010551 SEAL REPAIR KIT Shown 0180811 MOUNT BRACKET 0180814 MOUNT PLATE 0180769 TRUNNION 0180815 970169 BLT HEXHD .250-20 2.00 GR5 986019 WASHER, FLAT, .25 STANDARD,...

  • Page 396: Electrical

    AB60J PARTS MANUAL TURNTABLE ELECTRICAL – CUMMINS ELECTRICAL TURNTABLE ELECTRICAL – CUMMINS Thu May 11 20:27:28 UTC 2017...

  • Page 397: Turntable Electrical - Cummins

    AB60J PARTS MANUAL TURNTABLE ELECTRICAL – CUMMINS Item Part No. Name 0181838 TURNTABLE ELECTRICAL – Shown CUMMINS 0181536 WIRING BOX, CUMMINS 0180993 SOLENOID SWITCH – CUMMINS 0180994 BOOM SWITCH 0181613 WIRE HARNESS, CUMMINS ENGINE 0181550 WIRE HARNESS, TURNTABLE 0150810 WLDMT BATTERY BOX...
  • Page 398 AB60J PARTS MANUAL TURNTABLE ELECTRICAL – CUMMINS TURNTABLE ELECTRICAL – CUMMINS Thu May 11 20:27:28 UTC 2017...
  • Page 399 AB60J PARTS MANUAL TURNTABLE ELECTRICAL – CUMMINS Item Part No. Name 970449 BLT HEXHD .375-16 .750 GR5 986299 WSHR FLAT .375 GR5 ZP 987119 WSHR LOCK .375 SPLIT TYPE 970049 BLT HEXHD .250-20 1.00 GR5 3070016 TEMPERATURE GAUGE 5560004 .250-20UNC HEX LOCK NUT 970889 BLT HEXHD .500-13 1.00 GR 5...
  • Page 400 AB60J PARTS MANUAL TURNTABLE ELECTRICAL – CUMMINS Item Part No. Name 0082029 MOUNT PLATE, ACTUATOR MODULE 7630230 SANDWICH MOUNT 20082046 ACTUATOR MODULE – INCLUDED WITH ENGINE 974659 MACHINE SCREW, RND HD, SLOTTED, #10-24 UNC X .50 MTS 16, 18 3040187 CONN .500 .313-.438...
  • Page 401 TURNTABLE ELECTRICAL AND CONTROL INSTALLATION, BEFORE JAN 2006 AB60J PARTS MANUAL ELECTRICAL TURNTABLE ELECTRICAL AND CONTROL INSTALLATION, BEFORE JAN 2006 Thu May 11 20:27:29 UTC 2017...
  • Page 402 TURNTABLE ELECTRICAL AND CONTROL INSTALLATION, BEFORE JAN 2006 AB60J PARTS MANUAL Item Part No. Name 0181779 TURNTABLE ELECTRICAL AND Shown CONTROL INSTALLATION 0181783 WIRING BOX, FORD 0180992 SOLENOIS SWITCH – FORD 0180994 BOOM SWITCH 0181785 WIRE HARNESS, FORD LRG-425 ENGINE...

  • Page 403: Turntable Electrical And Control Installation, Before Jan 2006

    TURNTABLE ELECTRICAL AND CONTROL INSTALLATION, BEFORE JAN 2006 AB60J PARTS MANUAL TURNTABLE ELECTRICAL AND CONTROL INSTALLATION, BEFORE JAN 2006 Thu May 11 20:27:29 UTC 2017...
  • Page 404 TURNTABLE ELECTRICAL AND CONTROL INSTALLATION, BEFORE JAN 2006 AB60J PARTS MANUAL Item Part No. Name 970449 BLT HEXHD .375-16 .750 GR5 986299 WSHR FLAT .375 GR5 ZP 987119 WSHR LOCK .375 SPLIT TYPE 970049 BLT HEXHD .250-20 1.00 GR5 3070021...
  • Page 405 TURNTABLE ELECTRICAL AND CONTROL INSTALLATION, BEFORE JAN 2006 AB60J PARTS MANUAL Item Part No. Name 3020081 SW TGL DPDT (M/ON) SEALED 0112093 ECM MOUNTING BRACKET 0181503 BRKT TILT ALARM 5560033 NUT HEX LKG .375-16 0081558 WIRE R61 FEM250FI 4 7630687...
  • Page 406 AB60J PARTS MANUAL ENGINE WIRING HARNESS – FORD 425 ELECTRICAL ENGINE WIRING HARNESS – FORD 425 Thu May 11 20:27:30 UTC 2017...

  • Page 407: Engine Wiring Harness - Ford 425

    AB60J PARTS MANUAL ENGINE WIRING HARNESS – FORD 425 Item Part No. Name 0182029 ENGINE WIRING HARNESS – Shown FORD 425 3011801 WIRE 18GA SINGLE CONDUCTOR WHT SAE J558A - TYPE GPT 3011601 WIRE 16GA SINGLE CONDUCTOR BLK-TYPE GPT 3011201 WIRE 12GA RED SINGLE CONDUCTOR-12 GA.
  • Page 408 AB60J PARTS MANUAL ENGINE WIRING HARNESS – FORD 425 ENGINE WIRING HARNESS – FORD 425 Thu May 11 20:27:30 UTC 2017...
  • Page 409 AB60J PARTS MANUAL ENGINE WIRING HARNESS – FORD 425 Item Part No. Name 3040047 TERM FEM250FI 22/18 3044855 TERM R250I 12/10- 3049881 TERM FEM312 16/12 3011820 CABLE 18 GA/20 CONDUCTOR 3011620 16GA TWISTED PAIR CABLE 3042263 TERMINAL #10 STUD INSULATED 8 GAUGE WIRE...
  • Page 410 TURNTABLE ELECTRICAL INSTALL, CUMMINS AFTER FEBRUARY 2008 AB60J PARTS MANUAL ELECTRICAL TURNTABLE ELECTRICAL INSTALL, CUMMINS AFTER FEBRUARY 2008 Thu May 11 20:27:31 UTC 2017...

  • Page 411: Turntable Electrical Install, Cummins After February 2008

    TURNTABLE ELECTRICAL INSTALL, CUMMINS AFTER FEBRUARY 2008 AB60J PARTS MANUAL Item Part No. Name 0182263 TURNTABLE ELECTRICAL Shown INSTALL 0182042 WIRING BOX ASSEMBLY – CUMMINS 0182044 ASSY CONT BOX MTG BRKT 0180994 BOOM SWITCH 0182025 HARNESS, ENG WIRE CU 0181550...
  • Page 412 TURNTABLE ELECTRICAL INSTALL, CUMMINS AFTER FEBRUARY 2008 AB60J PARTS MANUAL TURNTABLE ELECTRICAL INSTALL, CUMMINS AFTER FEBRUARY 2008 Thu May 11 20:27:31 UTC 2017...
  • Page 413 TURNTABLE ELECTRICAL INSTALL, CUMMINS AFTER FEBRUARY 2008 AB60J PARTS MANUAL Item Part No. Name 970449 BLT HEXHD .375-16 .750 GR5 986299 WSHR FLAT .375 GR5 ZP 987119 WSHR LOCK .375 SPLIT TYPE 970049 BLT HEXHD .250-20 1.00 GR5 0151816 WIRE 16 R10I R10I 7.5 5560004 .250-20UNC HEX LOCK NUT...
  • Page 414 TURNTABLE ELECTRICAL INSTALL, CUMMINS AFTER FEBRUARY 2008 AB60J PARTS MANUAL TURNTABLE ELECTRICAL INSTALL, CUMMINS AFTER FEBRUARY 2008 Thu May 11 20:27:31 UTC 2017...
  • Page 415 TURNTABLE ELECTRICAL INSTALL, CUMMINS AFTER FEBRUARY 2008 AB60J PARTS MANUAL Item Part No. Name 0082046 ACTUATOR MODULE SUB ASSY 1 974659 MACHINE SCREW, RND HD, SLOTTED, #10-24 UNC X .50 MTS 16, 18 3040187 CONN .500 .313-.438 3040070 NUT LKG HUB .500...
  • Page 416 AB60J PARTS MANUAL TURNTABLE ELECTRICAL INSTALLATION – GM ENGINE ELECTRICAL TURNTABLE ELECTRICAL INSTALLATION – GM ENGINE Thu May 11 20:27:32 UTC 2017...

  • Page 417: Turntable Electrical Installation - Gm Engine

    AB60J PARTS MANUAL TURNTABLE ELECTRICAL INSTALLATION – GM ENGINE Item Part No. Name 0182174 TURNTABLE ELECTRICAL Shown INSTALLATION – GM ENGINE 0182175 WIRING BOX ASSEMBLY – GM ENGINE 0182044 ASSY CONT BOX MTG BRKT 0180944 HOSE-20-20S-20S 33 SP 0182183 ENGINE WIRE ASSEMBLY...
  • Page 418 TURNTABLE ELECTRICAL INSTALLATION – GM ENGINE AB60J PARTS MANUAL TURNTABLE ELECTRICAL INSTALLATION – GM ENGINE Thu May 11 20:27:32 UTC 2017...
  • Page 419 AB60J PARTS MANUAL TURNTABLE ELECTRICAL INSTALLATION – GM ENGINE Item Part No. Name 986299 WSHR FLAT .375 GR5 ZP 987119 WSHR LOCK .375 SPLIT TYPE 970049 BLT HEXHD .250-20 1.00 GR5 5560004 .250-20UNC HEX LOCK NUT 970889 BLT HEXHD .500-13 1.00 GR 5 987139 WSHR LOCK .500 SPLIT TYPE...
  • Page 420 TURNTABLE ELECTRICAL INSTALLATION – GM ENGINE AB60J PARTS MANUAL TURNTABLE ELECTRICAL INSTALLATION – GM ENGINE Thu May 11 20:27:32 UTC 2017...
  • Page 421 AB60J PARTS MANUAL TURNTABLE ELECTRICAL INSTALLATION – GM ENGINE Item Part No. Name 3040046 TERM MALE250FI 22/18 0071557 WIRE 18 R8I MALE250FI 7 300804 WIRE 18 R8I FEM250FI 6 TURNTABLE ELECTRICAL INSTALLATION – GM ENGINE Thu May 11 20:27:32 UTC 2017...

  • Page 422: Lps Installation - Gm Engine

    AB60J PARTS MANUAL LPS INSTALLATION – GM ENGINE ELECTRICAL LPS INSTALLATION – GM ENGINE Thu May 11 20:27:32 UTC 2017...
  • Page 423 AB60J PARTS MANUAL LPS INSTALLATION – GM ENGINE Item Part No. Name 0182252 LPS INSTALLATION – GM Shown ENGINE 3010026 WIRE 16 GA SXL 3090006 FLEXGARD TUBE, 77 INCH LONG 3044161 BOOT BTRY CABLE END BLACK 3044071 TERM BUTT CONN INSUL 16/14...
  • Page 424 AB60J PARTS MANUAL LPS INSTALLATION – GM ENGINE Item Part No. Name 970259 BLT HEXHD .313-18 1.00 GR5- PLATED 986269 WASHER, FLAT, .313 STANDARD, PLATED 987109 WSHR LOCK .313 SPLIT TYPE 3040291 DIOID 3040082 TERM MALE250FI 16/14 3040083 TERM FEM250FI 16/14 30400478 HEAT SHRINK TUNING .375 ID...
  • Page 425 AB60J PARTS MANUAL SOLENOID SWITCH – CUMMINS ELECTRICAL SOLENOID SWITCH – CUMMINS Thu May 11 20:27:32 UTC 2017...

  • Page 426: Solenoid Switch - Cummins

    AB60J PARTS MANUAL SOLENOID SWITCH – CUMMINS Item Part No. Name 0180993 SOLENOID SWITCH – CUMMINS Shown 0181589 SUPPORT BRACKET 3040506 SOLENOID SWITCH SPST N.O. 3020049 SWITCH, BATTERY DISCONNECT 0073089 PLAC BATTERY DISCONNECT SWITCH 5560004 .250-20UNC HEX LOCK NUT 970049 BLT HEXHD .250-20 1.00 GR5...

  • Page 427: Solenoid Switch - Ford

    AB60J PARTS MANUAL SOLENOID SWITCH – FORD ELECTRICAL SOLENOID SWITCH – FORD Thu May 11 20:27:33 UTC 2017...
  • Page 428 AB60J PARTS MANUAL SOLENOID SWITCH – FORD Item Part No. Name 0180992 SOLENOIS SWITCH – FORD Shown 0181589 SUPPORT BRACKET 3040506 SOLENOID SWITCH SPST N.O. 3020049 SWITCH, BATTERY DISCONNECT 0073089 PLAC BATTERY DISCONNECT SWITCH 5560004 .250-20UNC HEX LOCK NUT 970049 BLT HEXHD .250-20 1.00 GR5...
  • Page 429 AB60J PARTS MANUAL WIRING BOX – CUMMINS, BEFORE MAY 2004 ELECTRICAL WIRING BOX – CUMMINS, BEFORE MAY 2004 Thu May 11 20:27:33 UTC 2017...
  • Page 430 AB60J PARTS MANUAL WIRING BOX – CUMMINS, BEFORE MAY 2004 Item Part No. Name 0181536 WIRING BOX – CUMMINS Shown 0180885 WIRING BOX 0181555 WIRING BOX PANEL, CUMMINS 0070967 CORROSION INHIBITOR 0180949 RHEOSTAT SUB ASSY 3040497 REPLACEMENT SWITCH Shown 3070001...
  • Page 431 AB60J PARTS MANUAL WIRING BOX – CUMMINS, BEFORE MAY 2004 WIRING BOX – CUMMINS, BEFORE MAY 2004 Thu May 11 20:27:34 UTC 2017...

  • Page 432: Wiring Box - Cummins, Before May 2004

    AB60J PARTS MANUAL WIRING BOX – CUMMINS, BEFORE MAY 2004 Item Part No. Name 3040116 CONN .75 .500-. 25 0180787 INSTRUMENT PANEL 3020093 SWITCH, MAGNETIC 984069 NUT 1/4-20 HEX 3070003 AMMETER 3020013 SW TGL SPST ON OFF SEALED 7630140 FILTER CONDITION INDICATOR 1 5093004 CLP CUSH .750 VINYL COATED...
  • Page 433 AB60J PARTS MANUAL WIRING BOX – CUMMINS, BEFORE MAY 2004 Item Part No. Name 0181104 WIRE 12 R6 R6 6 0070747 WIRE 16 R6I R6I 3 0070742 WIRE 12 R6I R6I 8 0071541 WIRE 12 R6I R10I 14 0070753 WIRE 16 R6I R6I 12...
  • Page 434 AB60J PARTS MANUAL WIRING BOX ASSEMBLY – CUMMINS ELECTRICAL WIRING BOX ASSEMBLY – CUMMINS Thu May 11 20:27:34 UTC 2017 4-10...

