Rail Network Video Recorder

User Manual

UD.6L0204D1165A01

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DS-MP3516-RS and is the answer not in the manual?

Questions and answers

Related Manuals for HIKVISION DS-MP3516-RS

Summary of Contents for HIKVISION DS-MP3516-RS

  • Page 1: User Manual

    Rail Network Video Recorder User Manual UD.6L0204D1165A01...
  • Page 2 BUSINESS PROFITS, BUSINESS INTERRUPTION, OR LOSS OF DATA OR DOCUMENTATION, IN CONNECTION WITH THE USE OF THIS PRODUCT, EVEN IF HIKVISION HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES. REGARDING TO THE PRODUCT WITH INTERNET ACCESS, THE USE OF PRODUCT SHALL BE WHOLLY AT YOUR OWN RISKS.

  • Page 3: Regulatory Information

    Rail Network Video Recorder User Manual Regulatory information FCC information FCC compliance: Please take attention that changes or modification not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. Note: This product has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules.
  • Page 4 Rail Network Video Recorder User Manual This device complies with Industry Canada licence-exempt RSS standard(s). Operation is subject to the following two conditions: this device may not cause interference, and this device must accept any interference, including interference that may cause undesired operation of the device.

  • Page 5: Safety Instruction

    Only use the battery, power adapter and assembly parts specified by the manufacturer. ● Consult the authorized dealer or technician from Hikvision for any question and request for product using. ●...
  • Page 6 Rail Network Video Recorder User Manual Applicable Models This manual is applicable to the models listed in the following table. Series Model DS-MP3516-RS DS-MP3516-RS Series DS-MP3516-RS/GW Conventions  Words Conventions Words Description Rail NVR Refers to Rail Network Video Recorder.

  • Page 7: Table Of Contents

    Rail Network Video Recorder User Manual TABLE OF CONTENTS Chapter 1Introduction ..........................9 Interfaces ............................9 SIM Card Installation........................10 HDD Installation ..........................12 Wiring ............................16 Chapter 2Getting Started and Basic Operations ..................18 Start-up ............................18 Right-Click Menu and Main Menu ....................18 2.2.1 Right-Click Menu .......................
  • Page 8 Rail Network Video Recorder User Manual Position ............................42 G-Sensor ............................42 Platform ............................43 Chapter 7Other Settings ..........................45 Display Settings ..........................46 Camera Settings ..........................48 7.2.1 OSD Settings ........................48 7.2.2 Image Settings........................49 7.2.3 Configuring Mask ......................49 7.2.4 Configuring Video Tampering Alarm .................
  • Page 9 Rail Network Video Recorder User Manual 10.6 Storage............................75 Chapter 11Shutdown and Reboot ......................76 11.1 Shutdown ............................76 11.2 Reboot ............................76 AppendixⅠ Specifications ........................77 AppendixⅡ List of Compatible IP Camera ....................78...

  • Page 10: Chapter 1Introduction

    It can cooperate with other devices to build a comprehensive surveillance system. Thanks to the features of high stability, easy-to-carry and low power consumption, the DS-MP3516-RS series rail NVR is widely applied to the surveillance projects of rail transportations.

  • Page 11: Sim Card Installation

    Rail Network Video Recorder User Manual Name Description USB1 USB 3.0 interface. USB2  2-ch relay signal output.  ALARM&RS422 8-ch relay signal input.  1 RS-422 interface VGA output. RS232 Serial interface. A OUT Audio output. V OUT Video output. LINE Interface for mobile intercom.
  • Page 12 Rail Network Video Recorder User Manual Figure 1. 3 Press Yellow Button Pull out SIM card base. Figure 1. 4 Pull Out SIM Card Base Place the SIM card into the SIM card base with the golden area facing up. Figure 1.

  • Page 13: Hdd Installation

    Rail Network Video Recorder User Manual Figure 1. 6 Push SIM Card Base into Slot 1.3 HDD Installation Purpose: 3 HDD boxes are provied. You can install 2 HDDs for each HDD box. That is up to 6 HDDs can be installed. Perform the following steps to install the HDD on the Rail NVR.
  • Page 14 Rail Network Video Recorder User Manual Figure 1. 7 Unlock HDD Box Pull out the HDD box. Figure 1. 8 Pull HDD Box Use a screwdriver to loosen and remove the two set screws marked in the figure. Figure 1. 9 Loosen and Remove Screws Separate the HDD box in to parts.
  • Page 15 Rail Network Video Recorder User Manual Figure 1. 10 HDD Box Parts Place the first HDD into the HDD box and tightly insert the first HDD into the bottom, with the PCB facing downward. Figure 1. 11 Install the First HDD Place the second HDD into the HDD box, with the PCB facing upward.
  • Page 16 Rail Network Video Recorder User Manual Figure 1. 13 Fix HDDs Tighten the 4 set screws on the side of the HDD box, shown as the following figure. Figure 1. 14 Fix HDDs Align the protective cover of the HDD box with the line marked in the figure, and assemble the whole HDD box.

