1.1 MODEL NUMBER DESIGNATION

The Model number of an instrument describes which input and output
options are installed and the AC mains voltage rating.
Temperature
R for RTD input
A for 4-20mA
The Model number of the instrument is displayed on first entering
the Calibration Mode (see Section 5).
415-M-V3.2
Model 415 R. 1 0 E C
C for Conformal Coating
E for 220/240 VAC
A for 110/120 VAC
D for DC Power Only
Options
0 for no option
1 for 4-20mA output
2 for RS232/422/485
3 for Relay option
4 for 4-20mA and relays
5 for RS232/422/485 and
relays
Mounting
1 for panel mounting
2 for field mounting
3 for explosionproof
I ntroduction 9