  • Page 435: Wiring Box Assembly - Cummins

    AB60J PARTS MANUAL WIRING BOX ASSEMBLY – CUMMINS Item Part No. Name 0182042 WIRING BOX ASSEMBLY – CUMMINS 0180885 WIRING BOX DRILLED 0182028 PANEL SUB ASSEMBLY 0070967 CORROSION INHIBITOR STICK- BACK 0180949 RHEOSTAT SUB ASSY 3070001 HOURMETER 3020020 SW EMER STOP PUSH/PULL...
  • Page 436 AB60J PARTS MANUAL WIRING BOX ASSEMBLY – CUMMINS WIRING BOX ASSEMBLY – CUMMINS Thu May 11 20:27:34 UTC 2017 4-10...
  • Page 437 AB60J PARTS MANUAL WIRING BOX ASSEMBLY – CUMMINS Item Part No. Name 3070003 AMMETER 3020013 SW TGL SPST (ON) OFF 7630140 FILTER MINDER GAUGE AIR CLNR 5093004 CLAMP .750 AEROQUIP HOSE SUPPORT 3040411 ALARM MINI SIREN 5660667 MACHINE SCREW, PAN HD, SLOTTED, #10-24 UNF X .375...
  • Page 438 AB60J PARTS MANUAL WIRING BOX ASSEMBLY CE/KU ELECTRICAL WIRING BOX ASSEMBLY CE/KU Thu May 11 20:27:35 UTC 2017 4-11...
  • Page 439 0180787 PANEL 0180885 WIRING BOX DRILLED 0180916E PLACARD LOWER CONTROL BOX ATB60 (CE) 0182428 ASSY ELEC PANEL AB60J KU 583406 PLUG HOLE 2.00 DIA PLASTIC 970009 BLT HEXHD .250-20 .500 GR5 970469 BLT HEXHD .375-16 1.00 GR5 974659 MACHINE SCREW, RND HD, SLOTTED, #10-24 UNC X .50 MTS...

  • Page 440: Wiring Box Assembly Ce/Ku

    AB60J PARTS MANUAL WIRING BOX ASSEMBLY CE/KU WIRING BOX ASSEMBLY CE/KU Thu May 11 20:27:36 UTC 2017 4-11...
  • Page 441 AB60J PARTS MANUAL WIRING BOX ASSEMBLY CE/KU Item Part No. Name 3040016 PLUG HOLE 1.00 3040069 CIRCUIT BREAKER 25 AMP 3040070 NUT LKG HUB .500 3040110 NUT LKG HUB .750 3040115 CONN .500 .375-.500 3040252 CIRCUIT BREAKER 15 AMP 3040295 CONN .75 .625-.75...
  • Page 442 AB60J PARTS MANUAL WIRING BOX ASSEMBLY CE/KU Item Part No. Name 974239 MACHINE SCREW, RND HD, SLOTTED, #6-32 UNC X .50 MTS 16, 18 3011641 WIRE 16GA SINGLE CONDUCTOR WHT-TYPE GPT TFFN 0070760 WIRE 18 R8I FEM250I 14 3044158 TERM R6I 16/14 0182202 WIRE 16 R6I F250FI 7 RSTR 7.5...
  • Page 443 AB60J PARTS MANUAL WIRING BOX ASSEMBLY CE/KU Item Part No. Name 3040047 TERM FEM250FI 22/18 3044146 TERM R10I 22/18 0421108 WIRE 16 FEM250FI FEM188I 28 Shown 0071840 WIRE 16 FEM188I FEM188I 11 0191619 WIRE 16 FEM188I R10I 22 0191154 WIRE 16 FEM188 FEM250 12...

  • Page 444: Electrical Panel - Cummins

    AB60J PARTS MANUAL ELECTRICAL PANEL – CUMMINS ELECTRICAL ELECTRICAL PANEL – CUMMINS Thu May 11 20:27:36 UTC 2017 4-12...
  • Page 445 AB60J PARTS MANUAL ELECTRICAL PANEL – CUMMINS Item Part No. Name 0182028 PANEL SUB ASSEMBLY Shown 0180796 PANEL, DRILLED 3044712 TERM STRIP (12) #10 STUD 3040433 TERMINAL STRIP 12 CIRCUIT 0181552 DECAL, POWER 0181553 DECAL, TERMINAL STRIP 0181107 DECAL, CONTROL #2...
  • Page 446 AB60J PARTS MANUAL ELECTRICAL PANEL – CUMMINS Item Part No. Name 0070682 DIODE WIRE 0083778 RESISTOR WIRE (3 OHM) 0140317 DIODE WIRE 0151205 WIRE 16 FEM188 FEM250FI 7 0081560 JUMPER WIRE 0070724 JUMPER WIRE 0181110 DIODE WIRE 0181031 WIRE 12 R10 FEM250FI 11...
  • Page 447 AB60J PARTS MANUAL WIRING BOX ASSEMBLY – GM ENGINE ELECTRICAL WIRING BOX ASSEMBLY – GM ENGINE Thu May 11 20:27:37 UTC 2017 4-13...

  • Page 448: Wiring Box Assembly - Gm Engine

    AB60J PARTS MANUAL WIRING BOX ASSEMBLY – GM ENGINE Item Part No. Name 0182175 WIRING BOX ASSEMBLY – GM ENGINE 0180885 WIRING BOX DRILLED 0182176 PANEL SUB ASSEMBLY 0070967 CORROSION INHIBITOR STICK- BACK 0082002 RHEOSTAT SUB ASSY 9070001 HOUR METER...
  • Page 449 AB60J PARTS MANUAL WIRING BOX ASSEMBLY – GM ENGINE WIRING BOX ASSEMBLY – GM ENGINE Thu May 11 20:27:37 UTC 2017 4-13...
  • Page 450 AB60J PARTS MANUAL WIRING BOX ASSEMBLY – GM ENGINE Item Part No. Name 984069 NUT 1/4-20 HEX 3072126 VOLTMETER 3020013 SW TGL SPST (ON) OFF 7630140 FILTER MINDER GAUGE AIR CLNR 5093004 CLAMP .750 AEROQUIP HOSE SUPPORT 3040411 ALARM MINI SIREN 5560667 SCR PANHD #10-24 X .375...

  • Page 451: Panel Assembly - Gm

    AB60J PARTS MANUAL PANEL ASSEMBLY – GM ELECTRICAL PANEL ASSEMBLY – GM Thu May 11 20:27:37 UTC 2017 4-14...
  • Page 452 AB60J PARTS MANUAL PANEL ASSEMBLY – GM Item Part No. Name 0182176 PANEL SUB ASSEMBLY Shown 0180796 PANEL, DRILLED 3044712 TERM STRIP (12) #10 STUD 3040433 TERMINAL STRIP 12 CIRCUIT 0181552 DECAL, POWER 0182201 DECAL, TERMINAL STRIP 0181107 DECAL, CONTROL #2...
  • Page 453 AB60J PARTS MANUAL PANEL ASSEMBLY – GM Item Part No. Name 0140317 DIODE WIRE 0151205 WIRE 16 FEM188 FEM250FI 7 0081560 JUMPER WIRE 0070724 JUMPER WIRE 0181110 DIODE WIRE 0181031 WIRE 12 R10 FEM250FI 11 0081559 WIRE 16 R10I FEM250FI 10-20/20...
  • Page 454 AB60J PARTS MANUAL WIRING BOX ASSEMBLY – KU, BEFORE JULY 2015 ELECTRICAL WIRING BOX ASSEMBLY – KU, BEFORE JULY 2015 Thu May 11 20:27:38 UTC 2017 4-15...

  • Page 455: Wiring Box Assembly - Ku, Before July 2015

    WIRING BOX ASSEMBLY – KU, BEFORE JULY 2015 Item Part No. Name 0182423 WIRING BOX ASSEMBLY – KU 0180885 WIRING BOX DRILLED 0182428 ASSY ELEC PANEL AB60J KU 0070967 CORROSION INHIBITOR STICK- BACK 0180949 RHEOSTAT SUB ASSY 583406 PLUG HOLE 2.00 DIA PLASTIC 3020020...
  • Page 456 AB60J PARTS MANUAL WIRING BOX ASSEMBLY – KU, BEFORE JULY 2015 WIRING BOX ASSEMBLY – KU, BEFORE JULY 2015 Thu May 11 20:27:38 UTC 2017 4-15...
  • Page 457 AB60J PARTS MANUAL WIRING BOX ASSEMBLY – KU, BEFORE JULY 2015 Item Part No. Name 5093004 CLAMP .750 AEROQUIP HOSE SUPPORT 3040411 ALARM MINI SIREN 5660667 MACHINE SCREW, PAN HD, SLOTTED, #10-24 UNF X .375 MTS 16, 18 5560033 NUT HEX LKG .375-16...
  • Page 458 AB60J PARTS MANUAL WIRING BOX ASSEMBLY – KU HF, AFTER JUNE 2015 ELECTRICAL WIRING BOX ASSEMBLY – KU HF, AFTER JUNE 2015 Thu May 11 20:27:39 UTC 2017 4-16...

  • Page 459: Wiring Box Assembly - Ku Hf, After June 2015

    WIRING BOX ASSEMBLY – KU HF, AFTER JUNE 2015 Item Part No. Name 0182448 WIRING BOX ASSEMBLY – KU 0180885 WIRING BOX DRILLED 0182428 ASSY ELEC PANEL AB60J KU 0070967 CORROSION INHIBITOR STICK- BACK 0082002 RHEOSTAT SUB ASSY 583406 PLUG HOLE 2.00 DIA PLASTIC 3020020...
  • Page 460 AB60J PARTS MANUAL WIRING BOX ASSEMBLY – KU HF, AFTER JUNE 2015 WIRING BOX ASSEMBLY – KU HF, AFTER JUNE 2015 Thu May 11 20:27:40 UTC 2017 4-16...
  • Page 461 AB60J PARTS MANUAL WIRING BOX ASSEMBLY – KU HF, AFTER JUNE 2015 Item Part No. Name 7630140 FILTER MINDER GAUGE AIR CLNR 5093004 CLAMP .750 AEROQUIP HOSE SUPPORT 3040411 ALARM MINI SIREN 5560667 SCR PANHD #10-24 X .375 5560692 MACHINE SCREW #10-24 X 1'' LG.
  • Page 462 AB60J PARTS MANUAL WIRIING BOX ASSEMBLY W/OVERLOAD KU SP CE ELECTRICAL WIRIING BOX ASSEMBLY W/OVERLOAD KU SP CE Thu May 11 20:27:41 UTC 2017 4-17...

  • Page 463: Wiriing Box Assembly W/Overload Ku Sp Ce

    WIRIING BOX ASSEMBLY W/OVERLOAD KU SP CE Item Part No. Name 0182480 A WIRING BOX ASSEMBLY W/OVERLOAD KU SP CE 0180885 WIRING BOX DRILLED Shown 0182428 ASSY ELEC PANEL AB60J KU 0070967 CORROSION INHIBITOR STICK- BACK 0082002 RHEOSTAT SUB ASSY 3040348 KNOB RHEOSTAT 0180787 PANEL 583406 PLUG HOLE 2.00 DIA PLASTIC...
  • Page 464 AB60J PARTS MANUAL WIRIING BOX ASSEMBLY W/OVERLOAD KU SP CE WIRIING BOX ASSEMBLY W/OVERLOAD KU SP CE Thu May 11 20:27:41 UTC 2017 4-17...
  • Page 465 AB60J PARTS MANUAL WIRIING BOX ASSEMBLY W/OVERLOAD KU SP CE Item Part No. Name 986299 WSHR FLAT .375 GR5 ZP 970469 BLT HEXHD .375-16 1.00 GR5 7630140 FILTER MINDER GAUGE AIR CLNR 5560703 WSHR STAR 10 EXTERNAL TOOTH 984049 NUT HEX 10-24...
  • Page 466 AB60J PARTS MANUAL WIRIING BOX ASSEMBLY W/OVERLOAD KU SP CE Item Part No. Name 3220096 OVERLOAD FAULT DETECTION 3040047 TERM FEM250FI 22/18 Shown 0421108 WIRE 16 FEM250FI FEM188I 28 Shown 0110835 WIRE 16 R10I FEM188I 24 Shown 0151910 WIRE 16 R6 R10 14...
  • Page 467 AB60J PARTS MANUAL WIRIING BOX ASSEMBLY W/OVERLOAD KU SP CE Item Part No. Name 3040065 TERM FEM250FI 12/10 FULLY INSULATED 0071555 WIRE 16 R10I FEM250I 6 0181549 WIRE ASSY INTERNAL WIRING 0421108 WIRE 16 FEM250FI FEM188I 28 3040082 TERM MALE250FI 16/14...
  • Page 468 ELECTRICAL SPANISH W/OVERLOAD SUB-ASSEMBLY KIT KU CE AB60J PARTS MANUAL ELECTRICAL Image does not exist ELECTRICAL SPANISH W/OVERLOAD SUB-ASSEMBLY KIT KU CE Thu May 11 20:27:41 UTC 2017 4-18...

  • Page 469: Electrical Spanish W/Overload Sub-Assembly Kit Ku Ce

    OPT HORN INSTL ATB60 0180994 BOOM SWITCH 0182479 PLATF CONT BOX ASSY AB60J KU SP W/OVERLOAD 0182480 ASSY WIRING BOX AB60J KU SP W/OVERLOAD 0182185 WIRE ASSY-TRNTBL GM T3 AB60J 0182417 HARNESS AB60 KU ENGINE ELECTRICAL SPANISH W/OVERLOAD SUB-ASSEMBLY KIT KU CE...