  • Page 17: Wiring

    Rail Network Video Recorder User Manual Figure 1. 16 Tighten Screws Insert the HDD box back to the Rail NVR, and then tighten the screws clockwise. Figure 1. 17 Insert HDD Disk Back to Rail NVR 1.4 Wiring Purpose: Wire and install your Rail NVR according to the following requirements. ...
  • Page 18 Rail Network Video Recorder User Manual Figure 1. 18 Wiring...

  • Page 19: Chapter 2Getting Started And Basic Operations

    Rail Network Video Recorder User Manual Chapter 2 Getting Started and Basic Operations Purpose: Perform following sections to start and configure your Rail NVR. It makes you can perform basic operations, including local menu operation, adding IP cameras, recording, etc. 2.1 Start-up Before you start: Wire your device according to 1.4 Wiring.

  • Page 20: Main Menu

    Rail Network Video Recorder User Manual Right-click menu is a shortcut for several operations. Step: Right click on Live View. Then the right-click menu pops up. Figure 2. 2 Right Click Menu Table 2. 1 Right Click Menu Description Item Description Single Camera Switch to the single full screen by choosing camera number from the...

  • Page 21: Setting Admin Password

    Rail Network Video Recorder User Manual 2.3 Setting Admin Password Purpose: For the first-time access, you need to activate the device by setting an admin password. No operation is allowed before activation. Steps: Create the password by inputting the same password in the text field of New Password and Confirm. Figure 2.

  • Page 22: Activating Ip Camera

    Rail Network Video Recorder User Manual Figure 2. 5 IP Camera Settings 2.4.1 Activating IP Camera Purpose: Before adding the cameras, make sure the IP cameras to be added are in active status. Or you need to follow the steps to activate it. Two methods are provided to activate IP camera, including quick activation and manual activation.

  • Page 23: Adding Ip Camera

    Rail Network Video Recorder User Manual Manual Activation Purpose: You can activate the IP camera by setting your custom password. Steps: Enter IPC Settings interface. Click to select IPC you want to activate. Click the button to enter Manual Activation interface. Create a password by inputting the same password in both New Password and Confirm.

  • Page 24: Managing Ip Camera

    Rail Network Video Recorder User Manual Select the IP channel No. for the IP camera. Input the required information, including the IP Address, Protocol, Port No., User Name, and Password. Click the Protocol button, and you can customize the protocol according to the actual needs. Click OK to add the IPC.

  • Page 25: Editing Ip Camera

    Rail Network Video Recorder User Manual Figure 2. 9 Manage IPC Devices To modify IP address, do following steps: Edit the IP Address. Input Password (Old). Click OK to save the new password. To modify password, do following steps: Input Password (Old). Input the same password in Password (New) and Confirm.

  • Page 26: Chapter 3Network Settings

    Rail Network Video Recorder User Manual Chapter 3 Network Settings Purpose: You can configure local network, dialing, Wi-Fi parameters. Figure 3. 1 Basic Settings Table 3. 1 Sub-Menu Description Sub-Menu Name Description Network You can configure network parameters. Dial You can connect the device to the network and transmit the data after dialing to internet.

  • Page 27: Local Network Settings

    Rail Network Video Recorder User Manual 3.1 Local Network Settings Purpose: You can configure the basic network parameters and time synchronization parameters. 3.1.1 Network Settings Purpose: You need configure the basic network parameters to ensure well network communication. Before you start: Connect the LAN 2 to a network switch with network cable.

  • Page 28: Dialing

    Rail Network Video Recorder User Manual Enter the Local Network Settings interface. Main Menu > Basic Settings > Network Click the Set button of NTP. Check the checkbox of NTP to enable the NTP settings. Input the Synchronization Interval. Input the IP address of NTP Server. Click OK to save the new settings and exit.

