BWT Infinity A Installation And Operating Manual

Automatic backwash filter dn 25 and dn 50 90 micron sediment filter complete with dual check valve, back flow prevention and timer control
Hide thumbs Also See for Infinity A:
Table of Contents

Advertisement

Quick Links

Installation and operating manual
AUS
Suitability:
Suitable for domestic and commercial
installations to remove sediment and
improve the service life of plumbing
fixtures and fittings Product Approval:
The product is certified to
ATS 5200.103
BWT Infinity
A
®
Automatic Backwash Filter
DN 25 and DN 50
90 micron sediment filter
Complete with dual check valve,
backflow prevention and timer control
Changes reserved!

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Infinity A and is the answer not in the manual?

Questions and answers

Related Manuals for BWT Infinity A

Summary of Contents for BWT Infinity A

  • Page 1 Product Approval: The product is certified to ATS 5200.103 BWT Infinity ® Automatic Backwash Filter DN 25 and DN 50 90 micron sediment filter Complete with dual check valve,...
  • Page 2 Thank you very much for the confidence that you have shown in us by purchasing a BWT appliance.

  • Page 3: Table Of Contents

    Table of Contents About This Documentation Validity of this documentation Symbols used Safety Instructions General safety instructions Product-specific safety instructions Personnel qualifications Transport, Installation Performance description Intended use Foreseeable misuse Disclaimer Other applicable documentation Scope of supply Intended Use Suitable Applications Function Installation conditions Installing the Filter...

  • Page 4: About This Documentation

    This documentation is intended for operators, ● Carry out only those activities that are descri- end users, installation technicians not trained by BWT, installation technicians trained by BWT (e.g. bed in this operating manual, unless you have “Trinkwasserprofi” or drinking water specialists) and been trained by BWT.

  • Page 5: Product-Specific Safety Instructions

    Using spare parts and consumables not approved Transport the system as a complete unit, if possible. by BWT. If you must dismantle the system before transport, check that all individual parts are present. If there is a risk of frost, drain all components that Disclaimer convey water.

  • Page 6: Scope Of Supply

    Scope of supply BWT Infinity A consisting of: Outer casing with DR brass body Electronic programmable controller Power supply unit (240 V AC / 24 V DC - IP40) and connection cable Transparent bowl with filter element Vent tube Wastewater connections Connection module complete with dual check valve and seals.

  • Page 7: Function

    Function Installation conditions Untreated water flows through the filter where 1. The unit must be installed by a licenced trades- impurities > 90 µm are trapped by the filter screen person to AS/NZS 3500. and removed. The filter screen can be cleaned by 2.

  • Page 8: Installing The Filter

    Installing the Filter Install the filter in the cold water pipes upstream of the plumbing fixtures to be protected. Install isolating valves when required. Install the connection module in correct flow direction as DN 25 indicated by the arrow on the connection module. Install support bracketing as required.

  • Page 9: Commissioning The Filter

    Commissioning the Filter Slowly open the isolating valve(s) and de-aerate the pipework. Check the seals of the installation and filter for leaks. Before connecting to power, check the filter di- scharge is connected to the drain. Insert the cable plug connector of the power supply unit into the socket marked 24 V DC.

  • Page 10: For Parallel Operation Only

    Operation For parallel operation only When 2, 3 or a maximum of 4 filters are operated in parallel, they must be electrically interlocked to We recommend programming the filter so that the prevent simultaneous backwashing. device is backwashed at least once a month to prevent foreign particles from adhering to the filter Insert an interlocking cable into the output of any element (more frequently for higher levels of soiling;...

  • Page 11: Maintenance

    Maintenance It is recommended and to assist in the longevity of your Infinity unit, that regular maintenance occurs. This should always be undertaken by specialist staff who will also replace worn parts. We advise you to conclude a maintenance contract. Maintenance must be performed once each year, and twice each year for municipal systems, by your local plumber/installer.

  • Page 12: Technical Data

    Technical data Infinity A Model DN25 DN50 Connection size 1” BSP 2” BSP Filter screen µm 90/110 Nominal pressure 1600 Operating pressure range 350-1600 Operating temperature (water) °C 5-30 Operating temperature (ambient) °C 5-40 Power supply V/Hz 240 / 50...

  • Page 13: Pressure Drop/Flow Rate

    12.1 Pressure Drop/Flow Rate DN 25 160,0 140,0 110,0 120,0 101,7 100,0 96,7 91,7 80,0 86,7 60,0 73,3 40,0 55,0 43,3 20,0 26,7 20,0 40,0 60,0 80,0 100,0 120,0 Flowrate Q in l/min DN 50 160,0 140,0 276,7 120,0 270,0 100,0 263,3 258,3...

  • Page 14: Type Label

    12.2 Type label The type label serves as product identifier. In case of any requests, please have the following infor- mation ready: nity A Infinity A 1. Device name 2. Order-no. 3/4" 1“ 1 1/4" Type: 1 1/2" 2“ 3. Serial number...

  • Page 15: Warranty

    Warranty Decommissioning and disposal In the event of a malfunction during the warranty 14.1 Decommissioning period, please contact our after-sales service de- The product may only be shut down and dismantled partment, stating the type of unit and the product by qualified specialists.
  • Page 16 Further information: Reece. Works for you. ™ Call 1800 032 566 or visit www.reece.com.au for your nearest Reece store. Due to limitations in the printing process the colours in this brochure are a guide only. The manufacturer/distributor reserves the right to vary specificytions or delete models from their range without prior notification.