  • Page 470: Electrical Panel Assembly - Ku

    AB60J PARTS MANUAL ELECTRICAL PANEL ASSEMBLY – KU ELECTRICAL ELECTRICAL PANEL ASSEMBLY – KU Thu May 11 20:27:42 UTC 2017 4-19...
  • Page 471 AB60J PARTS MANUAL ELECTRICAL PANEL ASSEMBLY – KU Item Part No. Name 0182428 ASSY ELEC PANEL AB60J KU Shown 0180796 PANEL, DRILLED 3044712 TERM STRIP (12) #10 STUD 3040433 TERMINAL STRIP 12 CIRCUIT 0181552 DECAL, POWER 0181553 DECAL, TERMINAL STRIP...
  • Page 472 AB60J PARTS MANUAL ELECTRICAL PANEL ASSEMBLY – KU Item Part No. Name 0070682 DIODE WIRE 0083778 RESISTOR WIRE (3 OHM) 0140317 DIODE WIRE 0151205 WIRE 16 FEM188 FEM250FI 7 0081560 JUMPER WIRE 0070724 JUMPER WIRE 0181110 DIODE WIRE 0181031 WIRE 12 R10 FEM250FI 11...
  • Page 473 AB60J PARTS MANUAL WIRING BOX – FORD, BEFORE JUNE 2003 ELECTRICAL WIRING BOX – FORD, BEFORE JUNE 2003 Thu May 11 20:27:43 UTC 2017 4-20...
  • Page 474 AB60J PARTS MANUAL WIRING BOX – FORD, BEFORE JUNE 2003 Item Part No. Name 0181783 WIRING BOX – FORD Shown 0180885 WIRING BOX 0181784 WIRING BOX PANEL, FORD 0070967 CORROSION INHIBITOR 0180949 RHEOSTAT SUB ASSY 3040497 REPLACEMENT SWITCH Shown 3070001...

  • Page 475: Wiring Box - Ford, Before June 2003

    AB60J PARTS MANUAL WIRING BOX – FORD, BEFORE JUNE 2003 WIRING BOX – FORD, BEFORE JUNE 2003 Thu May 11 20:27:43 UTC 2017 4-20...
  • Page 476 AB60J PARTS MANUAL WIRING BOX – FORD, BEFORE JUNE 2003 Item Part No. Name 0180787 INSTRUMENT PANEL 5560609 SCREW, #10-24 X .50 TRHD PLTD 5 984069 NUT 1/4-20 HEX 3070003 AMMETER 3020013 SW TGL SPST ON OFF SEALED 7630140 FILTER CONDITION INDICATOR 1 5093004 CLP CUSH .750 VINYL COATED...
  • Page 477 AB60J PARTS MANUAL WIRING BOX – FORD, BEFORE JUNE 2003 Item Part No. Name 0070753 WIRE 16 R6I R6I 12 0071583 WIRE 12 R8I R8I 5 0070746 WIRE 16 R6I R6I 9 0060373 JUMPER STRAP - (USED ON SQUARE D SWITCH ONLY) 0070730 WIRE 16 R6I R6I 5.5...
  • Page 478 AB60J PARTS MANUAL WIRING BOX PANEL – CUMMINS ELECTRICAL WIRING BOX PANEL – CUMMINS Thu May 11 20:27:44 UTC 2017 4-21...

  • Page 479: Wiring Box Panel - Cummins

    AB60J PARTS MANUAL WIRING BOX PANEL – CUMMINS Item Part No. Name 0181555 WIRING BOX PANEL – Shown CUMMINS 0180796 PANEL, DRILLED 3044712 TERM STRIP (12) #10 STUD 3040433 TERMINAL STRIP 12 CIRCUIT 0181552 DECAL, POWER 0181553 DECAL, TERMINAL STRIP...
  • Page 480 AB60J PARTS MANUAL WIRING BOX PANEL – CUMMINS Item Part No. Name 0073253 WIRE R10I R10I 11 DIO SP 0181434 DIODE/RESISTER WIRE 0070682 DIODE WIRE 0181073 RESISTER WIRE - (5 OHM) 0140317 DIODE WIRE 0151205 WIRE 16 FEM188 FEM250FI 7...

  • Page 481: Wiring Box Panel - Ford

    AB60J PARTS MANUAL WIRING BOX PANEL – FORD ELECTRICAL WIRING BOX PANEL – FORD Thu May 11 20:27:45 UTC 2017 4-22...
  • Page 482 AB60J PARTS MANUAL WIRING BOX PANEL – FORD Item Part No. Name 0181784 WIRING BOX PANEL – FORD 0180796 PANEL, DRILLED 3044712 TERM STRIP (12) #10 STUD 3040433 TERMINAL STRIP 12 CIRCUIT 0181552 DECAL, POWER 0181553 DECAL, TERMINAL STRIP 0181107...
  • Page 483 AB60J PARTS MANUAL WIRING BOX PANEL – FORD Item Part No. Name 0073253 WIRE R10I R10I 11 DIO SP 0110471 DIODE WIRE 0070682 DIODE WIRE 0181073 RESISTER WIRE - (5 OHM) 0140317 DIODE WIRE 0151205 WIRE 16 FEM188 FEM250FI 7...

  • Page 484: Platform Foot Switch

    AB60J PARTS MANUAL PLATFORM FOOT SWITCH ELECTRICAL PLATFORM FOOT SWITCH Thu May 11 20:27:45 UTC 2017 4-23...
  • Page 485 AB60J PARTS MANUAL PLATFORM FOOT SWITCH Item Part No. Name 0071800 FOOT SWITCH ASSEMBLY Shown 3020021 FOOT SWITCH 3020037 REPLACEMENT SWITCH, Shown SQUARE D SWITCH 3020038 REPLACEMENT SWITCH, Shown SQUARE D SWITCH, 8 POLE – NOT SHOWN 0070596 WIRE HARNESS, PLATFORM...
  • Page 486 AB60J PARTS MANUAL UPPER CONTROL BOX – 2 WHEEL DRIVE ELECTRICAL UPPER CONTROL BOX – 2 WHEEL DRIVE Thu May 11 20:27:46 UTC 2017 4-24...

  • Page 487: Upper Control Box - 2 Wheel Drive

    AB60J PARTS MANUAL UPPER CONTROL BOX – 2 WHEEL DRIVE Item Part No. Name 0181609 UPPER CONTROL BOX, 2 Shown WHEEL DRIVE 0180842 CONTROL BOX 0180846 PLACARD PLATFORM CONTROL BOX FRONT 0180845 PLACARD PLATFORM CONTROL BOX TOP 3040068 CIRCUIT BREAKER 3 AMP...
  • Page 488 AB60J PARTS MANUAL UPPER CONTROL BOX – 2 WHEEL DRIVE UPPER CONTROL BOX – 2 WHEEL DRIVE Thu May 11 20:27:47 UTC 2017 4-24...
  • Page 489 AB60J PARTS MANUAL UPPER CONTROL BOX – 2 WHEEL DRIVE Item Part No. Name 0072530 DECAL DNGR ELEC HAZARD 7190001 GASKET 3040187 CONN .500 .313-.438 3040070 NUT LKG HUB .500 3040110 NUT LKG HUB .750 5560663 WSHR STAR 6 EXTERNAL...
  • Page 490 AB60J PARTS MANUAL UPPER CONTROL BOX – 2 WHEEL DRIVE Item Part No. Name 0180851 HARNESS 3040508 TIME DELAY MODULE 0060373 JUMPER CONTROLLER 0070747 WIRE 16 R6I R6I 3 3040083 TERM FEM250FI 16/14 0070730 WIRE 16 R6I R6I 5.5 0070711...
  • Page 491 AB60J PARTS MANUAL UPPER CONTROL BOX – 2 WHEEL DRIVE Item Part No. Name 986019 WASHER, FLAT, .25 STANDARD, PLATED 5560341 WSHR STAR .250 EXT TOOTH 5569711 GROMMET .438ID .938OD .125 480652 ALARM97DBA DUAL TONE 12/24V 0181030 WIRE 16 FEM188 FEM250FI 15...
  • Page 492 AB60J PARTS MANUAL UPPER CONTROL BOX – 4 WHEEL DRIVE ELECTRICAL UPPER CONTROL BOX – 4 WHEEL DRIVE Thu May 11 20:27:48 UTC 2017 4-25...

  • Page 493: Upper Control Box - 4 Wheel Drive

    AB60J PARTS MANUAL UPPER CONTROL BOX – 4 WHEEL DRIVE Item Part No. Name 0181610 UPPER CONTROL BOX, 4 Shown WHEEL DRIVE 0180842 CONTROL BOX 0180846 PLACARD PLATFORM CONTROL BOX FRONT 0180845 PLACARD PLATFORM CONTROL BOX TOP 3040068 CIRCUIT BREAKER 3 AMP...
  • Page 494 AB60J PARTS MANUAL UPPER CONTROL BOX – 4 WHEEL DRIVE UPPER CONTROL BOX – 4 WHEEL DRIVE Thu May 11 20:27:48 UTC 2017 4-25...
  • Page 495 AB60J PARTS MANUAL UPPER CONTROL BOX – 4 WHEEL DRIVE Item Part No. Name 0072530 DECAL DNGR ELEC HAZARD 7190001 GASKET 3040187 CONN .500 .313-.438 3040070 NUT LKG HUB .500 3040110 NUT LKG HUB .750 5560663 WSHR STAR 6 EXTERNAL...
  • Page 496 AB60J PARTS MANUAL UPPER CONTROL BOX – 4 WHEEL DRIVE Item Part No. Name 0060373 JUMPER CONTROLLER 0070747 WIRE 16 R6I R6I 3 0070730 WIRE 16 R6I R6I 5.5 0070711 WIRE 12 R10I R10I 3 0070712 WIRE 12 R10I R10I 5...
  • Page 497 AB60J PARTS MANUAL UPPER CONTROL BOX – 4 WHEEL DRIVE Item Part No. Name 480652 ALARM97DBA DUAL TONE 12/24V 0181030 WIRE 16 FEM188 FEM250FI 15 0071511 WIRE 18 FEM188I FEM188I 11 3044161 BOOT BTRY CABLE END BLACK 0090622 WIRE 18 FEM188I FEM250I 9...
  • Page 498 AB60J PARTS MANUAL PLATFORM CONTROL BOX ASSEMBLY – KU ELECTRICAL PLATFORM CONTROL BOX ASSEMBLY – KU Thu May 11 20:27:49 UTC 2017 4-26...
  • Page 499 AB60J PARTS MANUAL PLATFORM CONTROL BOX ASSEMBLY – KU Item Part No. Name 0182422 PLATFORM CONTROL BOX Shown ASSEMBLY – KU 0180842 CONTROL BOX 0180846 PLACARD PLATFORM CONTROL BOX FRONT 0180845 PLACARD PLATFORM CONTROL BOX TOP 3040068 CIRCUIT BREAKER 3 AMP...

  • Page 500: Platform Control Box Assembly - Ku

    AB60J PARTS MANUAL PLATFORM CONTROL BOX ASSEMBLY – KU PLATFORM CONTROL BOX ASSEMBLY – KU Thu May 11 20:27:49 UTC 2017 4-26...
  • Page 501 AB60J PARTS MANUAL PLATFORM CONTROL BOX ASSEMBLY – KU Item Part No. Name 3040110 NUT LKG HUB .750 5560663 WSHR STAR 6 EXTERNAL TOOTH 3040116 CONN .75 .500-.625 3040295 CONN .75 .625-.75 3020090 SW ANTI-RESTART IGNITION 987349 WSHR LOCK 6...
  • Page 502 AB60J PARTS MANUAL PLATFORM CONTROL BOX ASSEMBLY – KU Item Part No. Name 0070712 WIRE 12 R10I R10I 5 0071546 WIRE 18 R6I FEM188I 8 0151910 WIRE 16 R6 R10 14 0181074 WIRE 16 SPECIAL (SEE DWG) 0180889 WIRE 18 DIO SEE DWG...
  • Page 503 AB60J PARTS MANUAL PLATFORM CONTROL BOX ASSEMBLY – KU Item Part No. Name 3044161 BOOT BTRY CABLE END BLACK 0090622 WIRE 18 FEM188I FEM250I 9 0151205 WIRE 16 FEM188 FEM250FI 7 987359 WASHER STAR #10 974269 SCR RDH 6-32 1.00...
  • Page 504 AB60J PARTS MANUAL PLATFORM CONTROL BOXASSEMBLY SP KU W/OVERLOAD ELECTRICAL PLATFORM CONTROL BOXASSEMBLY SP KU W/OVERLOAD Thu May 11 20:27:51 UTC 2017 4-27...

  • Page 505: Platform Control Boxassembly Sp Ku W/Overload

    AB60J PARTS MANUAL PLATFORM CONTROL BOXASSEMBLY SP KU W/OVERLOAD Item Part No. Name 0182479 B PLATFORM CONTROL Shown BOXASSEMBLY SP KU W/OVERLOAD 0180842 CONTROL BOX 0180846 PLACARD PLATFORM CONTROL BOX FRONT 3040068 CIRCUIT BREAKER 3 AMP 3040353 CIRCUIT BREAKER 3 AMP...
  • Page 506 PLATFORM CONTROL BOXASSEMBLY SP KU W/OVERLOAD AB60J PARTS MANUAL PLATFORM CONTROL BOXASSEMBLY SP KU W/OVERLOAD Thu May 11 20:27:51 UTC 2017 4-27...
  • Page 507 AB60J PARTS MANUAL PLATFORM CONTROL BOXASSEMBLY SP KU W/OVERLOAD Item Part No. Name 3040295 CONN .75 .625-.75 3020090 SW ANTI-RESTART IGNITION 0180886 DECAL TERM STRIP HORIZ 10TERM 0180887 DECAL TERM STRIP HORIZ 13TERM 0180888 DECAL TERM STRIP HORIZ 13TERM 3040508...
  • Page 508 AB60J PARTS MANUAL PLATFORM CONTROL BOXASSEMBLY SP KU W/OVERLOAD Item Part No. Name 5560034 10-24UNC HEX LOCK NUT 5560004 .250-20UNC HEX LOCK NUT 5560673 MACHINE SCREW, RND HD, SLOTTED, #10-24 UNC X 1.00 MTS 16, 18 970029 BLT HEX .250-20 .75 GR5-Z/P...
  • Page 509 AB60J PARTS MANUAL PLATFORM CONTROL BOXASSEMBLY SP KU W/OVERLOAD Item Part No. Name 0181031 WIRE 12 R10 FEM250FI 11 0071557 WIRE 18 R8I MALE250FI 7 0181030 WIRE 16 FEM188 FEM250FI 15 0090975 WIRE 12 R10I FEM250FI 9 0070747 WIRE 16 R6I R6I 3...
  • Page 510 AB60J PARTS MANUAL PLATFORM CONTROL BOXASSEMBLY SP KU W/OVERLOAD Item Part No. Name 0181877 CAPACITOR ASSY 0071534 WIRE 18 R10I FEM188I 21 3044584 TERM R10I 12/10 3040083 TERM FEM250FI 16/14 PLATFORM CONTROL BOXASSEMBLY SP KU W/OVERLOAD Thu May 11 20:27:51 UTC 2017...
  • Page 511 AB60J PARTS MANUAL PLATFORM CONTROL BOX ASSEMBLY 4X4 – FLUID TECH ELECTRICAL PLATFORM CONTROL BOX ASSEMBLY 4X4 – FLUID TECH Thu May 11 20:27:52 UTC 2017 4-28...