  • Page 29: Wi-Fi

    Rail Network Video Recorder User Manual Check the checkbox of Enable Dialing to enable the 3G dialing function of the device. Select Network Mode as Auto, Adjust, or 3G Only.  Auto: the work mode is set as the detected stronger signal. ...

  • Page 30: Wi-Fi Settings

    Rail Network Video Recorder User Manual Figure 3. 6 Wi-Fi Settings 3.3.1 Wi-Fi Settings Steps: Check the checkbox of Enable WiFi to turn on the Wi-Fi settings. Select the Configuration file to which you want to connect. Rail NVR can remember 5 Wi-Fi in the 5 configuration files. To connect Wi-Fi conveniently, configure Wi-Fi parameters to which you connect frequently in these configuration files.

  • Page 31: Wi-Fi Ap Settings

    Rail Network Video Recorder User Manual Figure 3. 7 IP & DNS Settings for Wi-Fi 3.3.2 Wi-Fi AP Settings Purpose: To configure WiFi AP, WiFi Broadcast, and Wifi Hotspot, do following steps. Steps: To Click the Set button of WiFi AP. Optionally, check the checkbox of Enable WiFi AP, Enable WiFi Broadcast, and Enable WiFi Hotspot.

  • Page 32: Chapter 4Record Settings

    Rail Network Video Recorder User Manual Chapter 4 Record Settings 4.1 Configuring Encoding Parameters 4.1.1 Initializing the HDD Before you start: Install at least one HDD on the Rail NVR for video data storage. Steps: Enter the HDD Management interface. Main Menu >...
  • Page 33 Rail Network Video Recorder User Manual Figure 4. 2 Record Settings Select the camera from the drop-down list. Configure the following settings:  Encoding Parameters Main Stream (Normal): used for schedule recording; Main Stream (Event): used for event recording; Sub Stream: used for network transmission. ...

  • Page 34: Configuring Motion Detection Record

    Rail Network Video Recorder User Manual You can view the recording status on the Record Status interface (Main Menu>Status>Record).  5 recording types are selectable: Normal, Motion Detection, Alarm, Motion | Alarm and Motion & Alarm.  Up to 8 time periods can be set for each day and each of the time periods cannot be overlapped. Figure 4.
  • Page 35 Rail Network Video Recorder User Manual Follow the procedure to configure alarm triggered recording. Steps: For detailed steps, refer to 7.5.2 Alarm Input Settings. Enter the Record Settings interface to and select Alarm as the record type. Main Menu > Basic Settings > Record Settings > Schedule...

  • Page 36: Chapter 5Video Search And Export

    Rail Network Video Recorder User Manual Chapter 5 Video Search and Export Purpose: You can search and play back the videos stored on the device. Step: Enter the Video Search interface. Main Menu > Video Search Figure 5. 1 Video Search Interface 5.1 Searching Videos Purpose: You can search and play back the videos stored on the device.

  • Page 37: Playing Video

    Rail Network Video Recorder User Manual Figure 5. 2 Search Results. 5.2 Playing Video Purpose: You can play back the history videos. 5.2.1 Playing by Time Purpose: You can specify a period, and then start playing back all the video segments in the period continually. Steps: Enter the Video Search interface.

  • Page 38: Managing Playback Control Bar

    Rail Network Video Recorder User Manual Figure 5. 3 Search Results Search Results Click to select the videos to playback. Click Play to start playing it. Figure 5. 4 Playback Window 5.2.3 Managing Playback Control Bar Purpose: You can mute playback and clip videos during playback process. Steps: ...

  • Page 39: Exporting Video

    Rail Network Video Recorder User Manual Click Control Panel to hide control bar. Repeat step 1) to 2) to show control bar. Figure 5. 6 Control Bar  To mute playback process, do following steps: Click the icon in control bar to mute. Click the icon again to turn on audio.

  • Page 40: Chapter 6Basic Settings

    Rail Network Video Recorder User Manual Chapter 6 Basic Settings Purpose: There are nine sub-menus provided in Basic Settings menu. Figure 6. 1 Basic Settings Table 6. 1 Sub-Menu Description Sub-Menu Name Description Record You can configure the parameter for videos. Serial Port Two types of serial ports are provided: RS-232 and RS-485.

  • Page 41: Serial Port

    Rail Network Video Recorder User Manual 6.1 Serial Port Purpose: Two types of serial ports are provided: RS-232 and RS-485. Step: Enter the Serial Port Settings interface to configure the parameters. Main Menu > Basic Settings > Serial Port 6.1.1 RS-232 Steps: Select Serial Port Type as RS-232.

