- Page 1 INFRA-RED VARIABLE POWER CERAMIC HEATERS "INFRA…ROSSO SCR 1" "INFRA…ROSSO SCR 1" 25m - 25a "INFRA…ROSSO SCR 1" 45m - 45a INSTRUCTIONS MANUAL "INSTALLATION - USE - MAINTENANCE"...
- Page 2 IMPORTANT Read carefully this manual before proceeding to the start up of the installation. In order to improve the product, SYSTEMA reserves the right to modify the content without prior notice. This product is manufactured and certified by SYSTEMA S.p.A.
-
Page 3: Table Of Contents
SYSTEMA Summary GENERAL RULES ....................4 EQUIPMENTS DESCRIPTION ................5 General description ......................5 Functionning description ..................... 6 PACKING - TYPOLOGY AND DIMENSIONS ............7 Ceramic heater packing ...................... 7 External dimension of equipment packing ................ 7 Packing dimensions on pallet ..................... 7 TECHNICAL DATA .................... -
Page 4: General Rules
SYSTEMA GENERAL RULES This manual is an integral and essential part of this device and it must be carefully stored in its vicinity for purposes of rapid consultation. Read carefully the instructions and warnings provided herein because they provide important information regarding safety, installation, use and maintenance. -
Page 5: Equipments Description
SYSTEMA EQUIPMENTS DESCRIPTION General description The "INFRA…ROSSO" ceramic heaters have to be considered as new generation products because they are based on new innovating concepts : a pre-mix burner, the very high thermal performance, the modularity of thermal power, the radiating performance, the highest flexibility of installation and use. -
Page 6: Functionning Description
SYSTEMA Functionning description The "INFRA…ROSSO" ceramic heaters models are the following: Mod. SCR 25 m with pre-mix combustion and manual variation of thermal power. Mod. SCR 45 m with pre-mix combustion and manual variation of thermal power. Mod. SCR 25 a with pre-mix combustion and automatic variation of thermal power by a InfraNet control network and a Inet electric board (see specifications in the following paragraphs). -
Page 7: Packing - Typology And Dimensions
SYSTEMA PACKING - TYPOLOGY AND DIMENSIONS The "INFRA…ROSSO SRC1" ceramic heaters are delivered completely assembled, ready to be installed in their definitive position. They are packed for transportation inside reinforced cardboard boxes. This cardboard box contains the ceramic heater and this manual. -
Page 8: Technical Data
SYSTEMA TECHNICAL DATA General technical data "INFRA…ROSSO” SRC CERAMIC HEATER TECHNICAL CHARACTERISTICS MODELES SCR 25a/m SCR 45 a/m THERMAL FLOW (maximum nominal) kW (HI) THERMAL FLOW (minimum nominal) kW (HI) Maximum 2,54 5.08 Natural gas G2O Minimum CONSUMPTION 1,27 2.54 Natural gas G2O Nominal at 15°C and... -
Page 9: Thermal Power Table
SYSTEMA Thermal power table CERAMIC HEATER “INFRA…ROSSO” SCR 25 a/m - SCR 45 a/m NOMINAL THERMAL FLOW AND GAS CONSUMPTION AT REGULATION LEVEL SRC 25a/m SRC 45a/m NAT.GAS NAT.GAS REGULATION THERMAL L.P.G. THERMAL L.P.G. LEVEL PWM FLOW FLOW kg/h kg/h... -
Page 10: Equipment Basic Parts
SYSTEMA EQUIPMENT BASIC PARTS Fan characteristics ventilateur Manufacturer ....................L.N. type ......................... EVB 30-230 electrical supply ....................230 V ~ 50 Hz electrical power ....................50 W protection degree ..................... IP 40 maximum rotation speed (r.p.m.) ..............4200 Gas solenoid valve Manufacturer .................... -
Page 11: Electrical Connections
SYSTEMA ELECTRICAL CONNECTIONS Wiring diagram SCR 25 m - SCR 45 m The following wiring diagram for "INFRA…ROSSO" SCR 25 m and 45 m ceramic heater concern only the internal connections of the equipment. The external connections of the equipment are under the responsibility of the installation technicians and they must respect the laws and the rules of the Country where the installation has been made. -
Page 12: Fan Digital Pwm Regulator
SYSTEMA Fan digital PWM regulator The fan speed is fixed by the digital regulator situated inside the equipment box. For each model the manufacturer is programming the minimum and maximum value of PWM which will determine the minimum and maximum thermal power of the ceramic heater (for instance : PWM minimum 25% = 12 kW - PWM maximum 60% = 24 kW) with no possibility of modification by the final user. -
Page 13: Wiring Diagram Of Scr 25 A - Scr 45 A
SYSTEMA Wiring diagram of SCR 25 a - SCR 45 a The following wiring diagram for the "INFRA…ROSSO" ceramic heaters SCR 25a and 45 a concerns exclusively the internal connections of the equipment. The external connections of the equipment up to the Master INFRANET board will be illustrated in the following paragraphs. -
Page 14: Serial Infranet Network Wiring Diagram
SYSTEMA Serial INFRANET network wiring diagram The INFRANET network allows to control from just one Master INET control board from a minimum of one SCR 25a/45a ceramic heater to a maximum of 16 SCR 25a/45a ceramic heaters divided in 4 independent zones. -
Page 15: Exploded Drawing Scr 25M - Scr 45M Equipments
SYSTEMA EXPLODED DRAWING SCR 25m - SCR 45m equipments 28 30 32 EXPLODED DRAWING SCR 25a - SCR 45a equipments Rev. 03GB0602... - Page 16 SYSTEMA Pos. Code Description Gas solenoid valve fastening bracket Main equipment body M 5X35 mm. zinc plated screw M 5x15 mm. bolt 14 5x10 mm zinc plated washer. Thermal isolation of equipment box SIT 577DBC flame control device Equipment box M4 x 40 mm.