  • Page 512: Platform Control Box Assembly 4X4 - Fluid Tech

    AB60J PARTS MANUAL PLATFORM CONTROL BOX ASSEMBLY 4X4 – FLUID TECH Item Part No. Name 0182200 PLATFORM CONTROL BOX Shown ASSEMBLY 4X4 – FLUID TECH 0180842 CONTROL BOX 0180846 PLACARD PLATFORM CONTROL BOX FRONT 0180845 PLACARD PLATFORM CONTROL BOX TOP...
  • Page 513 PLATFORM CONTROL BOX ASSEMBLY 4X4 – FLUID TECH AB60J PARTS MANUAL PLATFORM CONTROL BOX ASSEMBLY 4X4 – FLUID TECH Thu May 11 20:27:52 UTC 2017 4-28...
  • Page 514 AB60J PARTS MANUAL PLATFORM CONTROL BOX ASSEMBLY 4X4 – FLUID TECH Item Part No. Name 3040110 NUT LKG HUB .750 PNNA WASHER STAR TOOTH #6 3040116 CONN .75 .500-.625 3040295 CONN .75 .625-.75 0084135 WIRE 16 F250FI F188I 9 RSTR7.5...
  • Page 515 AB60J PARTS MANUAL PLATFORM CONTROL BOX ASSEMBLY 4X4 – FLUID TECH Item Part No. Name 0070711 WIRE 12 R10I R10I 3 0070712 WIRE 12 R10I R10I 5 0071546 WIRE 18 R6I FEM188I 8 0151910 WIRE 16 R6 R10 14 0181074...
  • Page 516 AB60J PARTS MANUAL PLATFORM CONTROL BOX ASSEMBLY 4X4 – FLUID TECH Item Part No. Name 3011061 TERM 10I 16/14 0090622 WIRE 18 FEM188I FEM250I 9 0151205 WIRE 16 FEM188 FEM250FI 7 5560703 WSHR STAR 10 EXTERNAL TOOTH 5560700 MACHINE SCREW, RND HD, SLOTTED, #6-32 UNC X 1.00 MTS...
  • Page 517 AB60J PARTS MANUAL PLATFORM CONTROL BOX ASSEMBLY KU HYDRAFORCE ELECTRICAL PLATFORM CONTROL BOX ASSEMBLY KU HYDRAFORCE Thu May 11 20:27:53 UTC 2017 4-29...

  • Page 518: Platform Control Box Assembly Ku Hydraforce

    AB60J PARTS MANUAL PLATFORM CONTROL BOX ASSEMBLY KU HYDRAFORCE Item Part No. Name 0182447 B PLATFORM CONTROL BOX Shown ASSEMBLY KU HYDRAFORCE 0180842 CONTROL BOX 0180846 PLACARD PLATFORM CONTROL BOX FRONT 0180845 PLACARD PLATFORM CONTROL BOX TOP 3040068 CIRCUIT BREAKER 3 AMP...
  • Page 519 PLATFORM CONTROL BOX ASSEMBLY KU HYDRAFORCE AB60J PARTS MANUAL PLATFORM CONTROL BOX ASSEMBLY KU HYDRAFORCE Thu May 11 20:27:53 UTC 2017 4-29...
  • Page 520 AB60J PARTS MANUAL PLATFORM CONTROL BOX ASSEMBLY KU HYDRAFORCE Item Part No. Name 5560663 WSHR STAR 6 EXTERNAL TOOTH 3040116 CONN .75 .500-.625 3040295 CONN .75 .625-.75 3020090 SW ANTI-RESTART IGNITION 987349 WSHR LOCK 6 986159 WASHER, FLAT, #6, NARROW,...
  • Page 521 AB60J PARTS MANUAL PLATFORM CONTROL BOX ASSEMBLY KU HYDRAFORCE Item Part No. Name 0151910 WIRE 16 R6 R10 14 0181074 WIRE 16 SPECIAL (SEE DWG) 0180889 WIRE 18 DIO SEE DWG 0071534 WIRE 18 R10I FEM188I 21 3040083 TERM FEM250FI 16/14 0181028 WIRE 16 R6 FEM188 10.5...
  • Page 522 AB60J PARTS MANUAL PLATFORM CONTROL BOX ASSEMBLY KU HYDRAFORCE Item Part No. Name 987359 WASHER STAR #10 974269 SCR RDH 6-32 1.00 5560673 MACHINE SCREW, RND HD, SLOTTED, #10-24 UNC X 1.00 MTS 16, 18 5560654 WSHR LOCK 10 984049...

  • Page 523: Platf Cont Box Assy Ce/Ku

    AB60J PARTS MANUAL PLATF CONT BOX ASSY CE/KU ELECTRICAL PLATF CONT BOX ASSY CE/KU Thu May 11 20:27:54 UTC 2017 4-30...
  • Page 524 AB60J PARTS MANUAL PLATF CONT BOX ASSY CE/KU Item Part No. Name 0182464 B PLATF CONT BOX ASSY CE/KU 0070967 CORROSION INHIBITOR STICK- BACK 0071269 DECAL HORN 0072530 DECAL DNGR ELEC HAZARD 0075247 PLACARD OVERLOAD 0161819E DECAL CE EMER LOWERING...
  • Page 525 AB60J PARTS MANUAL PLATF CONT BOX ASSY CE/KU PLATF CONT BOX ASSY CE/KU Thu May 11 20:27:55 UTC 2017 4-30...
  • Page 526 AB60J PARTS MANUAL PLATF CONT BOX ASSY CE/KU Item Part No. Name 986009 WASHER, FLAT, #10, STANDARD 986019 WASHER, FLAT, .25 STANDARD, PLATED 986159 WASHER, FLAT, #6, NARROW, PLTD (SAE) 3020013 SW TGL SPST (ON) OFF 3020017 SWITCH TOGGLE DPDT...
  • Page 527 AB60J PARTS MANUAL PLATF CONT BOX ASSY CE/KU Item Part No. Name 3040493 CONTROLLER 33HZ LIFT/SWING 1 3040508 TIME DELAY MODULE 3040535 CIRCUIT BREAKER 3 AMP 3044710 TERM STRIP (10) #10 STUD 3069524 LIGHT, RED LED 12V .69DIA 5560004 .250-20UNC HEX LOCK NUT 5560033 NUT HEX LKG .375-16...
  • Page 528 AB60J PARTS MANUAL PLATF CONT BOX ASSY CE/KU Item Part No. Name 0070730 WIRE 16 R6I R6I 5.5 0070711 WIRE 12 R10I R10I 3 0070712 WIRE 12 R10I R10I 5 0060373 JUMPER CONTROLLER 0151910 WIRE 16 R6 R10 14 0181074...
  • Page 529 AB60J PARTS MANUAL PLATF CONT BOX ASSY CE/KU Item Part No. Name 0084135 WIRE 16 F250FI F188I 9 RSTR7.5 0172248 WIRE 16 FEM188I FEM188I DIO 0150756 WIRE 16 R8I FEM250FI 36 3046697 TERM FEM188I 16/14GA 0074589 WIRE 12 R6I R10I 34...
  • Page 530 AB60J PARTS MANUAL UPPER CONTROL BOX – CE ELECTRICAL UPPER CONTROL BOX – CE Thu May 11 20:27:56 UTC 2017 4-31...
  • Page 531 AB60J PARTS MANUAL UPPER CONTROL BOX – CE Item Part No. Name A18054C UPPER CONTROL BOX – CE Shown 0180842 CONTROL BOX 0180846 PLACARD PLATFORM CONTROL BOX FRONT 0180845E PLACARD PLATFORM CONTROL BOX TOP ATB60 (CE) 3040068 CIRCUIT BREAKER 3 AMP...

  • Page 532: Upper Control Box - Ce

    AB60J PARTS MANUAL UPPER CONTROL BOX – CE UPPER CONTROL BOX – CE Thu May 11 20:27:56 UTC 2017 4-31...
  • Page 533 AB60J PARTS MANUAL UPPER CONTROL BOX – CE Item Part No. Name 3040110 NUT LKG HUB .750 5560663 WSHR STAR 6 EXTERNAL TOOTH 3040116 CONN .75 .500-.625 3040295 CONN .75 .625-.75 3020090 SW ANTI-RESTART IGNITION 5560288 SCR SLFTPG .250-.50 TYPE B...
  • Page 534 AB60J PARTS MANUAL UPPER CONTROL BOX – CE Item Part No. Name 0070712 WIRE 12 R10I R10I 5 0075256 WIRE 18 (SEE DRW) 0151910 WIRE 16 R6 R10 14 0181074 WIRE 16 SPECIAL (SEE DWG) 0180889 WIRE 18 DIO SEE DWG...
  • Page 535 AB60J PARTS MANUAL UPPER CONTROL BOX – CE Item Part No. Name 0151205 WIRE 16 FEM188 FEM250FI 7 5560703 WSHR STAR 10 EXTERNAL TOOTH 974269 SCR RDH 6-32 1.00 5560673 MACHINE SCREW, RND HD, SLOTTED, #10-24 UNC X 1.00 MTS 16, 18...
  • Page 536 AB60J PARTS MANUAL UPPER CONTROL BOX – CE Item Part No. Name 0172248 WIRE 16 FEM188I FEM188I DIO 0182067 WIRE 16 NONE NONE 2 0192093 WIRE 3040293 DIODE 3 AMP 600V 0083980 WIRE 16 R6I FEM188I 20 DIO 0071812 WIRE 16 R10 FEM250FI 18...
  • Page 537 AB60J PARTS MANUAL BOOM EXTEND SWITCH ELECTRICAL BOOM EXTEND SWITCH Thu May 11 20:27:57 UTC 2017 4-32...

  • Page 538: Boom Extend Switch

    AB60J PARTS MANUAL BOOM EXTEND SWITCH Item Part No. Name 0180923 BOOM EXTEND SWITCH 3020079 SWITCH 0180927 WIRE HARNESS, BOOM EXTEND SWITCH 3040187 CONN .500 .313-.438 3040070 NUT LKG HUB .500 BOOM EXTEND SWITCH Thu May 11 20:27:57 UTC 2017...

  • Page 539: Boom Lift Switch

    AB60J PARTS MANUAL BOOM LIFT SWITCH ELECTRICAL BOOM LIFT SWITCH Thu May 11 20:27:57 UTC 2017 4-33...
  • Page 540 AB60J PARTS MANUAL BOOM LIFT SWITCH Item Part No. Name 0180994 BOOM SWITCH Shown 0180995 WIRE HARNESS, BOOM LIFT SWITCH 3020059 SWITCH 3028809 ASSY LIMIT SWITCH SR ADJ Shown 3040115 CONN .500 .375-.500 3011601 WIRE 16GA SINGLE CONDUCTOR BLK-TYPE GPT 3040070 NUT LKG HUB .500...

  • Page 541: Gfci 110 Volt Power

    AB60J PARTS MANUAL GFCI 110 VOLT POWER ELECTRICAL GFCI 110 VOLT POWER Thu May 11 20:27:57 UTC 2017 4-34...
  • Page 542 AB60J PARTS MANUAL GFCI 110 VOLT POWER Item Part No. Name A07034F 110 VOLT POWER TO Shown PLATFORM INSTALLATION 3040252 CIRCUIT BREAKER 15 AMP 3044854 TERM R10I 12/10 0071582 WIRE 12 R10I FKD81 4.5 3040624 -RECEPTICAL GFCI OUTLET 20AMP 3040397...

  • Page 543: Controller - Drive/Steer

    AB60J PARTS MANUAL CONTROLLER – DRIVE/STEER ELECTRICAL CONTROLLER – DRIVE/STEER Thu May 11 20:27:58 UTC 2017 4-35...
  • Page 544 AB60J PARTS MANUAL CONTROLLER – DRIVE/STEER Item Part No. Name 3040779 CONTROLLER DRIVE/STEER Shown UNIVERSAL 2660002 KNOB 3040086 SHAFT 3040146 BOOT 8150145 RING 8150146 TENSION CLIP 3040169 BOOT CLAMP RING 8150147 8150009 FIXED CAM 8150135 “E” CLIP 8150148 MODIFIED BRACKET...
  • Page 545 AB60J PARTS MANUAL CONTROLLER – DRIVE/STEER Item Part No. Name 8150082 BLANK CAM SHAFT 8150013 TENSION PIN 8150153 HEAT SINK 8150140 SCREW #4-40 X 1-1/4 INCH LONG 4 8150137 SCREW #4-40 X 3/4 INCH LONG 3040392 POT WITH BRACKET AND...

  • Page 546: Controller - Lift/Swing

    AB60J PARTS MANUAL CONTROLLER – LIFT/SWING ELECTRICAL CONTROLLER – LIFT/SWING Thu May 11 20:27:58 UTC 2017 4-36...
  • Page 547 AB60J PARTS MANUAL CONTROLLER – LIFT/SWING Item Part No. Name 3040780 A CONTROLLER – LIFT/SWING Shown 2660002 KNOB 3040086 SHAFT 3040146 BOOT 8150145 RING 8150146 TENSION CLIP 3040169 BOOT CLAMP RING 8150009 FIXED CAM 8150135 “E” CLIP 8150148 MODIFIED BRACKET...
  • Page 548 AB60J PARTS MANUAL CONTROLLER – LIFT/SWING Item Part No. Name 3040392 POT WITH BRACKET AND CONNECTOR 8150154 SCREW METRIC M4 X 6MM LONG DIN 85 8150155 WASHER METRIC M4 8150141 WASHER METRIC M3.5 X 16MM LONG DIN 85 8150156 WASHER...