  • Page 42: Start Control

    Rail Network Video Recorder User Manual Figure 6. 3 RS-485 6.2 Start Control Purpose: You can specify the startup/shutdown time for the Rail NVR. Steps: Enter the Start Control interface. Main Menu > Basic Settings > Start Select Auto Work Type as Auto Working. Select the Date on which you want to start up/shut down the device automatically.

  • Page 43: Position

    Rail Network Video Recorder User Manual 6.3 Position Purpose: The built-in GNSS module supports GPS (Global Positioning System), contributing to the device positioning and speed limit alarm. Steps: Enter the Satellite Positioning Settings interface. Main Menu > Basic Settings > Position Figure 6.

  • Page 44: Platform

    Rail Network Video Recorder User Manual Figure 6. 6 G-Sensor Settings Select the mode of G-sensor Module. Only built-in module is provided. Built-in: The G-sensor is built in the Rail NVR. Set the limit value for acceleration alarm in X, Y and Z directions. X, Y and Z represent the direction of acceleration and the unit of alarm value is G (G=9.8 m/s Set the linkage actions for acceleration alarm, including Audio Alarm and Alarm Output.
  • Page 45 Rail Network Video Recorder User Manual Figure 6. 7 iVMS Platform Settings Select Platform as Platform iVMS or 3G_SDK.  Platform WVS: Reserved  Platform iVMS: It refers to iVMS-7200.  3G_SDK: It refers to platform developed by yourself based on the SDK provided by our company. Configure the following parameters: ...

  • Page 46: Chapter 7Other Settings

    Rail Network Video Recorder User Manual Chapter 7 Other Settings Purpose: There are ten sub-menus provided in Basic Settings menu. Figure 7. 1 Other Settings Table 7. 1 Sub-Menu Description Sub-Menu Name Description Display You can set the system time, select the CVBS output standard, enable the password, configure the DST settings, etc.

  • Page 47: Display Settings

    Rail Network Video Recorder User Manual 7.1 Display Settings Purpose: You can set the system time, select the CVBS output standard, enable the password, configure the DST settings, etc. Steps: Enter the Display Settings interface. Main Menu > Other Settings > Display The system language is set as English by default and is not editable.
  • Page 48 Rail Network Video Recorder User Manual Figure 7. 3 DST Settings  Click the Set button of Advance Settings, and you can configure the advanced parameters for display.  Device Name: Input the system name as desired in the text field. ...

  • Page 49: Camera Settings

    Rail Network Video Recorder User Manual Click Apply to save the settings and click OK to exit. 7.2 Camera Settings Purpose: You can configure OSD, image, mask, video tamper-proof, motion detection, and video loss parameters. 7.2.1 OSD Settings Purpose: You can configure the OSD (On Screen Display) settings which include the display of camera name, date and week, and the corresponding position information.

  • Page 50: Image Settings

    Rail Network Video Recorder User Manual Figure 7. 6 More Setting 7.2.2 Image Settings Purpose: Perform the following steps to adjust the video parameters, including Brightness, Contrast, Saturation and Hue. Steps: Enter Camera Settings interface. Main Menu > Other Settings > Camera Settings Click the Set button of More Settings.

  • Page 51: Configuring Video Tampering Alarm

    Rail Network Video Recorder User Manual  Up to 4 mask areas can be configured for each channel.  The mask area information of one channel cannot be copied to another one.  You cannot view the image of the mask area either from the live view interface or videos. 7.2.4 Configuring Video Tampering Alarm Purpose: A tampering alarm is triggered when the camera is covered and the monitoring area cannot be viewed.

  • Page 52: Configuring Motion Detection

    Rail Network Video Recorder User Manual Figure 7. 8 Linkage Action of Tamper-proof Click Apply to save the new settings and click OK to exit. 7.2.5 Configuring Motion Detection Purpose: In the motion detection record, once a motion event occurs, the device starts to record and multiple linkage actions will be triggered.

  • Page 53: Configuring Video Loss

    Rail Network Video Recorder User Manual Click the Handle button of motion detection to set the arming schedule and alarm linkage actions. Select the day from the drop-down list, and set the arming schedule for the alarm linkage actions. Optionally, you can copy the current settings to other days in the week. Check the checkboxes to enable the corresponding linkage actions.

