Pod Assembly

28mm Standoff
8
FPV Camera
7
Attach 2, 28mm standoffs
with M3 x 10mm screws (As
shown in the diagram). Attach
the ProSight camera to the
side plate using an M2 screw.
What you need for this step
M3 x 10 Screw
M3 Lock nut
28mm Standoff
6
x 4
x 4
x 2