  • Page 549: Options

    AB60J PARTS MANUAL LP OPTION OPTIONS LP OPTION Thu May 11 20:27:58 UTC 2017...

  • Page 550: Lp Option

    AB60J PARTS MANUAL LP OPTION Item Part No. Name 0180169 LP OPTION Shown 5010011 HOSE SAE30R2-05 .312 FUEL 0070974 COUPLER FEMALE LPG PACKAGE QT 5550028 CLP WORM DRV .25-.63 .31 BAND 0080668 BULKHEAD TEE MTG ANGLE 0081441 DECAL CAUTN LIQ...
  • Page 551 AB60J PARTS MANUAL LP OPTION Item Part No. Name PNNA WASHER, 1/4 FLAT 3044070 TERM BUTT CONN INSUL 22/18 LP OPTION Thu May 11 20:27:58 UTC 2017...
  • Page 552 AB60J PARTS MANUAL FUEL EMPTY INDICATOR LIGHT OPTIONS FUEL EMPTY INDICATOR LIGHT Thu May 11 20:27:59 UTC 2017...

  • Page 553: Fuel Empty Indicator Light

    AB60J PARTS MANUAL FUEL EMPTY INDICATOR LIGHT Item Part No. Name 0180152 FUEL EMPTY INDICATOR Shown LIGHT 3020116 SWITCH, 40 PSI PRESSURE 3060079 INDICATOR LIGHT, WHITE 3061815 LIGHT BULB 5090043 NIPPLE , 1/4 NPT CLOSE, BRASS 5090042 STREET TEE, 1/4 NPT FEM,...

  • Page 554: Driving Lights 2 Front 2 Rear

    AB60J PARTS MANUAL DRIVING LIGHTS 2 FRONT 2 REAR OPTIONS DRIVING LIGHTS 2 FRONT 2 REAR Thu May 11 20:27:59 UTC 2017...
  • Page 555 AB60J PARTS MANUAL DRIVING LIGHTS 2 FRONT 2 REAR Item Part No. Name 0182259 DRIVING LIGHTS 2 FRONT 2 Shown REAR 3069528 WORK LIGHT – LED OVAL 5569003 GROMMET 5093019 CLP CUSH .375 VINYL COATED 3044142 TERM R6I 22/18 3040068...
  • Page 556 AB60J PARTS MANUAL DRIVING LIGHTS 2 FRONT 2 REAR Item Part No. Name 0182278 DECAL LIGHTS CIRCUIT BREAKER DRIVING LIGHTS 2 FRONT 2 REAR Thu May 11 20:27:59 UTC 2017...
  • Page 557 AB60J PARTS MANUAL PERSONAL FALL ARREST ANCHORAGE OPTIONS PERSONAL FALL ARREST ANCHORAGE Thu May 11 20:27:59 UTC 2017...

  • Page 558: Personal Fall Arrest Anchorage

    AB60J PARTS MANUAL PERSONAL FALL ARREST ANCHORAGE Item Part No. Name 0182146 PERSONAL FALL ARREST Shown ANCHORAGE 0182138 BRACKET, PFAS LANYARD MOUNT 0182139 CLAMP, PFAS LANYARD MOUNT 0182140 DOUBLER, PFAS LANYARD MOUNT 0182147 DECAL, DO NOT LIFT 0182149 DECAL, DANGER PFAS...
  • Page 559 AB60J PARTS MANUAL BUMP GUARD INSTALLATION OPTIONS BUMP GUARD INSTALLATION Thu May 11 20:27:59 UTC 2017...
  • Page 560 AB60J PARTS MANUAL BUMP GUARD INSTALLATION Item Part No. Name 0180115 N PLATFORM BUMPGUARD – Shown AFTER MAY 2013 0181389 PLATFORM BUMPER FRAME WELDMENT 0181377 FRAME WELDMENT 0181382 SPRING KEEPER MOUNT ANGLE 0181381 SPRING KEEPER 5530013 SPRING 0181408 CHAIN ASSEMBLY 986019 WASHER, FLAT, .25 STANDARD,...

  • Page 561: Bump Guard Installation

    AB60J PARTS MANUAL BUMP GUARD INSTALLATION BUMP GUARD INSTALLATION Thu May 11 20:28:00 UTC 2017...
  • Page 562 AB60J PARTS MANUAL BUMP GUARD INSTALLATION Item Part No. Name SEE NOTE 1 CONNECTOR 3040187 CONN .500 .313-.438 3040110 NUT LKG HUB .750 986009 WASHER, FLAT, #10, STANDARD 974769 SCR RDH MACH 10-24 2.25 0181407 PLACARD 9980004 COVER KIT 9980003 PIPE INSULATION CLOSED 732"...

  • Page 563: Swing Gate Before May 2013

    AB60J PARTS MANUAL SWING GATE BEFORE MAY 2013 OPTIONS SWING GATE BEFORE MAY 2013 Thu May 11 20:28:00 UTC 2017...
  • Page 564 AB60J PARTS MANUAL SWING GATE BEFORE MAY 2013 Item Part No. Name 0182156 SWING GATE Shown 0071837 TORSION - SPRING 0074468 FULL HEIGHT SWINGING GATE , STEEL PLATFORMS (FULL HEIGHT SWINGING GATE FOR 8FT STEEL PLATFORMS) 0182155 WLDMNT, 8'' STL WTSG BMP...

  • Page 565: Swing Drive After May 2013

    AB60J PARTS MANUAL SWING DRIVE AFTER MAY 2013 OPTIONS SWING DRIVE AFTER MAY 2013 Thu May 11 20:28:00 UTC 2017...
  • Page 566 AB60J PARTS MANUAL SWING DRIVE AFTER MAY 2013 Item Part No. Name 0182156 SWING GATE Shown 0071837 TORSION - SPRING 0074468 FULL HEIGHT SWINGING GATE , STEEL PLATFORMS (FULL HEIGHT SWINGING GATE FOR 8FT STEEL PLATFORMS) 0182155 WLDMNT, 8'' STL WTSG BMP...
  • Page 567 AC GENERATOR HYDRAULIC POWERED BEFORE MARCH 2012 AB60J PARTS MANUAL OPTIONS AC GENERATOR HYDRAULIC POWERED BEFORE MARCH 2012 Thu May 11 20:28:01 UTC 2017...

  • Page 568: Ac Generator Hydraulic Powered Before March 2012

    AC GENERATOR HYDRAULIC POWERED BEFORE MARCH 2012 AB60J PARTS MANUAL Item Part No. Name 0180084 AC GENERATOR HYDRAULIC Shown POWERED AFTER MARCH 2012 0151471 AC GENERATOR SUB-ASSY 970909 BLT HEXHD .500-13 1.50 GR5- 5560039 NUT HEX LKG .500-13 0090757 JUMPER WIRE...
  • Page 569 AC GENERATOR HYDRAULIC POWERED BEFORE MARCH 2012 AB60J PARTS MANUAL Item Part No. Name 3040064 TERM MALE250FI 12/10 3044142 TERM R6I 22/18 3044158 TERM R6I 16/14 0151459 PLAC AC GENERATOR SWITCH 3040047 TERM FEM250FI 22/18 0181188 WIRE ASSY 110V POWER CORD...
  • Page 570 AB60J PARTS MANUAL OPTION BUMP GUARD 36X96 W/PADDING-SNORKELGUARD OPTIONS Image does not exist OPTION BUMP GUARD 36X96 W/PADDING-SNORKELGUARD Thu May 11 20:28:01 UTC 2017...

  • Page 571: Option Bump Guard 36X96 W/Padding-Snorkelguard

    AB60J PARTS MANUAL OPTION BUMP GUARD 36X96 W/PADDING-SNORKELGUARD Item Part No. Name 0113640A OPTION BUMP GUARD 36X96 W/PADDING-SNORKEL GUARD 1430385 ASSY PLAT BUMP GUARD 36X96 W/PADDING 0070901 PLAC CAUTN SERIAL NUMBER 0071425 PLAC PLATF IDENTIFICATION 0075372 PLAC PLAT CAP 500LBS 2...

  • Page 572: Airline To Platform

    AB60J PARTS MANUAL AIRLINE TO PLATFORM OPTIONS AIRLINE TO PLATFORM Thu May 11 20:28:02 UTC 2017 5-10...
  • Page 573 AB60J PARTS MANUAL AIRLINE TO PLATFORM Item Part No. Name 0180092 AIRLINE TO PLATFORM Shown 5240004 HOSE REEL 0181282 AIR HOSE, LOWER 0181281 AIR HOSE, UPPER 5550021 CABLE GUIDE 4 ROLLER 0181266 0181273 CABLE GUIDE BRACKET 0080749 BASE BOOM CABLE GUIDE...
  • Page 574 AB60J PARTS MANUAL AIRLINE TO PLATFORM Item Part No. Name 970589 BLT HEXHD .375-16 4.50 GR5 970469 BLT HEXHD .375-16 1.00 GR5 987119 WSHR LOCK .375 SPLIT TYPE 986299 WSHR FLAT .375 GR5 ZP 0150759 GUSSET 583466 CLAMP 970049 BLT HEXHD .250-20 1.00 GR5 986019 WASHER, FLAT, .25 STANDARD,...
  • Page 575 OPTION, 39 X 96 STL PLAT 500# TRI ENTRY SNORKEL GUARD CE AB60J PARTS MANUAL OPTIONS Image does not exist OPTION, 39 X 96 STL PLAT 500# TRI ENTRY SNORKEL GUARD CE Thu May 11 20:28:02 UTC 2017 5-11...

  • Page 576: Option, 39 X 96 Stl Plat 500# Tri Entry Snorkel Guard Ce

    OPTION, 39 X 96 STL PLAT 500# TRI ENTRY SNORKEL GUARD CE AB60J PARTS MANUAL Item Part No. Name 0182474 B OPTION, 39 X 96 STL PLAT 500# TRI ENTRY SNORKEL GUARD 1431573 GLOBAL STD PLATFORM ASSY W/SNORKEL GUARD 5560039 NUT HEX LKG .500-13...
  • Page 577 AB60J PARTS MANUAL COLD START WITH BATTERY – CUMMINS OPTIONS COLD START WITH BATTERY – CUMMINS Thu May 11 20:28:03 UTC 2017 5-12...

  • Page 578: Cold Start With Battery - Cummins

    AB60J PARTS MANUAL COLD START WITH BATTERY – CUMMINS Item Part No. Name 0180096 COLD START WITH BATTERY – Shown CUMMINS 7630014 COLD START KIT -(KIT INCLUDES ALL FITTINGS, NYLON TUBING AND ATOMIZER NOZZLE - NOT SOLD SEPARATELY 3011601 WIRE 16GA SINGLE...
  • Page 579 AB60J PARTS MANUAL COLD START WITH BATTERY – CUMMINS Item Part No. Name 0090125 BATTERY BRACKET 3050004 BLT BTRY HLDN .313-18 X 10.00 (J-BOLT) 3050008 BATTERY HOLD DOWN 0101566 WIRE 2/0 R375 R375 56 RED COLD START WITH BATTERY – CUMMINS...
  • Page 580 AB60J PARTS MANUAL DUAL FUEL – FORD-425 OPTIONS DUAL FUEL – FORD-425 Thu May 11 20:28:03 UTC 2017 5-13...

  • Page 581: Dual Fuel - Ford-425

    AB60J PARTS MANUAL DUAL FUEL – FORD-425 Item Part No. Name 0181795 DUAL FUEL – FORD-425 Shown 0112100 DUAL FUEL ENGINE, FORD LRG-425 0070974 COUPLER FEMALE LPG PACKAGE QT 0151815 JUMPER WIRE 0080668 BULKHEAD TEE MTG ANGLE 0081441 DECAL CAUTN LIQ...
  • Page 582 AB60J PARTS MANUAL DUAL FUEL – FORD-425 Item Part No. Name 5090033 STREET ELBOW 90° 1/4 NPT BRASS 970009 BLT HEXHD .250-20 .500 GR5 987099 WSHR LOCK .250 SPLIT TYPE 986019 WASHER, FLAT, .25 STANDARD, PLATED 0090492 PLACARD, DUAL FUEL SWITCH...
  • Page 583 AB60J PARTS MANUAL LP FUEL – FORD LRG-425 OPTIONS LP FUEL – FORD LRG-425 Thu May 11 20:28:04 UTC 2017 5-14...

  • Page 584: Lp Fuel - Ford Lrg-425

    AB60J PARTS MANUAL LP FUEL – FORD LRG-425 Item Part No. Name 0181804 LP FUEL – FORD LRG-425 Shown 0112100 DUAL FUEL ENGINE, FORD LRG-425 0070974 COUPLER FEMALE LPG PACKAGE QT 0181034 MOUNT BAR 0080668 BULKHEAD TEE MTG ANGLE 0081441...
  • Page 585 AB60J PARTS MANUAL LP FUEL – FORD LRG-425 Item Part No. Name 5090033 STREET ELBOW 90° 1/4 NPT BRASS 970009 BLT HEXHD .250-20 .500 GR5 987099 WSHR LOCK .250 SPLIT TYPE LP FUEL – FORD LRG-425 Thu May 11 20:28:04 UTC 2017...

  • Page 586: Driving Lights 4 Flood

    AB60J PARTS MANUAL DRIVING LIGHTS 4 FLOOD OPTIONS DRIVING LIGHTS 4 FLOOD Thu May 11 20:28:05 UTC 2017 5-15...
  • Page 587 AB60J PARTS MANUAL DRIVING LIGHTS 4 FLOOD Item Part No. Name 0180113 B DRIVING LIGHTS 4 FLOOD Shown 3067619 HALOGEN FLOOD LIGHT 5569003 GROMMET 5093019 CLP CUSH .375 VINYL COATED 3044142 TERM R6I 22/18 3040068 CIRCUIT BREAKER 3 AMP 3040469...
  • Page 588 AB60J PARTS MANUAL DRIVING LIGHTS WITH RED REAR LIGHTS OPTIONS DRIVING LIGHTS WITH RED REAR LIGHTS Thu May 11 20:28:05 UTC 2017 5-16...

