7.3 EX 410 ENCLOSURE DIMENSIONS

(all dimensions in mm)
Ex 410 Enclosure with 5 Keys
Door
Hinge
Enclosure with 3 x M20 Gland holes
Material: Cast Aluminium
Finish:
415-M-V3.2
302
Bottom View
Mounting Holes
70.0
130.0
Gland Holes
3 x M20
Light beige powdercoat
288
4 x M8
Earth Point
71.5
Enclosure with 3 x ¾" NPT Gland holes
Installation
Mounting Holes (4) on rear
Metric thread M8
NPT thread 5/16 UNF
115.0
221
Mounting Holes
4 x 5/16 UNF
70.0
71.5
Gland Holes
130.0
3 x ¾" NPT
75
