- Page 1 KERN & Sohn GmbH Ziegelei 1 Phone: +49-[0]7433- 9933-0 D-72336 Balingen Fax: +49-[0]7433-9933-149 E-Mail: info@kern-sohn.com Internet: www.kern-sohn.com Návod na obsluhu(EN) Listová váha KERN FOB-S Version 1.2 08/2013 FOB-S-BA-e-1312...
-
Page 2: Table Of Contents
KERN FOB-S Version 1.2 08/2013 Operating instructions Compact balance Contents Technical data ....................3 Basic Information (General)................4 Proper use ..........................4 Improper Use..........................4 Warranty ............................. 4 Monitoring of Test Resources..................... 5 Basic Safety Precautions ................5 Pay attention to the instructions in the Operation Manual............5 Personnel training........................ -
Page 3: Technical Data
1 Technical data KERN FOB 500-1S FOB 5K1S Readability (d) 0.1 g Weighing range (max) 500 g 5,000 g Reproducibility 0.1g Linearity ± 0.2 g ± 2 g Weighing Units g, lb, oz, dwt, ozt 200 g / 2,000 g /... -
Page 4: Basic Information (General)
The balance may only be used according to the described conditions. Other areas of use must be released by KERN in writing. 2.3 Warranty Warranty claims shall be voided in case... -
Page 5: Monitoring Of Test Resources
Information is available on KERN’s home page (www.kern-sohn.com) with regard to the monitoring of balance test substances and the test weights required for this. In KERN's accredited DKD calibration laboratory test weights and balances may be calibrated (return to the national standard) fast and at moderate cost. -
Page 6: Unpacking, Setup And Commissioning
5 Unpacking, Setup and Commissioning 5.1 Installation Site, Location of Use The balances are designed in a way that reliable weighing results are achieved in common conditions of use. You will work accurately and fast, if you select the right location for your balance. Therefore, observe the following for the installation site: Place the balance on a firm, level surface;... -
Page 7: Placing
5.2.1 Placing The balance must be installed in a way that the weighing plate is exactly in horizontal position. 5.2.2 Scope of delivery Serial accessories: Balance Weighing pan Mains adapter (optional) Protective working cover Operating instructions 5.2.3 Assembly/disassembly of the operating cover ... -
Page 8: Mains Connection (Optional)
5.3 Mains connection (optional) The balance may be operated via the optional mains adapter. The stated voltage value must be the same as the local voltage. Only use original KERN mains adapters. Using other makes requires consent by KERN. 5.4 Battery operation Remove battery cover at the lower side of the casing. -
Page 9: Initial Commissioning
5.5 Initial Commissioning In order to obtain exact results with the electronic balances, your balance must have reached the operating temperature (see warming up time chap. 1). During this warming up time the balance must be connected to the power supply (mains or battery). - Page 10 Procedure when adjusting: Observe stable environmental conditions. A warming up time (see chapter 1; Technical Data) is required for stabilization. Ensure that there are no objects on the weighing plate. Balance display Operation Start balance by pressing The balance carries out an autotest and changes then into the weighing mode, the zero display „0.0“...
-
Page 11: Operating Elements
6 Operating elements 6.1 Keyboard overview Buttons specification: Description Pressed once and released [ON/OFF] Turn on/off In menu: Passing through menu [TARE] Taring items from top to bottom [UNIT] Weighing units Passing through menu switching over items from left to right Invoke adjustment 6.2 Overview of display Display... -
Page 12: Operation
7 Operation 7.1 Simple weighing Balance display Operation Start balance by pressing The balance will carry out a self-test. „Wait for 0.0“ display Should the balance not display exactly „0.0“ despite empty weighing pan, press the button. (example) The balance returns to „0.0“... -
Page 13: Weighing Units Switch-Over
Passing through menu items from top to bottom Confirm selection Passing through menu items from left to right 8.3 Menu overview Preset values may only be modified by trained and specialized personnel. Model FOB 500-1S Model FOB 5K1S FOB-S-BA-e-1312... -
Page 14: Menu Settings
8.4 Menu settings 8.4.1 Setting weighing units Balance display Operation In weighing mode press button for approx. 3 seconds. „SEt“, followed by „Unit“ is displayed Press again, the weighing unit „g“ is displayed Use to change to the desired unit (example) , „OFF“... -
Page 15: Automatic Switch-Off Function „Auto Off" In Stand-By Mode
Press , „A.Off“ will be shown Press , „CAP.“ is displayed Press , „End“ is displayed Use to return to weighing mode Use to change between the set units (example) In order to switch off the units display, proceed as described above and set the selected unit to „Off“. - Page 16 Press , the current setting will be displayed. Use to select the desired setting: 120s = Auto off after 120 seconds 180s = Auto off after 180 seconds 240s = Auto off after 240 seconds 300s = Auto off after 300 seconds OFF = Auto off switched off ...
-
Page 17: Error Messages
Spilled weighing goods must be removed immediately. 10.2 Service, maintenance The appliance may only be opened by trained service technicians who are authorized by KERN. Before opening, disconnect from power supply. 10.3 Disposal Disposal of packaging and appliance must be carried out by operator according to valid national or regional law of the location where the appliance is used. -
Page 18: Instant Help
11 Instant help In case of an error in the program process, briefly turn off the balance and disconnect from power supply. The weighing process must then be restarted from the beginning. Help: Fault Possible cause The displayed weight The balance is not switched on. does not glow.