  • Page 589: Driving Lights With Red Rear Lights

    AB60J PARTS MANUAL DRIVING LIGHTS WITH RED REAR LIGHTS Item Part No. Name 0180127 E DRIVING LIGHTS – AFTER MAY Shown 2013 3067619 HALOGEN FLOOD LIGHT 3064414 FLOOD LIGHT, WITH ROUND Shown BASE 3060017 TURN SIGNAL LIGHT 3020013 SW TGL SPST (ON) OFF...
  • Page 590 AB60J PARTS MANUAL DRIVING LIGHTS WITH RED REAR LIGHTS Item Part No. Name 986019 WASHER, FLAT, .25 STANDARD, PLATED 5560004 .250-20UNC HEX LOCK NUT DRIVING LIGHTS WITH RED REAR LIGHTS Thu May 11 20:28:05 UTC 2017 5-16...
  • Page 591 AB60J PARTS MANUAL EXTRA LP TANK OPTIONS EXTRA LP TANK Thu May 11 20:28:05 UTC 2017 5-17...

  • Page 592: Extra Lp Tank

    AB60J PARTS MANUAL EXTRA LP TANK Item Part No. Name 0181688 D EXTRA LP TANK Shown 9940018 LP TANK -FILLED -DUAL CERTIFY 43.5 LB LIQUID WITHDRAWAL 0070969 BRACKET ASSY LPG CYLINDER -(LEFT AND RIGHT HAND BRACKETS) 970449 BLT HEXHD .375-16 .750 GR5 986299 WSHR FLAT .375 GR5 ZP...

  • Page 593: Operators Horn After September 2010

    AB60J PARTS MANUAL OPERATORS HORN AFTER SEPTEMBER 2010 OPTIONS OPERATORS HORN AFTER SEPTEMBER 2010 Thu May 11 20:28:05 UTC 2017 5-18...
  • Page 594 AB60J PARTS MANUAL OPERATORS HORN AFTER SEPTEMBER 2010 Item Part No. Name 0180085 C OPERATORS HORN AFTER Shown SEPTEMBER 2010 3040127 HORN, 12 VOLT DC 3026027 SW PUSH BUTTON 7140092 SEAL KIT 600-0002-5/8 3040128 HORN RELAY, 12 VOLT DC 0071269...

  • Page 595: Heat Exchanger

    AB60J PARTS MANUAL HEAT EXCHANGER OPTIONS HEAT EXCHANGER Thu May 11 20:28:06 UTC 2017 5-19...
  • Page 596 AB60J PARTS MANUAL HEAT EXCHANGER Item Part No. Name 6050001 HEAT EXCHANGER 0181526 MOUNT BRACKET, HEAT EXCHANGER 6050003 TEMPERATURE CONTROLLER 0181529 MOUNT PLATE, TEMPERATURE CONTROLLER 5033729 MALE 90° ELBOW 5033720 MALE 90° ELBOW 5033633 MALE ADAPTER 5037011 FTG ELB90SWVL-20S-20S STL-...
  • Page 597 AB60J PARTS MANUAL HEAT EXCHANGER Item Part No. Name 970969 BLT HEXHD .500-13 3.00 GR 5 986359 WSHR FLAT .500 GR5 ZP 5560039 NUT HEX LKG .500-13 HEAT EXCHANGER Thu May 11 20:28:06 UTC 2017 5-19...
  • Page 598 AB60J PARTS MANUAL ISOLATION VALVE OPTIONS ISOLATION VALVE Thu May 11 20:28:06 UTC 2017 5-20...

  • Page 599: Isolation Valve

    AB60J PARTS MANUAL ISOLATION VALVE Item Part No. Name 0180117 A ISOLATION VALVE Shown 6010498 BALL VALVE 6010495 BALL VALVE 7720604 REDUCER BUSHING 3/4 X 1/2 7740014 CLOSE NIPPLE 1/2 NPT 7741214 CLOSE NIPPLE 1-1/2 NPT 0020277 3/8 INCH HYDRAULIC HOSE...
  • Page 600 AB60J PARTS MANUAL MOTION ALARM – DRIVE OPTIONS MOTION ALARM – DRIVE Thu May 11 20:28:06 UTC 2017 5-21...

  • Page 601: Motion Alarm - Drive

    AB60J PARTS MANUAL MOTION ALARM – DRIVE Item Part No. Name A18044 MOTION ALARM – DRIVE Shown 3040129 MOTION WARNING ALARM, STANDARD 3040462 MOTION WARNING ALARM, UL Shown APPROVED 5093000 CLP CUSH .438 VINYL COATED 0100570 WIRE 16 R101 R313 3...
  • Page 602 AB60J PARTS MANUAL OIL PRESSURE GAUGE – CUMMINS OPTIONS OIL PRESSURE GAUGE – CUMMINS Thu May 11 20:28:07 UTC 2017 5-22...

  • Page 603: Oil Pressure Gauge - Cummins

    AB60J PARTS MANUAL OIL PRESSURE GAUGE – CUMMINS Item Part No. Name 0180135 OIL PRESSURE GAUGE – Shown CUMMINS 0181459 INSTRUMENT PANEL 5210009 OIL PRESSURE GAUGE 5038801 FEMALE ADAPTER 5033703 FTG ELB90 MALE -2N-4S 5090018 PIPE TEE 0070772 HOSE-4-4S-4S 54 100R1 OIL PRESSURE GAUGE –...

  • Page 604: Platform Lights

    AB60J PARTS MANUAL PLATFORM LIGHTS OPTIONS PLATFORM LIGHTS Thu May 11 20:28:07 UTC 2017 5-23...
  • Page 605 AB60J PARTS MANUAL PLATFORM LIGHTS Item Part No. Name 0072012 F PLATF BOX COURTESY LIGHT Shown 0072004 LIGHT BRACKET WLDMT 5560648 SCR RDHD 10-24 .750 5560034 10-24UNC HEX LOCK NUT 5569003 GROMMET 3040038 FUSE HOLDER 3040039 FUSE 10 AMP AGC- -BUSS: 10...

  • Page 606: Proximity Sensing System

    AB60J PARTS MANUAL PROXIMITY SENSING SYSTEM OPTIONS PROXIMITY SENSING SYSTEM Thu May 11 20:28:07 UTC 2017 5-24...
  • Page 607 AB60J PARTS MANUAL PROXIMITY SENSING SYSTEM Item Part No. Name 0181436 D PROXIMITY SENSING SYSTEM Shown 0181333 PLATFORM, PROXIMITY SWITCH 0152257 ACTUATOR ROD 0152258 LIMIT SWITCH 0181437 LIMIT SWITCH MOUNT PLATE 970049 BLT HEXHD .250-20 1.00 GR5 986019 WASHER, FLAT, .25 STANDARD,...
  • Page 608 AB60J PARTS MANUAL PROXIMITY SENSING SYSTEM Item Part No. Name 3040300 CONN. .500 .188-.313 3040070 NUT LKG HUB .500 0181104 WIRE 12 R6 R6 6 9980006 3/8 ID PLASTIC FLEXIBLE PIPE 5093003 CLAMP 5093005 CLAMP 987099 WSHR LOCK .250 SPLIT TYPE...

  • Page 609: Tow Package

    AB60J PARTS MANUAL TOW PACKAGE OPTIONS TOW PACKAGE Thu May 11 20:28:08 UTC 2017 5-25...
  • Page 610 AB60J PARTS MANUAL TOW PACKAGE Item Part No. Name 0180091 E TOW PACKAGE Shown 6010616 STEERING FLOAT VALVE 0110817 TOW BAR WELDMENT UNO 41 0111464 CHASSIS BRKT WELDMENT 0181256 TIE ROD 0111465 TIE ROD 0080884 STEERING LUG 0111345 MOUNTING BAR...
  • Page 611 AB60J PARTS MANUAL TOW PACKAGE Item Part No. Name 0082160 DECAL, DANGER TOW PACKAGE 5569886 CAPSCREW 1/4-20 X 1-3/4 INCH LONG HEX HEAD GRADE 5 987099 WSHR LOCK .250 SPLIT TYPE 986019 WASHER, FLAT, .25 STANDARD, PLATED 5035705 FTG ELB45STRTHD-6B-6S STL-...
  • Page 612 AB60J PARTS MANUAL SAFETY BELT ANCHOR OPTIONS SAFETY BELT ANCHOR Thu May 11 20:28:08 UTC 2017 5-26...

  • Page 613: Safety Belt Anchor

    AB60J PARTS MANUAL SAFETY BELT ANCHOR Item Part No. Name 0080119 E SAFETY BELT ANCHOR Shown 0130088 BRACKET, SAFETY BELT 0130090 DOUBLER PLATE 5560674 CAPSCREW 5/16-18 X 1-1/2 INCH LONG HEX HEAD GRADE 5 5560031 .3125-18UNC HEX LOCK NUT SAFETY BELT ANCHOR...
  • Page 614 AB60J PARTS MANUAL SANDBLAST KIT OPTIONS SANDBLAST KIT Thu May 11 20:28:09 UTC 2017 5-27...

  • Page 615: Sandblast Kit

    AB60J PARTS MANUAL SANDBLAST KIT Item Part No. Name 0180086 A SANDBLAST KIT Shown 0181159 BELLOWS, LEVEL CYLINDERS 0181158 BELLOWS, MAIN LIFT CYLINDER 0181157 BELLOWS, RISER BOOM LIFT CYLINDER 5550020 CLP WORM DRV .75-1.75 SAE#20 5550050 CLAMP WORM DRV #52...

  • Page 616: Upper Control Box Cover Before June 2014

    AB60J PARTS MANUAL UPPER CONTROL BOX COVER BEFORE JUNE 2014 OPTIONS UPPER CONTROL BOX COVER BEFORE JUNE 2014 Thu May 11 20:28:09 UTC 2017 5-28...
  • Page 617 AB60J PARTS MANUAL UPPER CONTROL BOX COVER BEFORE JUNE 2014 Item Part No. Name 0071654 H PLATFORM COVER TB/ATB Shown 0073076 UPPER CONTROL BOX COVER – STANDARD 5560657 POP RIVET 1/8 INCH ALUMINUM #RVT-AD48 ABS 5560656 RVT POP .125 DIA .375 DMD STL...
  • Page 618 AB60J PARTS MANUAL WARNING LIGHT – 5° SLOPE INDICATOR OPTIONS WARNING LIGHT – 5° SLOPE INDICATOR Thu May 11 20:28:09 UTC 2017 5-29...

  • Page 619: Warning Light - 5° Slope Indicator

    AB60J PARTS MANUAL WARNING LIGHT – 5° SLOPE INDICATOR Item Part No. Name 0180109 C TILT ALARM LIGHT Shown 3065111 WARNING LIGHT, RED 0081384 DECAL WRN TILT LIGHT 0181374 JUMPER WIRE 0070730 WIRE 16 R6I R6I 5.5 WARNING LIGHT – 5° SLOPE INDICATOR...
  • Page 620 AB60J PARTS MANUAL WARNING LIGHTS – DUAL AMBER DRIVING OPTIONS WARNING LIGHTS – DUAL AMBER DRIVING Thu May 11 20:28:09 UTC 2017 5-30...

  • Page 621: Warning Lights - Dual Amber Driving

    AB60J PARTS MANUAL WARNING LIGHTS – DUAL AMBER DRIVING Item Part No. Name M00338 WARNING LIGHTS – DUAL Shown AMBER DRIVING 3060043 WARNING LIGHT, STROBE AMBER LENS 8050034 REPLACEMENT BULB Shown 5093019 CLP CUSH .375 VINYL COATED 5093001 CUSHION CLAMP #8 (1/2") 3090019 TUBE FLEXGARD .250 ID...
  • Page 622 AB60J PARTS MANUAL WARNING LIGHTS – DUAL BEACON OPTIONS WARNING LIGHTS – DUAL BEACON Thu May 11 20:28:09 UTC 2017 5-31...

  • Page 623: Warning Lights - Dual Beacon

    AB60J PARTS MANUAL WARNING LIGHTS – DUAL BEACON Item Part No. Name M00339 WARNING LIGHTS – DUAL Shown BEACON 3060083 WARNING LIGHT, AMBER LENS 3060085 REPLACEMENT AMBER LENS Shown 3060087 REPLACEMENT BULB Shown 3060084 WARNING LIGHT, RED LENS Shown 3060086...

  • Page 624: Water Line To Platform

    AB60J PARTS MANUAL WATER LINE TO PLATFORM OPTIONS WATER LINE TO PLATFORM Thu May 11 20:28:10 UTC 2017 5-32...
  • Page 625 AB60J PARTS MANUAL WATER LINE TO PLATFORM Item Part No. Name 0180162 WATER LINE TO PLATFORM Shown 5240010 HOSE REEL WITH HOSE 5010015 WATER HOSE 1 INCH DIAMETER X 18 FEET LONG 5260014 FITTING 1 INCH HOSE TO 1 INCH NPT...
  • Page 626 AB60J PARTS MANUAL WATER LINE TO PLATFORM Item Part No. Name 5560031 .3125-18UNC HEX LOCK NUT WATER LINE TO PLATFORM Thu May 11 20:28:10 UTC 2017 5-32...
  • Page 627 AB60J PARTS MANUAL WORK LIGHTS OPTIONS WORK LIGHTS Thu May 11 20:28:10 UTC 2017 5-33...
  • Page 628 AB60J PARTS MANUAL WORK LIGHTS Item Part No. Name 0080768 H PLATFORM WORKING LIGHTS 2 Shown FLOOD 3064413 LIGHT FLOOD WITH CLAMP – INCANDESCENT 3067620 LIGHT FLOOD WITH CLAMP – Shown HALOGEN 5093019 CLP CUSH .375 VINYL COATED 5093002 CLP CUSH .562 VINYL COATED...
  • Page 629 AB60J PARTS MANUAL GLAZIER PACKAGE INSTALLATION WORLD PLATFORM OPTIONS GLAZIER PACKAGE INSTALLATION WORLD PLATFORM Thu May 11 20:28:10 UTC 2017 5-34...