  • Page 54: User Settings

    Rail Network Video Recorder User Manual 7.3 User Settings Purpose: You can add and manage users here. The admin user has all the operation permissions of the device. 7.3.1 Adding User Steps: Enter the User Management interface. Main Menu > Other Settings > User Figure 7.

  • Page 55: Modifying User

    Rail Network Video Recorder User Manual Select the user Level from the drop-down list.  Operator: The operator has permissions of Preview, Playback, Backup, Log Search, and Parameters Settings.  Guest: The Guest has permission of Preview, Playback, Backup, and Log Search. Click the OK button to save the settings and go back to the User Management interface.
  • Page 56 Rail Network Video Recorder User Manual Steps: Enter the Preview Settings interface. Main Menu > Other Settings > Preview Figure 7. 14 Preview Settings Select the Video Output from the drop-down list according to the actual needs. Select the Preview Mode, Dwell Time for live view, Check the checkbox of Enable Audio Output to enable the function.

  • Page 57: Alarm Settings

    Rail Network Video Recorder User Manual Click the Apply button to save the new settings and click OK to exit. 7.5 Alarm Settings Purpose: You can configure handling method for alarm events. 7.5.1 Exception Settings Purpose: Exception Settings refer to the handling methods of various exceptions, e.g. ...
  • Page 58 Rail Network Video Recorder User Manual Main Menu > Other Settings > AlarmIn Figure 7. 17 Alarm Input Settings Select the Alarm Input No.. Input the Alarm Name as desired in the text field. Set the Alarm Type as NO (Normally Open) or NC (Normally Closed) of the alarm input according to the actual needs.

  • Page 59: Alarm Output Settings

    Rail Network Video Recorder User Manual When an alarm is triggered, the local monitor displays the video image from the alarming channel configured for full screen monitoring.  Audio Warning: Trigger an audible beep when an alarm input is detected. ...

  • Page 60: Firewall Settings

    Rail Network Video Recorder User Manual Set the Alarm Duration time. To set Alarm Schedule, do following steps: Click the Set button of Schedule to set the arming schedule for alarm outputs. Up to 8 time periods can be set within each day. And the time periods can’t be overlapped with each other.
  • Page 61 Rail Network Video Recorder User Manual Figure 7. 22 Firewall Settings Optionally, you can select Enable SSH Service, thus to effectively prevent information leakage during remote management. Click the Add button to enter the Add IP Address dialog box, input the trusted IP address, and click OK. Figure 7.

  • Page 62: Ptz Settings

    Rail Network Video Recorder User Manual To delete the trusted IP address, you can select it on the white list and then click the Delete button. Or you can also click the Clean All button to clear all the trusted IP address on the white list. 7.7 PTZ Settings Purpose: Follow the procedure to set the parameters for PTZ.
  • Page 63 Rail Network Video Recorder User Manual Figure 7. 26 PTZ Control Panel Table 7. 2 Description of PTZ Control Panel Icon Description Icon Description Icon Description Direction button and Zoom+/Focus+/Iris+ Zoom-/Focus-/Iris- the auto-cycle button Moving speed Light on/off Wiper on/off...

  • Page 64: Chapter 8Hdd Settings

    Rail Network Video Recorder User Manual Chapter 8 HDD Settings Purpose: You can initialize HDD and view HDD information. Figure 8. 1 HDD Management 8.1 Initializing the HDD Purpose: Initialization will erase all data on the HDD. Before you start: Install at least one HDD on the Rail NVR for video data storage.

  • Page 65: Advanced Hdd Settings

    Rail Network Video Recorder User Manual Select the Hard Disk from the drop-down list. Click Format and click OK in popup confirmation window. 8.2 Advanced HDD Settings Purpose: You can enable/disable overwrite, configure the HDD property, and view the S.M.A.R.T information. Steps: Select the Hard Disk to configure in the drop-down list.

  • Page 66: Chapter 9Status

    Rail Network Video Recorder User Manual Chapter 9 Status Purpose: You can view status for seven functions. Figure 9. 1 Status Table 9. 1 Sub-Menu Description Sub-Menu Name Description Record Recording status of each IP camera is listed. Dial Dialing status and information is listed. Plat The current platform, login status, and exception information are listed.

  • Page 67: Record Status

    Rail Network Video Recorder User Manual 9.1 Record Status Purpose: Recording status of each IP camera is listed. Steps: Enter the Record Status interface. Main Menu > Status > Record icon represents the IP camera is recording. icon represents it is not recording. To view record schedule, click Query.