-
Page 17: Exploded Drawing Scr 25 M - Scr 25 A Equipments
SYSTEMA Exploded Drawing SCR 25 m - SCR 25 a equipments Position Code De scription M 5 stainless steel nut Equipment body Thermal isolation Ceramic plate Ceramic fiber thermal isolation Stainless steel parabola reflector Fastening bars M 5 x 25 mm. stainless steel... -
Page 18: Exploded Drawing Scr 45 M - Scr 45 A Equipment
SYSTEMA Exploded drawing SCR 45 m - SCR 45 a equipment Position Code Description M 5 stainless steel nut Equipment body Thermal isolation Ceramic plate 5 x16 stainless steel washer M 5 stainless steel nuts Ceramic fiber thermal isolation Stainless steel parabola reflector (standard) -
Page 19: "Infra
SYSTEMA "INFRA…ROSSO SCR" HEATERS INSTALLATION The "INFRA…ROSSO SCR" ceramic heaters can be installed only in premises which are compatible with this type of equipment. Before deciding the installation a project has to be done by a qualified technician, who has to evaluate the environmental risk. -
Page 20: Ceiling Installation
SYSTEMA Ceiling installation THE "INFRA…ROSSO SCR1" CERAMIC HEATERS ARE PERFECTLY FONCTIONNING IN ANY POSITION AND WITH ANY INCLINATION. The "INFRA…ROSSO SCR1" ceramic heaters, installed at the ceiling have to be fixed in an adequate manner, in order to avoid hunting or risk of crash. -
Page 21: Installation On A Wall
SYSTEMA Installation on a wall Pos. Description Indications for installa tion “INFRA…ROSSO” ceramic heater Lateral view of installation SCR 25/45 m/a “INFRA…ROSSO” ceramic heater Front view of installation SCR 25/45 m/a Use rigid material to avoid oscillation movements Supporting structure (for instance Ø... -
Page 22: Start Up And Operating
SYSTEMA START UP AND OPERATING Before starting up the equipment, verify 1) The correct installation of the equipment : 2) The respect of safety conditions. 3) Verify the gas pipeline and if necessary purge the gas pipes. 4) VERIFY THE PRESSURE AND THE TYPE OF GAS SUPPLY. -
Page 23: Change Of Fuel Supply
SYSTEMA CHANGE OF FUEL SUPPLY The change of fuel type must be done by qualified personnel in the respect of security rules in force. The manufacturer refuse any responsibility in case of damages due to a wrong transformation or an inadequate and/or incorrect use of the equipment. -
Page 24: 10.1 Operating Anomalies
SYSTEMA 10.1 Operating anomalies Anomaly Reason Intervention No gas supply Open the gas valve Verify the electrode position Verify the connection of the electrode cables Replace the 577 DBC electronic device No ignition discharge Verify the electrical connections = remake... -
Page 25: Guaranty
BEING FORMALLY EXCLUDED ANY OTHER FORM OF GUARANTY OR PAIEMENT OF DAMAGES, ACCORDING TO THE LAW OR THE USAGE. Parts to be replaced will be rapidly sent back to SYSTEMA, at its factory of Zdunska Wola - Poland, at the charge of the Customer. - Page 26 SYSTEMA Rev. 03GB0602...
- Page 27 SYSTEMA Rev. 03GB0602...