  • Page 630: Glazier Package Installation World Platform

    AB60J PARTS MANUAL GLAZIER PACKAGE INSTALLATION WORLD PLATFORM Item Part No. Name 0421812 A PLATFORM GLAZIER PACKAGE Shown 302544 -PIN SNAPPER W/ LNYD .375X2.25 0421811 GLAZIER TRAY ASSEMBLY 3 ENTRY PLATFORM 0421283 BRACKET, GLAZIER PACKAGE 0421285 DECAL, GLAZIER PACKAGE 562386 COMPARTMENT LITITURE 8.5 X...
  • Page 631 AB60J PARTS MANUAL FALL ANCHORAGE INSTALLATION OPTIONS FALL ANCHORAGE INSTALLATION Thu May 11 20:28:11 UTC 2017 5-35...

  • Page 632: Fall Anchorage Installation

    AB60J PARTS MANUAL FALL ANCHORAGE INSTALLATION Item Part No. Name 1430797 B FALL ANCHORAGE Shown INSTALLATION 0182139 CLAMP, PFAS LANYARD MOUNT 0182140 DOUBLER, PFAS LANYARD MOUNT 0182147 DECAL, DO NOT LIFT 0182149 DECAL, DANGER PFAS FALLING HAZARD 0360891 BRACKET, PFAS LANYARD...

  • Page 633: Glazier Package Installation

    AB60J PARTS MANUAL GLAZIER PACKAGE INSTALLATION OPTIONS GLAZIER PACKAGE INSTALLATION Thu May 11 20:28:11 UTC 2017 5-36...
  • Page 634 AB60J PARTS MANUAL GLAZIER PACKAGE INSTALLATION Item Part No. Name 0421068 A PLATFORM GLAZIER PACKAGE Shown 302544 -PIN SNAPPER W/ LNYD .375X2.25 0421811 GLAZIER TRAY ASSEMBLY 3 ENTRY PLATFORM 0421283 BRACKET, GLAZIER PACKAGE 0421285 DECAL, GLAZIER PACKAGE 562386 COMPARTMENT LITITURE 8.5 X...
  • Page 635 AB60J PARTS MANUAL GRAVITY GATE SIDE ENTRY OPTIONS GRAVITY GATE SIDE ENTRY Thu May 11 20:28:11 UTC 2017 5-37...

  • Page 636: Gravity Gate Side Entry

    AB60J PARTS MANUAL GRAVITY GATE SIDE ENTRY Item Part No. Name 0075500 C GRAVITY GATE SIDE ENTRY Shown 0071953 SPCR .451ID .500OD 1.88 STL 0072563 BAR, PLATFORM WELDMENT 0075502 WELDMENT, GRAVITY GATE- SIDE 0150509 ROLLER 0181485 END CAP 5569865 BLT HEXHD .375-16 2.75 GR5 5560033 NUT HEX LKG .375-16...

  • Page 637: Swing Gate Side Midrail

    AB60J PARTS MANUAL SWING GATE SIDE MIDRAIL OPTIONS SWING GATE SIDE MIDRAIL Thu May 11 20:28:12 UTC 2017 5-38...
  • Page 638 AB60J PARTS MANUAL SWING GATE SIDE MIDRAIL Item Part No. Name 0075478 G SWING GATE SIDE MIDRAIL Shown 0071837 TORSION - SPRING 0075469 WELDMENT, SWING GATE BRACKET 0075471 WELDMENT, END SWING GATE 0075479 BRACKET, LATCH MOUNTING 300491 LATCH RH TRAY ROTARY...

  • Page 639: 220V Ac Generator Installation

    AB60J PARTS MANUAL 220V AC GENERATOR INSTALLATION OPTIONS 220V AC GENERATOR INSTALLATION Thu May 11 20:28:12 UTC 2017 5-39...
  • Page 640 AB60J PARTS MANUAL 220V AC GENERATOR INSTALLATION Item Part No. Name 0182054 B 220V AC GENERATOR Shown INSTALLATION 0074981 AC GENERATOR SUB- ASSEMBLY PNNA BOLT, HEXHD .50-13 X 1.50 GR5 PNNA NUT, 1/2-13 ESNA 0090757 JUMPER WIRE 3044161 BOOT BTRY CABLE END BLACK...
  • Page 641 AB60J PARTS MANUAL 220V AC GENERATOR INSTALLATION Item Part No. Name 3040064 TERM MALE250FI 12/10 3044142 TERM R6I 22/18 3044158 TERM R6I 16/14 0151459 PLAC AC GENERATOR SWITCH 3040047 TERM FEM250FI 22/18 0181188 WIRE ASSY 110V POWER CORD 110 in 5093004 CLAMP .750 AEROQUIP HOSE...

  • Page 642: All Motion Alarm

    AB60J PARTS MANUAL ALL MOTION ALARM OPTIONS ALL MOTION ALARM Thu May 11 20:28:13 UTC 2017 5-40...
  • Page 643 AB60J PARTS MANUAL ALL MOTION ALARM Item Part No. Name 0181994 A ALL MOTION ALARM Shown 3040129 MOTION WARNING ALARM, STANDARD 5093000 CLP CUSH .438 VINYL COATED 0151813 DIODE WIRE - (INCLUDES 3040293 DIODE) 3011801 WIRE 18GA SINGLE 3.0 FT...
  • Page 644 Always refer to the hydraulic system installation draw- Do not modify this aerial platform without prior writ- ings and the electrical wiring diagram before removing ten consent of the Snorkel Engineering Department. or disassembling associated parts. Modification may void the warranty, adversely affect...
  • Page 645 “Safety First” is a good slogan. function properly. Replace any guards and protective devices that have been removed to carry out maintenance and repair work. Maintenance – 2 AB60J – 0181971...
  • Page 646 Driving and Platform Work Lights No damage or deformation, proper operation Tow Kit In place, no damage or deformation Platform Glazier Package Good condition Bumpguard System Good condition, proper operation Placards and Decals In place and readable AB60J – 0181971 Maintenance – 3...
  • Page 647 Maintenance – 4 AB60J – 0181971...
  • Page 648 Main lift cylinder holding valve (3,4) Riser boom pin caps and tie wire (2,6) Follower arm pin caps and tie wire (2,6) Jib cylinder pin caps and tie wire (2,6) Jib cylinder holding valve (3,4) AB60J – 0181971 Maintenance – 5...
  • Page 649 Note: If correction action is required on any item, attach sheet indicating problem and action taken. All items have been properly checked and tested and found to be operating satisfactory or necessary corrective action has been completed. Inspected By: Date Maintenance – 6 AB60J – 0181971...
  • Page 650 Mobil Mobilube HD 80W-90 Engine coolant Check Condition See engine manufacturer's owner's manual Front wheel bearings Clean and repack Conoco Super Sta #2 Above 32° Mobilgrease CM-P Below 32° Mobilgrease CM-L Performed by: Date: AB60J – 0181971 Maintenance – 7...
  • Page 651 Maintenance – 8 AB60J – 0181971...
  • Page 652 Major Repairs Date Part Number Part Description Repair Performed AB60J – 0181971 Maintenance – 9...
  • Page 653 Maintenance – 10 AB60J – 0181971...
  • Page 654 Lubrication Points Lubrication Swing Drive Specific lubricants as recommended by Snorkel, Swing drive – Item 4. To check oil level, remove check should be used in maintaining the unit. If in doubt plug located on the front side of the gear box. Unit is...
  • Page 655 If questions still remain, contact Snorkel Customer Service Department for further information. When changing the filter element, the oil inside of the filter element, should be examined for deposits...
  • Page 656 6.35 volts for a 6 volt (open circuit, charged and discharged) can locate battery. a bad cell or weak battery. Load testing will pick out a bad cell when other methods fail. The point AB60J – 0181971 Maintenance – 13...
  • Page 657 One charging cycle per day is preferable. 24. Never store a battery in a discharged state. The sulfate that forms during discharge can make the battery impossible to recharge fully. Maintenance – 14 AB60J – 0181971...
  • Page 658 The chart may be used with both coarse and fine thread fasteners lightly lubricated. Increase torque by 20% when multiple tapered tooth (shake proof) lock washers are used. The torque values are given in foot-pounds. Inch/pound equivalent may be obtained by multiplying by 12. AB60J – 0181971 Maintenance – 15...
  • Page 659 Foot/pound equivalent may be obtained by dividing by 12. Inch/pound equivalent may be obtained by multiplying by 12. Newton/meter equivalent may be obtained by multiplying inch/pound by 0.1130. Newton/meter equivalent may be obtained by multiplying foot/pound by 1.3558. Maintenance – 16 AB60J – 0181971...
  • Page 660 AWA18022A Chassis hydraulics 2 wheel drive Page17 Snorkel model AB60J...
  • Page 661 AWA18023A Chassis hydraulics 4 wheel drive Page 18 Snorkel model AB60J...
  • Page 662 AWA18021A Hydraulic schematic Turntable/booms Page 19 Snorkel model AB60J...
  • Page 663 AW0181846 Wiring schematic Cummins 2 wheel drive Page 20 Snorkel model AB60J...
  • Page 664 AW0181847 Wiring schematic Cummins 4 wheel drive Page 21 Snorkel model AB60J...
  • Page 665 LEFT RIGHT BATTERY 12 VOLTS LEVEL DUAL SENSOR FUEL TILT (SHOWN RELAY SWITCH STARTER LEVEL) SOLENIOD FUEL FILTER PUMP OIL PRESSURE LOCK TILT MALFUNCTION SWITCH ALARM INDICATOR SWITCH AW0181821 Wiring schematic Ford 2 wheel drive Page 22 Snorkel model AB60J...
  • Page 666 AW0181820 Wiring schematic Ford 4 wheel drive Page 23 Snorkel model AB60J...
  • Page 667 AB60J PARTS MANUAL Appendix A:Pages Index CENTERPOST SUB-ASSEMBLY 4WD 3-31 220V AC GENERATOR INSTALLATION 5-39 CHASSIS AND TURNTABLE MOUNTING AC GENERATOR HYDRAULIC POWERED CHASSIS HYDRAULICS 4 WD BEFORE MARCH 2012 CHASSIS HYDRAULICS 4 WD, BEFORE JANUARY AC GENERATOR SUB-ASSEMBLY 2-69...
  • Page 668 AB60J PARTS MANUAL DUAL RELIEF/ANTI CAVITATION VALVE FLUID TECH 3-57 3-54 FLOW DIVIDER/COMBINER VALVE 2 WHEEL ELECTRICAL PANEL ASSEMBLY – KU 4-19 DRIVE 3-56 ELECTRICAL PANEL – CUMMINS 4-12 FLOW DIVIDER/MOTION CONTROL VALVE ELECTRICAL SCHEMATICS, AB60J ASSEMBLY 3-13 ELECTRICAL SPANISH W/OVERLOAD SUB-...

  • Page 669: Maintenance, Ab60J

    AB60J PARTS MANUAL LP FUEL – FORD LRG-425 5-14 PLACARDS AND DECALS 2-57, 2-58 LP OPTION PLACARDS AND DECALS INSTALL AFTER LPS AIR CLEANER INSTALLATION 2-46 FEBRUARY 2014 2-59 LPS INSTALLATION – GM ENGINE PLACARDS AND DECALS INSTALL AFTER MAIN BOOM LIFT CYLINDER...
  • Page 670 AB60J PARTS MANUAL SANDBLAST KIT 5-27 – GM ENGINE SENSE LINE DUMP VALVE 3-72 TURNTABLE ELECTRICAL – CUMMINS SLAVE LEVEL CYLINDER 3-49 TURNTABLE HYDRAULICS 4 WHEEL DRIVE 3-10 SLAVE LEVEL CYLINDER – GBI 3-51 TURNTABLE HYDRAULICS 4 WHEEL DRIVE, SLAVE LEVEL CYLINDER – PRINCE, before...

