- Page 1 62 MAX/62 MAX + Infrared Thermometer Users Manual...
- Page 2 Introduction The Fluke 62 MAX and 62 MAX + Infrared Thermometers (the Product) can determine the surface temperature by measuring the amount of infrared energy radiated by the target’s surface. Note that the Japanese models indicate Celsius only. WWarning Read all safety information before you use the Product.
-
Page 3: Safety Information
62 MAX/62 MAX + Users Manual Safety Information A Warning identifies conditions and procedures that are dangerous to the user. A Caution identifies conditions and procedures that can cause damage to the Product or the equipment under test. Table 1 tells you about symbols used on the Product and in this manual. *WWarning To prevent eye damage and personal injury: •... - Page 4 Infrared Thermometer Safety Information • See emissivity information for actual temperatures. Reflective objects result in lower than actual temperature measurements. These objects pose a burn hazard. • Do not look directly into the laser with optical tools (for example, binoculars, telescopes, microscopes). Optical tools can focus the laser and be dangerous to the eye.
- Page 5 62 MAX/62 MAX + Users Manual Table 1. Symbols Symbol Meaning Symbol Meaning Do not dispose of this product as unsorted municipal waste. Risk of danger. Important information. See Manual. Conforms to European Union Warning. Laser. directives. Conforms to relevant Australian ...
-
Page 6: Maintenance
Infrared Thermometer Maintenance Maintenance WCaution To avoid damage to the Product, do not leave the thermometer on or near objects of high temperature. How to Change the Battery To install or change the AA IEC LR06 battery, open the battery compartment and replace the battery as shown in Figure 16. -
Page 7: Specifications
62 MAX/62 MAX + Users Manual Specifications 62 MAX 62 MAX + -30 °C to 500 °C -30 °C to 650 °C Temperature Range (-22 °F to 932 °F) (-22 °F to 1202 °F) ≥0 °C: ±1.5 °C or ±1.5 % of ≥0 °C: ±1 °C or ±1 % of reading, whichever is reading, whichever is... - Page 8 Infrared Thermometer Specifications 10:1 12:1 Optical Resolution (calculated at 90 % energy) (calculated at 90 % energy) 0.1 °C (0.2 °F) Display Resolution ±0.8 % of reading or ±1.0 °C ±0.5 % of reading or ±0.5 °C Repeatability (% of reading) (2 °F), whichever is greater (1 °F), whichever is greater Power...
-
Page 9: Standards And Agency Approval
62 MAX/62 MAX + Users Manual IP Rating IP 54 per IEC 60529 Drop Test 3 meters Vibration and Shock IEC 68-2-6 2.5 g, 10 to 200 Hz, IEC 68-2-27, 50 g, 11 ms EN 61326-1:2006 EN 61326-2:2006 Standards and Agency Approval Compliance .......... -
Page 10: The Product
Infrared Thermometer The Product The Product... - Page 11 62 MAX/62 MAX + Users Manual Max/Min/Avg/Diff gtt14.eps...
- Page 12 Infrared Thermometer The Product 10 min...
- Page 13 62 MAX/62 MAX + Users Manual 30 Min 0ºC 32ºF 22ºC 72ºF ° F 1 2 5...
- Page 14 Infrared Thermometer The Product 60 mm @ 100 mm @ 38 mm @ 33 mm @ 50 mm @ 85 mm @ 600 mm 900 mm 300 mm 300 mm 600 mm 900 mm 1.5" @ 2.4" @ 4" @ 1.4"...
- Page 15 62 MAX/62 MAX + Users Manual...
- Page 16 Infrared Thermometer The Product 7 5 ° 2 2 5 ° 7 5 °...
- Page 17 62 MAX/62 MAX + Users Manual Shop for other automotive tools on our website.