  • Page 68: Platform Status

    Rail Network Video Recorder User Manual 9.3 Platform Status Purpose: The current platform, login status, and exception information are listed. Step: Enter the Platform interface. Main Menu > Status > Plat Figure 9. 4 Platform Registration Status 9.4 Position Status Purpose: Position status shows the positioning information and status.

  • Page 69: Alarm Status

    Rail Network Video Recorder User Manual Step: Enter the Platform interface. Main Menu > Status > G-Sensor Figure 9. 6 G-Sensor Status 9.6 Alarm Status Purpose: Whether alarm input/alarm output occurs is listed. Steps: Enter the Platform interface. Main Menu > Status > G-Sensor icon represents alarm input/alarm output is occurring.
  • Page 70 Rail Network Video Recorder User Manual Enter the Platform interface. Main Menu > Status > G-Sensor Figure 9. 8 Wi-Fi Status...

  • Page 71: Chapter 10Maintenance

    Rail Network Video Recorder User Manual Chapter 10 Maintenance Purpose: You can upgrade, search log, restore device, import/export configuration file, view device information, initialize USB storage device, and reboot device. Figure 10. 1 Maintenance Table 10. 1 Sub-Menu Description Sub-Menu Name Description Upgrade You can upgrade the Rail NVR via local USB flash disk or remote FTP server.

  • Page 72: System Upgrade

    Rail Network Video Recorder User Manual 10.1 System Upgrade Purpose: The Rail NVR can be upgraded via local USB flash disk or remote FTP server. You’re recommended to upgrade Rail NVR under the help of professional technical support. 10.1.1 Local USB Flash Disk Upgrade Before you start: Connect the USB device on which the upgrade firmware is stored to the Rail NVR.

  • Page 73: Log Search And Export

    Rail Network Video Recorder User Manual Figure 10. 3 Upgrade Interface Select the Upgrade Type as FTP Upgrade. Input the FTP Server Address in the text field. Click Upgrade to start upgrading and reboot the device to activate the new settings. 10.2 Log Search and Export Purpose: The operation, alarm, exception, and information of the device can be stored in log files, which can be viewed...

  • Page 74: Restoring System

    Rail Network Video Recorder User Manual Click the Search button. The logs matching the search conditions will be displayed on a list. Figure 10. 5 Log Search Results To view the detailed information of the selected log, double click a log, or select the log item and then click Details.

  • Page 75: Importing/Exporting Configuration Files

    Rail Network Video Recorder User Manual NIC working mode, default route, server port, etc.) and user account parameters, to the factory default settings.  Factory: Restore all parameters to the factory default settings. Click the OK button to restore the default settings. 10.4 Importing/Exporting Configuration Files Purpose: The configuration files of the Rail NVR can be exported to local device for backup;...

  • Page 76: Storage

    Rail Network Video Recorder User Manual You can view the system information including device name, model, serial No., firmware version, encoding version, and panel version. Step: Enter the System Information interface. Main Menu > Maintenance > Information 10.6 Storage Purpose: You can view the status and the free space/capacity of the connected USB storage device.

  • Page 77: Chapter 11Shutdown And Reboot

    Rail Network Video Recorder User Manual Chapter 11 Shutdown and Reboot 11.1 Shutdown Steps: Insert the key into the Lock slot in front panel. To shut down device, rotate it from 11.2 Reboot Steps: Enter Reboot interface. Main Menu > Maintenance > Reboot Click Maintenance to enter Maintenance menu.

  • Page 78: Appendixⅰ Specifications

    Rail Network Video Recorder User Manual AppendixⅠ Specifications Name Description GNSS GNSS antenna interface WIFI Wi-Fi antenna interface. (only supported by the “/GW” devices) M-ANT 3G antenna interface IR: IR receiver Receive IR signal from remote control. PWR: Power indicator Turns green after device starts up;...

  • Page 79: Appendixⅱ List Of Compatible Ip Camera

    Rail Network Video Recorder User Manual AppendixⅡ List of Compatible IP Camera Model Version Max. Resolution Sub-stream Audio DS-2CD6510DT-I(O) 1280 × 960 √ √ DS-2CD6520DT-I(O) 1920 × 1080 √ √ DS-2CD6510D-I(O) 1280 × 960 √ √ V5.4.0 Build 160401 DS-2CD6520D-I(O) 1920 ×...