  • Page 671: Work Lights

    AB60J PARTS MANUAL WIRING BOX – CUMMINS, BEFORE MAY 2004 WIRING BOX – FORD, BEFORE JUNE 2003 4-20 WORK LIGHTS 5-33 Thu May 11 20:28:13 UTC 2017...
  • Page 672 AB60J PARTS MANUAL Appendix B:Parts Index 0070256 0020267 2-17, 2-18, 2-19 007039 2-50 0020270 3-5, 3-6, 3-7, 3-8, 3-9, 3-10, 3-12 0070418 2-58 0020273 5-8, 5-39 0070472 0020276 3-5, 3-6, 3-7, 3-8, 3-9, 3-10, 3-12 0070473 2-5, 2-10, 2-11, 2-15, 2-16, 2-17, 2-18, 2-19, 2-...
  • Page 673 AB60J PARTS MANUAL 0070758 4-30, 4-31, 5-2, 5-5, 5-24 0071275 3-70 0070760 4-9, 4-11, 4-17, 4-20 0071342 2-24, 2-25 0070764 3-1, 3-2 0071425 2-57, 2-58, 2-62, 5-9 0070768 0071425ES 2-64 0070769 2-10 0071510 2-24, 2-25, 2-42 0070772 2-1, 3-1, 3-2, 3-5, 3-5, 3-6, 3-6, 3-7, 3-...
  • Page 674 AB60J PARTS MANUAL 0071927 2-57, 2-58 0073295 4-24, 4-25, 4-26, 4-28, 4-31 0071927P 2-64 0073298 2-57, 2-58 0071953 2-27, 2-28, 5-37 0073340 2-17, 2-18, 2-19 0072004 5-23 0073342 2-17, 2-18 0072012 F 5-23 0073343 2-17, 2-18, 2-19 0072177 0073359 0072276...
  • Page 675 AB60J PARTS MANUAL 0074687 2-37 0080119 E 5-26 0074688 2-37 0080293 2-17, 2-18, 2-19 0074732 2-3, 2-4, 3-52 0080294 2-17, 2-18, 2-19 0074913 2-57, 2-63 0080348 2-3, 2-4 0074921 2-57 0080360 0074972 2-36 0080365 2-56 0074979 4-34 0080483 3-12, 4-5...
  • Page 676 AB60J PARTS MANUAL 0082123 2-42 0090589E 2-61, 2-62, 5-9 0082138 2-37 0090621 4-12, 4-14, 4-19, 4-21 0082160 5-25 0090622 4-24, 4-25, 4-26, 4-28, 4-31 0082164 5-25 0090757 4-9, 4-20, 5-8, 5-39 0082185 2-56 0090760 5-25 0082694 2-42 0090866 0082695 2-42...
  • Page 677 AB60J PARTS MANUAL 0110831 5-25 0112233 2-66 0110833 5-25 0112272 2-66 0110835 4-11, 4-17, 4-17, 5-5 0112418 2-66 0110836 5-25 0112421 2-66 0110837 2-66 0112422 2-66 0110842 2-17, 2-18, 2-19 0112423 2-66 0110943 5-25 0112424 2-66 0111084 2-5, 3-31 0112471...
  • Page 678 AB60J PARTS MANUAL 0150562 3-15, 3-15, 3-15, 3-49, 3-51, 3-61, 3-65 0151813 4-1, 4-2, 5-40 0150563 3-15, 3-15, 3-15, 3-15, 3-15, 3-38, 3-65 0151815 5-13 0150586 2-17, 2-18, 2-19 0151816 4-4, 4-24, 4-25, 4-26, 4-27, 4-28, 4-29, 4-30, 4- 0150602...
  • Page 679 AB60J PARTS MANUAL 0172248 4-30, 4-31 0180520 0172372 2-44 0180521 2-21, 2-22 0172373 2-44 0180522 3-49, 3-50, 3-51 0172374 2-44 0180549 2-10 0172451 2-27, 2-62 0180596 2-21, 2-22 0180084 0180597 2-21, 2-22 0180085 4-18 0180599 2-10 0180085 C 5-18 0180606...
  • Page 680 AB60J PARTS MANUAL 0180704 2-3, 2-4 0180796 4-12, 4-14, 4-19, 4-21, 4-22 0180716 2-17, 2-18, 2-19 0180801 3-15, 3-15, 3-15, 3-54 0180717 2-24, 2-25 0180802 3-14, 3-15, 3-17 0180718 2-24, 2-25 0180805 3-5, 3-6, 3-7, 3-8, 3-9, 3-10, 3-12 0180735...
  • Page 681 AB60J PARTS MANUAL 0180862 3-7, 3-8 0180925 0180863 3-7, 3-8, 3-16 0180927 4-32 0180864 3-5, 3-6, 3-7, 3-8, 3-9, 3-10, 3-34 0180930 2-5, 3-12 0180865 3-7, 3-8, 3-9, 3-10, 3-11 0180935 2-5, 3-33 0180866 3-6, 3-7, 3-8, 3-9, 3-10, 3-11, 3-74...
  • Page 682 AB60J PARTS MANUAL 0181028 4-24, 4-25, 4-26, 4-27, 4-28, 4-29, 4-30, 0181126 2-21, 2-22 4-31 0181136 4-12, 4-19, 4-21, 4-22 0181029 4-24, 4-25, 4-26, 4-27, 4-28, 4-29, 4-30, 0181138 2-17, 2-18, 2-19, 2-19 4-31 0181154 2-33, 2-38, 2-39 0181030 4-12, 4-14, 4-21, 4-22, 4-24, 4-25, 4-26,...
  • Page 683 AB60J PARTS MANUAL 0181374 5-29 0181529 5-19 0181376 5-3, 5-15, 5-16, 5-23 0181531 3-5, 3-6, 3-7, 3-8, 3-9, 3-10, 3-12 0181377 0181536 4-1, 4-9 0181381 0181538 3-5, 3-6, 3-14 0181382 0181541 3-5, 3-6, 3-7, 3-8, 3-9, 3-10, 3-11, 3-72 0181389...
  • Page 684 AB60J PARTS MANUAL 0181685 2-58 0181915 3-39, 3-40 0181688 D 5-17 0181916 4-20 0181712 5-25 0181970 2-57 0181713 5-25 0181994 A 5-40 0181779 0182002 2-37 0181783 4-2, 4-20 0182003 2-37 0181784 4-20, 4-22 0182004 2-36, 2-37 0181785 0182005 2-38 0181786...
  • Page 685 AB60J PARTS MANUAL 0182127 2-50 0182254 2-46 0182132 2-50 0182257 0182138 0182259 0182139 5-4, 5-35 0182261 2-46 0182140 5-4, 5-35 0182262 2-46 0182146 0182263 0182147 5-4, 5-35 0182275 2-43 0182149 5-4, 5-35 0182276 2-43 0182150 0182278 0182155 5-6, 5-7 0182326...
  • Page 686 AB60J PARTS MANUAL 0182461 3-11 0191811 2-23, 3-37, 3-38 0182461 A 3-35 0191892 4-10 0182462 3-11 0192009 4-31 0182462 A 3-20 0192086 4-31 0182464 B 4-30 0192089 4-31 0182465 D 4-11 0192090 4-31 0182466 2-16 0192093 4-31 0182466 A 2-19...
  • Page 687 AB60J PARTS MANUAL 0421285 5-34, 5-36 104883-000 2-47 0421299 5-34, 5-36 106960-001 2-47 0421321 2-27, 2-28 110175 2-65 0421519 2-27, 2-28, 5-7 116346-000 2-32, 5-11 0421529 2-27, 2-28, 5-7 116347-000 4-27 0421796 2-47 1430080 2-27, 2-28 0421811 5-34, 5-36 1430099...
  • Page 688 AB60J PARTS MANUAL 25560089 3020013 4-9, 4-10, 4-11, 4-13, 4-15, 4-16, 4-17, 4-20, 4- 2572007 2-27, 2-28, 5-6, 5-7, 5-38 24, 4-25, 4-26, 4-27, 4-28, 4-29, 4-30, 4-31, 5-3, 5-13, 5- 2580001 2-3, 2-4 15, 5-16, 5-23 2610001 2-34 3020015...
  • Page 689 AB60J PARTS MANUAL 302555 2-27, 2-28, 5-7, 5-38 3040083 2-53, 4-2, 4-3, 4-6, 4-11, 4-17, 4-17, 4-24, 4- 3026027 4-11, 4-30, 4-31, 5-12, 5-18 25, 4-26, 4-27, 4-28, 4-29, 5-3, 5-8, 5-12, 5-15, 5-16, 5- 3028809 4-33 18, 5-21, 5-30, 5-31, 5-33, 5-39...
  • Page 690 AB60J PARTS MANUAL 3040293 4-31 3040506 4-7, 4-8 3040295 4-9, 4-10, 4-11, 4-13, 4-15, 4-16, 4-17, 3040508 4-24, 4-25, 4-26, 4-27, 4-28, 4-29, 4-30, 4-31 4-20, 4-24, 4-25, 4-26, 4-27, 4-28, 4-29, 4-30, 4- 3040518 4-36 3040535 4-24, 4-25, 4-26, 4-28, 4-29, 4-30, 4-31...
  • Page 691 AB60J PARTS MANUAL 3044836 4-34 3069524 4-11, 4-17, 4-27, 4-30, 4-31 3044854 2-24, 3-12, 4-1, 4-3, 4-4, 4-30, 4-34 3069528 3044855 3070001 4-9, 4-10, 4-11, 4-16, 4-17, 4-20 3044856 3070003 4-9, 4-10, 4-20 3046697 4-3, 4-30, 5-12 3070016 3046972 2-24, 3-12, 4-1, 4-2, 4-4, 5-2, 5-12, 5-...
  • Page 692 AB60J PARTS MANUAL 5031810 5-19 5035705 3-31, 3-31, 3-32, 3-54, 3-75, 5-25 5033012 3-2, 3-3, 3-4 5035709 3-35 5033038 3-69 5035710 3-21, 3-34 5033604 2-1, 3-12 5036103 2-30, 2-31 5033608 2-33 5036105 5-8, 5-25, 5-39 5033614 3-69 5036503 2-48, 3-35, 3-59...
  • Page 693 AB60J PARTS MANUAL 5060034 5070005 3-5, 3-6, 3-7, 3-8, 3-9, 3-10, 3-18, 3-34 5063701 2-30, 2-31, 3-1, 3-75 5070027 3-18, 3-20 5063704 3-69 5070028 3-7, 3-8, 3-9, 3-10, 3-12, 3-34, 3-35 5063905 2-5, 2-17, 2-18, 2-19, 3-14, 3-16, 3-18, 5074401...
  • Page 694 AB60J PARTS MANUAL 5093004 2-12, 2-15, 2-16, 3-12, 4-1, 4-2, 4-4, 4- 5550020 5-27 5, 4-9, 4-10, 4-11, 4-13, 4-15, 4-16, 4-17, 4-20, 5- 5550021 5-10 1, 5-8, 5-10, 5-13, 5-14, 5-39 5550026 2-34, 2-37, 2-44, 2-46 5093005 5-24 5550028...
  • Page 695 AB60J PARTS MANUAL 34, 5-36 5560211 5560036 2-39 5560213 2-21, 2-22 5560038 3-12, 4-1, 4-2, 4-4, 4-7, 4-8, 4-12, 4-14, 5560215 2-10 4-19, 4-21, 4-22, 4-24, 4-25, 4-26, 4-28, 4-29, 4- 5560216 5560217 2-30 5560039 2-10, 2-17, 2-18, 2-19, 2-24, 2-25, 2-26,...
  • Page 696 AB60J PARTS MANUAL 5560629 2-37 4-31 5560634 2-34 5560713 5560639 2-33, 2-39, 3-12 5560719 2-36 5560641 2-7, 3-5, 3-6, 3-7, 3-8, 3-12 5561550 5-25 5560642 5563028 5-4, 5-35 5560644 5563029 5-4, 5-35 5560647 5-25 5563038 2-17 5560648 5-23 5563044 5-38...
  • Page 697 AB60J PARTS MANUAL 5569904 2-34 6010321 3-65 5569906 3-14 6010322 3-15, 3-15, 3-15 5569909 3-75, 3-76 6010328 3-15, 3-15, 3-54 5569910 4-1, 4-2, 4-5 6010392 3-14, 3-15, 3-17 5569911 5-3, 5-15 6010409 3-15 5569953 6010419 3-15 5569967 2-36 6010426 3-15, 3-15...
  • Page 698 AB60J PARTS MANUAL 6010580 3-15 6010655 3-56 6010581 3-15 6010656 3-34 6010582 3-15, 3-15 6010686 3-49, 3-51 6010584 3-15 6010694 3-17 6010585 3-15 6010695 3-17 6010586 3-15 6010696 3-17 6010587 3-15 6010697 3-17 6010590 3-15 6010698 3-17 6010591 3-14, 3-15, 3-17...
  • Page 699 AB60J PARTS MANUAL 6019173 3-19 6091241 3-38, 3-40, 3-48 6019189 3-19, 3-22 6091242 3-40 6019190 3-19, 3-22 6091243 3-40 6019192 3-19, 3-22 6091245 3-40 6019194 3-22 6091246 3-38, 3-40, 3-48 6019195 3-19, 3-22 6091272 3-48 6019196 3-19, 3-22 6091288 3-38...
  • Page 700 AB60J PARTS MANUAL 7030162 2-53 7630014 5-12 7030163 2-54 7630015 2-37 7050004 2-57, 2-58 7630016 2-34, 2-42, 2-46 7050006 5-34, 5-36 7630024 2-46 7050007 5-34, 5-36 7630117 2-33, 2-36, 2-39, 2-40, 2-41 7110012 3-15 7630140 2-42, 4-9, 4-10, 4-11, 4-13, 4-15, 4-16, 4-17, 4-...
  • Page 701 AB60J PARTS MANUAL 7630685 2-39, 2-40, 2-41 7741214 5-20 7630686 2-39, 2-40, 2-41 8010021 2-65, 2-65 7630687 8010027 2-65 7630688 8010028 2-65 7630689 2-42 8010029 2-65 7630691 2-39, 2-40, 2-41 8010030 2-65 7630703 8010075 2-65 7630704 8010080 2-65 7630707 2-36...
  • Page 702 AB60J PARTS MANUAL 8010248 2-67, 2-68 8070015 3-46 8010260 2-67, 2-68 8070017 3-46 8010261 2-67, 2-68 8070149 2-65 8010262 2-67, 2-68 8070168 2-65 8010263 2-67, 2-68 8070209 3-46 8010264 2-67, 2-68 8070210 3-46 8010265 2-67, 2-68 8070238 3-42, 3-51 8010266...
  • Page 703 AB60J PARTS MANUAL 8080015 3-70 8150145 4-35, 4-36 8080016 3-70 8150146 4-35, 4-36 8080018 3-70 8150147 4-35 8080038 3-70 8150148 4-35, 4-36 8080039 3-70 8150149 4-35 8080040 3-70 8150150 4-35, 4-36 8080041 3-70 8150151 4-35, 4-36 8080060 3-70 8150152 4-35, 4-36...
  • Page 704 AB60J PARTS MANUAL 8160302 3-47 2-34, 2-38, 2-39, 2-54, 4-24, 4-25, 4-26, 4-27, 4-28, 4-29, 8160303 3-47 4-30, 4-31, 5-3, 5-6, 5-15, 5-16, 5-18, 5-30, 5-31, 5-33 8160304 3-47 970049 2-17, 2-18, 2-19, 2-33, 2-34, 2-36, 2-38, 2-39, 3- 8160315...
  • Page 705 AB60J PARTS MANUAL 970479 2-18, 2-34, 2-49, 3-5, 3-6, 3-7, 4-7 974239 4-11, 4-12, 4-14, 4-19, 4-21, 4-22, 4-24, 4-25, 4- 970489 2-17, 2-18, 2-18, 2-19, 2-39, 3-5, 3-12, 26, 4-27, 4-28, 4-29, 4-30 4-1, 4-2, 4-4, 4-5, 5-10, 5-19...
  • Page 706 AB60J PARTS MANUAL 984979 987089 3-69, 4-21, 4-22, 4-22, 4-25 986009 2-17, 2-18, 2-19, 3-12, 4-5, 4-9, 4-10, 4- 987099 2-15, 2-21, 2-22, 2-26, 2-36, 2-39, 3-5, 3-6, 3-7, 11, 4-12, 4-13, 4-14, 4-15, 4-16, 4-17, 4-19, 4-20, 3-8, 3-12, 4-1, 4-4, 4-5, 4-7, 4-8, 4-9, 4-10, 4-13, 4-15, 4-...
  • Page 707 AB60J PARTS MANUAL 9980006 5-5, 5-5, 5-24 9980008 5-34, 5-36 9980012 2-5, 2-10, 2-11, 2-15, 2-17, 2-18, 2-19, 2-21, 2-30 9980017 2-58 9980018 2-58 9980021 2-57 9980022 2-57, 2-63 A07034F 4-34 A18043K 2-63 A18044 5-21 A18048 3-31, 3-32 A18054C 4-31...

This manual is also suitable for:

Ab60jrt

Table of Contents

Save PDF
